S&C PureWave SMS-250 Installation guide

S&C PureWave® SMS-250 Storage Management System
Power Conversion System
263 kW/263 kVA, 380 V
October 3, 2016
© S&C Electric Company 2015-2016, all rights reserved Instruction Sheet 659-520
Table of Contents
Section Page Section Page
Introduction
Qualified Persons ..............................2
Read this Instruction Sheet ......................2
Retain this Instruction Sheet .....................2
Proper Application..............................2
Warranty .....................................2
Warranty Qualifications..........................2
Safety Information
Understanding Safety-Alert Messages .............3
Following Safety Instructions .....................3
Replacement Instructions and Labels...............3
Location of Safety Labels ........................4
Safety Precautions.............................5
Components and Controls
Enclosure ....................................6
LCD Screen ..................................6
Dead-Front Access Panels .......................7
Inner Components .............................7
User Interface .................................8
Control Assembly ..............................9
Inverter ......................................9
Ac and Dc Circuit Breakers......................10
EMI Filters...................................11
Cable Termination Area......................... 11
Fuses ...................................... 12
Service Shelf ................................ 12
Radio Provisions .............................. 14
Human Machine Interface....................... 14
HMI Program................................. 15
Operation
System Design ...............................24
System Operation .............................24
States ......................................24
Resets .....................................25
Alarm Types .................................25
Basic Operation ..............................25
Alarm List and Troubleshooting Tips ...............29
Specifications ................................42
Maintenance
Annual Inspections ............................43
Maintenance Checklist .........................43
Annual Maintenance Checklist ...................43
Operation and Maintenance

2S&C Instruction Sheet 659-520
Qualified Persons WARNING
The equipment covered by this publication must be installed, operated, and maintained by
qualified persons who are knowledgeable in the installation, operation, and maintenance
of energy storage equipment along with the associated hazards. A qualified person is one
who is trained and competent in:
• The skills and techniques necessary to distinguish exposed live parts from nonlive parts
of electrical equipment
• The skills and techniques necessary to determine the proper approach distances corre-
sponding to the voltages and arc-flash levels to which the qualified person will be exposed
• The proper use of the special precautionary techniques, personal protective equipment,
insulating and shielding materials, and insulated tools for working on or near exposed
energized parts of electrical equipment
These instructions are intended only for such qualified persons. They are not intended to
be a substitute for adequate training and experience in safety procedures for this type of
equipment.
Read this
Instruction Sheet NOTICE
Thoroughly and carefully read this entire instruction sheet before operating and main-
taining the PureWave® SMS-250 Storage Management System and power conversion
system (PCS). Familiarize yourself with the Safety Information and Safety Precaution on
pages 3 through 5. The latest version of this instruction sheet is available online in
PDF format at sandc.com/Support/Product-Literature.asp
Retain this
Instruction Sheet
This instruction sheet is a permanent part of your PCS. It does not include instruction
sheets from the original battery manufacturer. Information sheets such as this one can
be placed inside a compartment in the PCS enclosure, where they can be easily retrieved
for future use.
Proper Application WARNING
The equipment in this publication must be selected for a specific application. The applica-
tion must be within the ratings furnished for the equipment. Refer to S&C General Brochure
659-G358 for the S&C PureWave SMS-250 Storage Management System. Failure to do so
may result in damage of the equipment.
Warranty The warranty and/or obligations described in S&C’s standard conditions of sale, as set
forth in Price Sheet 150, plus any special warranty provisions, as set forth in the applica-
ble product-line specification bulletin, are exclusive. The remedies provided in the former
for breach of these warranties shall constitute the immediate purchaser’s or end user’s
exclusive remedy and a fulfillment of all seller’s liability. In no event shall the seller’s
liability to the immediate purchaser or end user exceed the price of the specific product
that gives rise to the immediate purchaser’s or end user’s claim. All other warranties,
whether express or implied or arising by operation of law, course of dealing, usage of
trade or otherwise, are excluded. The only warranties are those stated in Price Sheet 150,
and THERE ARE NO EXPRESS OR IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. ANY EXPRESS WARRANTY OR OTHER
OBLIGATION PROVIDED IN PRICE SHEET 150 IS GRANTED ONLY TO THE IMMEDI-
ATE PURCHASER AND END USER, AS DEFINED THEREIN. OTHER THAN AN END
USER, NO REMOTE PURCHASER MAY RELY ON ANY AFFIRMATION OF FACT OR
PROMISE THAT RELATES TO THE GOODS DESCRIBED HEREIN, ANY DESCRIPTION
THAT RELATES TO THE GOODS, OR ANY REMEDIAL PROMISE INCLUDED IN PRICE
SHEET 150.
Warranty
Qualifications
The seller’s warranties are contingent upon the installation and adjustment of the S&C
PureWave SMS-250 Storage Management System in accordance with S&C’s applicable
instruction sheets, data sheets, and/or data bulletins.
Introduction

