Sanyo VCC-ZM400P User manual
Pickup device: 1/4”, Effective pixels: 752 (H) x 582 (V)
Horizontal resolution: Over 520 TV lines
Lens: x22 zoom lens, f=3.6-79.2 mm (F1.6-3.8),
Electronic zoom and gearing, Zoom speed setting possible
Electronic zoom: 16 power (combined with optic zoom gives 352 power max)
Max zoom magnification setting possible, Vertical resolution ON/OFF setting
Autofocus: AUTO/MANUAL, AF area setting possible (3 step)
Iris control: AUTO/MANUAL, 1/2 EV steps
Synchronization method: Internal synchronization/Line lock, V phase adjustment possible
Lowest image illumination: 1.2 lx (F 1.6, AGC gain at maximum, COLOR mode)
0.06 lx (F 1.6, B/W mode)
0.04 lx (F1.6, x32 electronic sensitivity increased, COLOUR mode)
0.002 lx (F 1.6, x32 SENSE UP, B/W mode)
S/N: Over 48dB
Backlight compensation: Multi-spot evaluative metering
5 spot centerweighted average metering, 48 multi-spot metering
Day/Night: AUTO/COLOR/B/W settings available
Electric shutter: •Fast shutter speed mode (SHORT);
1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000
•Slow shutter speed mode (LONG); x1, x2, x4, x8, x16, x32
Electronic sensitivity boosting: AUTO/OFF, works with auto iris, Up to x32 max setting possible
White balance: ATW/AWC/MWB, AGC gain: OFF/-6/±0/+6/+9/+12/+15 dB
Motion detector: ON/OFF, ON allows setting of detection patterns on a 48 zone screen for
6 motion settings (size, masking, sensitivity, zoom, interval, alarm sign)
Privacy masking: ON/OFF, max of 4 masked locations, Password lock possible
Alarm input/output (back panel control terminals): Alarm input: 1 (for external alarm switch)
Alarm output: 1 (for sending a signal to the system controller or an alarm
detection device such as a buzzer)
Mirror image effect: Horizontally (H), vertically (V), horizontally and vertically (HV)
Camera ID: ON/OFF, 16 characters
View settings: 9 (0-8) screen files can be established, and each file can set
7 capturing characteristics such as iris
Communications: Coaxial control, RS-485
Operational temperature/humidity: -10 - 50 °C/below 90 % RH
Power source: 24 V AC, 50 Hz/12-15 V DC, Power consumption: 4.5 W, Weight: 380 g
SERVICE MANUAL
COLOUR CCD Camera VCC-ZM400P
(Product Code : 117 118 00)
(Europe)
FILE NO.
REFERENCE No. SM5310469
L5AD2/XE
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
PRODUCT SAFETY NOTICE
CONTENTS
1. DISASSEMBLY AND
BOARD LOCATION ....................... 2
2. ADJUSTMENT ............................... 3
3. PARTS LIST ................................... 6
CIRCUIT DIAGRAM &
PRINTED WIRING BOARDS ........... C1
SPECIFICATIONS
– 2 –
1. DISASSEMBLY AND BOARD LOCATION
1. Three screws 2 x 4
2. Cabinet back
3. Three screws 3 x 4
4. Cover top
5. Two screws 3 x 6
6. Cover mounting
7. Two screws 3 x 4
8. Cover bottom
9. Cabinet front
10. Two screws 2 x 3
11. Frame
12. Screw 2 x 3
13. Chassis front
14. Screw 2 x 3
15. Connector
16. Connector
17. FPC
18. Screw 2 x 3
19. Connector
20. CA4 board
21. Two screws 2 x 3
22. Screw 3 x 6
23. Screw 3 x 6
24. Screw 3 x 10
25. Terminal
26. CA5 board
27. Two screws 2 x 3
28. Two FPCs
29. Connector
30. CA2 board
31. Screw 2 x 3
32. Connector
CA1 board
CA3 board
CA2 board
CA4 board
CA5 board
33. CA3 board
34. Three screws 2 x 5
35. Chassis
36. Two screws 1.7 x 5
37. Screw 2 x 3
38. CA1 board
–3 –
2-3. TABLE FOR SERVICING TOOLS
Note: Adjustment commander relay jig (VHJ-0142) is for 100 V.
2-3-1. Computer screen during adjustment
2-4. Iris Adjustment
Adjustment location: VR202, VR203 (CA-2)
Measuring location: TP221 (CA-2)
Measuring equipment: Digital multi meter
Subject: No designation
Adjusting method:
1. Click the adjustment software installed from the personal
computer, and the adjustment window will be displayed.
2. Click the START.
3. Select the COLOR in the adjustment display.
4. Select the IRIS 1V in the adjustment display.
5. Turn the VR203 so that the voltage of TP221 is 1.0 V ±0.1 V.
6. Select the IRIS 3V in the adjustment display.
7. Turn the VR202 so that the voltage of TP221 is 3.0 V ±0.1 V.
2. ADJUSTMENT
2-1. ADJUSTMENT CONDITION
1. Use the 5,100K viewer for the subject.
2. Set the trigger signal of oscilloscope to VIDEO OUT, and
apply H sync unless specified.
3. Connect the video output to a video monitor with an input
impedance of 75 Ω.
4. Ground test point is TP200 (CA-2).
5. Set the distance from the subject to about 60 cm and adjust
the camera position so that the picture frame size becomes
as shown below when performing the adjustment with the
gray scale chart (ITE gray scale chart/ γ = 0.45).
2-2. PREPARATION
1. Install the adjustment software (VHJ-0150) in a computer
running the Windows operating system.
2. Use the adjustment commander cable (VHJ-0143) to con-
nect the adjustment commander relay jig (VHJ-0142) and
CN204.
3. Use the adjustment commander relay jig (VHJ-0142) to con-
nect CN204 of side B in the CA-2 board and serial port (RS-
232C) of computer, and then turn on the power for the com-
puter, camera, and the jig.
VIDEO OUTPUT
Ref. No. Name Part code
J-1
J-2
J-3
VJ8-0007
VJ8-0009
Color viewer
Gray scale chart
Color bar chart
VJ8-0010
J-4
J-5
J-6
VHJ-0142
VHJ-0150
Adjustment commander relay jig
Calibration software
L: Distance from CS mount to pattern (mm)
H: Pattern height (mm)
f : Lens focal length (standard 12 mm)
h: Height (4.8 mm) of CCD imaging surface
Note : The video monitor should be an under-scan TV.
L = x f –12.5 mm
(H + h)2
H x h
L
CS mount surface
CCD camera
5,100 K viewer
H
VHJ-0139
Privacy masking chart
J-7 VHJ-0143
Adjustment commander cable
AGC
R GAIN
R HUE
B GAIN
B HUE
WDD
L5AD Series Adjustment x
0
0
0
0
0
AUTO
ROM CLEAR
START END CLOSE
TRIG INT L-L
IRIS 1V
IRIS 3V
LENS T AUTO
TELE
LENS X
LENS Y
0
0
TELE
POS1
POS2
R
B
STATUS
DAY/NIGHT COLOR B/W AUTO
–4 –
2-5. Lens Tracking Adjustment
Adjustment location:
Measuring location:
Measuring equipment: Monitor display, siemens star chart
Subject: No designation
Adjusting method:
1. Select the LENS T in the adjustment display.
2. Set the siemens star chart at the position of 940 mm ±10
mm so that it becomes center of the screen.
3. Click the AUTO button.
4.When AUTO ADJ. NG display, carry out the adjustment again.
2-6. Privacy Masking Compensation
Adjustment location:
Measuring location:
Measuring equipment: Monitor display, privacy masking chart
Subject: No designation
Adjusting method:
1. Set the privacy masking chart at the position of 940 mm ±
10 mm from the lens.
2. Select the TELE under the LENS T in the adjustment dis-
play. Adjust the field angle so that the center of the privacy
masking chart becomes center of the screen.
3. Operate the LENS X and LENS Y in the adjustment display.
Adjust so that masking is center of the screen.
4. Select the TELE under the LENS Y in the adjustment dis-
play. Confirm that masking is within the limit of the screen.
When the masking is out of the frame, carry out adjustment
again.
2-7. Frequency Adjustment (INT)
Adjustment location: CT252, CT202 (CA-2)
Measuring location: TP203, TP202 (CA-2)
Measuring equipment: Digital multi meter, Frequency counter
Subject: No designation
Adjusting method:
1. Click the adjustment software installed from the personal
computer, and the adjustment window will be displayed.
2. Click the START.
3. Select the TRIG, and select the INT by the ← → key of a
keyboard.
4. Adjust with TP203 to 17734475 Hz ±50 Hz.
5. Adjust with CT202 so that the voltage of TP202 is 7.0 V ±
0.5 V.
2-8. Frequency Adjustment (L-L)
Adjustment location: CT201 (CA-2)
Measuring location: TP201 (CA-2)
Measuring equipment: Digital multi meter
Subject: No designation
Adjusting method:
1. Select the TRIG, and select the L-L by the ← → key of a
keyboard.
2. Adjust with CT201 so that the voltage of TP201 is 7.0 V ±
0.5 V.
3. Select the INT by the ← → key of a keyboard.
2-9. AGC Level Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope
Subject: Gray scale chart
Adjusting method:
1. Select the POS1 in the adjustment display, and project the
gray scale at the field angle of below figure.
2. Select the AGC in the adjustment display.
3. Use the computer’s mouse to adjust the AGC in the adjust-
ment window so that the video out terminal is 750 ±10 mVp-p.
2-10. Hue and Chroma Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope, vectorscope
Subject: Color bar chart
1. Select POS2 in the adjustment display, and project the color
bar chart at the field angle of below figure.
2. Select the R and B in the adjustment display. Adjust by oper-
ating ← → key of a keyboard so that the white luminescent
spot is the center of the vectorscope.
3. Select the R GAIN, R HUE, B GAIN and B HUE in the ad-
justment display. Adjust by operating level scroll bar so that
the red and yellow luminescent spots are the size and po-
sition which are designated in the vectorscope.
4. Select the ROM CLEAR in the adjustment display.
siemens star chart
lens
VIDEO OUTPUT
10
35 µsec
940 mm ±10 mm
camera
viewer
–5 –
2-11. CCD White Point Defect Detect Adjustment
Measuring location: VIDEO OUT
Measuring equipment: Monitor display
Adjustment method:
1. Shield light with a lens cap to provide dark condition.
2. Set the camera mode, and click the “AUTO”at the WDD on
the adjustment software.
3. After completing this adjustment, it comfirms that white point
can not be seen on the monitor display.
