S&C IntelliRupter PulseCloser User manual

IntelliRupter®PulseCloser®Fault Interrupter
Outdoor Distribution (15.5 kV, 27 kV, and 38 kV)
Protection and Communication Setup
Table of Contents
Section Page Section Page
Introduction
Qualified Persons .......................... 2
Read this Instruction Sheet ................... 2
Retain this Instruction Sheet. . . . . . . . . . . . . . . . . . . 2
Proper Application .......................... 2
Special Warranty Provisions................... 2
Safety Information
Understanding Safety-Alert Messages........... 4
Following Safety Instructions .................. 4
Replacement Instructions and Labels ........... 4
Safety Precautions ......................... 5
Overview................................... 6
IntelliRupter®Fault Interrupter Software
Requirements and Installation ................. 9
Coordinaide™—The S&C Protection & Coordination
Assistant .................................. 9
IntelliLink®Setup Software
Operation Screen ...........................10
IntelliLink Software Workspace ................11
General Setup
Site-Related ...............................15
User Commands .......................... 26
Time .................................... 30
Software Versions.......................... 33
User Notes ............................... 33
Communication Enhanced Coordination
CEC Operation ............................ 34
CEC Example for a Temporary Fault ........... 35
CEC Example for a Permanent Fault ........... 37
CEC Example for a Complex Network .......... 38
Protection Setup
Initial Trip Settings—Direction 1 ............... 39
TCCs for Test Sequence .................... 62
TCCs for Coordination ...................... 67
Direction 2 Configuration .................... 72
Testing After Initial Trip ..................... 73
Voltage Trip............................... 78
Frequency Trip ............................ 83
Sectionalizing Trip.......................... 86
Hot Line Tag .............................. 88
Closing Profile............................. 98
Closing Profile 2 Configuration ................109
Cold Load Pickup ..........................109
Advanced Setup ...........................111
Loop Restoration
Profile Configuration Options .................116
Loop Restoration Configuration Example........125
Normally Open Configuration .................134
Normally Closed Configuration................135
Restoration—External Device ..............140
Communication Setup
DNP Configuration .........................144
Serial Ports ...............................151
Routing ..................................152
Ethernet .................................153
Wi-Fi Settings .............................155
Communications Tests ......................157
DNP Diagnostics ..........................160
DNP Status Points .........................161
DNP Analog Input Points ....................165
DNP Control Points ........................167
DNP Analog Output Points ...................168
Security
Password Management .....................169
Security Screen ...........................174
Log Management ..........................175
Apply Configuration .......................178
IntelliRupterEC 7.3 Conversion Script
Overview.................................180
Software Requirements .....................180
Procedure ................................180
January 11, 2021
© S&C Electric Company 2008-2021 all rights reserved Instruction Sheet 766-530

The standard warranty contained in S&C’s standard conditions of sale, as set forth in
Price Sheets 150 and 181, applies to the IntelliRupter fault interrupter, except the rst
paragraph of the said warranty is replaced by the following:
(1) General: The seller warrants to the immediate purchaser or end user for a period of
10 years from the date of shipment that the equipment delivered will be of the
kind and quality specified in the contract description and will be free of defects of
workmanship and material. Should any failure to conform to this warranty appear
under proper and normal use within 10 years after the date of shipment, the seller
agrees, upon prompt notification thereof and confirmation the equipment has
been stored, installed, operated, inspected, and maintained in accordance with
the recommendations of the seller and standard industry practice, to correct the
nonconformity either by repairing any damaged or defective parts of the equipment
or (at the seller’s option) by shipment of necessary replacement parts. The seller’s
warranty does not apply to any equipment that has been disassembled, repaired, or
altered by anyone other than the seller. This limited warranty is granted only to the
Special Warranty
Provisions
Introduction
2 S&C Instruction Sheet 766-530
Qualified Persons WARNING
Only qualified persons who are knowledgeable in the installation, operation, and
maintenance of overhead and underground electric distribution equipment, along
with all associated hazards, may install, operate, and maintain the equipment covered
by this publication. A qualified person is someone who is trained and competent in:
• The skills and techniques necessary to distinguish exposed live parts from nonlive
parts of electrical equipment
• The skills and techniques necessary to determine the proper approach distances
corresponding to the voltages to which the qualified person will be exposed
• The proper use of special precautionary techniques, personal protective
equipment, insulated and shielding materials, and insulated tools for working on
or near exposed energized parts of electrical equipment
These instructions are intended ONLY for such qualified persons. They are
not intended to be a substitute for adequate training and experience in safety
procedures for this type of equipment.
Read this
Instruction Sheet NOTICE
Thoroughly and carefully read this instruction sheet and all materials included in
the product’s instruction handbook before installing or operating the IntelliRupter
PulseCloser Fault Interrupter. Familiarize yourself with the Safety Information
and Safety Precautions on pages 4 and 5. The latest version of this publication is
available online in PDF format at sandc.com/en/support/product-literature/.
Retain this
Instruction Sheet
This instruction sheet is a permanent part of your IntelliRupter® fault interrupter.
Designate a location where you can easily retrieve and refer to this publication.
Proper Application WARNING
The equipment in this publication is only intended for a specific application. The
application must be within the ratings furnished for the equipment. Ratings for the
IntelliRupter fault interrupter are listed in the ratings table in Specification Bulletin
766-31.

