Samsung HN-M101MBB User manual

Mobile SATA
Spinpoint M8
320GB 500GB 750GB 1TB
Model 8 MB HN-M320MBB
HN-M500MBB
HN-M750MBB
HN-M101MBB
FEATURES
• Max. 500GB formatted capacity per disk • ATA Security Mode Feature Set
• SATA Native Command Queuing Feature • ATA S.M.A.R.T. Feature Set
• TuMR/PMR head with FOD technology • SilentSeek™
• Serial ATA 3.0Gbps Interface Support • NoiseGuard™
• Load/Unload Head Technology
Capacity1320 / 500 / 750GB, 1TB Temperature
Interface SATA 3.0 Gbps (1.5Gbps) Operating 5 ~ 55 ℃
Buffer DRAM Size28 MB Non-operating -40 ~ 70 ℃
Rotational Speed 5,400 RPM class Humidity (non-condensing)
Operating 5-90 %
Non-operating 5-95 %
Average Seek time (typical) 12 ms Linear Shock (1/2 sine pulse)
Average Latency 5.6 ms Operating, 2ms 325 G
Data Transfer Rate Non-operating, 2ms 750 G
Media to/from Buffer (Max.) 145 Mbits/s
Vibration (swept sine, 1/4 octave per minute)
Buffer to/from Host (Max.) 300 MB/s Operating 1 .5 Grms
Drive Ready Time (typical)34 sec Altitude (relative to sea level)
Operating -300 to 3000 m
Non-operating -400 to 15000 m
Non-recoverable Read Error 1 sector in 1014 bits
Controlled Ramp Load/Unload 600,000
Height 9.5 ± 0.2 mm
Idle 2.4 Bel Width 69.75 ± 0.25 mm
Performance Seek 2.6 Bel Length 100.3 ± 0.4 mm
Weight (max.) 107 g
Voltage +5V±5% * Note : Design and specifications are subject to change without prior notice.
Spin-up Current (Max.) 1000 mA 1.1MB = 1,000,000 Bytes, 1GB = 1,000,000,000 Bytes
Seek (AVG)42 W Accessible capacity may vary as some OS uses binary numbering system
Read/Write (AVG) 2.2 W for reported capacity
Low Power Idle (AVG) 0.7 W 2 A small portion of the 8MB buffer memory is reserved for firmware use
Standby (AVG) 0.2 W 3 Power-On to Drive Ready
Sleep (AVG) 0.2 W 4 30% duty cycle, random seek
2.5" HDD product specification Rev 0.1(preliminary)
Match with product manual Rev 00
POWER REQUIREMENTS
ACOUSTICS
Capacity
DRIVE CONFIGURATION
ENVIRONMENTAL SPECIFICATIONS
PERFORMANCE SPECIFICATIONS
RELIABILITY SPECIFICATIONS
PHYSICAL DIMENSION
