S&B Filters 75-5053 User manual

1. With the ignition switched off and the
parking brake set, disconnect the negative
battery terminal from both batteries.
INSTALLATION INSTRUCTIONS
VEHICLE APPLICATION
Year: 2011-16
Make: Ford
Model: F-250, F-350
Engine: 6.7L Diesel
TOOLS REQUIRED
•8mm Wrench or Socket
•Phillips head Screwdriver
•5/16” Nut Driver or Flat Blade
Screwdriver
NOTES
Kit may not fit with the following
Aftermarket Parts Installed:
•Custom Hood
•Turbo Upgrade
• Please read the entire product guide before proceeding.
• Ensure all components listed on page 4 are present.
• If you are missing any of the components, call our customer
support.
• Do not work on your vehicle while engine is hot.
• Make sure the engine is turned off and the vehicle is in Park
or the Parking Brake is set.
4. Loosen the clamp at the turbo inlet and
remove the bolt securing the resonator tube
to the shroud.
7. Remove the air box by carefully pulling it
up out of the OE grommets. Be sure the
grommets remain in position for the S&B
installation.
2. Disconnect the electrical connection for
the MAF sensor in the OE intake tube. Unclip
the wiring harness from the air box lid.
5. Disconnect all rubber hoses and coolant
lines for the intake tube assembly and remove
the tube from the vehicle.
8.Remove the air inlet gasket from OE air
box.
3. Loosen the hose clamp at the intake tube
and unclip the 4 hinges on the air box lid.
Remove the lid assembly from the vehicle.
6. Remove the bolt securing the air box to
the battery tray. Remove the OE filter from
the air box. The bolt will be reused with the
S&B air box.
9.Install the air inlet gasket onto the Air Box
(A). Push the two prongs into the holes
located on the bottom of the Air box.
P/N: 75-5053 / 75-5053D
SEE EXPLODED VIEW ON PAGE 4
1
S&B FILTER MAINTENANCE
Cleanable (KF-1050). If the enclosed filter is Red, it came pre-
oiled from the factory.
Disposable (KF-1050D). If the enclosed filter is White, it is a
disposable filter and should be discarded once it reaches
capacity. This filter (does not require oil).
BEFORE YOU START
CARB Status -Exempt
CARB EO #: D-590-9
Legal for use in CA or other states
adopting CA emissions standards
See Page 3 for more info.
Approx. Install Time 1Hrs 00Min

14. Remove the MAF sensor and ring
gasket from the OE air box lid. Insert the MAF
sensor and ring gasket into the Adapter Tube
(B). Secure using the supplied M4 Screws
(N). Do not over tighten the screws.
INSTALLATION INSTRUCTIONS (Continued)
12.Line up the air inlet gasket and install
the Air Box (A) into the two OE rubber
grommets. Make sure the Air Box is fully
pushed down into the grommets. Secure
using the factory bolt removed in Step #6.
15. Install the Silicone Adapter (M) over the
turbo inlet using the two #72 Hose Clamp (F).
Only tighten the hose clamp on the turbo inlet
at this time.
20.Slide the Hump Adapter (L) over onto
the Adapter Tube (B) and tighten both #72
Hose Clamp (F).
16. Install the Hump Adapter (L) over the
Intake Tube (C) using the remaining two #72
Hose Clamp (F) until it is nearly flush with the
end of the tube.
18. Install the Air Filter (D) onto the Adapter
Tube (B) and tighten the #80 Hose Clamp (E).
19. Carefully install the Filter/ Adapter
assembly in the Air Box (A).
SEE EXPLODED VIEW ON PAGE 4
2
P/N: 75-5053 / 75-5053D
17. Install the Intake tube assembly into
the Silicone Adapter (M) and tighten the #72
Hose Clamp (F).
10. Place the large Rubber Washer (O)
over the threaded hole located on the
mounting tab on the battery tray.
13. Remove the filter minder and grommet
from the OE air box lid. Insert the grommet
into the Adapter Tube (B) and then reinstall
the filter minder.
11. For those concerned about minimal engine heat; insert the Air Inlet Plug (T) into the side of the
Air Box (A). For those seeking additional air flow, set the Air Inlet Plug aside. Plug will snap into
place and can be removed by taking the lid off and pushing from inside the air box. (See page 3 for
more info)

