Samyung SPR-1400 User manual

SAMYUNG ENC
CONTENTS
CHAPTER 1. OVERVIEW ································································································································· 1
1.1 OVERVIEW ············································································································································1
1.2 WHAT IS GPS ······································································································································1
1.3 FEATURES ············································································································································1
1.4 CAUTION ················································································································································ 1
CHAPTER 2. COMPONENT·····························································································································2
2.1 BASIC COMPONENT ····························································································································2
2.2 OPTION ··················································································································································2
CHAPTER 3. SPECIFICATION ························································································································3
3.1 GPS RECEIVER ·····································································································································3
3.2 GENERAL SPECIFICATION ················································································································3
CHAPTER 4. INSTALLATION ··························································································································5
4.1 UNPACKING & CHECK ·······················································································································5
4.2 SELECT INSTALLATION'S SPACE ···································································································5
4.3 POWER CONNECTION ························································································································5
4.4 CONNECT WITH EXTERNAL DATA································································································5
4.5 INSTALLATION OF GPS ANTENNA ································································································6
4.6 INSTALLATION OF DGPS(OPTION) ································································································6
4.7 COMPOSITE CONNECTION ···············································································································7
CHAPTER 5. OPERATION ·······························································································································8
5.1 FUNCTIONS ··········································································································································8
5.2 FRONT BOARD ···································································································································13
5.3 DISPLAY SELECTION ······················································································································15
5.4 NAVIGATION SCREEN ······················································································································16
5.5 PLOTTER SCREEN DISPLAY & FUNCTION ··············································································17
5.6 HIGHWAY SCREEN SETTING ······································································································19
5.7 STEERING ···········································································································································20
5.8 USER DISPLAY ·································································································································21
5.9 MENU ····················································································································································22
5.10 MENU STRUCTURE & INITIAL SETTING VALUE ································································23
CHAPTER 6. HOW TO SET-UP & PROCESS ························································································24
6.1 NAVIGATION ·····································································································································24
6.2 SET-UP PLOTTER ··························································································································27
6.3 ALARMS SET-UP ····························································································································28
6.4 ERASE ················································································································································28
6.5 DGPS ····················································································································································29
6.6 CALCULATE ······································································································································30
6.7 MESSAGES ·······································································································································31
6.8 SATELLITE ········································································································································32
6.9 USER DISPLAY ·······························································································································33
6.10 GPS SET-UP ····································································································································34
6.11 SYS SET-UP ·····································································································································35
6.12 I/O SET-UP ·······································································································································36
CHAPTER 7. BLOCK DIAGRAM
CHAPTER 8. PACKING LIST

SAMYUNG ENC
CHAPTER 1. OVERVIEW
1.1 OVERVIEW
Thank you for purchasing SPR-1400.
We would be appreciate to read detailed manual and then keep it.
SAMYUNG has intelligent property rights for software and hardware of SPR-1400.
Therefore illegal copy of this product is not allowed.
This GPS is proud of high-tech navigation, however component navigator should follow his decision for
person and property loss, not GPS receiver.
This product is the lion among existent navigation equipments. But when there is a possibility if losing
person's life or fortune, you don't want to depend on this GPS only.
We guarantee to our dear customers good SERVICE and quality of SPR-1400.
1.2 WHAT IS GPS
GPS(Global Positioning System) is on the basis of position, velocity, time systems with spec, control, users.
GPS consist of 24 satellite in orbit. This satellite turn around 12 circle, inclined 55 20200 Km far form
earth. The interval of this satellite is PDOP=6. World people can see at least 4 satellites in orbit.
This satellite transmits L1(1575.42 MHz) and L2(1,227.6 MHz) with "L"band. L1 transmits P code and
C/AZHEM, L2 transmits P code. All data message go to these code. Both frequency transmit same
navigation data.
At first GPS purpose to use in military service until now, however USA admit GPS to use in civil category.
IGPS(International GPS Service for geodynamics) supervise GPS.
1.3 FEATURES
1. Compliant to IMO and MSC.
2. Available to be used in range of power consumption.
Compact design for easy installation job.
3. Easy to operate as graphic LCD with large range of visual field angle.
4. Can search for current satellite because of edit time and position value.
5. Adjustable the lightness of LCD, back light bright, it is very useful at night.
6. Can use to input-output data(NMEA 0183 and etc.) and others.
7. Can input the information about waypoints, markers routes to PC and output from PC.
8. There are various display mode and can setup the mode by user.
9. Convenience operation by using plotter function during waypoints navigation and route navigation.
10. Various kinds of alarms and self-test function for safe navigation.
1.4 CAUTION
This receiver be manufactured under the professional experience for a long time and accumulated
knowledge. Therefore please do not change the original figures, circuits, systems of itself without technical
advise.
The product can keep the best condition of it by professional technicians and engineers for maintain and
repair.
if you need help for after service, please do not hesitate to contact us.