Introduction
immediate purchaser or, if the equipment is purchased by a third party for instal-
lation in third-party equipment, the end user of the equipment. The seller’s duty to
perform under any warranty may be delayed, at the seller’s sole option, until the
seller has been paid in full for all goods purchased by the immediate purchaser. No
such delay shall extend the warranty period.
Replacement parts provided by the seller or repairs performed by the seller
under the warranty for the original equipment will be covered by the above special
warranty provision for its duration. Replacement parts purchased separately will
be covered by the above special warranty provision.
For equipment/services packages, the seller warrants for a period of one year
after commissioning that the IntelliRupter fault interrupter will provide automatic
fault isolation and system reconfiguration per agreed-upon service levels. The
remedy shall be additional system analysis and reconfiguration of the IntelliTeam®
SG Automatic Restoration System until the desired result is achieved.
Warranty of the IntelliRupter fault interrupter is contingent upon the installa-
tion, configuration, and use of the control or software in accordance with S&C’s
applicable instruction sheets.
This warranty does not apply to major components not of S&C manufacture,
such as batteries and communication devices. However, S&C will assign to imme-
diate purchaser or end user all manufacturer’s warranties that apply to such major
components.
Warranty of equipment/services packages is contingent upon receipt of ade-
quate information on the user’s distribution system, sufficiently detailed to prepare
a technical analysis. The seller is not liable if an act of nature or parties beyond
S&C’s control negatively impact performance of equipment/services packages; for
example, new construction that impedes radio communication, or changes to the
distribution system that impact protection systems, available fault currents, or
system-loading characteristics.
S&C Instruction Sheet 766-530 3

Understanding
Safety-Alert Messages
Following
Safety Instructions
Replacement
Instructions and
Labels
Several types of safety-alert messages may appear throughout this instruction sheet
and on labels attached to the IntelliRupter PulseCloser Fault Interrupter. Familiarize
yourself with these types of messages and the importance of these various signal words:
DANGER
“DANGER” identifies the most serious and immediate hazards that will result
in serious personal injury or death if instructions, including recommended
precautions, are not followed.
WARNING
“WARNING” identifies hazards or unsafe practices that can result in serious
personal injury or death if instructions, including recommended precautions, are not
followed.
CAUTION
“CAUTION” identifies hazards or unsafe practices that can result in minor personal
injury if instructions, including recommended precautions, are not followed.
NOTICE
“NOTICE” identifies important procedures or requirements that can result in product
or property damage if instructions are not followed.
If you do not understand any portion of this instruction sheet and need assistance,
contact your nearest S&C Sales Office or S&C Authorized Distributor. Their
telephone numbers are listed on S&C’s website sandc.com, or call the S&C Global Support
and Monitoring Center at 1-888-762-1100.
NOTICE
Read this instruction sheet thoroughly and carefully
before installing or operating the IntelliRupter
PulseCloser Fault Interrupter.
If additional copies of this instruction sheet are required, contact your nearest S&C Sales
Ofce, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
It is important that any missing, damaged, or faded labels on the equipment be replaced
immediately. Replacement labels are available by contacting your nearest S&C Sales
Office, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
Safety Information
4 S&C Instruction Sheet 766-530

