Sangean PR-D7 User manual

PR-D7
Version 1
GB

1
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with
the instructions.
Do not install near any heat sources such as radiators, heat reg-
isters, stoves or other apparatus (including ampliers) that pro-
duce heat.
Do not defect the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet –
USA version only.
Important Safety Instructions
1.
2.
3.
4.
5.
6.
7.
8.
9.

2
GB
Protect the power cord from being walked on or pinched par-
ticularly at plug, convenience receptacles, and the point where
they exit from the apparatus.
Only use attachments/accessories specified by the manufac-
turer.
Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate nor-
mally, or has been dropped.
To reduce the risk of re or electric shock, Do not expose this
appliance to Rain or Moisture.
The Shock Hazard Marking and Associated Graphical Symbol
is provided on the bottom panel of unit.
Apparatus shall not be exposed to dripping or splashing and no
objects lled with liquids, shall not be placed on the apparatus.
10.
11.
12.
13.
14.
15.
16.
17.

3

4
GB
Controls
Speaker
Band Selection
LCD Display
Charge LED indicator
Alarm by radio
Alarm by buzzer
Power/Auto shut off button
Volume Control
Tuning Control
Station Scan and Time Set
Station Presets
Battery Compartment
FM Telescopic Antenna
Headphone socket
DC In socket
2
1
3
5
7
15
14
13
12
11
10
9
4
6
8
LCD Display
Radio Band
Station Frequency
Sleep and Snooze
Clock Set
Clock
Buzzer Alarm
Radio Alarm
PM
Frequency unit
Preset Station
Battery Power Indicator
G
F
E
D
C
B
A
K
J
I
H

5
Battery operation using alkaline batteries
1. Remove the battery cover on the back of the unit by sliding the
cover in the direction of the arrow.
2. Insert 6 x AA ( UM3, LR6 ) alkaline batteries into the spaces in
the compartment. Take care to ensure the batteries are inserted
with correct polarity as shown inside the battery compartment.
3. Slide the battery switch to the Alkaline position and then replace
the battery cover.
Important:
when using alkaline batteries, the battery switch must be placed in
the alkaline position. Failure to do so could result in serious
damage to the batteries or radio.
Reduced power, distortion and a “ stuttering “ sound are all signs
that the batteries may need replacing.
If the radio is not to be used for any extended of time, it is recom-
mended that the batteries are removed from the radio.
We would suggest for economy that the radio is used via the sup-
plied AC power adaptor whenever possible, with battery operation
for occasional or stand-by use only. If extended listening using an-
ticipated, then the use of rechargeable batteries is suggested.

6
GB
Battery operation using rechargeable batteries
1. Remove the battery cover on the back of the unit by sliding the
cover in the direction of the arrow.
2. Insert 6 x rechargeable AA ( UM3 ) batteries into the spaces in
the compartment. Take care to ensure all batteries are inserted
with the correct polarity as shown inside the battery compartment.
The radio is designed to be used with Nickel Metal Hydrive
(NiMH) rechargeable batteries.
3. Slide the battery switch to the Rechargeable position and then
replace the battery cover.
4. Insert the supplied AC power adaptor into the DC IN socket on
the left hand side of the radio and plug the adaptor into a standard
13A mains socket outlet.
5. The charge light will flash indicating batteries are charging.
Batteries will be fully charged in around 7 hours while charge
LED will stop ashing.
Important:
when using rechargeable batteries, the battery switch must be
placed in the Rechargeable position. Batteries will only be charged
when the radio is switched off and connected to the AC adaptor.
6. Reduced power, distortion and a “ stuttering “ sound are all signs
that the batteries may need recharging. Charge LED will be
lighted when batteries have no power to turn on the radio.
7. If the radio is not to be used for any extended period of time, it is
suggested that the batteries are removed from the radio.