4. Click the End button.
CT201
TP221
CA-2 board (Side B)
VR203
TP200
CT252
VR202
TP201
TP203
CT202
TP202
45 µsec
R
YL
MG
Cy
G
B
75%
100%
cy
g
yl
mg
b
U
v
YL R
W
6
3. PARTS LIST
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
N.S.P.: Not available as service parts.
L5AD2/XE(MS)
NJ510
5009
5008
NJ530
NJ520
5010
CA2
NJ610
5001
6025
NJ620
7504
7505
6005
6015 NJ520
7506
NJ610
CA1
NJ630
NJ610
CA4
CA5
NJ610
NJ620
(N.S.P.)
NJ640
NJ650
5020 NJ540
NJ520 5005
NJ600
6010
(N.S.P.)
5006
5006
6030
(N.S.P.)
(N.S.P.)
5030
7508
5025
NJ630
NJ610
NJ610
CA3
NJ600
7507
ACCESSORIES & PACKING MATERIALS
9001 613 198 6176 CAP
9102 613 199 8025 INSTRUCTION MANUAL
9206 645 052 1997 CORE,FERRITE
9001 613 199 5918 CARTON CASE INNER
9002 613 184 1659 CUSHION BAG
CABINET & CHASSIS PARTS
5001 613 199 5888 CABINET FRONT
5005 613 199 7943 COVER TOP
5006 645 055 8634 PAD(L=100)
5008 613 198 6220 MOUNTING
5009 613 198 6190 COVER MOUNTING
5010 613 198 8316 COVER BOTTOM
5020 613 198 6152 CABINET BACK
5025 613 199 5895 DEC,INDICATOR
5030 613 188 0627 BUTTON
6005 613 199 2917 SPACER
6010 CHASSIS (N.S.P.)
6015 613 198 6213 FRAME (N.S.P.)
6025 613 198 6169 CHASSIS FRONT (N.S.P.)
6030 613 198 6244 TERMINAL (N.S.P.)
7504 645 055 8665 LENS(ASSY)
7505 645 055 8672 OPTICAL FILTER
7506 613 199 1705 ASSY,UNIT,CCD PAL
7507 613 199 2597 COMPL,MECHA DN
7508 645 053 7639 TERMINAL,PWB 2P,CN515
CA1 613 199 5666 COMPL PWB,CA-1
CA2 613 199 5598 COMPL PWB,CA-2
CA3 613 199 5673 COMPL PWB,CA-3
CA4 613 199 5635 COMPL PWB,CA-4
CA5 613 199 5642 COMPL PWB,CA-5
NJ510 411 126 4702 SCR PAN+SW+W 3X6
NJ520 412 051 6007 SPECIAL SCREW-3X4
NJ530 411 021 5705 SCR S-TPG BIN 3X6
NJ540 411 030 5406 SCR BIN 2X4
NJ600 411 108 4607 SCR TPG PAN PCS 2X5
NJ610 411 030 5000 SCR BIN 2X3
NJ620 411 030 5000 SCR BIN 2X3
NJ630 411 176 7005 SCR S-TPG PAN PCS 1.7X5.0
NJ640 411 023 3709 SCR S-TPG PAN 3X10
NJ650 411 126 4702 SCR PAN+SW+W 3X6
7
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U :
µ
FP:pF
4. Inductors
UH :
µ
H MH : mH
5. N.S.P. : Not available as service parts.
ELECTRICAL PARTS
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CA-1
613 199 5666
(SEMICONDUCTORS)
Q1101 405 045 8200 TR 2SK443-6-TB
Q1102 405 079 6302 TR 2SC4399-5
(INTEGRATED CIRCUITS)
IC102 409 366 9700 IC CXD1267AN
IC103 409 525 5901 IC AD9848AKST
IC121 409 368 5809 IC TC7SH08FU
IC122 409 400 9109 IC TC7SET08FU
IC131 409 301 5408 IC TC7S14FU(BRA)
(DIODES)
D1101 407 113 5609 DIODE DSH015
D1301 407 113 5609 DIODE DSH015
D1302 407 113 5609 DIODE DSH015
(INDUCTORS)
L1001 645 003 9386 INDUCTOR,10U J
L1003 645 003 9386 INDUCTOR,10U J
L1004 645 003 9386 INDUCTOR,10U J
L1101 645 003 9423 INDUCTOR,12U J
(CAPACITORS)
C1001 403 164 0204 CERAMIC 0.1U Z 25V
C1002 403 285 3603 TA-SOLID 4.7U M 6.3V
C1003 403 285 3603 TA-SOLID 4.7U M 6.3V
C1004 403 164 0204 CERAMIC 0.1U Z 25V
C1005 403 164 0204 CERAMIC 0.1U Z 25V
C1006 403 164 0204 CERAMIC 0.1U Z 25V
C1007 403 164 0204 CERAMIC 0.1U Z 25V
C1008 403 164 0204 CERAMIC 0.1U Z 25V
C1009 403 164 0204 CERAMIC 0.1U Z 25V
C1010 403 283 6309 CERAMIC 1U Z 10V
C1011 403 283 6309 CERAMIC 1U Z 10V
C1012 403 164 0204 CERAMIC 0.1U Z 25V
C1013 403 164 0204 CERAMIC 0.1U Z 25V
C1014 403 164 0204 CERAMIC 0.1U Z 25V
C1015 403 164 0204 CERAMIC 0.1U Z 25V
C1016 403 175 4505 ELECT 47U M 6.3V
C1021 403 164 0204 CERAMIC 0.1U Z 25V
C1024 403 164 0204 CERAMIC 0.1U Z 25V
C1108 403 175 4109 ELECT 22U M 16V
C1111 403 285 6406 TA-SOLID 1U M 35V
C1113 403 164 0204 CERAMIC 0.1U Z 25V
C1115 403 155 1807 CERAMIC 0.01U K 25V
C1116 403 113 4109 CERAMIC 2200P K 50V
C1117 403 155 1807 CERAMIC 0.01U K 25V
C1118 403 376 6902 TA-SOLID 3.3U M 25V
C1125 403 164 0204 CERAMIC 0.1U Z 25V
C1134 403 285 4808 TA-SOLID 3.3U M 20V
C1135 403 164 0204 CERAMIC 0.1U Z 25V
C1136 403 376 6902 TA-SOLID 3.3U M 25V
C1137 403 164 0204 CERAMIC 0.1U Z 25V
C1138 403 285 3603 TA-SOLID 4.7U M 6.3V
C1139 403 164 0204 CERAMIC 0.1U Z 25V
C1201 403 164 0204 CERAMIC 0.1U Z 25V
C1202 403 164 0204 CERAMIC 0.1U Z 25V
C1302 403 113 3805 CERAMIC 1000P K 50V
(RESISTORS)
R1001 401 105 0306 MT-GLAZE 10 JA 1/16W
R1003 401 105 0306 MT-GLAZE 10 JA 1/16W
R1004 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1005 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1006 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1013 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1014 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1015 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1016 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1017 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1026 401 105 3901 MT-GLAZE 33 JA 1/16W
R1027 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1028 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1071 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1072 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1073 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1074 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1075 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1076 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1077 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1078 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1079 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1080 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1101 401 105 7503 MT-GLAZE 82K JA 1/16W
R1102 401 105 0702 MT-GLAZE 100K JA 1/16W
R1104 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1105 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1106 401 105 8005 MT-GLAZE 1M JA 1/16W
R1113 401 105 4601 MT-GLAZE 3.9K JA 1/16W
R1116 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1117 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1118 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1124 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1134 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1141 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1201 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1202 401 105 0504 MT-GLAZE 1K JA 1/16W
R1203 401 105 3901 MT-GLAZE 33 JA 1/16W
R1204 401 105 8005 MT-GLAZE 1M JA 1/16W
R1206 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1207 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1301 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1303 401 105 0603 MT-GLAZE 10K JA 1/16W
R1304 401 105 0702 MT-GLAZE 100K JA 1/16W
R1311 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1312 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
(CONNECTORS)
CN102 645 051 2254 SOCKET,PWB-PWB 36(N.S.P)
CN105 645 023 1193 PLUG,PWB-PWB 70P (N.S.P)
8
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CA-2
613 199 5598
(SEMICONDUCTORS)
Q2001 405 135 9407 TR DTA114EUA
Q2003 405 133 8907 TR DTC114EUA
Q2004 405 135 9407 TR DTA114EUA
Q2006 405 133 8907 TR DTC114EUA
Q2055 405 137 2000 TR 2SA1576A-R
Q2056 405 137 2000 TR 2SA1576A-R
Q2057 405 092 4101 TR 2SC4081-R
Q2058 405 092 4101 TR 2SC4081-R
Q2059 405 137 2000 TR 2SA1576A-R
Q2060 405 137 2000 TR 2SA1576A-R
Q2086 405 139 7706 TR IMZ1A
Q2087 405 139 7706 TR IMZ1A
Q2088 405 129 2803 TR UMH10N
Q2450 405 131 0408 TR DTC115EUA
Q2451 405 131 0408 TR DTC115EUA
(INTEGRATED CIRCUITS)
IC201 410 437 7402 IC SCC0030A (N.S.P.)
