Santerno SUNWAY M XS User manual

•15P0077B100 •
SUNWAY M XS
4600TL – 5000TL – 6000TL – 7500TL
SINGLE-PHASE SOLAR INVERTER
USER MANUAL
-Installation and Programming Instructions-
Issued on 15/02/2012
R.00.1
Applicable from Inverter Software Version 3.00
Applicable from Display Software Version 1.3.3
Elettronica Santerno S.p.A.
Strada Statale Selice, 47 - 40026 Imola (BO) Italy
Tel. [phone] -Fax [phone]
santerno.com [e-mail]
•This manual is integrant and essential to the product. Carefully read the instructions contained
herein as they provide important hints for use and maintenance safety.
•This device is to be used only for the purposes it has been designed to. Other uses should be
considered improper and dangerous. The manufacturer is not responsible for possible damages
caused by improper, erroneous and irrational uses.
•Elettronica Santerno is responsible for the device in its original setting.
•Any changes to the structure or operating cycle of the device must be performed or authorized by
the Engineering Department of Elettronica Santerno.
•Elettronica Santerno assumes no responsibility for the consequences resulting by the use of non-
original spare-parts.
•Elettronica Santerno reserves the right to make any technical changes to this manual and to the
device without prior notice. If printing errors or similar are detected, the corrections will be included
in the new releases of the manual.
•The information contained herein is the property of Elettronica Santerno and cannot be reproduced.
Elettronica Santerno enforces its rights on the drawings and catalogues according to the law.
•
All the names and marks mentioned in this manual are the proprietary of their respective owners.

SUNWAY M XS
4600 TL
5000 TL
6000 TL
7500 TL

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
3/148
0. TABLE OF CONTENTS
0. TABLE OF CONTENTS............................................................................................ 3
0.1. INDEX OF FIGURES ...............................................................................................5
0.2. INDEX OF TABLES..................................................................................................6
1. SCOPE OF THIS MANUAL...................................................................................... 8
2. GENERAL INFORMATION ...................................................................................... 8
2.1. DESCRIPTION OF THE PRODUCT ........................................................................8
2.2. BENEFITS ...............................................................................................................8
2.3. OPERATING PRINCIPLE ........................................................................................9
2.4. MAIN STANDARD INTEGRATED FUNCTIONS ....................................................10
2.5. ATTACHED DOCUMENTATION............................................................................10
3. BASIC INSTALLATION ...........................................................................................11
3.1. CAUTION STATEMENTS......................................................................................11
3.2. CHECKING THE PRODUCT ON DELIVERY.........................................................13
3.2.1. DATAPLATE................................................................................................................ 14
3.3. TRANSPORT AND HANDLING .............................................................................17
3.4. INSTALLATION......................................................................................................20
3.4.1. ENVIRONMENTAL REQUIREMENTS FOR THE EQUIPMENT STORAGE,
INSTALLATION AND OPERATION............................................................................. 20
3.4.2. WALL MOUNTING....................................................................................................... 21
3.4.3. ELECTRICAL CONNECTION...................................................................................... 24
3.4.4. REMOVING THE PROTECTIVE FILM FROM THE DISPLAY.................................... 29
3.4.5. FISCAL SEAL .............................................................................................................. 30
3.5. COMMISSIONING .................................................................................................30
3.5.1. STOPPING THE INVERTER....................................................................................... 32
3.6. QUICK CONFIGURATION.....................................................................................32
3.6.1. SETTING THE LANGUAGE........................................................................................ 33
3.6.2. SETTING THE COUNTRY .......................................................................................... 34
3.6.3. SETTING THE TIME ZONE......................................................................................... 35
3.6.4. SETTING THE DATE AND TIME ................................................................................ 37
3.6.5. SETTING THE CURRENCY........................................................................................ 38
3.6.6. SETTING THE FEED-IN TARIFF................................................................................ 39
3.6.7. RESETTING THE HISTORY DATA............................................................................. 40
3.6.8. RESETTING THE DISPLAY........................................................................................ 41
3.7. CONNECTIVITY ....................................................................................................42
3.7.1. WI-FI CONNECTIVITY ................................................................................................ 42
3.7.2. ACCESSING THE INVERTER DATA.......................................................................... 47
3.7.3. SUNWAYPORTAL.IT................................................................................................... 50
3.7.4. TECHNICAL SUPPORT .............................................................................................. 50