Safety Precautions
DANGER
IntelliRupter PulseCloser Fault Interrupters operate at high voltage. Failure to
observe the precautions below will result in serious personal injury or death.
Some of these precautions may differ from your company’s operating procedures and
rules. Where a discrepancy exists, follow your company’s operating procedures and
rules.
1. QUALIFIED PERSONS. Access to an IntelliRupter
fault interrupter must be restricted only to qualified
persons. See the “Qualified Persons” section on
page 2.
2. SAFETY PROCEDURES. Always follow safe operating
procedures and rules.
3. PERSONAL PROTECTIVE EQUIPMENT. Always use
suitable protective equipment, such as rubber gloves,
rubber mats, hard hats, safety glasses, and flash
clothing, in accordance with safe operating procedures
and rules.
4. SAFETY LABELS. Do not remove or obscure any of
the “DANGER,” “WARNING,” “CAUTION,” or “NOTICE”
labels.
5. OPERATING MECHANISM AND BASE. IntelliRupter
fault interrupters contain fast-moving parts that can
severely injure fingers. Do not remove or disassemble
operating mechanisms or remove access panels on the
IntelliRupter fault interrupter base unless directed by
S&C Electric Company.
6. ENERGIZED COMPONENTS. Always consider all
parts live until de-energized, tested, and grounded. The
integrated power module (IPM) contains components
that can retain a voltage charge for many days after the
IntelliRupter fault interrupter has been de-energized
and can derive a static charge when in close proximity
to a high-voltage source. Voltage levels can be as high
as the peak line-to-ground voltage last applied to the
unit. Units that have been energized or installed near
energized lines should be considered live until tested
and grounded.
7. GROUNDING. The IntelliRupter fault interrupter base
must be connected to a suitable earth ground at the
base of the utility pole, or to a suitable building ground
for testing, before energizing an IntelliRupter fault
interrupter, and at all times when energized.
The ground wire(s) must be bonded to the system
neutral, if present. If the system neutral is not resent,
proper precautions must be taken to ensure the local
earth ground, or building ground, cannot be severed or
removed.
8. VACUUM INTERRUPTER POSITION. Always confirm
the Open/Close position of each interrupter by visually
observing its indicator.
Interrupters, terminal pads, and disconnect blades on
disconnect style models may be energized with the
interrupters in any position.
Interrupters, terminal pads, and disconnect blades on
disconnect style models may be energized from either
side of the IntelliRupter fault interrupter.
9. MAINTAINING PROPER CLEARANCE. Always
maintain proper clearance from energized
components.
S&C Instruction Sheet 766-530 5

This instruction sheet is used with software version IntelliRupterECInstaller-7.3.x.exe.
The “x” can indicate any number from 0 to 255. Other related software component version
information is found on the Setup>General>Revisions screen. IntelliRupterECInstaller-
7.3.x.exe is the name of the installer le available at the S&C Automation Customer
Support Portal.
These instructions cover protection and communication setup of an IntelliRupter
PulseCloser Fault Interrupter. IntelliRupter fault interrupters may be used in standalone
radial-protection applications, for source-transfer operations, for loop restoration, or as
part of an IntelliTeam SG Automatic Restoration System.
The Standard Control Group can operate stand-alone (non-communicating) appli-
cations, SCADA communications, and automatic loop restoration. It also includes
IntelliTeam SG Bronze-Level Software for applications with two sources, including auto-
matic source transfer. Optional IntelliTeam SG Silver-Level Software is used for basic
closed-loop applications, and IntelliTeam SG Gold-Level Software is for applications
with three or more sources.
The automatic loop-restoration system is non-communicating and uses normally closed
IntelliRupter fault interrupters or conventional reclosers with a normally open IntelliRupter
fault interrupter switching point. The feeders on either side of the switching point are
fed from different sources. When a fault occurs on either feeder, the normally closed
IntelliRupter fault interrupters (or reclosers) in that feeder open and then use PulseClosing®
Technology (or reclose) sequentially to sectionalize and isolate the fault. Service is auto-
matically restored to unfaulted line segments by closing the IntelliRupter fault interrupter
at the normally open switching point.
The automatic source-transfer system uses two IntelliRupter fault interrupters
with peer-to-peer communication to ensure a high degree of critical-load continuity by
minimizing interruptions resulting from the loss of one source.
The IntelliTeam SG system monitors real-time load, and it uses peer-to-peer
communication to determine fault location and alternate source-restoration capa-
bility. After protection operations isolate the fault, the IntelliTeam SG system
automatically restores service to as many unfaulted line segments as the alternate source
has reserve capacity to supply. An IntelliTeam SG system with a Gold license can be
easily expanded to automate large distribution regions by using multiple alternate sources.
The Standard Control Group with Battery Backup is the same software in the
Standard Control Group and includes a battery that can operate for a minimum of four
hours after loss of ac-line voltage on both sides of the IntelliRupter fault interrupter to
provide extended dead-line switching.
The Universal Control Group includes IntelliTeam SG Automatic Restoration Software
with a Gold license and IntelliTeam® Designer software. This group will operate all fea-
tures of the IntelliTeam SG system with three or more sources, and it can be configured
to operate in an IntelliTeam® II Automatic Restoration System.
IntelliRupter fault interrupters may be configured before installation or on site with
a secure Wi-Fi communication link to a laptop computer running IntelliLink® Setup
Software. User-selectable setup parameters include device name and location, phase
identifications, terminal designations, current-flow directions, voltage-reporting units,
and a time-synchronization source.
6 S&C Instruction Sheet 766-530
Overview