SAMYUNG ENC
CHAPTER 2. COMPONENT
2.1 BASIC COMPONENT
ITEM MODEL Q'TY REMARKS
MAIN UNIT SPR-1400 1 SET
ANTENNA
&
CABLE
GPS SAN-60 RG-58C/U
(Connector Incl.)
1 SET
10M
DGPS SANB-300
Cable(Connector Incl.) 1 SET 15M
DC Power Cable,
Installation material,
Instruction manual
Cable(Connector Incl.)
(Regard packing list)
Korean, Russian and English
3M
1 SET
1 EA Option
2.2 OPTION
ITEM MODEL Q'TY REMARKS
AC POWER SUPPLY
AC POWER CABLE
AC POWER
SP-100
Cable (Connector Incl.)
(Regard packing List)
1 SET
3M
1 LOT

SAMYUNG ENC
CHAPTER 3. SPECIFICATION
3.1 GPS RECEIVER
1) Antenna
1-1 GPS
①Center Frequency : 1575.42 MHz
②Dimension & Weight :90(H)x65(W)mm (127mm mounting bar) 0.15kg
1-2 DGPS(Option)
①Receiving frequency : 283.5 ~ 325KHz
②Channel interval : 500Hz
③MSK Bit Rates : 50, 100, 200(Automatic)
④Dimentions & Weight : 14(H)x115(W)mm (127mm mounting bar) 0.72Kg
2) Receiver
①Receiving frequency : 1575.42±1MHz
②Receiving Channel : 12 Channels
③Receiving Code : C/A code(1.023 MHz chip rate)
④Tracking Capacity : 12 simultaneous satellite vehicles
⑤Receiving Sensitivity : -130 dBm and below
(After picking up the signal, -133 dBm and below)
3.2 GENERAL SPECIFICATION
1) Accuracy
①Tracking velocity : 1,000 Knots(514 m/s)
②Ststic precision : Measure antenna's position error at HDOP=4 or PDOP=6
* GPS : Errors in the range of 100m(95%)
* DGPS : Errors in the range of 10m(95%)
③Dynamic precision : Measure vessel's position error at HDOP=4 or PDOP=6 (In the ocean)
* GPS : Errors in the range of 100M(95%)
* DGPS : Errors in the range of 10M(95%)
④Resolution : 1/1000 latitude & longitude
⑤Velocity precision : 0.1 Knots RMS, HDOP<2.0 (Without SA)
⑥Accuracy time : Warm start average < 13 Sec.
Cold start average < 105 Sec.
⑦Up-date interval of accuracy data : Every 1 Sec.
2) Input data & Output data
①Data 1 : Input RS-232c, Output RS 232C & TTL
* Input data : NMEA0183 Ver 1.5 & Ver 2.0
* Output data : NMEA0183 Ver 1.5, NMEA0183 Ver 2.0
FURUNO CIF
Input in personal computer (WAYPOINTS/ROUTES DATA)
Output in personal computer (WAYPOINTS/ROUTES DATA)
②Data 2 : RS-232C
* Input Data : DGPS input signal (RTCM SC-104, Version 2.1)