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
4/148
3.7.5. CONNECTIVITY TROUBLESHOOTING..................................................................... 51
3.8. DATALOGGING.....................................................................................................52
4. GRAPHIC INTERFACE MODULE...........................................................................54
4.1. NAVIGATING IN THE GRAPHIC INTERFACE ......................................................55
4.1.1. NAVIGATION BAR ...................................................................................................... 57
4.1.2. MENU AREA................................................................................................................ 57
4.1.3. STATUS BAR AREA.................................................................................................... 58
4.2. DISPLAY WINDOWS AND DATA ENTER WINDOWS ..........................................60
4.2.1. GRAPH WINDOW........................................................................................................ 61
4.2.2. ALPHANUMERIC KEYPAD WINDOW........................................................................ 62
4.2.3. LIST WINDOW............................................................................................................. 63
4.2.4. COMMAND EXECUTION WINDOW........................................................................... 64
4.3. DESCRIPTION OF THE MENUS...........................................................................64
4.3.1. ORGANISATION OF MEASURES AND PARAMETERS ........................................... 65
4.3.2. INFO MENU................................................................................................................. 67
4.3.3. GRAPH MENU............................................................................................................. 75
4.3.4. CONNECTIVITY MENU............................................................................................... 78
4.3.5. TOOLS MENU ............................................................................................................. 84
4.3.6. ALARMS MENU......................................................................................................... 107
4.3.7. STATUS MENU ......................................................................................................... 120
4.3.8. WI-FI STATUS MENU ............................................................................................... 124
5. ADVANCED INSTALLATION................................................................................125
5.1. SERIAL COMMUNICATIONS..............................................................................126
5.1.1. GENERAL.................................................................................................................. 126
5.1.2. DIRECT LINKING ...................................................................................................... 128
5.1.3. MULTIDROP CONNECTION..................................................................................... 128
5.1.4. CONNECTION........................................................................................................... 129
5.1.5. COMMUNICATIONS PROTOCOL............................................................................ 131
5.1.6. SPECIFICATIONS OF THE SERIAL COMMUNICATIONS...................................... 132
5.2. USB CONNECTION.............................................................................................132
5.3. MULTI-INVERTER PLANTS ................................................................................132
5.3.1. CONNECTION TO THE LV GRID............................................................................. 133
5.3.2. CONNECTION TO THE MV GRID............................................................................ 133
5.3.3. POWER BALANCE.................................................................................................... 133
5.3.4. POWER BALANCE CONFIGURATION .................................................................... 136
5.4. GRID INTERFACE PROTECTION AUTOTEST...................................................140
5.5. MAINTENANCE...................................................................................................142
6. SPECIFICATIONS.................................................................................................143
6.1. POWER LIMITING...............................................................................................144
6.2. DYNAMIC ADJUSTMENT OF THE MPPT RANGE..............................................146
7. INDEX....................................................................................................................147