IC202 409 320 9104 IC TC7SU04FU
IC203 409 323 9002 IC TC7S04FU
IC205 409 320 9104 IC TC7SU04FU
IC206 409 323 9002 IC TC7S04FU
IC208 409 246 9707 IC LA6358NM
IC215 409 475 2005 IC BA7664FV
IC221 409 368 5809 IC TC7SH08FU
IC223 409 367 8108 IC NJM3414AM
IC225 409 246 9707 IC LA6358NM
IC227 409 246 9707 IC LA6358NM
IC228 409 531 3809 IC UPD16879
IC229 409 531 3809 IC UPD16879
IC231 410 473 1907 IC UPD70F3017AGC-8EU
IC232 409 387 5606 IC AT24C16-10PC
IC233 409 525 1002 IC S80830CNUA-B8P
IC234 410 420 9703 IC UPD6462GS-642
IC236 409 520 5203 IC HY57V161610DTC-7
IC251 409 320 9104 IC TC7SU04FU
IC252 409 323 9002 IC TC7S04FU
(DIODES)
D2001 407 215 9208 DIODE MA365(E)
D2002 407 215 9208 DIODE MA365(E)
D2140 407 113 5609 DIODE DSH015
(OSCS)
X2001 645 055 5299 OSC,CRYSTAL 14.1875MHZ
X2140 645 049 9821 OSC,CERAMIC 20MHZ
X2501 645 055 5282 OSC,CRYSTAL 17.734475MHZ
(VARIABLE RESISTORS)
VR202 645 000 0270 VR,SEMI,47K S
VR202 645 017 2984 VR,SEMI,47K S
VR203 645 000 0232 VR,SEMI,10K S
VR203 645 017 2922 VR,SEMI,10K S
(TRIMMERS)
CT201 645 051 7655 TRIMMER,30PF
CT202 645 051 7655 TRIMMER,30PF
CT252 645 051 7655 TRIMMER,30PF
(INDUCTORS)
L2001 645 003 9386 INDUCTOR,10U J
L2002 645 007 6862 INDUCTOR,5.6U J
L2003 645 003 9546 INDUCTOR,47U J
L2040 645 003 9386 INDUCTOR,10U J
L2055 645 003 9485 INDUCTOR,22U J
L2057 645 003 9386 INDUCTOR,10U J
L2058 645 003 9386 INDUCTOR,10U J
L2059 645 003 9560 INDUCTOR,68U J
L2082 645 003 9386 INDUCTOR,10U J
L2083 645 003 9386 INDUCTOR,10U J
L2140 645 003 9386 INDUCTOR,10U J
L2142 645 003 9386 INDUCTOR,10U J
L2301 645 003 9386 INDUCTOR,10U J
L2302 645 003 9386 INDUCTOR,10U J
L2303 645 003 9386 INDUCTOR,10U J
L2304 645 003 9386 INDUCTOR,10U J
L2305 645 003 9386 INDUCTOR,10U J
L2306 645 003 9386 INDUCTOR,10U J
(CAPACITORS)
C2001 403 285 5003 TA-SOLID 1U M 25V
C2002 403 164 0204 CERAMIC 0.1U Z 25V
C2003 403 150 2106 NP-ELECT 4.7U M 25V
C2004 403 164 0204 CERAMIC 0.1U Z 25V
C2005 403 150 2106 NP-ELECT 4.7U M 25V
C2006 403 311 3409 CERAMIC 0.01U K 16V
C2007 403 311 3409 CERAMIC 0.01U K 16V
C2008 403 346 2309 CERAMIC 0.1U K 10V
C2011 403 285 6802 TA-SOLID 10U M 6.3V
C2012 403 346 2309 CERAMIC 0.1U K 10V
C2013 403 346 2309 CERAMIC 0.1U K 10V
C2014 403 311 3409 CERAMIC 0.01U K 16V
C2015 403 311 7506 CERAMIC 22P J 50V
C2016 403 311 4505 CERAMIC 1000P K 50V
C2017 403 207 0307 CERAMIC 1U Z 16V
C2018 403 327 1406 TA-SOLID 4.7U M 25V
C2019 403 285 6802 TA-SOLID 10U M 6.3V
C2020 403 346 2309 CERAMIC 0.1U K 10V
C2021 403 285 6802 TA-SOLID 10U M 6.3V
C2022 403 311 4505 CERAMIC 1000P K 50V
C2023 403 311 4505 CERAMIC 1000P K 50V
C2026 403 285 4006 TA-SOLID 4.7U M 10V
C2027 403 346 2309 CERAMIC 0.1U K 10V
C2028 403 346 2309 CERAMIC 0.1U K 10V
C2030 403 309 8201 CERAMIC 6P D 50V
C2040 403 285 3603 TA-SOLID 4.7U M 6.3V
C2051 403 311 7506 CERAMIC 22P J 50V
C2052 403 311 7506 CERAMIC 22P J 50V
C2053 403 311 7506 CERAMIC 22P J 50V
C2055 403 309 8409 CERAMIC 10P D 50V
C2056 403 175 4505 ELECT 47U M 6.3V
C2057 403 285 4006 TA-SOLID 4.7U M 10V
C2058 403 305 0001 TA-SOLID 10U M 10V
C2059 403 305 0001 TA-SOLID 10U M 10V
C2060 403 285 4006 TA-SOLID 4.7U M 10V
C2061 403 346 2309 CERAMIC 0.1U K 10V
C2062 403 285 5003 TA-SOLID 1U M 25V
C2063 403 311 3409 CERAMIC 0.01U K 16V
C2066 403 346 2309 CERAMIC 0.1U K 10V
C2067 403 311 3409 CERAMIC 0.01U K 16V
C2068 403 311 7506 CERAMIC 22P J 50V
C2070 403 305 0001 TA-SOLID 10U M 10V
C2071 403 285 6901 TA-SOLID 22U M 6.3V
C2072 403 175 0606 ELECT 100U M 6.3V
C2078 403 311 4901 CERAMIC 470P K 50V
C2079 403 305 0001 TA-SOLID 10U M 10V
C2080 403 346 2309 CERAMIC 0.1U K 10V
C2081 403 346 2309 CERAMIC 0.1U K 10V
C2082 403 305 0001 TA-SOLID 10U M 10V
C2083 403 346 2309 CERAMIC 0.1U K 10V
C2084 403 346 2309 CERAMIC 0.1U K 10V
C2086 403 311 7704 CERAMIC 4700P K 25V
C2087 403 346 2309 CERAMIC 0.1U K 10V
C2088 403 346 2309 CERAMIC 0.1U K 10V
C2089 403 305 0001 TA-SOLID 10U M 10V
C2090 403 346 2309 CERAMIC 0.1U K 10V
C2091 403 311 3409 CERAMIC 0.01U K 16V
C2092 403 305 0001 TA-SOLID 10U M 10V
C2093 403 311 3409 CERAMIC 0.01U K 16V
C2094 403 346 2309 CERAMIC 0.1U K 10V
C2095 403 346 2309 CERAMIC 0.1U K 10V
C2096 403 346 2309 CERAMIC 0.1U K 10V
C2098 403 311 4901 CERAMIC 470P K 50V
C2099 403 346 2309 CERAMIC 0.1U K 10V
C2100 403 305 0001 TA-SOLID 10U M 10V
C2101 403 346 2309 CERAMIC 0.1U K 10V
C2102 403 320 0406 CERAMIC 68P J 50V
C2103 403 311 4505 CERAMIC 1000P K 50V
C2104 403 311 4505 CERAMIC 1000P K 50V
C2105 403 311 4505 CERAMIC 1000P K 50V
C2106 403 311 4505 CERAMIC 1000P K 50V
C2107 403 305 0001 TA-SOLID 10U M 10V
C2108 403 346 2309 CERAMIC 0.1U K 10V
C2109 403 320 0406 CERAMIC 68P J 50V
C2110 403 311 4505 CERAMIC 1000P K 50V
C2111 403 311 4505 CERAMIC 1000P K 50V
C2113 403 311 4505 CERAMIC 1000P K 50V
9
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C2114 403 311 4505 CERAMIC 1000P K 50V
C2115 403 305 0001 TA-SOLID 10U M 10V
C2140 403 346 2309 CERAMIC 0.1U K 10V
C2142 403 346 2309 CERAMIC 0.1U K 10V
C2143 403 285 6802 TA-SOLID 10U M 6.3V
C2144 403 346 2309 CERAMIC 0.1U K 10V
C2145 403 285 6802 TA-SOLID 10U M 6.3V
C2146 403 346 2309 CERAMIC 0.1U K 10V
C2147 403 346 2309 CERAMIC 0.1U K 10V
C2148 403 285 6802 TA-SOLID 10U M 6.3V
C2149 403 346 2309 CERAMIC 0.1U K 10V
C2150 403 285 6802 TA-SOLID 10U M 6.3V
C2151 403 346 2309 CERAMIC 0.1U K 10V
C2152 403 285 6802 TA-SOLID 10U M 6.3V
C2157 403 346 2309 CERAMIC 0.1U K 10V
C2301 403 285 6802 TA-SOLID 10U M 6.3V
C2302 403 346 2309 CERAMIC 0.1U K 10V
C2303 403 346 2309 CERAMIC 0.1U K 10V
C2304 403 346 2309 CERAMIC 0.1U K 10V
C2305 403 346 2309 CERAMIC 0.1U K 10V
C2306 403 346 2309 CERAMIC 0.1U K 10V
C2307 403 346 2309 CERAMIC 0.1U K 10V
C2308 403 346 2309 CERAMIC 0.1U K 10V
C2309 403 346 2309 CERAMIC 0.1U K 10V
C2310 403 346 2309 CERAMIC 0.1U K 10V
C2311 403 285 6802 TA-SOLID 10U M 6.3V
C2312 403 346 2309 CERAMIC 0.1U K 10V
C2313 403 285 6802 TA-SOLID 10U M 6.3V
C2314 403 346 2309 CERAMIC 0.1U K 10V
C2315 403 346 2309 CERAMIC 0.1U K 10V
C2316 403 346 2309 CERAMIC 0.1U K 10V
C2317 403 346 2309 CERAMIC 0.1U K 10V
C2318 403 285 6802 TA-SOLID 10U M 6.3V
C2319 403 346 2309 CERAMIC 0.1U K 10V
C2320 403 285 6802 TA-SOLID 10U M 6.3V
C2321 403 285 6802 TA-SOLID 10U M 6.3V
C2322 403 346 2309 CERAMIC 0.1U K 10V
C2324 403 346 2309 CERAMIC 0.1U K 10V
C2325 403 346 2309 CERAMIC 0.1U K 10V
C2330 403 285 6802 TA-SOLID 10U M 6.3V
C2331 403 346 2309 CERAMIC 0.1U K 10V
C2332 403 285 6802 TA-SOLID 10U M 6.3V
C2333 403 346 2309 CERAMIC 0.1U K 10V
C2450 403 346 2309 CERAMIC 0.1U K 10V
C2501 403 346 2309 CERAMIC 0.1U K 10V
C2502 403 311 3805 CERAMIC 12P J 50V
(RESISTORS)
R2001 401 225 8701 MT-GLAZE 120K JA 1/16W
R2002 401 224 9006 MT-GLAZE 10K JA 1/16W
R2003 401 225 1702 MT-GLAZE 39K JA 1/16W
R2004 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R2005 401 227 5609 MT-GLAZE 8.2K JA 1/16W
R2006 401 224 8900 MT-GLAZE 100K JA 1/16W
R2009 401 225 8701 MT-GLAZE 120K JA 1/16W
R2010 401 224 9808 MT-GLAZE 220K JA 1/16W
R2011 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2012 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2013 401 229 3900 MT-GLAZE 180 JA 1/16W
R2014 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2015 401 224 8900 MT-GLAZE 100K JA 1/16W
R2016 401 224 9006 MT-GLAZE 10K JA 1/16W
R2019 401 225 1405 MT-GLAZE 47K JA 1/16W
R2020 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R2021 401 224 8900 MT-GLAZE 100K JA 1/16W
R2022 401 225 0507 MT-GLAZE 33K JA 1/16W
R2023 401 158 4009 MT-GLAZE 3.3 JA 1/16W
R2024 401 224 9006 MT-GLAZE 10K JA 1/16W
R2026 401 224 9006 MT-GLAZE 10K JA 1/16W
R2028 401 224 8900 MT-GLAZE 100K JA 1/16W
R2029 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R2030 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2031 401 224 8801 MT-GLAZE 100 JA 1/16W
R2032 401 224 8801 MT-GLAZE 100 JA 1/16W
R2045 401 224 8801 MT-GLAZE 100 JA 1/16W
R2048 401 105 6407 MT-GLAZE 68 JA 1/16W
R2053 401 225 0309 MT-GLAZE 33 JA 1/16W
R2054 401 224 9303 MT-GLAZE 1K JA 1/16W
R2055 401 224 9303 MT-GLAZE 1K JA 1/16W
R2056 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2057 401 226 2401 MT-GLAZE 560 JA 1/16W
R2058 401 224 9303 MT-GLAZE 1K JA 1/16W
R2059 401 225 1801 MT-GLAZE 47 JA 1/16W
R2060 401 235 2201 MT-GLAZE 180K JA 1/16W
R2061 401 224 8900 MT-GLAZE 100K JA 1/16W
R2062 401 224 9303 MT-GLAZE 1K JA 1/16W
R2063 401 225 2006 MT-GLAZE 680 JA 1/16W
R2064 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2065 401 235 1402 MT-GALZE 1.2K JA 1/16W