SAMYUNG ENC
3) General Information
①Display unit : 128 * 64 Dot LCD
②Display mode : Plotter mode, Steering mode, Highway mode,
NAV data mode, user mode(Digital, Speed meter)
③Enlarging display
* Plotter mode : 0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 160, 320nm
* Highway mode : 0.2, 0.4, 0.8, 1, 2, 4, 8, 16nm
④Memory capacity : WAYPOINT/MARK/MOB etc. (Total 1,000 items),
Routes 50 units (Each route - 30 WAYPOINT),
Track 1,000 points
⑤Protection circuit : Even if antenna or input-output terminal is under situation like
short-circuit or grounding, don't sustain permanent damage.
⑥Temperature : Antenna -40 ~ +85℃
Main unit : -20 ~ +55℃
⑦Humidity : 95% (+30 ~ +60℃)
⑧Power supply : DC10 ~ 36V/0.08 ~ 0.3A (Max. 4W)
⑨Dimensions & Weight : 190(W)*112(H)73(D)mm
(Installation prop incl.) / 0.9Kg
4) Performance standard
①Compliant with IMO Res. A. 819(19)
②Compliant with MSC-112(73)
③Compliant with ITU-R M.823

SAMYUNG ENC
CHAPTER 4. INSTALLATION
4.1 UNPACKING & CHECK
Should confirm same products as you ordered and external shape be checked.
If finding some damage, should take equivalent actions or contact us.
This receiver is easy to install according to vessel's conditions. At least User
should follow this instruction of manual.
4.2 SELECT INSTALLATION'S SPACE
1) Space for good ventilation and checking and maintenance.
2) Space far from rain and sea's water, keep dry.
3) Space for avoiding sunlight.
4) Space for low vibration.
5) Space far from another electrical device.
4.3 POWER CONNECTION
1) 2P connector at the rear panel is for power supplying.
No.1 is (+), No.2 is (-). Connect DC between 10V and 36V.
2) After 2P plug(for supplying power) connect with 2P cable, be careful of (+)(-) polarity.
* Power cables have white (+) and black (-) colors.
4.4 CONNECT WITH EXTERNAL DATA
The connector is for input & output the data which interface with other
equipment. It is available for RS-232C input & output and TTL level output.
1. 4P connectors at the rear side have functions following each pin number.
Connector No. Pin name Functions
1Data RX Connecting with external equipment
(input RS-232C)
2Ddata TX Connecting with external equipment
(output RS-232C)
3Ddata TTL Connecting with external equipment
(output TTL level)
4Ddata COM Connecting with external equipment
2. Signals of connector No.2 and No.4 have same polarity.
The difference : Connector No.3's signal level is outputting as 0V(L) or
5V(H) TTL level.

SAMYUNG ENC
4.5 INSTALLATION OF GPS ANTENNA
Refer to external connecting drawings for GPS antenna. Keep over 1m distance far from another antenna
and interference. Should not expose connecting side for water proof.
1. When connecting antenna, power supply is supposed to be off.
Press key for three sec.
2. The higher place it is, the better for installation antenna.
3. It is supposed to be installed far from the antenna of radio transmitter.
Especially install the GPS antenna in the different height from high
output-radar antenna and VHF or UHF transmitting antenna.
This kind of effect from transmitters might harm antenna and main unit.
4. Tighten up RF connector with main unit.
And RF connector to antenna should take waterproofing.
4.6 INSTALLATION OF DGPS(OPTION)
For DGPS antenna, 7P connectors at the rear side have functions following each pin number.
Connector No. Pin Name Functions
1Data TX DATA TX (output RS-232C)
2Data RX DATA RX (input RS-232C)
3Ddata COM DATA COM
4Earth Grounding (Connect to case)
5Interface NA
6Power -Power supply -
7Power +Power supply +
1. DGPS antenna : Please refer to "4.5 Installation of GPS antenna".

SAMYUNG ENC
4.7 COMPOSITE CONNECTION
Refer to block diagram for external connection, install at convenient space.
1. DC cable for power should be supplied by SAMYUNG or it should has enough capacity current.
2. Antenna connector of navigation equipment, power connector, data out connector should be tightened.
<GPS>
<DGPS>