INSTALLATION INSTRUCTIONS (Continued)
Performance Testing
• Engage parking brake and start your engine.
Listen for abnormal noises. If an air leak is
detected, re-inspect hoses and connections as
they may need to be repositioned and tightened.
•S&B FILTERS recommends that you keep your
OE intake system in the event it is required in the
future.
• In order to maintain your warranty, all connections
and components must be checked periodically for
alignment and for proper tension on all
connections. Failure to do so may void your
warranty.
• Use only S&B FILTERS cleaning and oil products
to service your filter. Using any other brand oil and
or cleaners on your S&B air filter may void your
warranty.
3
P/N: 75-5053 / 75-5053D
Related Items for Your Purchase
•Replacement Air Filter (Oiled)
(S&B P/N: KF-1050)
•Replacement Air Filter (Dry)
(S&B P/N: KF-1050D)
•Air Filter Wrap (S&B P/N: WF-1031)
23. Using the factory location, secure the
OE hose assembly using the supplied Loop
Clamp (P), M6 Hex Screw (S) and 6mm
Washer (R).
25. Reconnect the batteries. Inspect your
installation, make sure the kit is properly
positioned and all fasteners are secure. Affix
the CARB sticker near the intake kit. The
installation is now complete.
24. Install the Insulation Tube (Q) around
the factory coolant hose by removing the
protective film on the adhesive and sticking
the two sides together.
Precision II
Filter Cleaning & Oiling
Part #: 88-0008
22. Reconnect the wiring harness to the
MAF sensor.
21. Remove the protective covering from
the Clear Lid (G), then install the lid. Start with
the 5/16” Screws (I) and Rubber Washers (H).
Then install the 10-24 Screws (K) and Sealing
Washers (J). Do not over tighten!
Emissions Standard
The California Air Resource Board (CARB) requires that an E.O. identification label be applied to the vehicle in order to pass a smog check inspection when a Performance
Intake Kit has been installed. You must place the E.O. label provided on or near the intake kit after installation so that a smog check technician can easily verify the E.O. number.
As of April 2009, S&B has never had a product where CARB denied an exemption request; however, the exemption process with CARB can take as long as 18 months. Check
the status of the exemption process by looking up a specific part number. The CARB Exemption number and/or status is listed under the Product Details section for each part
number. If the status shows as “Pending,” CARB has yet to issue an exemption. Products that have not been issued an EO number are street legal in most states, but may not
be used on emission controlled vehicles in the state of California and are for off road use only. If you purchased your kit from S&B Filters directly, we will automatically mail you
your Exemption Sticker when it is issued to us. If you purchased your kit from an authorized S&B Filters Dealer, log onto our web site and register to receive your Exemption
Sticker.
SEE EXPLODED VIEW ON PAGE 4
Air Box End Cap Testing
Stock air boxes are a significant contributor to
poor air flow which is why S&B designs
custom air boxes with secondary and/or
enlarged openings. With that said, S&B
recognizes the benefits of cooler air, so we
have included a plug to seal off the opening if
so desired. For optimal performance, we
recommend that the intake be used with the
end cap. Plug should also be removed during
heavy snow to keep the air box from loading
up with snow.
Warning!
If your vehicle has a Vehicle Emission Control Information decal affixed to the factory airbox, a new
replacement label must be obtained and installed in a readily visible position in the engine compartment in
order to remain CARB compliant. Failure to do so will prevent the vehicle from passing a smog check.
Replacement labels can be ordered from your local dealership. Regulations state that the VECI label shall
not be affixed to any equipment which is easily detached from the vehicle. Label placement, under the hood
on a painted surface is recommended.

ITEM
QTY.
DESCRIPTION
P/N
A
1
Air Box
AL1151-00
B
1
Adapter Tube
AL1152-00
C
1
Intake Tube
AL1153-00
D
1
S&B Air Filter
KF-1050
E
1
Hose Clamp, #80
AG1010-00
F
4
Hose Clamp, #72
AG1009-00
G
1
Clear Lid
AI1493-00
H
2
Rubber Washer, 5/16”
AI1435-00
I
2
Truss Head Screw, 5/16”-18x1”
AI1297-00
J
2
S.S. Sealing Washer, #10
AI1272-00
K
2
S.S. Screw, 10-24x1/2”
AI1287-00
L
1
Hump Adapter, 4.25”ID
AI1286C-00
M
1
Silicone Adapter, 4.50”ID
AI1523C-00
N
2
Screw, M4-0.7x8mm
AI1360-00
EXPLODED VIEW
4
P/N: 75-5053 / 75-5053D
ITEM
QTY.
DESCRIPTION
P/N
O
1
Rubber Washer, 1.75”OD
AI1471-00
P
1
Loop Clamp, 5/8”OD
AI1511-00
Q
1
Insulation Tube, 3/4”ID
AI1522-00
R
1
Washer, Flat, 6mm
AI1416-00
S
1
Hex Cap Screw, M6-1.0x30mm
AI1257-00
T
1
Box Plug
AI1597-00