Up to four general profiles can be configured; one is selected for normal use.
IntelliTeam SG software allows selection of an alternate profile for use when the IntelliRupter
fault interrupter is powered from an alternate source. See Instruction Sheets 766-532,
“IntelliRupter® PulseCloser® Fault Interrupter: IntelliTeam® Automatic Restoration
System Setup,” and 1044-570, “IntelliTeam® Designer: User’s Guide,” for more informa-
tion regarding the setup and confirmation of the IntelliTeam SG system.
A wide variety of features and functions can be selected and configured in the general
profiles, including the following:
Overcurrent Elements—Simultaneous Independent Directional Phase, Ground,
Negative-Sequence, and Sensitive Earth Time-Overcurrent, Instantaneous-
Overcurrent, and Denite-Time elements are provided.
PulseClosing Operations—The IntelliRupter fault interrupter can be congured to
test for faults using PulseClosing Technology—a unique, patented means for verifying
the line is clear of faults before initiating a closing operation. It uses precisely timed,
quick close and open operation of the interrupters and analysis of the current pulse to
determine whether a fault is present. A PulseClosing Technology operation subjects the
system to a small fraction of the fault energy experienced during conventional reclosing.
If no fault is detected, the device will close. A PulseClosing Technology operation can
also be initiated before a regular closing operation from the fully open and locked out
condition to determine whether a fault is present.
Conventional Closing—The IntelliRupter fault interrupter can be congured to use
a conventional close for any test after the initial fault trip. The “hard” close may be
required to allow a fuse operation after the initial fuse-saving operation. Up to four test
operations can be congured, and each can be a PulseClosing Technology operation or
a conventional close. A different inverse curve can be used for each close. Conventional
closing subjects the system to high-impact fault current at each closing operation.
PulseFinding™ Fault Location Technique Operations—When a fault occurs
downstream of series-connected IntelliRupter fault interrupters that cannot be selectively
coordinated, the devices can be congured so they all trip open. The fault is quickly
located by sequential PulseClosing Technology operations, starting at the open device
closest to the source. Each successive downstream device will perform a PulseClosing
Technology operation, nd no fault and, quickly close. But the device nearest the fault
will perform a PulseClosing Technology operation, sense the fault, and stay open.
Intelligent Fuse Saving—In conventional fuse-saving schemes, the upstream protective
device operates to save the lateral fuse. Intelligent fuse saving congures the IntelliRupter
fault interrupter so when fault current is above the point where the fuse would be faster
than the device, the IntelliRupter fault interrupter operates on a delayed curve so only the
fuse operates to isolate the fault. Customers downstream of the device do not experience
a momentary outage.
Sequence Coordination—The Sequence Coordination element maintains proper
coordination between the IntelliRupter fault interrupter and downstream reclosers. If a
fault is cleared by a downstream recloser, the IntelliRupter fault interrupter will shift to a
slower time-current coordination curve before fault testing by the downstream recloser.
S&C Instruction Sheet 766-530 7
Overview

Hot Line Tag Prole—The Hot Line Tag mode can be set locally with the HOT LINE
TAG lever and with an IntelliLink or SCADA command. The Hot Line Tag prole allows
the user to select alternate overcurrent, voltage, and frequency protection with one trip-
to-lockout, and it blocks all closing commands. For more information, see the “Manual
Hot Line Tag” section in Instruction Sheet 766-510, “S&C IntelliRupter® PulseCloser®
Fault Interrupter: Installation.”
Closing Proles—A Closing Prole operation is used when the IntelliRupter fault
interrupter is closed from the Open and Locked Out position. The Synch Check mode
may be used before closing, or a PulseClosing Technology operation, to test for faults.
Overcurrent, voltage, and frequency protection may all be set for one trip to lockout.
Closing Prole operations are time-limited and will switch to the assigned general
prole when closing is successful. A second Closing Prole operation with different
parameters than the rst Closing Prole operation may be selected.
Single-Phase Trip—IntelliRupter fault interrupters can be congured to open only the
faulted phases for an overcurrent trip signal.
Cold Load Pickup—The Cold Load Pickup modier can be set to modify overcurrent
protection after an extended outage.
Ground Trip Block—The Ground Trip Block mode prevents an inadvertent trip
caused by the imbalance created by diverting current on one or two phases through
single-phase bypass switches.
DNP Point Mapping—DNP points for the IntelliRupter fault interrupter can be mapped
to different point numbers on a SCADA system. See S&C Instruction Sheet 766-560,
“IntelliRupter® PulseCloser® Fault Interrupter: DNP Points List and Implementation.”
8 S&C Instruction Sheet 766-530
Overview