7
Note:
Please be aware that the rechargeable battery undergoes a time of
charging and discharging, the battery capacity will gradually decline
during over time with repeated use. The battery icon shows the re-
maining battery life on the LCD screen when the radio is turned on.
In addition, the calculation of charging time is based on the capac-
ity of the rechargeable battery and charging current power output
of the charger. The two examples in the below table are for your
reference only.
PR-D7(p6)
Size Model Capacity
(mAh)
Charging Current
(mA)
Charging Time
(hrs)
AA GP2700 2600 Approx. 350 Approx. 7.5
GP1800 1800 350 5

8
GB
Using the supplied AC power adaptor
The supplied AC adaptor is 12 Volts DC output 500 mA center pin
positive.
1. Insert the adaptor plug into the DC IN socket on the left hand side
of the radio.
2. Plug the adaptor into a standard 13A mains socket outlet. Whenever
the adaptor is plugged into the radio and switched on the mains,
the batteries are automatically disconnected.
If the adaptor is plugged into the radio but not the mains is not
switched on then the radio will run from the batteries if tted.
The AC adaptor should be disconnected from the mains supply and
the radio when not is use.
Setting the clock
1. Clock can be set either the radio is power on or off.
2. Display will show “ - : - - “ when the batteries are installed when
the radio is connected to the mains supply.
3. Press and hold the button for more than 2 seconds, display
will ash time set symbol and also the hour digit, followed
by a beep.
4. Press Tuning Up/Down to set required hour.
5. Press button again, the minute digits will ash.
6. Press Tuning Up/Down to set required minute.
7. Press button to complete time setting.

9
Operating the radio
This radio is equipped with three tuning methods – Scan tuning,
Manual tuning and Memory presets recall.
Scan tuning
1. Press the Power button to turn on the radio.
2. Select the required waveband by pressing the Band button. For
FM band fully extend and rotate telescopic aerial to get best
reception. For AM ( MW ) band, rotate the radio to get best signal.
3. Press and release Scan button ( long press Scan button more
than 2 seconds will activate time setting ), the radio will up search
and stop automatically when it nds a radio station with good signal.
Press the Scan button again to pick up the found station.
The radio will continue to search next available stations if you do
not press Scan button again when it nds a radio station.
4. Rotate the Volume Control to get required sound level.
5. To turn off the radio, press the Power button. Display will show
OFF.

10
GB
Manual tuning / station searching
1. Press the Power button to turn on the radio.
2. Select the required waveband by pressing the Band button.
Adjust the antenna as described above.
3. A single press on either the Tuning Up or Down button will change
the frequency in the following increments:
FM: 50 or 100 kHz
AM (MW): 9 or 10 kHz
4. Press and hold either Tuning Up or Down button until the frequency
in the display begins to change rapidly. Release the button.
Your radio will search the selected waveband and stop automatically
when it nds a station of sufcient signal.
5. Rotate the Volume control to get required sound level.
6. To turn off the radio, press the Power button.
Display will show off.
Storing stations in preset memories
There are 5 memory presets for each waveband.
1. Press the Power button to turn on the radio.
2. Tune to a required station using one of the methods previously
described.
3. Press and hold down the required preset until the radio beeps.
The preset number will appear in the display and the station will
be stored under chosen preset station.
4. Repeat this procedure for the remaining presets.
5. Stations stored in preset memories can be overwritten by following
above procedures.

11
Recalling stations from preset memories
1. Press the Power button to turn on the radio.
2. Select the required waveband.
3. Momentarily press the required preset button, the preset number
and station frequency will appear in the display.
Setting the radio alarm
When the radio alarm is selected, the radio will turn on and play the
chosen radio station at the chosen alarm time. The radio alarm will
continue for an hour unless turned off by pressing the Power but-
ton. Press the Power button whilst the alarm is activated will cancel
the alarm for 24 hours.
Note:
Radio alarm can be activated only until both radio alarm time and
radio alarmed station are set. Radio alarm will be automatically
switched to buzzer alarm when the radio is in low battery status or
the selected radio alarm station signal is too weak.

12
GB
1. The radio alarm can be set either radio is on or off.
2. Press and hold the radio alarm button for 2 seconds, the radio
will show radio alarm symbol followed by a beep.
3. Display Hour will flash, using Tuning up/Down button to select
the hour then press button again to conrm hour setting.
4 Press the Tuning up/down button to select the desired minute and
press button to conrm minute setting.
5. While radio alarm symbol is ashing, press the Tuning up/down to
select desired wake-up band and station, then press button
to conrm the selection. Radio alarm setting is now completed.
Active alarms are shown using alarm indicator on the display.
6. To cancel a sounding alarm, press the Standby button to cancel a
sounding alarm.
7. To cancel the radio alarm setting before the alarm sounds off,
press and hold the radio alarm button for 2 seconds (followed by
a beep).
Note:
If the signal of the set station cannot be found, the buzzer alarm
will be used instead.