- W A
Y
P O
I
N T
S
C
R E
A
T E -
N A M E :
W
P T
-
0
0
1
N U M B
E
R :
0
0 1 M
A
R K
/
M O B :
+
L
A
T
:
3
5
°
0
4
.
9
7
4
′
N
L O N :
2
9
°
0
4
.
3 9
9
′
E
E x
ii
t
[
M E
N
U ] L
O
G [
E
N T ]
- W A
Y
P O
I
N T S
C
R E
A
T E -
N A M E :
W
P T - 0
0
1
N U M B
E
R :
0
0 1 M
A
R K
/
M O B :
L
A
T
:
3
5
°
0
4
.
9
7
4
′
N
L O N :
2
9
°
0 4
.
3 9
9
′
E
E x
ii
t
[
M E
N
U ] L
O
G [
E
N T ]
SAMYUNG ENC
CHAPTER 5. OPERATION
5.1 FUNCTIONS
Power on/off and adjusting illumination
* Press this key more than one sec. : On
* Press this key more than two sec. : Off
* When the power is on, press this key less than one sec.
: Adjusting illumination
1. Operation of navigation
1) Registration of way point or mark
→ <NAVIGATE>→ → <WP/MARK CREATE/VIEW>→ →▲,▼→
* Input WAYPOINT name, WAYPOINT number, Kind of Mark, Longitude and Latitude.
→ <LOG>→ : Input
→ <Exit> →: Cancellation input
→: Cancellation input
<Input waypoints or mark>
2) Registration of MOB(Man overboard)
→ <NAVIGATE>→ → <WPT/MARKCREATE/VIEW>→ →▲,▼→
* Select ” “in <Mark Create>.
* Input(or correct) Name(the next spot of “MOB"), Number, Longitude and altitude.
→ <LOG>→ : Input
→ <Exit> →: Cancellation input
→: Cancellation input
<Registration of MOB>

--ROUTES CREATE--
NAME:RUT-01 NO.01
0 1 W P T - 0 0 1 + 0 0 1
0 2
0 3
0 4
Exit[MENU] LOG[ENT]
WPTS/MRKS LIST
0 1 0 1 0 0 1 W P T - 0 0 1 +
0 1 0 2 0 0 2 W P T - 0 0 2 x
- - - - 0 0 3 W P T - 0 0 3 o
- - - - 0 0 4 W P T - 0 0 4 ㅁ
0 1 0 3 0 0 5 W P T - 0 0 5 *
- - - - 0 0 6 W P T - 0 0 6 ^
R O U T E S L I S T
0 1 R U T - 0 1 0 4
0 2 R U T - 0 2 0 7
0 3 R U T - 0 3 1 2
0 4 R U T - 0 4 0 5
0 5 R U T - 0 5 0 7
0 6 R U T - 0 6 2 0
SAMYUNG ENC
3) Registration of ROUTES
→<NAVIGATE>→ → <ROUTES CREATE/VIEW>→ →▲,▼→
* Input route name, number, way point number, route order, route beginning.
→<LOG>→: Input
→<Exit> →: Cancellation input
→: Cancellation input
<Registration of route>
4) Selection of Next Way Point
→<NAVIGATE>→ → <NEXT WAYPOINT Select>→→▲,▼(WAYPOINT number)
→: Input
→: Cancellation input
<Next Waypoints>
5) Selection of Next Route
→<NAVIGATE>→ → <NEXT ROUTES Select>→ →▲,▼(Select ROUTES number)→
→▲,▼(Select WAYPOINT number)
→: Input
→: Cancellation input
<Next Route>

--CALCULATION--
MODE:WAYPOINT
FROM:SHIP
T O : 0 0 1
SPD :AUTO 12.6kt
T T G : E T A :
RNG:000.2nm BRG:002
--CALCULATION--
M O D E : R O U T E ( R = 0 1 )
F R O M : 0 1 ( W = 0 0 1
T O : 2 ( W = 0 0 2
S P D : A U T O 1 2 . 6 k t
T T G : E T A :
RNG:000.0nm BRG:00
2'
SAMYUNG ENC
2. Calculate distance, direction, time
1) Calculate from Daughter ship to Way point.
→<CALCULATE>→
* Mode Selection :→<MODE:WAYPOINTS>→
* Selection Beginning point :→<FORM:SHIP>→
<Calculate ROUTES>
* Selection Calculation place :
→<TO:xxxxxxxx>→ → <Selection of WAYPOINTS>→
* Enter Speed of the vessel : →<SPD:AUTO>→
* Display calculated TTG, ETA, RNG, BRG.
: Back to the main menu.
2) Calculating Between WAY POINT and WAY POINT
From Above “1)”Beginning point, it should be choice “FORM:WAYPOINTS".
3) Calculating ROUTES
→<CALCULATION>→
* Selection Mode : →<MODE:ROUTE>→
* Selection routes : →<ROUTES number>→
<Calculate ROUTES>
* Selection Beginning point :
→<FORM:>→ → <WAYPOINTS Number>→
* Selection calculating point :
→<TO:>→ → <WAYPOINTS No>→
* Enter Speed of the vessel :→ → <SPD:AUTO>→
Note) : If you selected "MANU", input the velocity of daughter ship.
* It should be calculate and indicate TTG, ETA, RNG, BRG from beginning point to the last
point to the last point.
: Be back to the Main menu.