Review the “Computer Requirements” and “Software Installation” sections in
Instruction Sheet 766-571, “IntelliRupter® PulseCloser® Fault Interrupter:
Software Installation.”
NOTICE
Install and use only the IntelliLink Setup Software supplied for IntelliRupter fault
interrupter. IntelliLink Setup Software furnished with other S&C products cannot be
used to access an IntelliRupter fault interrupter.
NOTICE
A remote or local upgrade puts a control into the Prohibit Restoration state. When
upgrading controls in an IntelliTeam SG system, use the following procedure:
STEP 1. Upgrade the control software. This can be done with IntelliLink Setup
Software.
STEP 2. After the upgrade, verify all settings were preserved.
STEP 3. Use IntelliTeam Designer Version 6.0.x.x to re-push IntelliTeam SG system
configurations to all FeederNets that have updated devices.
STEP 4. If a device is an open point, push the configuration to both FeederNets for
that device.
STEP 5. Verify the team configurations.
STEP 6. For IntelliNode™ Interface Modules only, set the External Device Data
Updated mode to the Running setting.
STEP 7. Enable the Automatic Restoration mode on all upgraded controls.
Coordinaide software can plot various TCC curves for a protection overcurrent element
direction. The curves appropriate for both the upstream and downstream protective
devices can then be selected, and their parameters downloaded to a Setpoints Group File
for uploading to the IntelliRupter fault interrupter control. A Setpoints Group File can
also be downloaded from a control and opened using Coordinaide software for evaluation.
The link to Coordinaide software is located on the S&C website at:
sandc.com/en/support/coordinaide/. When selected, the link the opening page has a
brief description of the protection applications Coordinaide software can handle. When
launching the program, the next page contains the Conditions of Use disclaimer, the
minimum Web browser requirements, and a link to the Coordinaide software users guide.
After agreeing to the Conditions of Use, one final click launches the program.
Requirements and
Installation
Coordinaide™—
The S&C Protection
& Coordination
Assistant
S&C Instruction Sheet 766-530 9
IntelliRupter®Fault Interrupter Software

Message
indicator
After the computer has been congured and set up for Wi-Fi communication, connection
is automatically accomplished through IntelliLink Setup Software.
To connect to an IntelliRupter fault interrupter with IntelliLink Setup Software, see
the “Wi-Fi Connection to an IntelliRupter Fault Interrupter with IntelliLink® Setup
Software” section in Instruction Sheet 766-571, “IntelliRupter® PulseCloser® Fault
Interrupter: Software Installation.”
After verification of the password, the Operation screen opens. See Figure 1.
It shows the present status of IntelliRupter fault interrupter, including voltage and current
readings and any existing fault or error conditions. The IntelliRupter fault interrupter is
also operated from this screen.
Operation Screen
Figure 1. The IntelliRupter fault interrupter Operation screen.
The left menu on every IntelliRupter screen shows topics that can be expanded and
clicked to navigate to another screen. On the Operation screen, “Operation” is highlighted
on the left menu. Screens having multiple topics are tabbed, as shown in Figure 2 on
page 11. When a particular topic is selected, the tab is highlighted.
Clicking on the change buttons next to the user commands found on the lower portion
of the Operation screen will toggle the command state. The active state is shown by the
word displayed on the change button.
When the Single-Phase Operation mode is enabled the 1, 2, and 3buttons found
under the Open and Close buttons can be selected to enable single-phase operation.
Select a pole by clicking on one of the buttons. The indication will change to orange to
show the next Open or Close request will be applied to the selected pole. One, two, or
three poles can be operated depending on the selections. Click the Open or Close but-
ton after making the selection.
The Active General Profile or the Active Closing Profile can be changed by
selecting an alternative profile from the Change pull down menu item next to the text
box displaying the active profile.
Operation Screen
10 S&C Instruction Sheet 766-530
IntelliLink®Setup Software

The IntelliLink User Interface includes many standard features found in Windows-based
products as well as some custom features designed to make navigating through the
IntelliRupter fault interrupter settings easier. See Figure 2.
IntelliLink Software
Workspace
Figure 2. IntelliLink software features.
Tool bar
Status bar
Navigation tools
Sub-screen selection tabs
Navigation tree
Screen area
Communication status
Return to the Operation screen from other IntelliLink software screens by clicking
on the Operation menu item on the navigation tree at the left of the screen.
The Operation screen contains three message indicators. See Figure 1 on page 10.
The list of possible messages in the order of precedence is:
Settings Mismatch LOCKOUT-OC
LOCKED OPEN LOCKOUT-SEF
Close Blkd No Energy PICKUP-FREQ
Fault-Pulseclosing PICKUP-SECT
Lockout-Pulseclosing PICKUP-VOLTS
Close Blkd-Sync Check PICKUP-OC
Close Blkd Pulse Inop PICKUP-SEF
LOCKOUT-FREQ TESTING
LOCKOUT-SECT TESTING-SEF
Note: Blkd = Blocked; Inop = Inoperable; FREQ = Frequency; SECT = Sectionalizing;
OC = Overcurrent; SEF = Sensitive Earth Fault.
S&C Instruction Sheet 766-530 11
IntelliLink®Setup Software