S&C Instruction Sheet 659-520 3
Understanding
Safety-Alert
Messages
Several types of safety-alert messages may appear throughout this instruction sheet and
on labels attached to the PureWave SMS-250 unit. Familiarize yourself with these types
of messages and the importance of these various signal words:
DANGER
“DANGER” identifies the most serious and immediate hazards that will likely result in
serious personal injury or death if instructions, including recommended precautions, are
not followed.
WARNING
“WARNING” identifies hazards or unsafe practices that can result in serious personal injury
or death if instructions, including recommended precautions, are not followed.
CAUTION
“CAUTION” identifies hazards or unsafe practices that can result in minor personal injury
if instructions, including recommended precautions, are not followed.
NOTICE
“NOTICE” identifies important procedures or requirements that can result in product or
property damage if instructions are not followed.
Following
Safety Instructions
If you do not understand any portion of this instruction sheet and need assistance, contact
your nearest S&C Sales Ofce or S&C Authorized Distributor. Their telephone numbers
are listed on S&C’s website sandc.com. Or call S&C Headquarters at [phone]; in
Canada, call S&C Electric Canada Ltd. at [phone].
NOTICE
Read this instruction sheet thoroughly and carefully
before installing or operating your S&C PureWave
SMS-250 Storage Management System.
Replacement
Instructions
and Labels
If you need additional copies of this instruction sheet, contact your nearest S&C Sales
Ofce, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
It is important that any missing, damaged, or faded labels on the equipment be replaced
immediately. Replacement labels are available by contacting your nearest S&C Sales Office,
S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
Safety Information

4S&C Instruction Sheet 659-520
A B C
Safety Information
Reorder Information for Safety Labels
Location Safety Alert Message Description Part Number
ADANGER KEEP OUT. RISK OF ELECTRICAL SHOCK … PE-70479-1
B★NOTICE REAR CLEARANCE … PE-70482-1
CDANGER ARC FLASH AND SHOCK … PE-70483-1
★ Label is on the left and right sides of the PCS enclosure.
Location of Safety Labels
AC
C
C
B B
Symbols and Terminal Markings
The “ ” symbol represents the power on button. When the “ ” button with the symbol is pressed, the breaker
places the equipment into a fully-powered state
Equipment grounding conductor.
The “ ” symbol represents the power off button. When the button with the “ ” symbol is pressed, the breaker
disconnects the load side from the power source. The dc breaker disconnects the SMS-250 from the battery.
The ac breaker disconnects the ac output to the load.
Direct current, also indicated as dc.
Alternating current, also indicated as ac.