R2066 401 224 9303 MT-GLAZE 1K JA 1/16W
R2067 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R2070 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2071 401 224 9303 MT-GLAZE 1K JA 1/16W
R2072 401 225 1405 MT-GLAZE 47K JA 1/16W
R2073 401 225 1405 MT-GLAZE 47K JA 1/16W
R2074 401 225 3805 MT-GLAZE 1.5K JA 1/16W
R2075 401 225 0200 MT-GLAZE 3.3K JA 1/16W
R2076 401 225 0309 MT-GLAZE 33 JA 1/16W
R2080 401 225 1405 MT-GLAZE 47K JA 1/16W
R2082 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2083 401 225 2105 MT-GLAZE 12K JA 1/16W
R2084 401 225 8701 MT-GLAZE 120K JA 1/16W
R2085 401 224 9006 MT-GLAZE 10K JA 1/16W
R2087 401 224 9600 MT-GLAZE 2.7K JA 1/16W
R2088 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R2092 401 234 9904 MT-GLAZE 6.8K JA 1/16W
R2093 401 235 1402 MT-GALZE 1.2K JA 1/16W
R2094 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R2095 401 224 9600 MT-GLAZE 2.7K JA 1/16W
R2096 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2097 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2098 401 224 9006 MT-GLAZE 10K JA 1/16W
R2099 401 225 8701 MT-GLAZE 120K JA 1/16W
R2100 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2101 401 224 9006 MT-GLAZE 10K JA 1/16W
R2102 401 224 9907 MT-GLAZE 22K JA 1/16W
R2103 401 225 0606 MT-GLAZE 5.6K JA 1/16W
R2104 401 225 0200 MT-GLAZE 3.3K JA 1/16W
R2105 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R2106 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R2107 401 225 1504 MT-GLAZE 3.9K JA 1/16W
R2108 401 225 1405 MT-GLAZE 47K JA 1/16W
R2109 401 224 9303 MT-GLAZE 1K JA 1/16W
R2110 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2111 401 224 9907 MT-GLAZE 22K JA 1/16W
R2112 401 224 8900 MT-GLAZE 100K JA 1/16W
R2113 401 224 9006 MT-GLAZE 10K JA 1/16W
R2114 401 224 9204 MT-GLAZE 15K JA 1/16W
R2115 401 224 8900 MT-GLAZE 100K JA 1/16W
R2116 401 224 9006 MT-GLAZE 10K JA 1/16W
R2117 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2118 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2119 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2120 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2121 401 224 8900 MT-GLAZE 100K JA 1/16W
R2122 401 224 8900 MT-GLAZE 100K JA 1/16W
R2124 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2125 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2126 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2127 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2128 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2129 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2131 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2132 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2134 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2135 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2136 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2137 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2141 401 105 5806 MT-GLAZE 56 JA 1/16W
R2142 401 224 8900 MT-GLAZE 100K JA 1/16W
R2143 401 224 8900 MT-GLAZE 100K JA 1/16W
R2144 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2146 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2147 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2148 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2149 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2151 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
10
R2152 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2153 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2154 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2155 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2156 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2157 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2158 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2159 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R2162 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2163 401 224 9006 MT-GLAZE 10K JA 1/16W
R2164 401 224 9006 MT-GLAZE 10K JA 1/16W
R2165 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2166 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2167 401 224 9006 MT-GLAZE 10K JA 1/16W
R2168 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2169 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R2177 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2178 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2179 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2183 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2187 401 225 3805 MT-GLAZE 1.5K JA 1/16W
R2189 401 225 3805 MT-GLAZE 1.5K JA 1/16W
R2191 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2192 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2205 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2206 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2209 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2210 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R2215 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2224 401 224 8900 MT-GLAZE 100K JA 1/16W
R2226 401 224 8801 MT-GLAZE 100 JA 1/16W
R2252 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2337 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2338 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2339 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2343 401 225 0309 MT-GLAZE 33 JA 1/16W
R2344 401 225 0309 MT-GLAZE 33 JA 1/16W
R2345 401 225 0309 MT-GLAZE 33 JA 1/16W
R2347 401 225 0309 MT-GLAZE 33 JA 1/16W
R2348 401 225 0309 MT-GLAZE 33 JA 1/16W
R2349 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2351 401 225 0309 MT-GLAZE 33 JA 1/16W
R2352 401 225 0309 MT-GLAZE 33 JA 1/16W
R2360 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2370 401 225 0309 MT-GLAZE 33 JA 1/16W
R2371 401 225 0309 MT-GLAZE 33 JA 1/16W
R2372 401 225 0309 MT-GLAZE 33 JA 1/16W
R2373 401 225 0309 MT-GLAZE 33 JA 1/16W
R2374 401 225 0309 MT-GLAZE 33 JA 1/16W
R2375 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2378 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2379 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2380 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2381 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2383 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2384 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2385 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2386 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2390 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2391 401 224 9006 MT-GLAZE 10K JA 1/16W
R2392 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2394 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2395 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2401 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2402 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2403 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2404 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2405 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2406 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2407 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2408 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2409 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2410 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2411 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2412 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2413 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2414 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2415 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2416 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2417 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2418 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2419 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2420 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2422 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2450 401 225 0606 MT-GLAZE 5.6K JA 1/16W
R2451 401 224 8900 MT-GLAZE 100K JA 1/16W
R2452 401 225 0606 MT-GLAZE 5.6K JA 1/16W
R2453 401 224 8900 MT-GLAZE 100K JA 1/16W
R2454 401 225 0309 MT-GLAZE 33 JA 1/16W
R2456 401 105 4502 MT-GLAZE 390 JA 1/16W
R2457 401 105 4502 MT-GLAZE 390 JA 1/16W
R2458 401 224 9303 MT-GLAZE 1K JA 1/16W
