Santos 54 Operating instructions

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20151 / 18 www.santos.fr
USER AND MAINTENANCE MANUAL
IMPORTANT: documents included in this manual to be kept:
•"CE" COMPLIANCE DECLARATION
•WARRANTY CERTIFICATE
Translation of the original version
Coffee grinders - Fruit juicers - Mixers - Blenders - Drinks dispensers - Planetary mixers
Cheese graters - Ice crushers - Mincers - Vegetable slicers – Dough mixer
Moulins à café - Presse-fruits - Mixers - Blenders - Distributeurs de boissons - Batteurs
mélangeurs - Pétrin - Râpes à fromage - Broyeurs à glaçons - Hache-viande - Coupe-légumes
MODELES DEPOSES FRANCE ET INTERNATIONAL
INTERNATIONALLY PATENTED MODELS
SANTOS
SAS:
140-150 AVENUE ROGER SALENGRO
69120 VAULX-EN-VELIN (LYON) - FRANCE
Phone [phone] - FAX [phone] -
E-Mail:[e-mail] www.santos.fr
DRINK MIXER N°54
!

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20152 / 18 www.santos.fr
CONTENTS
“CE” COMPLIANCE DECLARATION ........................................................................................3
IMPORTANT SAFEGUARDS ........................................................................................................4
IMPROPER USE .............................................................................................................................4
ELECTRICAL CONNECTION:.......................................................................................................5
USING FOR THE 1st TIME: ...........................................................................................................5
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE..........................................6
YOUR DRINK MIXER N°54 ...........................................................................................................7
USING THE APPLIANCE ...............................................................................................................7
START-UP: ......................................................................................................................................7
IDLE POSITION..............................................................................................................................8
CLEANING:.....................................................................................................................................8
STORAGE:.......................................................................................................................................8
MAINTENANCE...............................................................................................................................9
CHANGING THE MIXING HEADS AND DEFLECTOR:..............................................................9
Spare Parts: .....................................................................................................................................9
FAULT FINDING............................................................................................................................10
The appliance does not start.......................................................................................................10
The appliance stops suddenly after operating for a long time: the motor is very hot................10
The machine stops because of an overload:...............................................................................10
The motor runs all the time even without the cup on the cup stand ..........................................10
The motor is running but the speed variation is not working ....................................................10
TECHNICAL SPECIFICATIONS ................................................................................................11
REFERENCE TO STANDARDS....................................................................................................11
Wiring diagram 110-120V~ 50/60Hz ............................................................................................12
Wiring diagram 220-240V~ 50/60Hz ............................................................................................13
FIGURES .......................................................................................................................................14
WARRANTY CERTIFICATE .....................................................................................................18
APPLIANCE IDENTIFICATION PLATE ................................................................................18

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20153 / 18 www.santos.fr
“CE” COMPLIANCE DECLARATION
THE MANUFACTURER:
SANTOS SAS - 140-150, Av. Roger SALENGRO 69120 VAULX-EN-VELIN (LYON) FRANCE
declares that the appliance intended for the professional market described below:
Description: DRINK MIXER
Type number: 54, 54N, 54L
complies with:
•the statutory provisions defined in appendix 1 of the European "machines" directive n°2006/42/CE
and the national legislation transposing it
•the statutory provisions of the following European directives and regulations:
oN° 2006/95/CE (low voltage directive)
oN° 2004/108/CE (EMC directive)
oNo. 2002/95/CE (RoHS directive)
oNo. 2002/96/CE (WEEE directive)
oN° 1935/2004/CE (regulation) relating to materials and articles intended to come into contact
with foodstuffs
Harmonised European standards used to give presumption of conformity with the essential requirements of
the above-mentioned directives:
•NF EN ISO 12100 -1 and 2:2004: Safety of machinery - General principles for design
•NF EN 60204-1: 2006 : Safety of machinery - Electrical equipment of machines-General
requirements
•NF EN 1672-2: 2005, Food processing machinery – Basic concepts – Hygiene requirements
•NF EN 60335-1: 2003 : Household and similar electrical appliances. Safety.
•NF EN 60335-2-64 :2004 : Particular requirements for commercial electric kitchen machines
EMC relevant standards used:
•EN 55014-1 +A1+A2:2011, Electromagnetic compatibility, Immunity
•EN 55014-2+A1+A2:2008, Electromagnetic compatibility, Emission
•IEC 61000-3-2 +A1+A2 :2009, Electromagnetic compatibility, Limits for harmonic current
emissions
•IEC 61000-3-3 :2008, Electromagnetic compatibility, voltage fluctuations and flicker
•IEC 61000-4-2:2010, Electromagnetic compatibility, Electrostatic discharge immunity test
•IEC 61000-4-3 +A1:2010, Electromagnetic compatibility, Radiated, radio-frequency,
•electromagnetic field immunity test
•IEC 61000-4-4:2011, Electromagnetic compatibility, Electrical fast transient/burst
immunity test
•IEC 61000-4-5:2006, Electromagnetic compatibility, Surge immunity test
•IEC 61000-4-6:2008, Electromagnetic compatibility, Immunity to conducted disturbances,
induced by radio-frequency fields
•IEC 61000-4-11:2004, Electromagnetic compatibility, Voltage dips, short interruptions and
voltage variations immunity tests
Drawn up in VAULX-EN-VELIN on: 01/01/2015
Signatory’s position: CHIEF EXECUTIVE OFFICER
Signatory’s name: Aurélien FOUQUET
Signature:

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20154 / 18 www.santos.fr
IMPORTANT SAFEGUARDS
When using, cleaning or maintaining the machine, always follow these instructions:
Read all instructions
IMPROPER USE
1. This appliance is not meant to contain solids such as ice cubes, frozen
foodstuffs or products, dry products that would jam the motor or damage the
mixing heads.
The following solids are accepted in a quantity of less than 20% with 80% liquid:
•Crushed ice
•Powder (soluble coffee, milk,...)
•Balls of soft ice cream.
The mixing heads are not designed to grind, crush or cut but only to mix or emulsify
liquid or smooth foodstuffs or products.
2. Never add products or foodstuffs to the cup during preparation or operation.
3. Never exceed the maximum filling level of the cup which may cause
products or foodstuffs to overflow during preparation.
Maximum capacity of cup: 0.5 liter.
4. Place the appliance on a smooth, non-sloped surface to ensure it is stable and for
the suction feet (14) to adhere properly.
5. You are not advised to operate the appliance with an empty cup.
6. The appliance should neither be cleaned in a jet of water nor with a high pressure
spray.
7. For electrocution risk protection reasons, never plunge the base into water or any
other liquid.
8. Unplug the appliance before carrying out any work on it: cleaning, maintenance or
repair.
9. The use of spare parts other than certified SANTOS original parts is prohibited.
10.Use the appliance if the power cord is damaged. It must be replaced by a special
assembly available from an approved SANTOS dealer or from SANTOS itself.
11.Connect several appliances to the same power socket.
12.Use the appliance outdoors.
13.Never place the appliance close to or on a source of heat.
14.This appliance is a professional machine designed exclusively for professional use.
It is not designed for household use.
15.This appliance is not designed for use by people (including children) whose physical,
sensorial or mental capacities are impaired or by people with no experience or
knowledge, unless they have been supervised or given training in the use of the
Note: You will find it easier to understand the next few paragraphs if you refer to
the diagrams at the end of this manual.
!

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20155 / 18 www.santos.fr
appliance beforehand by a person responsible for their safety.
Supervise children to ensure they do not play with the appliance.
ELECTRICAL CONNECTION:
The appliance is available in with a choice of two voltages for the power supply
•220-240V 50/60 Hz single phase
•110-120V 50/60 Hz single phase
Line protection: the appliance should be connected to a standard 2-pole + earth electric
socket. The installation should be fitted with an RCD and a fuse rated at 16A. or the
relevant value according to local electrical codes, taking into account the unit rated
current. The appliance must be earthed
CARE:
•Before connecting the machine, check that the mains electrical voltage is the
same as the voltage for your appliance. Its value is shown:
either on the identification plate under the machine.
or on the identification plate on the last page of this manual.
•If the power cable (10) is damaged, it should be replaced by a special
assembly available from approved SANTOS dealers or from SANTOS.
USING FOR THE 1st TIME:
Carefully clean the parts in contact with the food (Fig. A, Fig. B and Fig. C).
•Wash the two cups (stainless steel (1) and plastic (2)) with standard washing up
liquid or in the dishwasher.
•Wash the flexible mixing head (4) supplied separately.
•To wash the mixing head (3) and deflector (5) which are assembled on the
appliance, take them down as follows:
-Hold the deflector (5) and unscrew the mixing head (3).
•Wash the mixing head (3) and deflector (5) with standard washing up liquid or in the
dishwasher.
•Put the deflector (5) and mixing head (3) back after washing as follows:
-Bring the two flat surfaces of the deflector (5) in register with those of the motor
shaft (6).
-Screw on the mixing head (3).
!