13
Setting the HWS (Humane Wake System) buzzer
alarm
A beep will activate when selecting the HWS alarm. The alarm
beep will increase in volume every 15 seconds for one minute fol-
lowed by one minute silence before repeating the cycle.
The HWS alarm will sound for an hour until turning off by pressing
the Power button. Press the Power button whilst the alarm is acti-
vated will cancel the alarm for 24 hours.
1. The HWS buzzer alarm can be set wither radio is on or off.
2. Press and hold the HWS buzzer alarm button for 2 seconds,
the symbol will show on the display followed by a beep.
Now the display hour digit will ash.
3. Press Tuning Up/Down button to select required alarm hour, then
press button again, the minute digit will then ash.
4. Press Tuning Up/Down button to select required alarm minute,
then press button again to complete alarm setting. Display
will appear when buzzer alarm has been set.
5. To cancel a sounding alarm, press the Standby button to cancel
a sounding alarm.
6. To cancel the buzzer alarm setting before the alarm sounds off,
press and hold the buzzer alarm button for 2 seconds (followed
by a beep).

14
GB
Snooze function
1. Whilst the alarm is activated, press any buttons except the Power
button will activate the snooze function. The radio or HWS buzzer
alarm will be silenced with interval of 5 minutes.
2. The display will ash both the snooze symbol and the alarm
symbol. The snooze function can be repeatedly during the one
hour that the alarms are active.
Sleep function
The sleep timer will automatically switched off the radio after a pre-
set time has elapsed.
1. Press and continue to hold down the Power button for more than
2 seconds, followed by a beep, the display will cycle through the
available sleep timers in the order of 60-45-30-15-120-90-60.
Release the Power button when the required sleep timer appears
in the display. The symbol will appear in the display and
the radio will play the last station selected.
2. To cancel the sleep function, press the Power button.
The symbol will disappear and radio is off.
Display backlight
Press any buttons will illuminate the LCD display for approx. 10
seconds. During scanning stations and alarm activated will also au-
tomatically illuminate the display.

15
Software version
The software display cannot be altered and is just for your refer-
ence.
1. Turn off the radio.
2. Press the Band/step button for 2 seconds until the software version
number (e.g. P01) shown on the display.
Time format
3. Continue pressing the Band/step button until ’24H’ or ’12H’ shown
on the display followed by a beep.
4. Press the Tuning up/down button to choose the desired selection
and press the Band/ step button to conrm the setting.
Setting tuning step
Tuning steps in some countries are different from where you pur-
chase the radio. If you buy the radio in Europe and intend to use in
Northern America or some Southern American countries. You may
have to adjust tuning step so that the radio can work properly.
5. After the FM range setting is completed, the display will switch to
tuning step setting. Press the Tuning up/ down button to choose
the desired FM tuning step (50 kHz or 100 kHz) and press the
Band/step button to conrm the setting.
6. After the conrmation of FM tuning step, press the Tuning up/down
button to choose the desired AM tuning step (9kHz or10 kHz) and
press the Band/step button to conrm the setting.
Headphone socket
A 3.5 mm headphone socket located on the left hand of your radio
is provided for use with either headphones or an earpiece. Insert a
plug automatically mutes the internal speaker.

16
GB
Specications
Power Requirements
AC Power adaptor: DC 12V 500 mA center pin positive
Batteries: 6 x UM-3 ( AA size, LR6 )
Battery life:
Approx. 38 hours of listening for 4 hours a day at normal volume
using alkaline cells.
Frequency Coverage:
FM 87.50 – 108 MHz
MW 522 – 1710 kHz ( 9 kHz/step ) or
MW 520 – 1710 kHz ( 10 kHz/step )
Circuit Feature
Loudspeaker: 3 inches, 8 ohm
Output Power: 1.0 Watt using AC power adaptor
Headphone socket: 3.5 mm dia
Aerial System: Telescopic aerial
If at any time in the future you should need to dispose of this product please note
that: Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice. (Waste Electrical and Electronic Equipment Directive)
The company reserves the right to amend the specications without notice.