R2461 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2462 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R2501 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R2502 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
(FILTERS)
F2001 645 006 3404 FILTER,EMI 470PF
F2002 645 006 3404 FILTER,EMI 470PF
(CONNECTORS)
CN202 645 002 3064 PLUG,8P (N.S.P)
CN203 645 038 6725 SOCKET,FPC 22P (N.S.P)
CN205 645 023 2527 SOCKET,PWB-PWB 70(N.S.P)
CN207 645 038 5247 SOCKET,FFC 6P (N.S.P)
COMPL PWB,CA-3
613 199 5673
(SEMICONDUCTORS)
Q3010 405 169 1101 TR 2SK3617
Q3011 405 131 4505 TR 2SD1767Q
Q3030 405 138 6700 TR DTC144EKA
Q3031 405 133 8907 TR DTC114EUA
Q3101 405 002 0308 TR 2SA1037K-R
Q3104 405 128 9605 TR 2SC2411K-Q
Q3104 405 035 5905 TR 2SC2411K-R
(INTEGRATED CIRCUITS)
IC301 409 506 8907 IC FA7700V
IC311 409 528 1405 IC TLV431ASNT1
IC312 409 528 1405 IC TLV431ASNT1
IC313 409 521 3703 IC BA00BC0WF
(DIODES)
D3010 407 218 7409 ZENER DIODE UDZS15B
D3011 407 222 1004 ZENER DIODE UDZS4.3B
D3015 407 173 1108 PHOTO COUPLE TLP181-GB
D3020 407 222 4500 DIODE 1SR156-400
D3030 407 206 6308 ZENER DIODE UDZS5.1B-TE17
D3101 407 177 5805 DIODE DRB060L-40
D3102 407 222 4500 DIODE 1SR156-400
D3103 407 167 3101 DIODE D1FS6
D3104 407 222 4500 DIODE 1SR156-400
D3107 407 231 2207 ZENER DIODE UDZS13B
D3120 407 207 7700 ZENER DIODE PTZ3.9B
D3601 407 206 5400 ZENER DIODE UDZS8.2B
D3602 407 206 5400 ZENER DIODE UDZS8.2B
D3603 407 206 5400 ZENER DIODE UDZS8.2B
D3604 407 206 5400 ZENER DIODE UDZS8.2B
D3605 407 206 5400 ZENER DIODE UDZS8.2B
D3606 407 206 5400 ZENER DIODE UDZS8.2B
(INDUCTORS)
L3101 645 052 4264 INDUCTOR,100U N
L3102 645 050 7489 INDUCTOR,100U K
L3103 645 052 4264 INDUCTOR,100U N
L3104 645 050 7489 INDUCTOR,100U K
(TRANSFORMER)
T3001 645 053 8223 TRANS,POWER,PULSE
(CAPACITORS)
C3010 403 372 4506 CERAMIC 2.2U K 25V
C3011 403 189 0807 CERAMIC 0.1U K 25V
C3013 403 376 7206 ELECT 22U M 35V
C3015 403 280 0300 CERAMIC 0.22U K 25V
C3020 403 376 9309 CERAMIC 0.047U K 250V
C3022 403 378 6306 CERAMIC 470P J 100V
C3030 403 070 0909 CERAMIC 0.1U K 50V
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
11
C3031 403 357 3302 CERAMIC 0.01U K 630V
C3032 403 358 7507 ELECT 100U M 50V
C3101 403 333 3609 POS-SOLID 33U M 10V
C3102 403 333 3609 POS-SOLID 33U M 10V
C3103 403 372 4506 CERAMIC 2.2U K 25V
C3104 403 372 4506 CERAMIC 2.2U K 25V
C3105 403 333 3609 POS-SOLID 33U M 10V
C3106 403 333 3609 POS-SOLID 33U M 10V
C3107 403 372 4506 CERAMIC 2.2U K 25V
C3108 403 372 4506 CERAMIC 2.2U K 25V
C3109 403 298 9609 CERAMIC 0.1U K 16V
C3110 403 189 0807 CERAMIC 0.1U K 25V
C3111 403 189 0807 CERAMIC 0.1U K 25V
C3112 403 372 4506 CERAMIC 2.2U K 25V
C3114 403 372 4506 CERAMIC 2.2U K 25V
C3115 403 189 0807 CERAMIC 0.1U K 25V
C3116 403 333 3609 POS-SOLID 33U M 10V
(RESISTORS)
R3011 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R3012 401 105 5103 MT-GLAZE 47 JA 1/16W
R3013 401 258 3308 MT-FILM 39K DU 1/16W
R3014 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3015 401 105 7602 MT-GLAZE 820K JA 1/16W
R3016 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R3018 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3019 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3020 401 302 7207 MT-FILM 330 JE 1W
R3030 401 038 0800 MT-GLAZE 22K JA 1/10W
R3101 401 105 2607 MT-GLAZE 22 JA 1/16W
R3102 401 166 8303 MT-FILM 1.2K DU 1/16W
R3103 401 166 8105 MT-FILM 1K DU 1/16W
R3105 401 105 1402 MT-GLAZE 150 JA 1/16W
R3108 401 105 0504 MT-GLAZE 1K JA 1/16W
R3109 401 166 7306 MT-FILM 470 DU 1/16W
R3110 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3111 401 166 8105 MT-FILM 1K DU 1/16W
R3112 401 166 3001 MT-FILM 2.7K DU 1/16W
R3113 401 105 0306 MT-GLAZE 10 JA 1/16W
R3114 401 105 5905 MT-GLAZE 560 JA 1/16W
R3115 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R3117 401 105 4007 MT-GLAZE 330 JA 1/16W
R3118 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3130 401 166 8105 MT-FILM 1K DU 1/16W
R3131 401 167 0306 MT-FILM 10K DU 1/16W
R3132 401 166 8105 MT-FILM 1K DU 1/16W
R3601 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3602 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
(CONNECTORS)
CN302 645 051 2247 PLUG,PWB-PWB 36P (N.S.P)
CN303 645 050 3917 SOCKET,FPC 9P (N.S.P)
COMPL PWB,CA-4
613 199 5635
(SEMICONDUCTORS)
Q4005 405 014 4509 TR 2SC2412K-R
Q4006 405 153 2008 TR 2SK3018
Q4010 405 141 0603 TR 2SA1037AK-R
Q4011 405 014 4509 TR 2SC2412K-R
Q4012 405 014 4509 TR 2SC2412K-R
Q4013 405 141 0603 TR 2SA1037AK-R
Q4021 405 131 4505 TR 2SD1767Q
Q4501 405 079 6302 TR 2SC4399-5
(INTEGRATED CIRCUITS)
IC401 410 464 4306 IC UPD78F0078Y-AD1
IC402 409 524 5407 IC MAX3471EUA
IC403 409 479 5606 IC PST9227N
IC403 409 479 5606 IC PST9227N
IC406 409 155 7702 IC TC4S66F
IC407 409 359 9007 IC BA7071F
IC408 409 377 4305 IC NJM2267
IC409 409 367 5305 IC NJM2903V
IC410 409 367 5305 IC NJM2903V
IC411 409 367 5305 IC NJM2903V
IC416 409 368 5809 IC TC7SH08FU
IC452 409 155 8006 IC TC7S04F
IC453 409 167 7202 IC NJM2406F
IC454 409 305 3103 IC TC7W74FU
IC455 409 301 5507 IC TC7S08FU
IC456 409 301 5507 IC TC7S08FU
(DIODES)
D4004 407 149 0807 DIODE 1SS355
D4502 407 113 5609 DIODE DSH015
D4503 407 113 5609 DIODE DSH015
(OSC)
X4001 645 053 3877 OSC,CERAMIC 5.00MHZ
(INDUCTORS)
L4001 645 001 4512 INDUCTOR,10U K
L4002 645 001 4529 INDUCTOR,100U K
L4003 645 001 4529 INDUCTOR,100U K
L4004 645 001 4529 INDUCTOR,100U K
L4005 645 001 4529 INDUCTOR,100U K
L4502 645 040 8069 INDUCTOR,1.2U J
L4503 645 003 9546 INDUCTOR,47U J
L4504 645 040 8069 INDUCTOR,1.2U J
L4506 645 001 4512 INDUCTOR,10U K
(CAPACITORS)
C4007 403 164 0204 CERAMIC 0.1U Z 25V
C4008 403 164 0204 CERAMIC 0.1U Z 25V
C4051 403 155 1807 CERAMIC 0.01U K 25V
C4052 403 175 4505 ELECT 47U M 6.3V
C4053 403 155 1807 CERAMIC 0.01U K 25V
C4054 403 113 3805 CERAMIC 1000P K 50V
C4055 403 157 3601 CERAMIC 100P J 50V
C4067 403 155 1807 CERAMIC 0.01U K 25V
C4068 403 155 1807 CERAMIC 0.01U K 25V
C4081 403 175 4505 ELECT 47U M 6.3V
C4082 403 155 1807 CERAMIC 0.01U K 25V
C4083 403 162 9506 ELECT 4.7U M 35V
C4084 403 175 4505 ELECT 47U M 6.3V
C4085 403 155 1807 CERAMIC 0.01U K 25V
C4086 403 155 1807 CERAMIC 0.01U K 25V
C4087 403 283 6309 CERAMIC 1U Z 10V
C4088 403 162 6000 ELECT 0.47U M 50V
C4089 403 283 6309 CERAMIC 1U Z 10V
C4090 403 113 3805 CERAMIC 1000P K 50V
C4091 403 155 1807 CERAMIC 0.01U K 25V
C4092 403 175 4505 ELECT 47U M 6.3V
C4093 403 162 4709 ELECT 10U M 16V
C4094 403 155 1807 CERAMIC 0.01U K 25V
C4095 403 175 4505 ELECT 47U M 6.3V
C4096 403 155 1807 CERAMIC 0.01U K 25V
C4097 403 155 1807 CERAMIC 0.01U K 25V
C4098 403 162 4709 ELECT 10U M 16V
C4099 403 155 1807 CERAMIC 0.01U K 25V
C4101 403 164 0204 CERAMIC 0.1U Z 25V
C4160 403 164 0204 CERAMIC 0.1U Z 25V
C4502 403 155 1302 CERAMIC 150P J 50V
C4503 403 164 0204 CERAMIC 0.1U Z 25V
C4506 403 215 0900 CERAMIC 390P J 50V
C4507 403 215 0900 CERAMIC 390P J 50V
C4508 403 113 3805 CERAMIC 1000P K 50V
C4509 403 153 9102 CERAMIC 5P C 50V
C4511 403 164 0204 CERAMIC 0.1U Z 25V
C4512 403 145 9905 CERAMIC 22P J 50V
C4513 403 164 0204 CERAMIC 0.1U Z 25V
C4517 403 279 9109 TA-SOLID 4.7U M 10V
C4518 403 164 0204 CERAMIC 0.1U Z 25V
C4522 403 215 2904 CERAMIC 0.022U K 25V
C4523 403 164 0204 CERAMIC 0.1U Z 25V
C4524 403 164 0204 CERAMIC 0.1U Z 25V
C4525 403 113 3805 CERAMIC 1000P K 50V
(RESISTORS)
R4010 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4032 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4033 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4036 401 105 4007 MT-GLAZE 330 JA 1/16W
R4037 401 105 4304 MT-GLAZE 330K JA 1/16W
R4041 401 105 0603 MT-GLAZE 10K JA 1/16W
R4042 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4044 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4045 401 105 2904 MT-GLAZE 22K JA 1/16W
R4048 401 105 0405 MT-GLAZE 100 JA 1/16W
R4049 401 113 4600 MT-GLAZE 110 JA 1/16W
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
12
R4050 401 105 0405 MT-GLAZE 100 JA 1/16W
R4051 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4052 401 105 5400 MT-GLAZE 47K JA 1/16W
R4053 401 105 5400 MT-GLAZE 47K JA 1/16W
R4054 401 105 5400 MT-GLAZE 47K JA 1/16W
R4055 401 105 5400 MT-GLAZE 47K JA 1/16W
R4056 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4057 401 105 0504 MT-GLAZE 1K JA 1/16W
R4058 401 105 0504 MT-GLAZE 1K JA 1/16W
R4059 401 105 0504 MT-GLAZE 1K JA 1/16W
R4060 401 105 0504 MT-GLAZE 1K JA 1/16W
R4061 401 105 0504 MT-GLAZE 1K JA 1/16W
R4064 401 105 5400 MT-GLAZE 47K JA 1/16W
R4065 401 105 5400 MT-GLAZE 47K JA 1/16W