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
5/148
0.1. Index of Figures
Figure 1: Block diagram of the SUNWAY M XS................................................................................................ 9
Figure 2: Packaging of the SUNWAY M XS.................................................................................................... 13
Figure 3: Dataplate of the SUNWAY M XS ..................................................................................................... 14
Figure 4: Label placed on the metal enclosure of the product ........................................................................ 16
Figure 5: Procedure for opening the package................................................................................................. 18
Figure 6: Package orientation symbol ............................................................................................................. 18
Figure 7: Procedure for removing the SUNWAY M XS from its packing......................................................... 19
Figure 8: SUNWAY M XS box with packing elements .................................................................................... 19
Figure 9: Minimum clearance (in mm) for proper ventilation of the SUNWAY M XS...................................... 21
Figure 10: Detail of the SUNWAY M XS bracket with the fixing screws ......................................................... 22
Figure 11: The SUNWAY M XS in upright position ......................................................................................... 22
Figure 12: Detail of the SUNWAY M XS with the side handles....................................................................... 23
Figure 13: Fastening the SUNWAY M XS to the wall-mounting bracket......................................................... 23
Figure 14: Removing the connector protective cover...................................................................................... 24
Figure 15: SUNWAY M XS connectors........................................................................................................... 25
Figure 16: Removing the protective film from the touchscreen display........................................................... 29
Figure 17: Slots for the application of the fiscal seal....................................................................................... 30
Figure 18: Example of the start menu ............................................................................................................. 31
Figure 19: Language setting page................................................................................................................... 33
Figure 20: Setting the dialogue language........................................................................................................ 33
Figure 21: Country setting page ...................................................................................................................... 34
Figure 22: Setting the Country......................................................................................................................... 35
Figure 23: Name of the Country displayed in the start menu.......................................................................... 35
Figure 24: Time zone setting page.................................................................................................................. 36
Figure 25: Setting the time zone...................................................................................................................... 36
Figure 26: Setting the date .............................................................................................................................. 37
Figure 27: Setting the date .............................................................................................................................. 38
Figure 28: Setting the currency ....................................................................................................................... 38
Figure 29: Setting the currency ....................................................................................................................... 39
Figure 30: Net metering setting page .............................................................................................................. 39
Figure 31: Setting the feed-in tariff .................................................................................................................. 40
Figure 32: History data resetting page ............................................................................................................ 40
Figure 33: History data resetting page ............................................................................................................ 41
Figure 34: Display resetting page.................................................................................................................... 41
Figure 35: Resetting the display...................................................................................................................... 42
Figure 36: Setting the AD HOC connectivity ................................................................................................... 43
Figure 37: Setting the ROUTER connectivity.................................................................................................. 44
Figure 38: Selecting the desired network........................................................................................................ 44
Figure 39: Setting the network access password............................................................................................ 45
Figure 40: IP address assignment mode......................................................................................................... 45
Figure 41: Setting the IP address.................................................................................................................... 46
Figure 42: Setting the subnet mask................................................................................................................. 46
Figure 43: Icon of the SUNWAY M XS application on the iPhone .................................................................. 49
Figure 44: Activating the Sunwayportal.it service............................................................................................ 50
Figure 45: Activating the Technical Support Service....................................................................................... 50
Figure 46: Displaying a measure graph........................................................................................................... 52
Figure 47: Graphic touchscreen display.......................................................................................................... 54
Figure 48: Touchscreen display – Start menu................................................................................................. 55
Figure 49: Example of a screen....................................................................................................................... 57
Figure 50: Screen of the Alarms menu............................................................................................................ 58
Figure 51: Screen of the Wi-Fi Status menu ................................................................................................... 58
Figure 52: Screen of the inverter Status menu................................................................................................ 59
Figure 53: Example of a measure graph......................................................................................................... 61
Figure 54: Example of alphanumeric keypad window..................................................................................... 62
Figure 55: Example of a list window................................................................................................................ 63
Figure 56: Example of a Run Command window............................................................................................ 64