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20156 / 18 www.santos.fr
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE
This equipment is marked with the selective sorting symbol relating to
wastes from electrical and electronic equipment. It signifies that this product
should be taken over by a selective collection system conforming to the
Guideline 2002/96/EC (WEEE) – part Professional Equipment – so that it
can be either recycled or dismantled in order to reduce any impact on the
environment.
For more information, please contact your Retailer or the SANTOS.
For eliminating or recycling components of equipment, please contact a specialized
company or contact SANTOS.
The electronic products not undergoing a selective sorting are potentially dangerous for
the environment.
The damaging materials should be eliminated or recycled according to the regulations in
force.

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20157 / 18 www.santos.fr
YOUR DRINK MIXER N°54
•The drink mixer N° 54 is designed especially for bars, cafés, hotels, restaurants,
cocktail bars, canteens, stores selling fruit juices, cake stores, ice cream parlors.…
•The drink mixer N° 54 is designed to mix and emulsify different foodstuffs in liquid
and smooth form.
•It is ideal for making:
odrinks (fruit, vegetable cocktails, punches, syrups,...)
odrinks with ice cream or crushed ice,….
oIce creams, milk shakes, smoothies,…
•The appliance comprises a motor unit fixed to a cast aluminum column.
2 cups are supplied to hold the products: one stainless steel cup and one see-through
plastic cup. The top part of the cups has been designed for quick fitting on the cup stand
and start up of the appliance.
USING THE APPLIANCE
START-UP:
1. Plug in the appliance.
2. Turn the motor speed knob (7) anti-clockwise to the low speed position (small mark
on the knob in front of the operator).
3. Put a small amount of liquid (approximately 0.25 liter) into the bottom of the
stainless steel (1) or plastic cup (2).
4. Place the stainless steel (1) or plastic cup (2) on the cup stand (8) (operating
position) (Fig. A) and the appliance starts up immediately at low speed.
5. Turn the motor speed knob (7) clockwise to high speed (big mark on the knob in
front of the operator).
6. Go back to low speed by turning the motor speed knob (7) anti-clockwise to the low
speed position (small mark on the knob in front of the operator).
-You have now tested the whole speed range.
7. Take the cup off the cup stand and the appliance will stop.
8. Repeat operations 4, 5, 6, and 7 with the second cup, if required.
TAKE NOTE:
1. For the first few operations, you are advised to start at low speed to
prevent splashing (cup too full).
2. You are not advised to operate the appliance with no liquid inside the
cup.

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20158 / 18 www.santos.fr
IDLE POSITION
Placing the cup (1) or (2) in the second position (lower position) on the cup stand (8) puts
it into the idle or stop position (Fig. E)
NOTE:
Emulsions or mixes are usually obtained in under 1 minute.
TAKE NOTE:
1. The appliance stops when the cup (1) or (2) is removed from its stand
(8), however, a rotation movement does persist for a few seconds due
to motor inertia: do not allow the cup to be off center so as not to
damage the mixing head (3) or (4) and deflector (5).
2. Wait for the motor to stop before removing the cup completely and
avoid splashes.
CLEANING:
IMPORTANT:
•When cleaning, stop the appliance and unplug the appliance’s power cord
(9).
•The appliance must not be cleaned with a water jet, pressurized water or
immersed.
•If, during preparation or incorrect handling, food or splashes have got into
the cup positioning area or on the cup stand (8), you are advised to clean
this area quickly with clean water and check the cup presence detection
finger (10) is working properly.
You are advised to clean the appliance as soon as you have finished using it.
It will be easier to clean if you do not wait until food has dried in the cup, on the mixing
head or deflector.
All these parts:
•stainless steel cup (1)
•plastic cup (2)
•mixing head (3)
•mixing head (4)
•deflector (5)
must be cleaned with standard washing up liquid or in the dishwasher.
Do not use abrasive products that could damage the parts.
STORAGE:
The stainless steel (1) and plastic cups (2) can be stacked for storage purposes.

