Failure to use specified installa�on parts or hardware will void
the product warranty.
For this product to operate at op�mum efficiency ,a good
electrical connec�on to chassis ground must be made.
It is recommended that these instruc�ons be stored in a safe
place and referred to when performing maintenance or
reinstalla�on of this product.
Do not install and/or operate this safety product unless you
have read and understand the safety informa�on contained in
this manual.
It is the responsibility of the vehicle operator to ensure during
use that all features of this product work correctly. In use, the
vehicle operator should ensure the projec�on of the warning
signal is not blocked by vehicle component,people, vehicles,or
other obstruc�ons.
Specifica�ons
OPERATION INSTRUCTION
Proper installa�on of this product requires the
installer to have a good understanding of
automo�ve electronics,systems and procedures.
8001-140
• Voltage: 10-30V
• IP Ra�ng: IP67
• Max Power: Tail 1.4W, Stop 3W, DI 4W, REV 3W
• Moun�ng: Surface mount
• Func�ons: Tail / Stop/Direc�on indicator/Reverse/Reflex
This document provides all the necessary informa�on to
allow your product to be properly and safely installed. Before
beginning the installa�on and opera�on of your new product,
the installa�on technician and operator must read this
manual completely.
Important! This unit is a safety device, and it must be
connected to its own separate, fused power point to assure its
con�nued opera�on should any other electrical accessory fail.
T/ST/DI/REF T/ST/REV/REF T/ST/DI/REV/REF
Mul�func�onal LED Rear Light
140 49.5
35
45
Notes Before Installa�on:
Read all safety notes and moun�ng guidelines before installing the
product. Verify that all parts listed under “In the Box” are present and
complete. (Picture 1)
Verify that all power supply comply to the specified voltage limits for
the light.
Note: Screw must go through the rubber cushion fully to install.
Installa�on Instruc�on
Wiring
The wiring for this configura�on is as shown in Picture 2 below . All
wiring should be of 22AWG at least. (Picture 2)
The posi�ve line must be having a 3 amp fuse.
1.
2.
SEQUENCE
Black
Yellow
Red
White
Power nega�ve
Tail
Stop
Direc�on indicator
DESCRIPTION
Picture 2
Picture 1
T/ST/DI/REF
T/ST/REV/REF
T/ST/DI/REV/REF
Green
Yellow
Red
Black
Ground
White
SEQUENCE
Black
Yellow
Red
White
DESCRIPTION
SEQUENCE DESCRIPTION
Power nega�ve
Tail
Stop
Reverse
Black
Green
Red
Yellow
White
Power nega�ve
Tail
Stop
Direc�on indicator
Reverse