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
6/148
Figure 57: Icons of the Menu Area in the start menu ...................................................................................... 64
Figure 58: Info menu tree ................................................................................................................................ 67
Figure 59: Graph menu.................................................................................................................................... 75
Figure 60: Selection page for the measure to be graphically displayed.......................................................... 75
Figure 61: Steps to take for the customization of the measures to be graphically displayed ......................... 76
Figure 62: Setting page of the Default View.................................................................................................... 76
Figure 63: Setting the Graph menu as the Default View................................................................................. 77
Figure 64: Connectivity menu tree................................................................................................................... 78
Figure 65: Tools menu tree ............................................................................................................................. 84
Figure 66: Tools menu, Customization submenu............................................................................................ 87
Figure 67: Tools menu, Advanced Configuration Submenu............................................................................ 90
Figure 68:Tools menu, Advanced Configuration > Inverter............................................................................. 91
Figure 69: Tools menu, Advanced Settings > Grid.......................................................................................... 94
Figure 70: Example of an alarm screen......................................................................................................... 107
Figure 71: ALARM RESET screen................................................................................................................ 119
Figure 72: Example of a status window......................................................................................................... 120
Figure 73: Example of a warning................................................................................................................... 122
Figure 74: Example of Wi-Fi Status window.................................................................................................. 124
Figure 75: Connection points of the SUNWAY M XS inverter – version with USB connector...................... 125
Figure 76: Connection points of the SUNWAY M XS inverter – version without USB connector ................. 126
Figure 77: Example of a SUNWAY M XS connected to a communication network...................................... 127
Figure 78: Multidrop network with RS485 connectors................................................................................... 128
Figure 79: Recommended Modbus wiring diagram for “2-wire” devices....................................................... 130
Figure 80: Wiring diagram for the external termination and polarization resistors........................................ 131
Figure 81: CAN connector............................................................................................................................. 133
Figure 82: CAN wiring diagram ..................................................................................................................... 134
Figure 83: Wiring diagram with Elettronica Santerno solution....................................................................... 135
Figure 84: Example of the start menu with Power Balance function activated ............................................. 136
Figure 85: Power Balance activation page.................................................................................................... 137
Figure 86: Activating the Power Balance function......................................................................................... 137
Figure 87: Phase setting page....................................................................................................................... 138
Figure 88: Inverter resetting page ................................................................................................................. 139
Figure 89: RUN status page.......................................................................................................................... 140
Figure 90: Example page of the Autotest function ........................................................................................ 142
0.2. Index of Tables
Table 1: Environmental requirements.............................................................................................................. 20
Table 2: Dimensioning of the MCCB and cable specifications........................................................................ 27
Table 3: Specifications of the PV field............................................................................................................. 28
Table 4: Logged variables ............................................................................................................................... 53
Table 5: Template of the measure descriptive tables...................................................................................... 66
Table 6: Template of the parameter descriptive tables................................................................................... 66
Table 7: Template of the variable descriptive tables....................................................................................... 67
Table 8: Info menu, Field submenu................................................................................................................. 68
Table 9: Info menu, Inverter submenu............................................................................................................. 70
Table 10: Info menu, Grid submenu................................................................................................................ 73
Table 11: Connectivity menu, Wi-Fi submenu................................................................................................. 79
Table 12: Connectivity menu, Services submenu ........................................................................................... 81
Table 13: Connectivity menu, Serial Communications submenu.................................................................... 82
Table 14: Tools menu, Quick Configuration submenu.................................................................................... 85
Table 15: Tools menu, Customization > Display submenu............................................................................. 87
Table 16: Tools menu, Customization submenu > Web page ........................................................................ 88
Table 17: Tools menu, Customization submenu > Access Level.................................................................... 89
Table 18: Tools menu, Advanced Configuration > Field submenu ................................................................. 90
Table 19: Tools menu, Advanced Configuration > Inverter > Advanced Parameters submenu..................... 91
Table 20: Tools menu, Advanced Configuration > Inverter > Power Balance ................................................ 92
Table 21: Tools menu, Advanced Configuration submenu > Inverter > Reactive Power ............................... 93
Table 22: Settings menu, Advanced Configuration > Grid > Grid Interface.................................................... 97

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
7/148
Table 23: Tools menu, Advanced Configuration > Grid > Grid Events ......................................................... 102
Table 24: Tools menu, Advanced Configuration > Grid > Energy................................................................. 103
Table 25: Tools menu, Commands submenu ............................................................................................... 104
Table 26: Alarms Menu.................................................................................................................................. 108
Table 27: Measures in the Alarm History ...................................................................................................... 109
Table 28: List of the SUNWAY M XS Alarms................................................................................................ 110
Table 29: Status messages for the SUNWAY M XS inverters...................................................................... 122
Table 30: DB9 Connector – RS485 Serial port ............................................................................................. 129
Table 31: Specifications of the RS485 serial port ......................................................................................... 129
Table 32: Specifications of RS485 serial port ............................................................................................... 132
Table 33: Recommended specifications for CAN connection cable ............................................................. 134
Table 34: Elettronica Santerno CAN wiring solutions.................................................................................... 135
Table 35: Protection trip times....................................................................................................................... 141
Table 36: Trip times....................................................................................................................................... 141
Table 37: Specifications of the SUNWAY M XS inverter............................................................................... 143