Tool Bar
Open Snapshot
Same as Main Menu>File>Open
Snapshot—Clicking on this icon opens
a le browser to allow the selection of a
snapshot le.
Save Data
Snapshot
Same as Main Menu>File>Save Data
Snapshot—Clicking on this icon allows
saving a snapshot of the control data.
It provides a picture of the controls
memory content is a programing format.
Save Setpoints
Same as Main Menu>File>Save
Setpoints—Clicking on this icon opens
the Save Setpoints dialog box.
Load Setpoints
Same as Main Menu>File>Load
Setpoints—Clicking on this icon opens
the Load Setpoints dialog box.
Zoom In
Clicking on this icon increases the size of
objects and text in the screen area. See
Figure 2 on page 11.
Zoom Out
Clicking on this icon decreases the size
of objects and text in the screen area. See
Figure 2 on page 11.
Validate
Same as Validate button on the
Setup>Validate/Apply screen. See
Figure 113 on page 178. Checks the
pending changes; does not apply them.
Apply
Same as Apply button on the
Setup>Validate/Apply screen. See Figure
113 on page 178. Checks the pending
changes, and applies them if no errors
are found.
Reset
Same as Reset Buffer button on the
Setup>Validate/Apply screen. See Figure
113 on page 178. Removes pending
changes and returns to settings in the
memor y.
12 S&C Instruction Sheet 766-530
IntelliLink®Setup Software

Navigation Tree
Expand Arrow
This indicates the item to the right
is collapsed with additional items
underneath. Clicking on this icon expands
the list to show the hidden sub-items.
Collapse Arrow
This indicates the item to the right is
expanded showing additional items
underneath. Clicking on this icon
collapses the list to hide the displayed
sub-items.
Status Bar
Connected to:
This eld shows the user dened device
name. The device name is entered on the
Setup>General>Site-Related screen.
Location:
This eld shows the user dened device
location. The device location is entered on
the Setup>General>Site-Related screen.
Validate Status This eld shows the status of the Validate
and Apply functions.
Navigation Tools
Navigation
History
Clicking on this icon opens a list of the
last 10 screens visited. Selecting a screen
from the list will automatically transition
from the present screen to the selected
screen.
Navigate Back Clicking on this icon selects the next
screen down in the history list.
Navigate
Forward
Clicking on this icon selects the next
screen up in the history list.
Bread crumb
Field
This eld contains the path of the current
screen.
S&C Instruction Sheet 766-530 13
IntelliLink®Setup Software

Screen Area and Data Entry
The screen area contains various data objects used for conguring your control as
well as some features for displaying and accessing the data objects. The basic data
objects contain text boxes for direct text entry and list boxes for data selection.
Editable Text
Boxes
Text boxes with white background and
light blue text indicate editable content.
The cursor will change when hovering
over and editable eld.
Non-editable
Text Boxes
Text boxes with a grey background
and dark blue text indicate dynamic
text populated by the control. This text
cannot be changed.
List Boxes
List boxes as indicated by the down arrow
supply a list of choices when selected. The
current selection will either be shown on
the list box or in an adjacent text box.
Check Boxes
Check boxes will be provided for enable/
disable decisions. Data elds for disabled
items will be automatically hidden or grey
shaded. Data elds for disabled items
cannot be changed.
Text Expanders
Expanders are provided to help manage
the view. When the data below the
expander is visible the expander icon
arrow points up. Clicking on the icon
collapses or hides the data from view.
When the data is hidden the expander
arrow points down. Clicking on the icon
displays the hidden date.
Communication Status
The communication status bar at the bottom of every IntelliLink software screen
displays the connection addresses, the refresh mode, and the last refresh. The time
changing after “Refresh:” indicates the control is communicating. The refresh defaults to
Auto mode but can be stopped by clicking on the Stop button and manually refreshed
by clicking on the Once button that comes into context when the refresh is stopped.
Sub-screen Selection Tabs
Active Tab Green indicates the active screen tab.
Inactive Tab
Grey indicates an inactive tab. Clicking on
an inactive tab changes from the active
screen to the screen associated with the
clicked tab.
14 S&C Instruction Sheet 766-530
IntelliLink®Setup Software

Figure 3. The Setup>General>Site-Related>Device screen.
Device Section
Device Name
Enter a name for the IntelliRupter fault interrupter, up to 12 characters. See Figure 3.
This name is displayed at the top of every screen as “Connected to:”
Site-Related
Device Location
Enter a location for the IntelliRupter fault interrupter, up to 64 characters. This location
is displayed at the top of every screen as “Location:”
GPS Coordinates
The location data provided by the integrated Global Positioning System is automatically
displayed.
IntelliRupter Base Serial Number
The serial number is automatically read from the base memory module.
IntelliRupter Control Serial Number
This serial number is automatically read from the protection and control module.
Catalog Number
The catalog number is automatically read from the base memory module.
Base Memory Module Version Number
This eld displays the version number for the base memory module.
Optional Disconnect Switch Installed
Presence of the integral disconnect is automatically determined from the base memory
module.
S&C Instruction Sheet 766-530 15
General Setup