R4067 401 105 0702 MT-GLAZE 100K JA 1/16W
R4068 401 105 0702 MT-GLAZE 100K JA 1/16W
R4069 401 105 0603 MT-GLAZE 10K JA 1/16W
R4071 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4076 401 105 5400 MT-GLAZE 47K JA 1/16W
R4077 401 105 5400 MT-GLAZE 47K JA 1/16W
R4080 401 105 0603 MT-GLAZE 10K JA 1/16W
R4081 401 105 6407 MT-GLAZE 68 JA 1/16W
R4082 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4083 401 105 1600 MT-GLAZE 15K JA 1/16W
R4084 401 105 0504 MT-GLAZE 1K JA 1/16W
R4085 401 113 4402 MT-GLAZE 75 JA 1/16W
R4086 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R4087 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R4088 401 105 4502 MT-GLAZE 390 JA 1/16W
R4089 401 105 0504 MT-GLAZE 1K JA 1/16W
R4090 401 177 2406 MT-GLAZE 10M JA 1/16W
R4091 401 105 0504 MT-GLAZE 1K JA 1/16W
R4092 401 105 0603 MT-GLAZE 10K JA 1/16W
R4093 401 105 3000 MT-GLAZE 220K JA 1/16W
R4094 401 250 5003 MT-GLAZE 100K DC 1/16W
R4095 401 105 2904 MT-GLAZE 22K JA 1/16W
R4097 401 105 4700 MT-GLAZE 39K JA 1/16W
R4099 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4103 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4104 401 105 4106 MT-GALZE 3.3K JA 1/16W
R4105 401 105 8005 MT-GLAZE 1M JA 1/16W
R4106 401 284 1101 MT-GLAZE 75 DD 1/16W
R4107 401 105 0504 MT-GLAZE 1K JA 1/16W
R4108 401 105 0504 MT-GLAZE 1K JA 1/16W
R4109 401 105 0603 MT-GLAZE 10K JA 1/16W
R4110 401 105 0603 MT-GLAZE 10K JA 1/16W
R4113 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4115 401 105 8203 MT-GLAZE 68K JA 1/16W
R4117 401 105 3208 MT-GLAZE 270 JA 1/16W
R4122 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4124 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4125 401 105 0702 MT-GLAZE 100K JA 1/16W
R4126 401 105 0702 MT-GLAZE 100K JA 1/16W
R4127 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4128 401 105 0603 MT-GLAZE 10K JA 1/16W
R4129 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4130 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R4131 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R4132 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R4133 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R4135 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4137 401 105 0603 MT-GLAZE 10K JA 1/16W
R4138 401 105 0603 MT-GLAZE 10K JA 1/16W
R4139 401 105 0603 MT-GLAZE 10K JA 1/16W
R4140 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4142 401 105 0603 MT-GLAZE 10K JA 1/16W
R4143 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4145 401 105 0603 MT-GLAZE 10K JA 1/16W
R4146 401 105 0603 MT-GLAZE 10K JA 1/16W
R4147 401 105 0603 MT-GLAZE 10K JA 1/16W
R4148 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4150 401 105 0603 MT-GLAZE 10K JA 1/16W
R4160 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4161 401 105 8203 MT-GLAZE 68K JA 1/16W
R4163 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4501 401 105 5400 MT-GLAZE 47K JA 1/16W
R4502 401 105 5400 MT-GLAZE 47K JA 1/16W
R4503 401 105 0504 MT-GLAZE 1K JA 1/16W
R4504 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4513 401 105 0405 MT-GLAZE 100 JA 1/16W
R4514 401 105 8005 MT-GLAZE 1M JA 1/16W
R4515 401 105 1600 MT-GLAZE 15K JA 1/16W
R4516 401 105 3406 MT-GLAZE 27K JA 1/16W
R4517 401 105 2904 MT-GLAZE 22K JA 1/16W
R4518 401 105 0702 MT-GLAZE 100K JA 1/16W
R4519 401 105 0603 MT-GLAZE 10K JA 1/16W
R4522 401 105 2706 MT-GLAZE 220 JA 1/16W
R4523 401 105 0504 MT-GLAZE 1K JA 1/16W
R4524 401 105 1709 MT-GLAZE 150K JA 1/16W
R4525 401 105 3307 MT-GLAZE 2.7K JA 1/16W
(CONNECTORS)
CN401 645 053 4676 SOCKET,FPC 9P (N.S.P)
CN402 645 002 3026 PLUG,4P (N.S.P)
CN403 645 002 3064 PLUG,8P (N.S.P)
CN404 645 003 2387 PLUG,2P (N.S.P)
CN405 645 024 8290 SOCKET,28P (N.S.P)
COMPL PWB,CA-5
613 199 5642
(VARISTORS)
VA501 407 226 0904 VARISTOR NV047D07
VA502 407 226 0904 VARISTOR NV047D07
VA511 408 050 6100 VARISTOR AVR-M2012C220KT
VA512 408 050 6100 VARISTOR AVR-M2012C220KT
VA514 408 050 6100 VARISTOR AVR-M2012C220KT
VA515 408 050 6100 VARISTOR AVR-M2012C220KT
(SEMICONDUCTORS)
Q5402 405 092 4101 TR 2SC4081-R
Q5403 405 092 4200 TR 2SA1576-R
(INTEGRATED CIRCUIT)
IC541 409 167 7202 IC NJM2406F
(DIODES)
D5001 407 065 3906 LED SLP-135B-51
D5002 407 206 5400 ZENER DIODE UDZS8.2B
D5003 407 206 5400 ZENER DIODE UDZS8.2B
D5015 407 222 6306 ZENER DIODE UDZS3.9B
D5016 407 222 6306 ZENER DIODE UDZS3.9B
D5017 407 222 6306 ZENER DIODE UDZS3.9B
D5018 407 222 6306 ZENER DIODE UDZS3.9B
D5019 407 149 0807 DIODE 1SS355
D5022 407 149 0807 DIODE 1SS355
D5201 407 103 0409 DIODE DBB08C
D5202 407 173 1108 PHOTO COUPLE TLP181-GB
(INDUCTOR)
L5001 645 025 7858 INDUCTOR,140 OHM
(CAPACITORS)
C5001 403 232 9405 CERAMIC 0.01U Z 1KV
C5002 403 232 9405 CERAMIC 0.01U Z 1KV
C5010 403 113 3805 CERAMIC 1000P K 50V
C5011 403 322 9308 ELECT 470U M 4V
C5012 403 113 3805 CERAMIC 1000P K 50V
C5021 403 164 0204 CERAMIC 0.1U Z 25V
C5022 403 164 0204 CERAMIC 0.1U Z 25V
C5203 403 114 5204 POLYESTER 0.01U K 250V
C5206 403 211 8801 ELECT 470U M 50V
C5241 403 232 9405 CERAMIC 0.01U Z 1KV
C5420 403 285 6307 TA-SOLID 0.22U M 35V
C5421 403 155 1807 CERAMIC 0.01U K 25V
C5422 403 285 6307 TA-SOLID 0.22U M 35V
C5423 403 285 5003 TA-SOLID 1U M 25V
C5424 403 193 7601 ELECT 220U M 6.3V
C5425 403 164 0204 CERAMIC 0.1U Z 25V
C5426 403 164 0204 CERAMIC 0.1U Z 25V
C5427 403 215 1006 CERAMIC 470P J 50V
(RESISTORS)
R5001 401 105 0702 MT-GLAZE 100K JA 1/16W
R5002 401 105 0702 MT-GLAZE 100K JA 1/16W
R5003 401 105 0702 MT-GLAZE 100K JA 1/16W
R5004 401 105 0702 MT-GLAZE 100K JA 1/16W
R5005 401 105 0702 MT-GLAZE 100K JA 1/16W
R5011 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R5012 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R5013 401 105 0504 MT-GLAZE 1K JA 1/16W
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
13
R5014 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R5015 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R5016 401 105 1204 MT-GLAZE 120K JA 1/16W
R5017 401 105 0702 MT-GLAZE 100K JA 1/16W
R5018 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R5201 401 105 0603 MT-GLAZE 10K JA 1/16W
R5202 401 105 0603 MT-GLAZE 10K JA 1/16W
R5203 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R5207 401 105 0603 MT-GLAZE 10K JA 1/16W
R5208 401 105 0603 MT-GLAZE 10K JA 1/16W
R5211 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R5420 401 105 0603 MT-GLAZE 10K JA 1/16W
R5421 401 105 0702 MT-GLAZE 100K JA 1/16W
R5422 401 105 6001 MT-GLAZE 5.6K JA 1/16W
R5423 401 105 4205 MT-GLAZE 33K JA 1/16W
R5424 401 105 1600 MT-GLAZE 15K JA 1/16W
R5425 401 105 0603 MT-GLAZE 10K JA 1/16W
R5426 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R5427 401 105 6001 MT-GLAZE 5.6K JA 1/16W
R5428 401 105 0504 MT-GLAZE 1K JA 1/16W
R5429 401 105 0405 MT-GLAZE 100 JA 1/16W
R5430 401 105 0603 MT-GLAZE 10K JA 1/16W
R5431 401 105 7404 MT-GLAZE 8.2K JA 1/16W
(SWITCHES)
S5001 645 023 3715 SWITCH,PUSH
S5002 645 023 3333 SWITCH,PUSH 1P-1T
(FUSE)
F5001 423 030 0800 FUSE 125V 2A
(CONNECTORS)
CN501 645 024 8115 PLUG,28P (N.S.P)
CN511 645 005 0237 SOCKET,BNC 1P (N.S.P)
CN513 645 054 1070 TERMINAL 5P
CN514 645 040 6027 TERMINAL 3P
(MISCELLANEOUS)
Y5001 645 053 7189 SPACER
FLEXIBLE FLAT CABLE
W0001 645 054 1087 FLEXIBLE FLAT CABLE
LOCATION PARTS NO. DESCRIPTION
C1
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS
TABLE OF CONTENTS
OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS
OVERALL WIRING C3
OVERALL CIRCUIT BLOCK DIAGRAM C4
CA-1 CIRCUIT C5
IC101, IC102 & IC103 BLOCK DIAGRAMS C6
CA-1 CIRCUIT WAVEFORMS
CA-2 CIRCUIT WAVEFORMS
CA-2 CIRCUIT C7
CA-3 CIRCUIT C10
IC313 BLOCK DIAGRAM
CA-4 CIRCUIT C11
CA-5 CIRCUIT C12
PRINTED WIRING BOARDS (P.W.B.)
CA-1 BOARD (SIDE A & B) C13
CA-2 BOARD (SIDE A & B)
CA-3 BOARD (SIDE A & B) C14
CA-4 BOARD (SIDE A & B)
CA-5 BOARD (SIDE A & B) C15
C2
NOTES:
1. All resistance values in "OHMS" unless otherwise noted.
(K=1,000 ; M=1,000,000)
2. All capacitance values in "µF" unless otherwise noted.
p=pico farad ; µ,u or U=micro farad
3. All inductance values in "µH" unless otherwise noted.
µ,u or U=micro henry ; m=milli henry
PRODUCT SAFETY NOTICE
THE COMPONENTS DESIGNATED BY A SYMBOL ( ) IN THIS
SCHEMATIC DIAGRAM DESIGNATES COMPONENTS WHOSE
VALUE ARE OF SPECIAL SIGNIFICANCE TO PRODUCT SAFETY.
SHOULD ANY COMPONENT DESIGNATED BY A SYMBOL NEED TO
BE REPLACED, USE ONLY THE PART DESIGNATED IN THE PARTS
LIST.
DO NOT DEVIATE FROM THE RESISTANCE, WATTAGE AND VOLT-
AGE RATINGS SHOWN.