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
8/148
1. SCOPE OF THIS MANUAL
Elettronica Santerno is committed to update its User Manuals available for download from santerno.com with
the latest software version officially released. Please contact Elettronica Santerno if you require technical
documents related to previous software versions.
2. GENERAL INFORMATION
2.1. Description of the Product
The inverters of the SUNWAY M XS series are full-digital devices that convert DC energy produced by
photovoltaic (PV) panels – when radiated by sunlight – into AC energy, which is delivered to the grid.
A solar system for the self-generation of electric power is composed of two elements:
-the PV generator, consisting of a set of PV panels;
-the SUNWAY M XS inverter, delivering power supply from the PV generator to the grid.
Operation in parallel to the grid allows consumers to exploit the power supply produced directly by the
system when radiated by sunlight, and to deliver power which is not locally consumed to the grid, by
conferring it to the Grid Administrator. Therefore, residual power can be used by other consumers connected
to the grid, thus allowing the exploitation of the green energy produced by the PV generator, as well as the
constant operation of the same PV generator at its max ratings for optimum performance.
At night-time or when sunlight is weak, consumers can exploit the grid to power their loads.
All the parameter values related to the operation of the equipment may be easily programmed through the
touchscreen display and the parameter menus and submenus.
The inverters of the SUNWAY M XS series have been designed and manufactured in compliance with the
requirements of the “Low Voltage Directive” and the “Electromagnetic Compatibility Directive” and comply
with the prescriptions for grid connection applying to self-generation electric plants.
2.2. Benefits
−Wide range of supply voltages: 330 to 845 Vdc;
−Full-digital DC/AC conversion through 32-bit microprocessor obtained with PWM technique and
IGBT bridge ensuring high efficiency, high reliability and low distortion of the grid current;
−Transformerless topology;
−Die cast aluminium enclosure for maximum robustness, thermal performance and weight
optimization, suitable for outdoor installation (IP65-rated);
−DC disconnect switch ensuring maximum safety when maintaining the inverter (optional);
−Input filters and output filters for the suppression of conducted disturbance and radiated disturbance;
−Testing circuit to check the isolation resistance between the input and the earth;
−Operation in parallel to the grid, power factor=1;
−Fast connection through quick-coupling MC4 connectors for the connection of up to 4 strings;
−User interface based on graphic touchscreen display, 240x320 pixels, 262,000 colours for user-
friendly control of the inverter functionality;
−RS485 serial link with Modbus protocol for remote monitoring and programming (optional);
−Wi-Fi connectivity for the access to LANs and interaction via smartphones;
−Remote Technical Support if the inverter is connected to the Internet;
−Power supply from the grid in order to maintain operation even in the event of weak solar radiation.

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
9/148
2.3. Operating Principle
The power conversion system (inverter) is connected directly to the PV field. By using a high-switching
frequency IGBT bridge, the DC coming from the PV field is converted into AC at the grid frequency. The
transformerless architecture ensures maximum efficiency without affecting safety: the system monitoring
current leakage to earth is integrated into the inverter (integrated RCD) and the redundant grid coupling
devices ensure proper safety even in the event of single fault.
The EMC filters for the suppression of electromagnetic disturbance, the isolation sensor monitoring the
isolation to earth of the PV panels as well as the device controlling the operation in parallel to the grid are
integrated into the inverter. Therefore, no additional device external to the inverter is required.
Figure 1: Block diagram of the SUNWAY M XS
L
N
PE
+
-
+
+
+
-
-
-
PE