S&C Instruction Sheet 659-520 5
Safety Precautions
1. QUALIFIED PERSONS. Access to the PureWave
SMS-250 system must be restricted only to qualified
persons. See “Qualified Persons” on page 2.
2. SAFETY PROCEDURES. Always follow safe
operating procedures and rules.
3. PERSONAL PROTECTIVE EQUIPMENT. Always use
suitable protective equipment, such as rubber gloves,
rubber mats, hard hats, safety glasses, and flame-retardant
clothing, in accordance with safe operating procedures
and rules.
4. SAFETY LABELS. Do not remove or obscure any of
the “DANGER,” “WARNING,” “CAUTION,” or “NOTICE”
labels.
5. ENCLOSURE. Do not open access doors unless the
system is offline or otherwise authorized by S&C Electric
Company.
6. MAINTAINING PROPER CLEARANCE. Always
maintain proper clearance from energized components,
ensuring the dead-front access panels are in place after
maintenance and before operation.
7. HAZARDOUS VOLTAGES. High-voltage dc is present
even without utility power connected. Hazardous
voltages should also be expected in all interconnecting
components and lines.
To maintain safety, the user should use a padlock
on the door of the PCS. The door and the use of the
padlock provide protection to inadvertent contact with
hazardous voltages.
8. GROUNDING.
For grounding purposes, the proceeding must be
followed:
• The PCS ground bar in the cable termination area
must be connected to a suitable earth ground for
testing before energizing the unit and at all times
when energized.
• The overall ground system should be sufficient to limit
the Ground Potential Rise, step voltage, and touch
voltage to acceptable limits as determined by the util-
ity’s practices and the National Electric Safety Code.
9. ENERGIZED COMPONENTS. Always consider all parts
live until de-energized, locked open, and tested.
10. ADDITIONAL CONNECTIONS. The user should not
attempt to connect any additional logic controls or power
connections to the PureWave SMS-250 system (beyond
the connections shown on the interconnect drawing)
without having received written approval from S&C
Electric Company.
11. INSULATED HAND TOOLS.
To use insulated hand tools, the proceeding must be
followed:
• Insulated hand tools are required when working on or
around any energized equipment. Use only properly
rated tools for the energy present.
• Tool inventories should be kept to ensure that all tools
that enter the system enclosure are removed prior to
energizing the system.
12. EMERGENCY PROCEDURES AND EQUIPMENT.
For emergency procedures:
• The owner should develop policies and procedures
for handling emergency situations.
• It is the responsibility of the owner to develop site-
specific emergency action plans for response to
such situations.
13. ADDITIONAL SAFETY INSTRUCTIONS. Consult the
battery supplier for additional safety instructions and
procedures regarding the battery used for the PureWave
SMS-250 system.
DANGER
The PureWave SMS-250 system operates at hazardous voltage. Failure to observe
the precautions below will result in serious personal injury or death.
Some of these precautions may differ from your company’s operating procedures and
rules. Where a discrepancy exists, follow your company’s operating procedures
and rules.

6S&C Instruction Sheet 659-520
Enclosure The enclosure houses the PCS. The weatherproof, tamper-resistant NEMA 4 enclosure
helps protect the system from environmental factors and unauthorized interference.
Access to the system components shall be by means of a door at the front of the enclo-
sure. Vents for air ow are located on the back. See Figure 1.
Figure 1. Front and rear view of the PCS enclosure.
LCD Screen A four-line, 40 character liquid-crystal display shall be mounted on the control panel,
protected by a clear plastic window. The display shall indicate status information such
as voltages (ac), currents (ac), power (ac), vars (ac), battery voltage (dc), inverter state,
operating mode, and active alarms. See Figure 2.
LCD
Figure 2. Location of the LCD screen.
Components and Controls