- - A L A R M S S E T U P - -
B U Z Z E R : S h o r t
ARRIVAL:Off 0.10nm
A N C H O R : O f f 0 . 1 0 n m
X T E : O f f 0 . 1 0 n m
S P E E D : O f f 1 0 . 0 k t
T R I P : O f f 1 0 0 n m
SAMYUNG ENC
3. Establishment of Alarm
1) Select Mode
→<ALARMS>→ →
* Select changing item:→ →▲,▼
* Change it.
* After all alteration or part alteration, →: After inputting, Exit. <Alarm setup>
2) Range of selection
* BUZZER (Type of the alarm): SHORT, LONG, CONSTANT
* ARV/ANC (Alarm of the arrival & Anchor): Arrival/Anchor & 0.00 - 9.99nm
* XTE (alarm of the course secession): On/off & 0.00 - 9.99nm
* SPEED: OFF/BELOW(LOW SPEED)/Over(HIGH) & 00.0 - 99.9kt
* TIME: OFF/ON & 00:00 - 23:59
* TRIP (Alarm of trip distance): Off/On & 000~999nm
4. Output and Input of the data(I/O)
1) Output of the data (Storage in external memory)
→<I/O SETUP>→ → <SAVE WP/RUT>→
* ▲,▼(select WP DATA or RUT DATA)→: After output, exit.
: After cancellation, exit
* DATA of WAYPOINT, MARK, MOB, ROUTES, TRACK be output in personal computer with
RS-232C.
2) Input of the data from external memory.
→<I/O SETUP>→ → <LOAD WP/RUT>→
* ▲,▼(After selecting WP DATA or RUT DATA)→: After input, exit.
: After cancellation, exit.
* DATA of WAYPOINT, MARK, MOB, ROUTES, TRACK be input in personal computer with RS-232C.
3) Set up input data
→<I/O SETUP>→ → <INPUT DATA>→
▲,▼(select one between INTERNAL or EXTERNAL.)→: After setup, exit.
* INTERNAL is GPS receiver, EXTERNAL is inputting GPS.
4) Set up OUT FORMAT
→<I/O SETUP>→ → <OUT FORMAT>→
▲,▼(select one among NMEA VER1.5, NMEA VER2.0, FURUNO CIF.)→: After setup, exit.

SAMYUNG ENC
5. Set up system
1) Install Coordinate
* Select Mode : WGS84, WGS72, KOREA/TOKYO, NORTH AMER1927,
EUROPEAN 1950, AUSTRALIAN 1984, ADIADAN, ETC.
SET(001~171)
→<SYS SETUP>→ → <DATUM>→ →▲,▼→
2) Install Unit
* Select Mode : nm/kt; mm/mh; km/kh
→<SYS SETUP>→ → <UNIT>→→▲,▼→
3) Install Time Difference
* Select Mode : +13:30~-13:30
→<SYS SETUP>→ → <TIME DIFF>→→▲,▼→
4) Install Time Mode
* Select Mode : 12 hours, 24 hours
→<SYS SETUP>→ → <TIME DISP>→→▲,▼→

SAMYUNG ENC
5.2 FRONT BOARD
1. Front LCD
It displays wide range of information. According to displaying mode with , it displays six kinds of
GPS screen and various menu screen.
Display unit is setting either (nm, kt and nm, km/h) and 24hours or 12hours displaying methods which set
up at units item in Menu.
2. (Direction key)
Using as a switch for choosing item in Menu screen or choosing setting value.
( ▲ , ▼ switch in Main display screen can be adjusting brightness of LCD letter)
3.
As a MENU selection switch, when Menu screen is presently being selected, it activates as a return switch
to previous screen.
4.
As a switch to input (for confirming set) setting value or function after selection at Menu screen, but it is
activated by selection switch in 6 kinds of information display screen mode selection switch at information
display screen at no Menu screen.
5. LED
When th unit is working properly, LED light comes up.