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
10/148
2.4. Main Standard Integrated Functions
This section contains a brief description of the equipment functions, to allow users who are not familiar with
the operation of PV fields to better understand this manual.
Device for constant isolation control:This is a device which constantly checks the isolation between the
earth and the polarities of the PV field and the earth. This function is obtained by measuring the isolation
resistance: the equipment is factory-set to detect isolation loss when the isolation resistance between polarity
+ or polarity – and the earth drops below 850 kΩ.
MPPT (Maximum Power Point Tracking): A sophisticated computing performed by the microprocessor
allows the inverter to detect the optimum operating point of the PV field, corresponding to the max power that
can be produced by the field depending on current solar radiation conditions.
Automatic Disconnecting Means:This device automatically disconnects the self-generation plant from the
grid when parallel operation is no longer possible. This typically occurs when the grid “opens” due to
maintenance needs or to safety circuit tripping. This function allows the inverter to instantly disconnect from
the grid, thus avoiding unwanted stand-alone operation of the plant and electric shock hazards for the
operators working on the grid. Trip times and levels are factory-set according to the applicable safety
standards. To modify the factory settings, please refer to the sections relating to the inverter programming.
The ratings of this safety function have been certified as prescribed by the Grid Administrator.
When required by the Grid Administrator, a simple self-test procedure performed via the touchscreen display
allows checking the efficiency of the grid disconnecting device.
2.5. Attached Documentation
The SUNWAY M XS inverter is supplied complete with the following documents:
−Multilingual “Quick Start Guide”, included as a hard copy and available for download from
santerno.com;
−“Wi-Fi Connection – Quick Start Guide”, included as a hard copy and available for download from
santerno.com;
−Multilingual “Certification and Grid Interface File”, available for download from santerno.com;
−“User Manual” (this document) available for download from santerno.com.

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
11/148
3. BASIC INSTALLATION
The basic installation consists in connecting the basic elements for system operation (grid and PV generator)
in a plant equipped with only one PV generator and one inverter.
Advanced configurations of the SUNWAY M XS inverter are covered in section 4. Fully read the basic
installation instructions before carrying out the advanced configurations.
3.1. Caution Statements
This section covers safety statements. The non-observance of the safety instructions below may cause
serious injury or death and equipment failure. Carefully read the instructions below before installing, starting
and operating the inverter.
Only competent personnel must carry out the equipment installation.
KEY TO SYMBOLS:
DANGER Indicates operating procedures that, if not correctly performed, may cause
serious injury or death due to electric shock.
CAUTION Indicates operating procedures that, if not
respected, may cause serious
equipment failure.
NOTE Indicates important information concerning the operation of the equipment.
SAFETY STATEMENTS TO FOLLOW WHEN INSTALLING AND OPERATING THE EQUIPMENT:
NOTE Always read this instruction manual
thoroughly before starting the
equipment.
DANGER Always earth the equipment
CAUTION The SUNWAY M XS must be powered by a photovoltaic field only, and
must be used exclusively for operation in parallel to the grid. Any other use
is to be considered as improper.

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
12/148
DANGER
CONNECTION TO THE PV FIELD – When exposed to solar radiation,
the photovoltaic panels produce DC
voltage that is applied to the
inverter.
ELECTRIC SHOCK HAZARD –Do not touch the electric parts of the
inverter and do not operate on the inverter when it is powered. Always wait
at least 20 minutes
from the instant when the DC and AC supply is
removed from the
inverter before carrying out any operation, because
electric energy is accumulated inside the inverter.
Do not operate on the equipment when it is powered.
Before operating on the electric connections, remove both DC and AC
voltage from the equipment and wait at least 20 minutes.
EXPLOSION AND FIRE –The risk of explosion and fire may exist if the
equipment is installed in presence of flammable fumes.
Do not install the
equipment where there is a risk of explosion and fire.
CAUTION
Do not connect supply voltages which exceed the rated voltage. If voltage
exceeding the rated value is applied, the internal circuits may be damaged.
In
the event of installation in presence of flammable and/or explosive
substances, please consult the relevant applicable standards.
In the event of an alarm, consult section 4.3.6 Alarms Menu.
Only restart
the equipment after the problem has been rectified.
Do not carry out isolation tests between the power terminals or between the
control terminals.
Make sure that the screws on the connection terminal boards have been
properly tightened.
Observe the environmental requirements for installation.
DANGER Certain parts of the product (side walls, heatsink and reactors)
may reach
temperatures as high as 100 °C.
Take all the necessary precautions to
avoid burns.
DANGER
Do not remove the inverter lid during installation. Removing the lid may
affect the IP rating of the inverter and may damage the internal parts.
Removing the lid voids the inverter warranty.

