Samsung ADT SmartThings F-ADT-PIR-1 User manual
ADT Motion Detector
Setup Guide
PRINTER’S INSTRUCTIONS:
MANUAL,QUICK START,NOVA,PIR - NORTEK P/N: 10015709C- INK: BLACK PLUS PMS 286C - MATERIAL: 105G COATED PAPER - SIZE: 105MM X 105MM -
SCALE: 1-1 - BINDING: TRIM, FOLD AND SADDLE STITCHED - PAGE 1 OF 16
Take the ADT Motion Detector to where you intend
to mount it after setup.
1. 2.
Setup
A
• Make sure that your ADT Security Hub is disarmed
before connecting a new device.
• Make sure you are within 350 feet from the
ADT Security Hub. (Exact range depends on
your home’s construction, the environment, the
position of the ADT Security Hub, and the position
and number of other connected devices.)
• Make sure that you only setup one new device
at a time.
3.
• Do not remove the battery tab until you are ready
to set up the detector.
Take the ADT Motion Detector to where you intend
to mount it after setup.
2. Use the SmartThings app on your smartphone
to select the “My Home” tab. Select "Things", and
then “Add a Thing".
Setup Setup
• Make sure that your ADT Security Hub is disarmed
before connecting a new device.
• Make sure you are within 350 feet from the
ADT Security Hub. (Exact range depends on
your home’s construction, the environment, the
position of the ADT Security Hub, and the position
and number of other connected devices.)
• Make sure that you only setup one new device
at a time.
3. Use the SmartThings app to scan the QR code on the
front of the detector and then follow the on-screen
instructions to complete setup.
QR Code
Walk Test Button
• Do not remove the battery tab until you are ready
to set up the detector.
Setup
5.4. Remove the tab on the detector marked “Pull
This Tab”.
Battery Tab
Walk Test Button
5. Remove the QR code from the front of the detector
and attach it inside the ADT Security Hub User Guide
for future reference.
Setup
Remove the tab on the detector marked “Pull
This Tab”.
Battery Tab
Placement
B
• Make sure you do not aim the detector at stairs,
furniture, or other surfaces that a pet might climb on.
• Make sure that you do not place the detector in a
room where large pets (over 55 lbs) may be present
and could cause false alarms.
• Make sure that you do not place the detector near
a source of heat that could cause false alarms, e.g.
a heating vent or replace.
• Make sure that there are no objects blocking the
detector's view and that it's in a stable location.
Place the ADT Motion Detector in a high-trafc area
where an intruderwould be likely to pass within a 30-foot
range, e.g. living room or hallway.
• Make sure that you do not place the detector facing
windows where car headlights could cause false
alarms.
60o Coverage In Both Directions
Placement
• Make sure you do not aim the detector at stairs,
furniture, or other surfaces that a pet might climb on.
• Make sure that you do not place the detector in a
room where large pets (over 55 lbs) may be present
and could cause false alarms.
• Make sure that you do not place the detector near
a source of heat that could cause false alarms, e.g.
a heating vent or replace.
• Make sure that there are no objects blocking the
detector's view and that it's in a stable location.
Place the ADT Motion Detector in a high-trafc area
where an intruderwould be likely to pass within a 30-foot
range, e.g. living room or hallway.
0o
60o
• Make sure that you do not place the detector facing
windows where car headlights could cause false
alarms.
30 Feet Range
60o Coverage In Both Directions
Placement
Mounting
C
Pick a location 6.5 to 7.5 feet above the oor and
mount the detector on a at wall or in a corner.
1.
Corner Mount
Flat Wall Mount
Wall Mount Bracket
Detector (Front)
Detector (Back)
2.
You can also use the supplied mounting tape if you do not
want to use the wall bracket.
Mounting
Pick a location 6.5 to 7.5 feet above the oor and
mount the detector on a at wall or in a corner.
Adjust the angle of the detector using a screwdriver.2.
Mounting
You can also use the supplied mounting tape if you do not
want to use the wall bracket.
Adjust With Screwdriver
Double Stick Tape Here For Flat Walls
DTesting
You can test the coverage of the ADT Motion Detector
by pressing the Walk Test button on the side. For the next
10 minutes, the red LED will illuminate when it senses
movement, allowing you to adjust the aim of the detector
to cover the desired protection area. Note that each time
the red LED illuminates, a signal will be sent to the
ADT Security Hub.