S&C Instruction Sheet 659-520 7
Dead-Front Access
Panels WARNING
Do not remove the dead-front access panels unless qualified to do so. Potentially lethal
voltages are present beyond the dead-front access panels. High-voltage dc may be
present even without the utility power connected.
Upon opening the PCS enclosure door, the three dead-front access panels are shown.
The panels protect the user from the energized components of the PCS. See Figure 3.
Dead-front access
panels
Figure 3. Dead-front access panels.
The panels may be removed starting from the top panel to the bottom panel. Use a #2
Phillips screwdriver for the two screws at the top of each panel and a 13-mm socket
wrench for the side ange nuts. Refer to Figure 34 on page 46 for an illustration of the
dead-front access panel removal procedure.
Inner Components DANGER
Before removing the dead-front access panels, make sure that the PCS is de-energized
to avoid serious injury. When removing the three dead-front access panels, remove them
from top to bottom to avoid injury or equipment damage.
User interface Control assembly
Cable termination
area
EMI filters
Shelf (stowed) Dc circuit breaker
Fuses
Ac circuit breaker
Radio (provisions) Inverter
Figure 4. Components inside the PCS enclosure.
Components and Controls

8S&C Instruction Sheet 659-520
User Interface The PureWave SMS-250 can be controlled through the user interface located at the top
left side of the unit. Figure 5 shows the controls available on the user interface.
Figure 5. User interface.
The controls on the user interface are as follows:
SMS CONTROL−This switch enables the user to switch control from SCADA mode
(SCADA ENABLE) to HMI mode (SCADA DISABLE) and vice versa.
RESET−This black pushbutton, when pressed, enables the user to administer a manual
reset.
INVERTER STOP−This red pushbutton, when pressed, enables the user to stop any run-
ning operation. Pushing this button will open the ac and dc circuit breakers.
WEB SERVER CONNECTION−The user can use this connection port to connect locally
to the system via Human Machine Interface (HMI) mode.
PRE-CHARGE−This key-lock is used when any work or maintenance requires the
inverter to be de-energized. When the inverter stop pushbutton is pressed and the pre-
charge key is turned to the OFF position (ac and dc circuit breakers are open), the
inverter bridge will discharge to a safe level in 5 minutes.
WARNING
Capacitors in the PCS may have residual charge after the pre-charge key has been
turned off. If there is no load connected to the unit, wait 5 minutes for the capacitors to
discharge before proceeding with work or maintenance.
When the pre-charge key-lock is in the OFF position, the key can be removed. The
inverter bridge will remain de-energized until the key is placed back in and turned to the
ON position (and source power is restored). Once the key-lock is in the ON position, the
key cannot be removed unless it is turned back to the OFF position.
Components and Controls

S&C Instruction Sheet 659-520 9
Components and Controls
Control Assembly The control assembly inputs and indicators are located on the front of the control
assembly pull-out drawer located at the top-right side of the unit. See Figure 6. This
assembly contains all the necessary DSP, microcontroller, application, and scale boards
for operation. The inputs and indicators on the assembly are for service and mainte-
nance personnel use.
NOTICE
Access and use of the control assembly should be done by authorized personnel who
are trained in servicing the PCS.
Figure 6. Control assembly inputs and indicators.
Inverter The inverter assembly consists of a three-phase, four-quadrant inverter that converts
the dc power to ac power. It creates the three-phase output from the dc battery bus.
Insulated-gate bipolar transistors (IGBTs) are used for switching, and pulse-width
modulation is used to control the real and reactive power produced and absorbed by
the PCS. See Figure 7.
Figure 7. Inverter assembly.

10 S&C Instruction Sheet 659-520
Ac and Dc Circuit
Breakers
The PCS has two circuit breakers located in the lower-middle section of the unit. See
Figure 8 for the location of the circuit breakers. The two circuit breakers are:
Ac Circuit Breaker (CB1)−The ac circuit breaker can automatically isolate the PCS
from the utility feeder in the event of a Trip Ofine alarm. The circuit breaker is
rated at 400 A. See Figure 8 for the location of the ac circuit breaker.
Dc Circuit Breaker (CB2)−The dc circuit breaker can automatically isolate the PCS
from the battery in the event of a Trip Ofine alarm or inverter stop. The circuit
breaker is rated at 400 A. See Figure 8 for the location of the dc circuit breaker.
NOTICE
A few operating controls on the ac and dc circuit breakers are located inside the
PCS. However, unless otherwise specified, these controls should only be operated by
authorized personnel. Indicators for circuit-breaker status are present not only on the
circuit breakers, but also on the Human Machine Interface (HMI).
Ac circuit breaker Dc circuit breaker
Figure 8. Ac and dc circuit breakers.
Components and Controls