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 20159 / 18 www.santos.fr
MAINTENANCE
Before any servicing of the appliance, it is essential to unplug the appliance from the
mains supply (9).
This machine requires no particular maintenance because the bearings are lubricated for
life.
If any intervention is necessary to replace parts subject to wear, such as the mixing heads,
the deflector, electrical or other components, please refer to the parts list (see the
exploded view at the end of this manual).
CHANGING THE MIXING HEADS AND DEFLECTOR:
Taking down the mixing head (3) or (4) and deflector (5)(Fig. A, Fig. B and Fig. C):
•Unscrew the mixing head (3) or (4) by hand holding the deflector (5) to
stop the motor shaft (6) from turning.
Mounting the deflector (5) and mixing head (3) or (4)(Fig. A, Fig. B and Fig. C):
•Put back the deflector (5) making the two flat surfaces register with the two
flat surfaces of the motor shaft (6). Screw on the mixing head (3) or (4) by
hand.
Spare Parts:
IMPORTANT:Use of spare parts other than certified original SANTOS
parts is prohibited
Please quote the following when ordering spare parts (see references in the exploded
view at the end of this manual):
•type
•appliance’s serial number
•electrical specifications given underneath the appliance.
!

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201510 / 18 www.santos.fr
FAULT FINDING
Identifying the cause of appliance stoppage precisely.
The appliance does not start
Check:
•the mains supply, the condition of the supply cord (9).
•the cup (1) or (2) is fitted properly on the cup stand (8). Check in particular that the
top part of the cup is not damaged.
•the cleanness of the cup (1) or (2) positioning area.
The appliance stops suddenly after operating for a long time: the motor is very
hot
The motor is protected by an integral thermal protection. In the event of overheating, the
motor stops automatically.
•Switch off the appliance (unplug the power supply cord (9)).
•Wait for the motor to cool down (20 to 45 minutes).
•Plug back in and resume work by placing the cup (1) or (2) on the cup stand (8).
The machine stops because of an overload:
If the motor is jammed (foreign body, object or hard foodstuffs blocking the mixing head),
the appliance stops automatically.
•Switch off the appliance (unplug the power supply cord (9)).
•Take the stainless steel (1) or plastic cup (2) off the cup stand (8) and place it on a
worktop.
•Remove the objects or hard bits blocking the mixing head.
•Reset the thermal protection device (10) underneath the appliance manually (Fig. F).
•Put the products or foodstuffs to be processed back in the cup.
•Plug back in and resume work by placing the cup (1) or (2) on the cup stand (8).
The motor runs all the time even without the cup on the cup stand
Check:
•the operation of the cup detection finger (10) in the cup stand (8).
•the cleanness of the cup presence detection finger area and clean this area if
required (Fig. D).
The motor is running but the speed variation is not working
Check:
•go through the whole speed range of the motor with the motor speed knob (7) (Fig.
A) several times.

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201511 / 18 www.santos.fr
NOTE:
If one of these problems persists, disconnect the electric power supply (unplug the power
supply cord (9)) and call on someone from the maintenance department or contact an
approved SANTOS dealer.
TECHNICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS (1)
Model 54
Single phase
Supply voltage
.(V)
220-240 100-120
Frequency
(Hz)
50/60 50/60
Motor: Rating
Power input
(W)
120 120
Speed: Minimum
Maximum
(rpm)
(rpm)
8 000 8 000
16 000 16 000
Cup capacity
(L)
0.560
Dimensions: Height
(mm)
530
Width
(mm)
182
Depth
(mm)
186
Weight: Net weight
(kg)
6
Weight including packing
(kg)
7
Noise: (2)
(dBA)
63
(1) These ratings are provided as a rough guide. The exact electrical specifications can be found
on the rating plate.
(2) Noise level measured with sound pressure appliance in operation 1 m from its centerline in
accordance with standard EN 31201.
REFERENCE TO STANDARDS
•CE (Europe)
•UL (USA) and cUL (Canada).
•NSF (USA).