PAL-C-EX
EXPLANATORY NOTES (EXAMPLES)
Resistor 10K:1/16J means 10kilo ohm ±5%, 1/16watt max.
1M:1/10K means 1mega ohm ±10%, 1/10watt max.
Capacitor 0.047:F means 0.047micro farad, Ftype.
Electrolytic capacitor
10:16 means 10micro farad, 16volt max.
Inductor 330:J means 330micro henry ±5%
470:K means 470micro henry ±10%
No description J or K means ±5%
A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
B
C
D
E
F
G
H
I
J
K
C3
OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS
OVERALL WIRING
CN202
CN514
CN501
CN402
CN401
CN405
CN403
CN513
W3001
CN207
CN203CN203
CN102 CN302
CN105 CN205
CN303
CN404
W1002
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
***
**
*
*
*
1
2
3
4
5
6
7
8
3
2
1
3
2
1
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
1
2
3
4
5
6
7
8
9
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
28
27
26
25
24
23
22
21
1
2
3
4
5
6
7
8
1
2
3
4
5
1
2
3
4
6
5
4
3
2
1
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21 21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
1
2
3
4
5
6
7
8
9
1
2
1
2
MAIN BOARD
CA-2
LENS UNIT
REWR_1(VDD)
GND
REWR_4
REWR_6
REWR_5
REWR_3(RESET)
REWR_0(IC/VPP)
REWR_7
CA-3 BOARD
CA-1
CCD&CDS
BOARD
POWER UNIT
GND
AC24V
AC24V
GND
B(-)
A(+)
NC
GND
SET
UP
DOWN
LEFT
RIGHT
3.3V
LED-
LED+
GND
V_PHASE
GND
DC_IN
DC_IN
FOCUS
COM
ZOOM
485GND
485B
485A
GND
+5V
GND
VIDEO OUT
COM
AL_OUT
ALARM IN
GND
+5V
GND
+3.3V
RXD
TXD
GND
DC_IN
DC_GND
VIDEO_OUT
AGND
V_GRID
GND
LED(-)
LED(+)
GND
V_PHASE
GND
DC_IN
DC_IN
FOCUS
COM
ZOOM
485GND
485B
485A
GND
+5V
GND
VIDEO OUT
COM
AL_OUT
ALARM IN
NC
GND
SET
UP
DOWN
LEFT
RIGHT
3.3V
Vpp
Vdd
RESET
SCK3
SI3
SO3
HS
Vss
CA-4
CA-5
I/O BOARD
TERMINAL BOARD
ZOOM
FOCUS
COMMON
ALARM OUT
ALARM IN
GND
+5V
GND
+3.3V
NC
FILTER_A-
FILTER_A+
FILTER_B+
FILTER_B-
NC
FOCUS_B
FOCUS_B-
FOCUS_A
FOCUS_A-
ZOOM_B
ZOOM_B-
ZOOM_A-
ZOOM_A
ZOOM_VCC
ZOOM_SENSE
ZOOM_LED
IR_SW_B
IR_SW_A
DRIVE-
HALL_OUT-
HALL_IN-
HALL_OUT+
HALL_IN+
DRIVE+
FOCUS_SENSE
FOCUS_LED
FOCUS_VCC
NC
FILTER_B-
FILTER_B+
FILTER_A+
FILTER_A-
NC
FOCUS_VCC
FOCUS_LED
FOCUS_SENSE
DRIVE+
HALL_IN+
HALL_OUT+
HALL_IN-
HALL_OUT-
DRIVE-
IR_SW_A
IR_SW_B
ZOOM_LED
ZOOM_SENSE
ZOOM_VCC
ZOOM_A
ZOOM_A-
ZOOM_B-
ZOOM_B
FOCUS_A-
FOCUS_A
FOCUS_B-
FOCUS_B
3.3V
3.3V
GND
GND
A5V
AGND
A15V
GND
-7V
GND
VIDEO_OUT
AGND
AGND
RXD
M6.5V
M6.5V
MGND
MGND
3.3V
3.3V
GND
GND
A5V
AGND
A15V
GND
-7V
GND
AGND
AGND
V_GRID
TXD
M6.5V
M6.5V
MGND
MGND
3.3V
3.3V
GND
GND
A5V
AGND
A15V
GND
-7V
GND
VIDEO_OUT
AGND
AGND
RXD
M6.5V
M6.5V
MGND
MGND
3.3V
3.3V
GND
GND
A5V
AGND
A15V
GND
-7V
GND
AGND
AGND
V_GRID
TXD
M6.5V
M6.5V
MGND
MGND
3.3V
3.3V
GND
GND
XSG1
V4
V2
GND
GND
AGC_CLK
VD
CLP
GND
GND
CCDI09
CCDI07
CCDI05
CCDI03
CCDI01
GND
3.3V
3.3V
GND
XSG2
VSUB
V3
V1
GND
AGC_DATA
AGC_CS
GND
GND
ADCK_B
GND
CCDI08
CCDI06
CCDI04
CCDI02
CCDI00
GND
MGND
MGND
M6.5V
M6.5V
RS232IN
GND
AGND
AGND
AGND
GND
A15V
AGND
A5V
GND
GND
MGND
MGND
M6.5V
M6.5V
RS2320UT
LINE
AGND
VIDEO_OUT
AGND
GND
A15V
AGND
A5V
GND
GND GND
GND
A5V
AGND
A15V
GND
AGND
VIDEO_OUT
AGND
LINE
RS232OUT
M6.5V
M6.5V
MGND
MGND
GND
GND
A5V
AGND
A15V
GND
AGND
AGND
AGND
GND
RS232IN
M6.5V
M6.5V
MGND
MGND
GND
CCDI00
CCDI02
CCDI04
CCDI06
CCDI08
GND
ADCK_B
GND
GND
AGC_CS
AGC_DATA
GND
V1
V3
VSUB
XSG2
GND
3.3V
3.3V
GND
CCDI01
CCDI03
CCDI05
CCDI07
CCDI09
GND
GND
CLP
VD
AGC_CLK
GND
GND
V2
V4
XSG1
GND
GND
3.3V
3.3V
RXD
TXD
GND
DC_IN
DC_GND
VIDEO OUT
AGND
V_GRID
GND
VIDEO_OUT
GND
VIDEO_OUT
GND
W1-11800/L5AD2-XE
A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
B
C
D
E
F
G
H
I
J
K
C4
OVERALL CIRCUIT BLOCK DIAGRAM
A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
B
C
D
E
F
G
H
I
J
K
C5
CA-1 CIRCUIT
IC102
C1111
C1108
D1101
C1113
R1102
R1101
L1101
R1113
R1104
R1134
Q1101
Q1102
R1105
C1115
C1117
R1106
C1118
R1118
R1124
R1117
R1116
C1001
C1003
C1002
C1010
C1012
C1015
C1009
IC103
L1001
C1005
L1004
R1013
C1125
C1021
C1014
C1013
C1008
C1007
C1006
C1004
R1017
R1016
R1015
R1014
R1006
R1005
C1016
L1003
R1003
R1001
R1004
TP100
C1135
C1137
C1139
C1134
C1136
C1138
C1116
C1024
R1141
CN105
CN102
R1028
R1027
R1026
C1011
R1202
R1203
D1302
C1302
R1303
R1304
D1301
IC131
R1207
C1201
IC121
IC122
C1202
R1204
R1201
R1206
R1301
R1071
R1072
R1073
R1074
R1075
R1076
R1077
R1078
R1079
R1080
R1311
R1312
W1002
TP102
TP101
CXD1267AN
1;35-T
22;16
DSH015
0.1;F
100K
82K
12;J
3.9K
0
0
2SK443AJ6
2SC4399
2.7K
0.01;B
0.01;B
1M
3.3;25-T
0
0
0
0
0.1;F
4.7;6.3-T
4.7;6.3-T
1.0
0.1;F
0.1;F
0.1;F
*
*
*
AD9848A
10;J
0.1;F
10;J
0
0.1;F
0.1;F
0.1;F
0.1;F
0.1;F
0.1;F
0.1;F
0.1;F
0
0
0
0
0
0
47;6.3
10;J
10
10
0
GND
0.1;F
0.1;F
0.1;F
3.3;20-T
3.3;25-T
4.7;6.3-T
2200P
0.1;F
0
*
*
0
0
33
1.0
1K
33
DSH015
1000P
10K
100K
DSH015
TC7S14FU
0
0.1
TC7SH08FU
TC7SET08FU
0.1
1M
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
*
VIDEO OUT
VIDEO OUT
V,SUB DRIVER
CDS,AGC,A/D
20
19
18
17
16
15
14
13
12
11
1
2
3
4
5
6
7
8
9
10
1234567
891011121314
VOUT
H2
V4 V3 V2 V1 NC
GND
VDD
GND
VSUB
VL
RG
H1
48
47
46
45
44
43
42
41
40
39
38
37
13
14
15
16
17
18
19
20
21
22
23
24
36 35 34 33 32 31 30 29 28 27 26 25
123456789101112
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
4
5
3
2
1
VCC
GND
1
2
3
5
4
GNDGND
4
5
3
2
1
1
2
V2
V1
XSG1
V3
XSG2
V4
VSUB
3.3V
A15V
-7V
CCDI9
CCDI8
CCDI7
CCDI6
CCDI5
CCDI4
CCDI3
CCDI2
CCDI1
CCDI0
AGC_CS
M_A_O_CLK
M_A_O_DATA
ADCK_B
VD
CLP
MGND
A5V
A15V
M6.5V
M6.5V
M6.5V
M6.5V
A5V
3.3V
3.3V
CLP
A15V
VD
VSUB
XSG1
XSG2
V1
V2
V3
V4
ADCK_B
AGC_CS
M_A_O_CLK
M_A_O_DATA
CCDI9
CCDI8
CCDI7
CCDI6
CCDI5
CCDI4
CCDI3
CCDI2
CCDI1
CCDI0
3.3V
A5V
A15V
-7V
M6.5V
M6.5V
-7V
A15V
A5V
3.3V
MGND
3.3V
RS232_IN
RS232_OUT
V_GRID
LINE
3.3VA5V
VIDEO OUT
RXD
TXD
V_GRID
LINE
RS232_OUT
VIDEO OUT
RS232_IN
TXD
RXD
CPP3
VH
DCIN
XSHT
XV2
XV1
XSG1
XV3
XSG2
XV4
VM
VL
VSHT
DCOUT
CPP2
CPP1
CT-B2
CE-C
CT-A
SL
REFT
REFB
CMLEVEL