Figure 4. The Setup>General>Site-Related>Operation screen.
Operation Section
Mode of Operation
Select the operation mode with the drop-down button. See Figure 4. The Radial mode
is the default and provides basic protection with no automatic load restoration. The
IntelliTeam SG mode starts IntelliTeam SG system operation after fault interruption
and isolation have completed. Refer to S&C Instruction Sheets 766-532, “IntelliTeam®
Automatic Restoration System Setup” and 1044-570, “S&C IntelliTeam® Designer: User’s
Guide” for information about IntelliTeam Automatic Restoration System conguration.
To use an IntelliRupter fault interrupter with the IntelliTeam II Automatic Restoration
System, the IntelliTeam SG software must be set to operate in the IntelliTeam
II Compatibility mode. The Loop mode uses a standard loop restoration system
conguration.
Battery Installed
The control automatically determines whether a battery is installed.
Open on Loss of Control Power
Select the Yes option to congure the IntelliRupter fault interrupter to open when
capacitor energy storage reaches a critical level because of loss of line power and a low
battery charge. Opening on loss of control power limits in-rush current when the circuit
is re-energized and feeder segments are sequentially picked up. Select the No option
to congure the IntelliRupter fault interrupter to remain closed when stored energy is
depleted.
Time Limit for Sleep—Do Not Resume Operations
This is the maximum number of minutes the IntelliRupter fault interrupter can remain
de-energized after opening on loss of control power and still be able to close automatically
when control power is restored. The IntelliRupter fault interrupter must have been in the
Closed position before loss of control power. Setting this value to 0 minutes will prohibit
an automatic close. (Range: 0-1440; Step: 1; Default: 120)
Time to Close After Wake-Up
When control power is restored and the Time Limit for Sleep—Do Not Resume
Operations Timer has not expired, automatic closing of the IntelliRupter fault interrupter
will be delayed by this timer. It may take up to 30 seconds after line power is restored for
the IntelliRupter fault interrupter to automatically close, even when the Time to Close
After Wake-Up Timer is set to 0 minutes. (Range: 0-30; Step: 1; Default: 0)
16 S&C Instruction Sheet 766-530
General Setup

On Next Power-up, Use Settings From:
Select from the drop-down list. Select the Control Once or Control Always options
when the IntelliRupter fault interrupter was previously congured and those control
settings will be used. When the protection-and-control module is a replacement, select
the Base Memory option. The replacement module will be congured with the settings
stored in the base memory module. Settings are stored for: Block Ground Trip, Use 2nd
Closing Prole, HLT Set by SCADA, HLT Set by Wi-Fi, HLT Set by IntelliLink,
Block Circuit Testing, Block Test on Backfeed, Block SEF Trip, Block Single
Phase Trip, Remote Operation, and the active General functions.
On Next Power-up, Use Command States From:
Select from the drop-down list. Select the Control Once or Control Always options
when the IntelliRupter fault interrupter was previously congured and those command
states will be used. When the protection-and-control module is a replacement, select
the Base Memory option. The replacement module will be congured by the command
states stored in the base memory module. States are stored for these functions:
• Ground/Neg-Seq Trip Enable/Block
• Loop Restoration Enable/Disable
• Circuit Testing Enable/Block
• Test on Backfeed Enable/Block
• Sensitive Earth Trip Enable/Block
• Single-Phase Trip Enable/Block
• Remote Operation Enable/Disable
• HLT Set by SCADA, HLT Set by IntelliLink.
• Latched Overcurrent Execute
When the GROUND TRIP manual lever is in the Blocked state, it takes precedence
over the saved user command state.
When the HOT LINE TAG manual lever is in the On state, it takes precedence over
the saved user command state.
On Next Power-up, Use Netlist From:
Select from the drop-down list. Select the Control Once or Control Always options
when the IntelliRupter fault interrupter was previously congured and that Netlist will
be used. When the protection-and-control module is a replacement, select the Base
Memory option. The replacement module will be congured with the Netlist stored in
the base memory module.
Timed Shut Down after Loss of AC Voltage
Select the Yes option to require timer expiration before shutdown. The No option is the
default.
Time to Disconnect Battery After Loss of Ac Voltage
This setting congures the timer. (Range: 1-240; Step: 1 minute; Default: 120)
S&C Instruction Sheet 766-530 17
General Setup

Figure 5. The Setup>General>Site-Related>Log screen.
Log Section
Logging Level
The selected logging level determines the type of data-log messages captured in
the base memory module and is displayed on the Logs>Historic Log screen. See
Figure 5. The Normal setting is the default. Every data-log message is assigned one of
these specic log levels:
Normal–User information
Extended–User information and internal status
All–User information, internal status, and internal trace/debugging information
Duplicate Event Margin (milliseconds)
Storing rapidly occurring duplicate events can ood the internal memory and does not
yield useful diagnostic information. Every element of their event records must match for
events to be considered duplicates. This setpoint selects data to be stored in the internal
memory and be displayed on the Logs>Historic Log screen. It determines the time
between logging a duplicate event. It has no effect on an alternating sequence of events.
For example, the setpoint can be set to 10 ms. For a sequence of events ABABAB (where
A and B are different), assume the next event occurs 1 ms after the previous one. Though
identical events occur within 2 ms, well within the value of the setpoint, all events will
be logged. (Range: 0-30; Step: 1 ms; Default: 10)
Time Average for Metering
This is the sampling period in minutes used in generating data for the compact ash
Metering.pro les. A smaller interval results in more log entries. (Minimum: 1; Maximum:
120; Increment: 1; Default:15)
18 S&C Instruction Sheet 766-530
General Setup