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201512 / 18 www.santos.fr
Wiring diagram 110-120V~ 50/60Hz
Black
Yellow or white
Black
Red
AMPEREMETRIC
THERMAL
PROTECTOR
TACHYMETRIC
ELEMENT
POTENTIOMETER
ELECTRONIC
BOARD
Yellow or white
Black
Red
Yellow or white
Black
Red
Brown
Blue
Brown
Blue
Black
Black
L
N
M
M
~
Brown
Blue
M
CUP
PRESENCE
SWITCH
T
Green/yellow

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201513 / 18 www.santos.fr
Wiring diagram 220-240V~ 50/60Hz
Blue
Brown
Brown
Black
White
Yellow or white
Black
Red
AMPEREMETRIC
THERMAL
PROECTOR
TACHYMETRIC
ELEMENT
POTENTIOMETER
ELECTRONIC
BOARD
Yellow or white
Black
Red
Yellow or white
Jaune
Black
Red
Brown
Blue
Black
White
Red
Red
L
N
M
M
~
Brown
Blue
M
CUP
PRESENCE
SWITCH
T
Green/Yellow
PARASITE
SUPPRESSOR
FILTER

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201514 / 18 www.santos.fr
FIGURES
1
2
4
3
5
7
FIG A
FIG B
11
- SLOWER
+ FASTER
SCREW
UNSCREW
11
8
12
7
12

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201515 / 18 www.santos.fr
11
8
10
FIG C
FIG D
12
8
6
11
7

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201516 / 18 www.santos.fr
11
8
1
FIG E
2

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201517 / 18 www.santos.fr
ITEM
Description
1
Stainless steel cup
2
Plastic cup
3
Mixing head
4
Flexible mixing head
5
Deflector
6
Motor shaft
7
Adjustment knob
8
Cup stand
9
Power supply cord
10
Cup detection finger
11
Base column
12
Motor unit
13
Rubber foot
14
Suction foot
15
Overload protector
9
13
14
11
15
13
FIG F

SANTOS: Instruction and maintenance manual
98154 US 3.0 - 01 201518 / 18 www.santos.fr
WARRANTY CERTIFICATE
WARRANTY
Since the 01.01.95, all our appliances comply with CE and possess the CE label. Our guarantee is
of 24 months from the manufacturing date mentioned on the descriptive plate, except concerning
the asynchronous motors (consisting of a rotor and a stator) which are warranted for 5 years from
their manufacturing date. Warranty is strictly limited to the free replacement of any part of origin
recognized by us as defective due to a defect or building default and identified as belonging to the
concerned appliance. Warranty does not apply to damages resulting from installation or use non-
complying with our appliance data sheet (user’s manual) or in case of an evident lack of
maintenance or disrespect of elementary security electric rules. It does not apply in case of regular
wear and tear. Any replacement of parts under warranty will be realized after return of the
defective part in our workshops, postage paid, supported by a copy of a conformity statement on
which appears the serial number of the appliance. Every appliance is equipped with a descriptive
plate conforming to the EC recommendations and of which a duplicate exists in the conformity
statement (serial number, manufacturing date, electrical characteristics …). In case of serious
damage judged repairable only in our workshops, and after prior consent from our departments,
any appliance under guarantee is sent by the Distributor, carriage paid. In case of repairs or
reconditioning of appliances not under guarantee, the round trip transport is payable by the
distributor. The parts and workforce are invoiced at the current rate. A preliminary estimate can be
supplied.
Coffee grinder not using SANTOS original burrs are not taken under guarantee. The warranty
conditions, repairs, reconditioning, of the espresso coffee grinder are the object of a specific note.
Our guarantee does not extend to the payment of penalties, the repair of direct or indirect
damages and notably to any loss of income resulting from the nonconformity or the defectiveness
of products, SANTOS's global responsibility being limited to the sale price of the delivered product
and to the possible repair of the defective products.
In case of revelation of an imperfection during the warranty period, the Distributor has to, unless a
different written agreement of SANTOS, indicate to his customer to stop any use of the defective
product. Such a use would release SANTOS of any responsibility.
APPLIANCE IDENTIFICATION PLATE
SPECIMEN
For all documents not supplied with
the appliance.
Printed, Faxed and Downloaded