S&C Instruction Sheet 659-520 11
EMI Filters Located below the circuit breakers are ac and dc electromagnetic interference (EMI)
lters. These lters are designed to prevent any IGBT interference by shunting the high
frequency. See Figure 9 for the location of the EMI lters.
Figure 9. Location of EMI filters.
Cable Termination
Area
The ac and dc cable termination area is located inside the enclosure at the bottom-left
corner. This user-accessible termination area shall include terminals for connecting the
utility-source cables and the dc terminals for connecting the battery pack cables. See
Figure 10 for the location of the cable-termination area.
Cable-termination
area
Figure 10. Cable-termination area.
Components and Controls
EMI filters

12 S&C Instruction Sheet 659-520
Fuses Six fuses are located to the left of the circuit breakers. See Figure 11. Some are rated
differently from others because the ratings pertain to their application.
Fuses
Figure 11. Location of fuses.
To replace a fuse, no hardware is necessary. Pulling the fuse latch forward will open
the holder. The fuse will then be exposed for replacement.
Service Shelf The PCS enclosure is supplied with a shelf assembly to assist personnel in servicing or
monitoring the unit. The shelf-top and brackets are bolted on the inside of the enclosure
door. See Figure 12.
Shelf
top
Shelf brackets
Figure 12. Location of stowed shelf-top and brackets.
Shelf Assembly
STEP 1. Using a 13-mm hexagonal wrench, unbolt the four ange nuts located at the
corners of the shelf-top.
(a) Unbolt the nuts holding the brackets. The nuts will be used to assemble
the shelf.
(b) Remove the shelf-top and brackets from the door.
CAUTION
Removal and placement of the shelf-top require careful attention so that mishandling,
which can lead to damage or personal injury, does not occur.
Components and Controls

S&C Instruction Sheet 659-520 13
STEP 2. Bolt the brackets in the location specied in Figure 13.
Figure 13. Location of brackets installation.
STEP 3. Place the shelf-top on top of the brackets and through the bolts as seen in
Figure 14.
Figure 14. Location of shelf attachment to the enclosure door.
STEP 4. Bolt the ange nuts to secure the shelf-top to the door. The shelf is now ready
for use. See Figure 15.
Figure 15. Shelf installed.
NOTICE
Do not close the enclosure door when the shelf is installed. The shelf will need to be
disassembled after servicing is complete. Failure to do this can result in damage to the
equipment.
The service shelf can also be used for removing and replacing the IGBT inverter pole
assemblies inside the PCS. Refer to Figure 36 on page 48 for an illustration of installing
the shelf inside the PCS to service these assemblies.
Components and Controls

14 S&C Instruction Sheet 659-520
Radio Provisions The PCS enclosure is supplied with provisions for radio communication. A removable
panel to mount the radio and 24-Vdc power are located next to the LCD circuitry on the
inside of the enclosure door. See Figure 16.
Radio
Provisions
Figure 16. Provisions for radio communication.
Human Machine
Interface
The Human Machine Interface (HMI) computer is used to control and monitor the Pure-
Wave SMS-250. A laptop computer can be used. Before connecting to the PureWave
SMS-250, the user computer network settings need to be congured to the following:
• An IP address of 192.168.10.n, where n is a number greater than 0 and less than 100.
• The subnet mask should be set to 255.255.255.0.
• The default gateway can be the same as the IP address.
• Domain Name System (DNS) is not needed.
After the user computer network settings are configured, the user can attempt to
connect to the HMI control by doing the following:
• Using an Ethernet cable, connect the computer to the WEB SERVER
CONNECTION port on the user interface.
• Open the Firefox Web browser.
• When prompted, provide the username and password (username: operator;
password: pass123).
• Enter the URL, http://192.168.10.100, into the address bar to access the HMI screens.
The user is now ready to navigate through the HMI screens.
NOTICE
The HMI has two levels of access credentials. The Level 1 access enables the user to
observe the system’s functions.The Level 2 access gives the user credentials to control
the system. Contact the system administrator if there are any issues with HMI accessibility.
Components and Controls