Figure 6. The Setup>General>Site-Related>System screen.
System Section
Pole 1 Phase Label (1 character)
This is the label for Pole 1. See Figure 6.
Pole 2 Phase Label (1 character)
This is the label for Pole 2.
Pole 3 Phase Label (1 character)
This is the label for Pole 3.
Information about Phase Rotation Settings
The IntelliRupter fault interrupter measures phase rotation (123, 132, or Undened)
using both terminal X & Y phase voltages. If viable voltage is present on both terminals,
only terminal X is used when determining phase rotation.
• When the IntelliRupter fault interrupter control powers up it may take sev-
eral minutes before the measured phase rotation is displayed on the Metering
screen. Until then, the Metering screen displays the phase rotation setting on the
Setup>General>System>Phase Rotation screen.
• Until terminal-X phase rotation is measured, the IntelliRupter fault interrupter
measures positive and negative sequence voltage based on the 123 or 132 setting in
Setup>General>System>Phase Rotation screen.
• In the event the phase rotation setting on the Setup>General>System>Phase
Rotation screen results in the IntelliRupter fault interrupter detecting both terminals
X & Y have higher negative sequence voltages than positive sequence voltages, the
Metering screen will initially display negative sequence voltages for both terminals.
After about 1 minute these terminal X & Y negative sequence voltages will change to
positive sequence voltages.
S&C Instruction Sheet 766-530 19
General Setup

Note: Exceptions to this may occur if there is a fault condition, the IntelliRupter fault
interrupter detects less than three-phase voltage present, or unequal phase-voltage
magnitudes are occurring.
• After phase rotation is measured, the measured-phase sequence is displayed on the
Metering screen.
Note: The measured System Phase Rotation displayed on the Metering screen
may be different than the Phase Rotation setpoint on the Setup>General>Site-
Related>System>Phase Rotation screen.
• After phase rotation is determined, it is not re-veried unless one of the following
events occur:
• Voltage is lost on both terminals.
• The 5-minute Phase Rotation Reverication Timer expires.
• Any new settings are applied.
For example, the Metering screen display of system-phase rotation may be delayed
five minutes if the terminal-phase associations have changed without a preceding
loss-of-voltage event on both terminals X & Y.
• At power up with all three poles open, and when terminals X & Y have unequal phase-
sequence voltages, the IntelliRupter fault interrupter presumes terminal-X voltage to
be positive sequence.
Phase Rotation
Phase rotation is automatically determined by the Protection and Control module.
Select the 123, 132, or Undened option. The control will update this after making the
measurement.
Direction 1 / Direction 2
This setting determines the normal current direction. Select the X->Y or Y->X option.
X is the lower terminal and Y is the upper terminal. Directional-overcurrent protection
is set with respect to the circuits named Direction1 and Direction2. When the Direction
1/Direction 2 conguration is X->Y, Direction 1 protection settings are applied to a fault
that ows into the Y terminal and out of the X terminal. See Figures 7, 8, and 9 on page 21.
The IntelliTeam Automatic Restoration System uses the voltage measured on the
terminal configured as Direction 1 to determine the Good-Source Voltage measure-
ment. The Direction 1 terminal must be configured as the terminal that is the normal-
source side of a normally closed IntelliRupter fault interrupter. For a normally open
IntelliRupter fault interrupter with the normal switch function defined as a Tie/Sub, the
Direction 1 terminal must be configured as the terminal on the alternate-source side of
the IntelliRupter fault interrupter. A normally open IntelliRupter fault interrupter with
a normal switch function defined as a Tie may have the Direction 1 terminal configured
as either terminal X or terminal Y.
Label for Direction 1 (6 char limit)
This label associates Direction 1 of the directional-overcurrent protection with the name
of a substation, source, or load. The designation selected should take into consideration
the source may change when the circuit is automatically recongured. Directional-
overcurrent protection should be set to protect against faults on circuits connected to
this terminal.
Label for Direction 2 (6 char limit)
This label associates Direction 2 of the directional overcurrent protection with the name
of a substation, source, or load. The designation selected should take into consideration
the source may change when the circuit is automatically recongured. Directional-
overcurrent protection should be set to protect against faults on circuits connected to
this terminal.
20 S&C Instruction Sheet 766-530
General Setup