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
13/148
3.2. Checking the Product on Delivery
On receiving delivery of the equipment, make sure that the packaging shows no signs of damage. Check that
it complies with your order by referring to the dataplates described below. In the event of any damage,
please contact the relative insurance company or the supplier. If the delivery does not match your order,
contact the supplier immediately.
Figure 2: Packaging of the SUNWAY M XS
If the equipment is to be stored before installation, make sure that the ambient conditions in the warehouse
meet the necessary specifications (see section 3.4.1). The warranty covers manufacturing defects. The
manufacturer shall not be held liable for any damage which may have occurred during transport and
unpacking. Under no circumstances shall the manufacturer be held liable for damage or faults caused by
incorrect use, misuse, incorrect installation or inadequate temperature or humidity conditions or exposure to
corrosives, nor for faults caused by operation outside the rated values. Nor shall the manufacturer be held
liable for consequential or accidental damage.
NOTE For the terms of warranty, please refer to the warranty certificate supplied
with the product.

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
14/148
3.2.1. Dataplate
The product is described and identified by a dataplate placed on its side.
Figure 3: Dataplate of the SUNWAY M XS
The product code is made up of the following elements:
SUNWAY
M
XS
6000
TL
1
2
3
4
5
1 Product line:
SUNWAY inverter for the conversion of photovoltaic energy
2
Type of connection to the grid:
M = single-phase
3
Product family:
XS = new generation of Santerno inverters
4
Size:
4600 = rated output current: 20 A (4600 W rated power for 230 V grid)
5000 = rated output current: 22 A (5060 W rated power for 230 V grid)
6000 = rated output current: 26 A (5980 W rated power for 230 V grid)
7500 = rated output current: 33 A (7590 W rated power for 230 V grid)
5
Grid connection technology:
TL = transformerless

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
15/148
Purchase code of the product:
ZZ01770
PP
D
A
C
U
W
X
Y
Z
1
2
3
4
5
6
7
8
9
10
11
1 Fixed elements of the purchase code:
ZZ01770 for the SUNWAY M XS
2
Size (two figures):
46 = 4600TL (4600 W rated power for 230 V grid)
50 = 5000TL (5060 W rated power for 230 V grid)
60 = 6000TL (5980 W rated power for 230 V grid)
75 = 7500TL (7590 W rated power for 230 V grid)
3
Blank field
4 DC disconnect switch (optional):
0 = Not fitted
1 = Fitted
5 Unused field:
0 = Default
6
Colour:
0 = Carmine Red (RAL 3002)
1 = Night Blue (RAL 5022)
2 = Traffic Black (RAL 9017)
3 = Traffic White (RAL 9016)
7
Unused field:
0 = Default
8
RS485 (optional)
0 = Not fitted
1 or 3 = Fitted
9
Unused field:
0 = Default
10
Unused field:
0 = Default
11 Unused field:
0 = Default

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
16/148
Figure 4: Label placed on the metal enclosure of the product
The basic configuration of the SUNWAY M XS inverter comprises the following:
−N. 1 SUNWAY M XS inverter;
−N. 1 Wall-mounting bracket;
−N. 1 Quick Start Guide;
−N. 1 Authentication form;
−N. 1 Warranty certificate;
−N. 1 Kit for quick-coupling connectors.
The following options are available for the SUNWAY M XS:
Available options Component Configuration
DC Disconnect switch
Integrated disconnect switch for the disconnection of the
photovoltaic field from the inverter
Integrated into
the product
Ambient sensors
Output voltage sensors or output current sensors, single-ended
or differential sensors
Integrated into
the product
RS485 Link Connector for RS485 bus communications
Integrated into
the product
NOTE
Before commissioning the SUNWAY M XS, make sure that all the options
required are fitted. Contact the Customer Service of Elettronica Santerno
SpA for any clarifications.