S&C Instruction Sheet 659-520 15
HMI Program The HMI program contains the following screens that, when selected, show the status of
the PureWave SMS-250 system and its different components. The screens are as follows:
PureWave SMS-250 System Oneline
The PureWave SMS-250 System Oneline tab displays an overview of the PureWave
SMS-250 system that includes the status of the island and ac and dc circuit breakers. If
the circuit breaker is red in color, this indicates that the circuit breaker is closed. If the
circuit breaker is green, this indicates that the circuit breaker is open.
The oneline screen also shows the inverter, utility, and battery information. The green
box to the left shows the alarm and communication status, system state, and current real
and reactive power output values. If the alarm types and/or communication items are
green, there are no alarms present and/or the communications are good. If the alarms
and/or communication items are red, an alarm is present and/or the communication
item(s) is not working. See Figure17.
Figure 17. PureWave SMS-250 System Oneline.
Components and Controls

16 S&C Instruction Sheet 659-520
Status
The Status tab displays the alarm, analog, and digital status for the PureWave
SMS-250 system. Figure 18 shows where the user can nd these screens by placing the
mouse over the Status tab to display the status drop-down menu items: Alarm Status,
Analogs, and Digitals.
Figure 19 is the Alarm Status menu screen, which displays the status of the alarms. In
addition, the user can place the mouse over the listed alarm to display a tool-tip pop-up
window that provides a description of what the alarm is and the suggested troubleshoot-
ing actions to clear it.
Figures 20 and 21 on page 17 show the Analogs and Digitals status menu screens,
respectively.
Figure 18. The Status drop down menu.
Figure 19. The Alarm and Status window.
Components and Controls

S&C Instruction Sheet 659-520 17
Figure 20. The Analog statuses window.
Figure 21. The Digital statuses window.
Components and Controls

18 S&C Instruction Sheet 659-520
Power Scheduling
The Power Scheduling tab enables the user to charge and discharge the PureWave
SMS-250 system at desired time durations and power levels during any time of the week.
As seen in Figure 22, the user can place the mouse over the Power Scheduling tab to
display the power scheduling drop-down menu items, Prole Setup and Week Setup.
Figures 23 and 24 (on page 19) show the screen of these menu items, respectively.
Figure 22. The Power Scheduling drop-down menu.
Figure 23. The Profile Setup window.
Components and Controls

S&C Instruction Sheet 659-520 19
Figure 24. The Week Schedule Setup window.
Command and Control
The Command and Control tab enables the user to command real or reactive power to
the load. It also allows the user to choose different modes of operation, such as peak
shaving, renewable smoothing, schedule follow, or islanding. See Figure 25.
Figure 25. The Command and Control window.
Components and Controls

20 S&C Instruction Sheet 659-520
SCADA Test
The SCADA Test tab enables the user to change SCADA inputs and outputs (analog
and digital) for a desired time to verify that the SCADA system is functioning properly.
As seen on Figure 26, the user can place the mouse over the SCADA Test tab to dis-
play the SCADA test drop-down menu items, AI (Analog Inputs), AO (Analog Outputs),
DI (Digital Inputs), and DO (Digital Outputs). Figures 27, and 28, 29 (on page 21), and
30 (on page 22) show the respective screens of these menu items.
Figure 26. The SCADA TEST drop-down menu.
Figure 27. The Analog Inputs window.
Components and Controls
