Samsung QM43B User manual

User Manual
© Samsung
Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited. Trademarks other than Samsung are property of their respective owners.
QM43B QM50B QM55B QM65B QM75B QM65B-N QM43B-T QM55B-T
The color and the appearance may differ depending on the product, and the content in the
manual is subject to change without prior notice to improve the performance.

Table of contents
Before Using the Product
Safety Precautions 5
Safety symbols 5
Electricity and Safety 6
Installation 7
Operation 9
Precautions when handling the panel 11
Cleaning 12
Storage and Maintenance 13
Preparations
Checking the Components 14
Parts 15
Ports 16
QM43B/QM50B/QM55B/QM65B/QM65B-N/
QM75B 16
QM43B-T/QM55B-T 17
Control menu 18
2
Administrator menu (Supported models:
QMB-T) 19
Remote Control 20
Before Installing the Product (Installation
Guide) 22
Tilting Angle and Rotation 22
Ventilation 22
Installing the Wall Mount 23
Preparing before installing Wall-Mount 23
Installing the Wall Mount 23
Wall Mount Kit Specifications (VESA) 24
Using a touchscreen monitor
(Supported models: QMB-T)
Touchscreen monitor 25
Read below before using the product 25
Connecting the touch overlay 25
Connecting the touchscreen monitor 26
Connecting to a PC 26
Connecting to a laptop or tablet PC 27
Configuring the touchscreen monitor
settings 28
Calibration 28
Connecting and Using
a Source Device
Before Connecting 30
Pre-connection Checkpoints 30
Connecting to a PC 30
Connection Using an HDMI Cable 30
Connection Using an DP Cable 31
Connection Using an HDMI-DVI Cable 31
Connecting to a Video Device 32
Connection Using an HDMI Cable 32
Connection Using an HDMI-DVI Cable 32
Connecting HDMI to Sound system and
Video device 33
Connecting to an Audio System 33
Connecting the LAN Cable 33
Changing the Input source 34
Source 34
Web Browser 35
Workspace 37
SMARTVIEW+ 37
Screen Mirroring 37

Table of contents
3
Multiple Display Control
Cable Connection 38
RS232C Cable 38
LAN Cable 39
Connection 41
Control Codes 42
Using MDC 49
MDC Program Installation/Uninstallation 49
Player feature
Player 50
Viewing content 50
When content is running 51
Available menu 51
File Formats Compatible with Player 52
Schedule 56
Custom Home 57
Clone Product 58
ID Settings 59
Device ID 59
Device ID Auto Set 59
PC Connection Cable 59
Video Wall 60
Video Wall 60
Horizontal x Vertical 60
Screen Position 61
Format 61
Network Status 62
On/Off Timer 63
On Timer 63
Off Timer 64
Holiday Management 64
Ticker 65
Menu
Picture 66
OnScreen Display 70
Sound 72
Network 74
Network Settings (Wired) 75
Network Settings (Wireless) 77
Use WPS 79
System 81
Support 93

Table of contents
4
Appendix
Responsibility for the Pay Service (Cost to
Customers) 105
Not a product defect 105
A Product damage caused by customer's
fault 105
Others 105
Prevention of Afterimage Burn-in 106
What is afterimage burn-in? 106
Recommended prevention practices 106
License 107
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 95
Testing the Product 95
Checking the Resolution and Frequency 95
Check the followings. 96
Specifications
General 102
Preset Timing Modes 104

5
Before Using the Product
Chapter 01
The following safety instructions are to ensure your personal safety and prevent property
damage. Please read the following to ensure the proper use of the product.
Safety symbols
Symbol Name Meaning
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions
are not followed.
Prohibition Do NOT attempt.
Instruction Follow directions.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE
ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high
voltage is present inside. It is
dangerous to make any kind of
contact with any internal part of this
product.
AC voltage: Rated voltage marked
with this symbol is AC voltage.
This symbol indicates that this
product has included important
literature concerning operation and
maintenance.
DC voltage: Rated voltage marked
with this symbol is DC voltage.
Class II product: This symbol indicates
that a safety connection to electrical
earth (ground) is not required. If this
symbol is not present on a product
with a mains lead, the product
MUST have a reliable connection to
protective earth (ground).
Caution. Consult instructions for use:
This symbol instructs the user to
consult the user manual for further
safety related information.
Safety Precautions