SAMYUNG ENC
6. Switch ON/OFF
As a switch for Power supply and light adjusting.
* For power supply on : press ON/OFF for one second.
* For power supply off : press ON/OFF for two seconds.
* For adjusting LCD light and switch Dimmer : press ON/OFF for one second.
Note) If pressed over 1 second, power will be off.
7. Buzzer
When switch on, beep and alarm comes out.

- -
-
-
-
M
a
i n M
e
n u - - - -
-
N A
V
I
G
A T
E
M
E
S S
A
G E S
P L
O
T
T
E R S
A
T E
L
L I T E
A L
A
R
M
S U
S
E R D I S P
E R
A
S
E
G
P
S
S
E T U P
D G
P
S S
Y
S
S
E T U P
C A
L
C
U
L A
T
E I
/
O
S
E T U P
C U R
S
O R : O f f
C E N
T
E R : S H I
P
Q u i
t
P R
E
S S
[
M E N U
]
T
O
M A
I
N
M
E N U
SAMYUNG ENC
5.3 DISPLAY SELECTION
1. If press , it changes a following screen.
→
↑
↓
User Display
Digital display
↗↘
↖↙
Speedometer display ↓
←
2. Press on Plotter MENU for the return to MAIN MENU.
<PLOTTER MENU> <MAIN MENU>

SAMYUNG ENC
5.4 NAVIGATION SCREEN
Receiver status Date Time
1 2 3
Position N
4
Position E
5
6 7 8
Speed Course Datum
1. Receiver status (2D)
GPS Receiving Status :(" "/“DR”/“2D”/“3D”/"DGPS"/"GPS"/“SIM")“2D”shown at the top of the left side
will be displayed “DR”when satellite is not being selected, while it displayed “2D”when the satellite
is selected and 2 dimension is processing. When the 3 dimension is processing, it displays “3D”.
When it is not identified whether status is "2D" or "3D". Or outside input.
It displays "GPS". When it is in the process of receiving DGPS, it displays DGPS.
* When it is working with simulator, "SIM" is flickering at this place.
2. Date(2002.02.07)
It represents the present year, month and day.
3. Time(02:13)
It can display 24 hours type (10:07 16) or 12 hours type (10:07AM).
If time is not accurate, number is flickering. When "U" is displayed in front of time, it means UTC time,
and in case of "L", it means Local time.
4. Latitude (35‘43.999N)
Ship's latitude : latitude at ship's location.
5. Longitude (139'34.439E)
Ship's longitude : longitude at ship's location.
6. Speed(SOG 12.0kt)
Ship's speed : The existing ship's moving speed which is relative against the land.
7. Course(COG 360')
Ship's direction : Ship's moving direction which is relative direction against the land.
8. Datum(WGS-84)
Datum : It displays presently using DATUM. If is set up by external data, it displays "EXTERN".

SAMYUNG ENC
5.5 PLOTTER SCREEN DISPLAY & FUNCTION
①②③④⑤
⑦
⑧ ⑥
⑨
1. Description on display
①Receiver status(3D)
GPS receiver status : “”,“DR”,“2D”,“3D”,“DGPS",”GPS","SIM".
* When it is working with simulator, “SIM"is flickering at this place.
②Horizontal display range setting (320nm)
It represents distance of horizontal width on the plotting screen.
It can set up 0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 40, 80, 160, 320nm by adjusting direction switch
like ◀(distance to be narrow), ▶(distance to be wide) without curse coming on the screen.
③Boat's track(~)
It displays ship's track as a line (hereinafter called ship's track).
When it displays on the existing screen, it displays as muce details as possible, but when it calls the past
track or memorized ship's track, it shows according ti ship's track memory width(Width is set at Menu.)
④Own ship mark (o blinking) : It displays ship's existing position as a dot.
⑤Waypoint mark(x Shape selectable) : it displays destination as a registered mark.
⑥Cursor(+) : It displays cursor as "+" which functioned ON/OFF at menu screen.
⑦TRK: -> Track Point(TRK:220)
It displays total track points so far recorded.
BRG: -> Bearing to cursor or Bearing to Course(BRG: 130°)
It displays direction for destination from existing position. When it displays "RNG:+", it means cursor
position from the exsiting position.
⑧Range to cursor or Range to Course(RNG:+ 8.4nm)
When "RNG:+8.4nm" comes on indicator, it means displayed distance for cursor point from the existing
position.
⑨Cursor position(35°05.221 N 129°04.180E)
When it displays cursor(+) on the indicator, it displays cursor's position, but when it is without cursor it
displays boat position.