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
17/148
3.3. Transport and Handling
State-of-the-art packing is provided when shipping the SUNWAY M XS. Handling should be done using a
transpallet or a lift truck with a carrying capacity of at least 100 kg, in order not to damage the product.
Get near the installation place, then unpack following the instructions provided below.
CAUTION
The whole original packing is to be kept
for the full duration of the
warranty period.
Based on the configuration of the product, the content of the packing may
have a maximum weight of 35 kg. The centre of gravity of the SUNWAY M
XS does not match with the geometrical centre of the packing. It is therefore
recommended that the packing be handled with extreme care by at least
three persons. Always use proper handling equipment.
The product packing contains a form stating the password required for
accessing the functioning data of the equipment.
For details about
accessing the inverter functioning data, see section 3.7.2.

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
18/148
1. Unpacking the product:
a. Cut with pincers the plastic straps that fix the package of the SUNWAY M XS to the pallet;
b. Cut with a cutter the adhesive tape closing the box on the side where the package
orientation symbol in Figure 6 is reproduced.
Figure 5: Procedure for opening the package
Figure 6: Package orientation symbol
2. Remove the SUNWAY M XS from its packing by lifting it from its sides. To avoid damaging the
packing, lift the product keeping it horizontal to the floor (see Figure 7).

INSTALLATION AND
PROGRAMMING INSTRUCTIONS SUNWAY M XS 7500TL
19/148
Figure 7: Procedure for removing the SUNWAY M XS from its packing
3. Put all the packing elements in the box and store it in a dry environment (see Figure 8).
Figure 8: SUNWAY M XS box with packing elements

SUNWAY M XS 7500TL INSTALLATION AND
PROGRAMMING INSTRUCTIONS
20/148
3.4. Installation
NOTE
Do not remove the inverter lid during installation. Removing the lid may
affect the IP rating of the inverter and may damage the internal parts.
Removing the lid voids the inverter warranty.
3.4.1. Environmental Requirements for the Equipment Storage, Installation
and Operation
Model 4600TL 5000TL 6000TL 7500TL
IP Rating (1) IP65 IP65 IP65 IP65
Mechanical dimensions w x h x d (mm) 414 x 703 x 260
Weight (kg) 31 31 35 35
Operating ambient temperature (°C) -25 ÷ +60
Rated operating temperature (°C) (2) -25 ÷ +45
Ambient temperature for storage and
transport (°C)
-25 ÷ +70
Maximum number of packed SUNWAY
M XS that can be stacked up
3
Installation site
Outdoor installation, degree of pollution 3 or better.
Do not install the equipment where it is
exposed to direct
sunlight or where it is exposed to
conductive dust, corrosive
gases, vibrations. Do not install in salty environments.
Altitude Up to 2000m a.s.l. For altitudes ranging from 2000m to 3000m
a.s.l. derate the output current by 1% every 100m. For higher
altitudes, please contact Elettronica Santerno.
Operating ambient humidity 0 % to 100 %, 1 g/m
3
to 25 g/m
3
, non-condensing and non-
freezing (class 3k3 according to EN 50178).
Storage ambient humidity 0 % to 100 %, 1 g/m
3
to 25 g/m
3
, non-condensing and non-
freezing (class 1k3 according to EN 50178).
Ambient humidity during transport Max. 100%. Up to 60g/m
3, condensation may appear when the
equipment is not running (class 2k3 according to EN 50178).
Operating and storage atmospheric
pressure
86 kPa to 106 kPa (class 3k3 and 1k4 according to EN 50178).
Atmospheric pressure during
transport
70 kPa to 106 kPa (class 2k3 according to EN 50178).
Table 1: Environmental requirements
(1)
(2)
The external fans are IP54 rated.
Beyond 45 °C, the SUNWAY M XS automatically decreases its output power in order to avoid
overheating.
CAUTION
Environmental conditions significantly affect the life-expectancy of the
product. Consequently, DO NOT install the product in a location which does
not meet the required specifications.