You can test your ADT Motion Detector by performing
a Walk Test on the ADT Security Hub, walking through the
detection eld and then checking its status on the ADT
Security Hub touchscreen. See the ADT Security Hub User
Guide for more details.
Note: If you have an ADT professional monitoring service
activated, additional testing is required whenever you
connect a new device. Follow the on-screen instructions
in the SmartThings app to complete testing.
E
If you’re still having trouble connecting the ADT Motion
Detector, please visit SmartThings.com/Support-ADT for
assistance.
1.
2.
3.
4.
Testing
You can test the coverage of the ADT Motion Detector
by pressing the Walk Test button on the side. For the next
10 minutes, the red LED will illuminate when it senses
movement, allowing you to adjust the aim of the detector
to cover the desired protection area. Note that each time
the red LED illuminates, a signal will be sent to the
ADT Security Hub.
You can test your ADT Motion Detector by performing
a Walk Test on the ADT Security Hub, walking through the
detection eld and then checking its status on the ADT
Security Hub touchscreen. See the ADT Security Hub User
Guide for more details.
Note: If you have an ADT professional monitoring service
activated, additional testing is required whenever you
connect a new device. Follow the on-screen instructions
in the SmartThings app to complete testing.
Troubleshooting
E
Press and release the Tamper Switch on the
detector twice.
If the detector did not pair successfully with the ADT
Security Hub, follow these instructions to reset it:
Press and hold the Tamper Switch. The red LED will
begin to blink quickly, and after a short period of time
will stay on.
Release the Tamper Switch and after 5 seconds the
red LED will begin to blink slowly.
Use the SmartThings app to complete setup.
If you’re still having trouble connecting the ADT Motion
Detector, please visit SmartThings.com/Support-ADT for
assistance.
1.
2.
3.
4.
Tamper Switch
FSuggestions
The ADT Motion Detector monitors motion in a dened
area of your home. When motion is detected, a notication
is sent wirelessly to your ADT Security Hub.
Your ADT Security Hub can then send an alert to your
smartphone, automate connected devices, or initiate
optional ADT professional monitoring services
(additional fees apply).
• Put one in your basement and set it to send you
a message if unexpected activity is detected.
• Put one in your hallway and set it to turn on
connected lights when motion is detected.
• Put one in your living room and set it to turn off
connected lights when everyone’s gone.
There are many ways you can use an ADT Motion
Detector in your home:
• Put one in your hallway or near your back door and
set it to initiate optional ADT professional monitoring
services if an intrusion is detected in your home
(additional fees apply).
Suggestions
Suggestions
The ADT Motion Detector monitors motion in a dened
area of your home. When motion is detected, a notication
is sent wirelessly to your ADT Security Hub.
Your ADT Security Hub can then send an alert to your
smartphone, automate connected devices, or initiate
optional ADT professional monitoring services
(additional fees apply).
Look for the Works with SmartThings label next time
you’re buying a connected device for your home, or visit
SmartThings.com to see the full list of compatible
devices.
G
SmartThings works with a wide range of connected
devices, including lights, cameras, locks, thermostats,
and sensors. It also works with the Google Assistant
and Amazon Alexa so you can control your smart home
with voice commands.
Suggestions
Visit SmartThings.com/Welcome for more ideas, tips,
and special offers.
• Put one in your storage room and set a connected
camera to send you a video alert when unexpected
activity is detected (additional fees may apply).
Note: To ensure proper functioning, all connected
devices must be congured correctly.
Look for the Works with SmartThings label next time
you’re buying a connected device for your home, or visit
SmartThings.com to see the full list of compatible
devices.
Works With SmartThings
G
SmartThings works with a wide range of connected
devices, including lights, cameras, locks, thermostats,
and sensors. It also works with the Google Assistant
and Amazon Alexa so you can control your smart home
with voice commands.
Visit SmartThings.com/Welcome for more ideas, tips,
and special offers.
• Put one in your storage room and set a connected
camera to send you a video alert when unexpected
activity is detected (additional fees may apply).
Note: To ensure proper functioning, all connected
devices must be congured correctly.
SmartThings, Inc., 665 Clyde Ave, Mountain View, CA 94043, USA. Information in this document
is subject to change without notice. Copyright 2017 SmartThings, Inc. All rights reserved.
ADT and the ADT logo are marks and/or registered marks of ADT. Unauthorized use is strictly
prohibited. Revised 06/17.
P/N 10015709C