-
- -
-
- M A
I
N
M
E N U
-
- -
-
-
N
A V
I
G A T E
M
E S S A
G
E S
P
L O
T
T E R
S
A T E L
L
I T
E
A
L A
R
M S
U
S E R
D
I S
P
E
R A
S
E
G
P S S
E
T U
P
D
G P
S
S
Y S S
E
T U
P
C
A L
C
U L A T
E
I
/ O S
E
T U
P
C U R
S
O R : O f f
C E N
T
E R : S H I
P
Q u i
t
P R
E
S S
[
M E N U
]
T
O
M A
I
N
M
E N U
SAMYUNG ENC
2. Setting-up the function
1) When menu switch is pressed on the plotter screen, menu screen for setting up the function comes up
and being displayed as follows.
2) Press the direction switch on plotter menu screen for selected position with changing to letter mode and
press for selection.
3) After changing to "Quit" letter on the indicator, press then it returns to plotter screen.
4) Press "MENU" on the plotter screen, it changs to MAIN MENU.
<PLOTTER MENU> <MAIN MENU>
5) Select CURSOR(ON/OFF)
It is function of setting-up whether it displays course on the plotter screen or not. When cursor is
displayed, it also displays the value of course position like the distance from the vessel position to course.
When the cursor is not displayed on the screen, it displays the value of the existing ship's position and the
distance from the ship to waypoint, and when press the "◀" switch, screen magnification ratio becomes
reduced and when press the "▶" switch, screen magnification ratio becomes increased.
When the cursor is on, if you move it : Central point of display will be changed as the spot of cursor.
6) Select CENTER(SHIP/CURSOR/OFF)
Select the center of plotter screen as the ship's existing position or cursor position. Once selected, it
automatically goes off.
* On plotter screen not selected center line with its cursor on.
Cursor position is on the center of screen(going out of the screen) when cursor is off, ship's position would
be automatically the center of screen(time about going out of the screen).

SAMYUNG ENC
5.6 HIGHWAY SCREEN SETTING
⑥⑤
① ⑦
②
⑪
③
④
⑧⑨⑩
1. Bearing from own ship to destination waypoint (BRG 153°)
It displays direction towards destination form the present position.
* When it is working with simulator,"SIM" is flickering at this place.
2. Course(COG 76°):It displays ship's moving direction.
3. Range from own ship to destination waypoint (RNG 8.4nm)
It displays distance from the present position to destination.
4. Speed(SOG 12.5kt) : It displays ship's moving speed.
5. Direction to steer(to return to course), (▶)
It displays when the present ship's direction differs from waypoint toward.
In order to go waypoint, it displays steering direction to right or left by arrow mark(◀or ▶).
6. Destination waypoint name(WPT-001)
It displays waypoint name and designates name at MENU
7. Destination waypoint([]) : It displays MARK of waypoint
8. Analog XTE(Cross-track error) scale
When the ship is out at sea , the course off distance is displayed to ▲on analogue scale.
If the waypoint is not set up, ▲mark is displayed to "N".
9. △(Delta Course)
When it does not set up waypoint, the ship's direction is displayed to arrow at North up Mode(top side is
North, downward is South). If it sets up waypoint, it displays the going direction of ship's direction
10. Digital XTE indication(0.00nm)
When the ship is out at sea, the course off distance is displayed to arabic number.
(Aforesaid clause 8, Analogue is displayed to Digital)
11. According to speed of ship's direction, it differs from moving speed on the display.