AVSS2
AVDD2
BYP3
CCDIN
BYP2
BYP1
AVDD1
AVSS1
D0
D1
D2
D3
D4
DVSS2
DVDD2
D6
D5
D7
D8
D9
NC
NC
DVDD3
DVSS3
HD
VD
PBLK
HBLK
CLPDM
CLPOB
SCK
SDI
H1
H2
DVSS0
DVDD0
H3
H4
DVSS1
RG
DVDD1
AVSS0
CL1
AVDD0
GND
CCDI01
CCDI03
CCDI05
CCDI07
CCDI09
GND
GND
CLP
VD
AGC_CLK
V2
XSG1
3.3V
GND
AGND
GND
GND
M6.5V
A15V
GND
XSG2
V3
GND
AGC_CS
VSUB
GND
CCDI06
CCDI02
GND
CCDI08
CCDI04
CCDI00
ADCK_B
AGC_DATA
V1
GND
3.3V
3.3V
GND
A5V
AGND
GND
AGND
VIDEO OUT
AGND
LINE
RS232OUT
M6.5V
MGND
MGND
MGND
MGND
M6.5V
M6.5V
RS232IN
AGND
AGND
AGND
A15V
A5V
GND
3.3V
GND
GND
GND
V4
GND
GND
GND
3.3V
3.3V
GND
GND
A5V
AGND
A15V
GND
-7V
GND
VIDEO OUT
AGND
AGND
RXD
M6.5V
M6.5V
MGND
MGND
MGND
MGND
M6.5V
M6.5V
TXD
V_GRID
AGND
AGND
GND
-7V
GND
A15V
AGND
A5V
GND
GND
3.3V
3.3V
IC101
VIDEO OUT
GND
14.6
14.6
3.2
0.1
3.2
3.0
3.2
3.0
-6.7
-6.7
-0.2
-0.2
-7.10.1
-6.7
-6.7
-0.2
-0.2
2.4
2.6
13.2
14.5
10.5
9.7
3.2
2.2
1.2
1.7
3.3
0.5
1.5
1.1
1.2
-7.1
9.9
14.9
6.8
CCD
TO CA-2
CN205
TO CA-3
CN302
TO CA-4
CN404
CA-1
C1-11800/L5AD2-XE
ICX279
A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
B
C
D
E
F
G
H
I
J
K
C6
Charge Pump
CPP3
V
H
DCIN
XSHT
XV2
XV1
XSG1
XV3
XSG2
XV4
CPP1
CPP2
DCOUT
VSHT
V
L
V
M
V 4
2
3
4
5
6
7
8
9
10 11
12
13
14
15
16
17
18
19
20
1
CXD1267AN
IC101 BLOCK DIAGRAM (ICX279) IC102 BLOCK DIAGRAM (CXD1267AN)
CA-2 CIRCUIT WAVEFORMS
WAVEFORM
TEST POINT
LOCATION
WAVEFORM
TEST POINT
LOCATION
IC101-1
2V/div
20 s/div
V4
IC101-2
5V/div
20 s/div
V3
IC101-3
5V/div
20 s/div
V2
IC101-12
2V/div
50ns/div
RG
IC103-43
2V/div
20 s/div
VD
IC101-13
2V/div
50ns/div
H1
IC101-14
2V/div
50ns/div
H2
IC103-44
2V/div
10ms/div
HD
IC101-4
5V/div
20 s/div
V1
WF-CA1-L54W2US
IC103-29
CA-1 CIRCUIT WAVEFORMS
TEST POINT
LOCATION WAVEFORM
IC215-4
200mV/div
10 s/div
CA OUT
IC215-2
200mV/div
10 s/div
YA OUT
WF-CA2-L54W2US
CDS PxGA VGA ADC
CLAMP CLAMP
VREF
HORIZONTAL
DRIVERS
PRECISION
TIMING
CORE
TM
INTERNAL
CLOCKS
10 or 12
VRT VRB
DOUT
CCDIN
CL1
RG
H1-H4
SYNC
GENERATOR
INTERNAL
REGISTERS
SL SCK SDATA
HD VD
PBLK
CLPDM
CLPOB
4–6 dB 2 to 36 dB
AD9848
IC103 BLOCK DIAGRAM (AD9848A)
A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
B
C
D
E
F
G
H
I
J
K
C7
CA-2 CIRCUIT
D2140
C2143
R2165
R2164
IC233
R2163
R2016
L2003
F2001
C2027
C2028
C2004
R2003
L2001
R2004
C2026
R2006
R2002 R2001
IC208
C2007
C2006
C2002
C2001
C2005
R2015
R2011
R2012
R2013
R2014
R2010
C2003
R2009
R2005
C2012
C2011
IC202
C2013
R2029
X2001
CT202
IC205
C2020
C2008
C2023
C2022
R2026 R2028
D2002
C2018
C2017
R2022 C2016R2021
D2001
C2015
C2014
R2020
Q2004
R2024
R2023
C2021
Q2001
R2019
IC203
IC206
L2002
Q2003
Q2006
IC201
IC231
IC234
C2053
C2058
R2058
C2052
L2055
R2055
C2051
Q2055
R2075
C2067
R2071
R2072
R2074
R2073
L2059
C2068
Q2057
Q2056
C2066
Q2058
C2056
R2059
R2061
R2060
R2062R2063
R2066
C2063 R2070
C2061
C2060
C2057
L2058
C2059
R2056
R2054
R2386
R2385
R2383
R2384
R2381
R2380
R2370
R2351
R2349
R2347
R2343
R2344
R2345
R2372
R2371
R2373
R2374
R2375
R2348
R2215
R2206
R2183
R2178
R2179
C2303
C2304
C2305
C2307
C2306
C2325
R2378
L2305
C2301
C2302
R2337
C2040
F2002
L2040
C2152
R2224
C2150
C2151
L2142
R2379
C2319
C2320
C2322
IC232
R2162
C2140
C2308
C2309
C2312
C2313
L2302
C2310
C2311
L2301
C2317
R2417
R2416
R2415
R2414
R2410
R2411
R2412
R2413
R2409
R2408
R2124
IC227
R2112
C2098
VR202
R2115 R2114
R2111
VR203
R2110
R2108
R2109
R2107
IC223
R2083
C2086
R2084
R2082
C2084
R2085
Q2086
R2106
R2104
R2103
C2095
R2105
IC225
R2100
R2101
R2098 C2093
R2099
C2087
R2096
R2097
R2087
R2405
R2406
R2407
R2401
R2402
R2403
R2404
R2422
R2420
R2419
R2418
L2304
C2321
C2318
L2303
R2339
R2338
C2315
R2053
R2076
C2147
CN202
IC221
C2081
R2080
C2080
C2078
C2096
C2082
C2083
C2108
C2099
C2107
C2115
CN203
Q2450
Q2451
R2454
C2090
R2093
R2453
R2451
R2452
R2450
R2457
R2456
R2116
R2113
C2450
C2146
C2145
C2144
C2149
C2148
L2140
C2092
C2142
R2095
R2094
L2083
C2019
C2316
C2314
X2140
CT201
Q2060
Q2059
R2064
R2065
L2057
C2055R2057
R2210 R2209
C2324
CN205
R2391
L2306
R2392
R2390
C2331
C2330
C2332
C2333
IC236
R2394
R2395
TP202
TP221
R2360
R2252
R2032
R2031
R2030
R2141
C2094 C2079
R2048
C2071
C2072 C2062
R2067
C2070
Q2087
R2092
C2089
C2088
R2352
R2166
R2167
R2088
R2045
R2205
R2102
R2187
R2189
R2226
C2030
TP201
C2091
TP200
IC215
L2082
IC252
C2502
IC251
CT252
X2501
R2501
C2501
CN207
IC228IC229
R2125
R2126
R2127
R2128
R2151
R2152
R2153
R2154
R2155
R2129
R2131
R2117
R2120
R2119
R2122
R2121
C2102
C2103
C2104
C2105
C2106
R2118
R2144
R2156
C2114
C2113
C2111
C2110
C2109
R2132
R2157
R2158
R2159
R2137
R2136
R2135
R2134
C2100
C2101
C2157
R2142
R2143
TP203
R2148
R2149
R2147
R2146
R2502
R2191 R2192
R2177
R2458
R2169
R2168
Q2088
R2462
R2461
DSH015
10;6.3-T
4.7K
10K
S80830CNUA
10K
10K
47;J
0.1;B
0.1;B
0.1;F
39K
10;J
1M
4.7;10-T
100K
10K 120K
LA6358NM
0.01;B
0.01;B
0.1;F
1;25-T
4.7;25-P
100K
4.7K
4.7K
180
4.7K
220K
4.7;25-P
120K
470P
0.1;B
10;6.3-T
TC7SU04FU
0.1;B
1M
30P
TC7SU04FU
0.1;B
0.1;B
1000P;B
1000P;B
10K 100K
4.7;25-T
1;F
33K 1000P;B
100K
MA365(E)
0.01;B
1M
DTA114EUA
10K
3.3
10;6.3-T
DTA114EUA
47K
TC7S04FU
TC7S04FU
DTC114EUA
DTC114EUA
22P;CH
MA365(E)
*
*
SCCC0030A
**
uPD70F3015BYGC-8EU
UPD6462GS
*
22P;CH
10;10-T
1K
22P;CH
22;J
1K
22P;CH
2SA1576A(R)
3.3K
0.01;B
1K
47K
1.5K
47K
68;J
22P;CH
2SC4081(R)
2SA1576A(R)
0.1;B
2SC4081(R)
47;6.3
47
100K
180K
1K680
1K
0.01;B 0
0.1;B
4.7;10-T
4.7;10-T
10;J
10;10-T
0
1K
0
0
0
0
0
0
33
33
0
33
33
33
33
33
33
33
33
0
33
0
0
0
0
0
0.1;B
0.1;B
0.1;B
0.1;B
0.1;B
0.1;B
0
10;J
10;6.3-T
0.1;B
0
4.7;6.3-T
470P
10;J
10;6.3-T
100K
10;6.3-T
0.1;B
10;J
0
0.1;B
10;6.3-T
0.1;B
AT24C16
0
0.1;B
0.1;B
0.1;B
0.1;B
10;6.3-T
10;J
0.1;B
10;6.3-T
10;J
0.1;B
0
0
0
0
0
0
0
0
0
0
0
LA6358NM
100K
470P;B
47K
100K 15K
22K
10K
4.7K
47K
1K
3.9K
NJM3414AM
12K
4700P;B
120K
0
0.1;B
10K
TIMZ1
2.2K
3.3K
5.6K
0.1;B
*
2.2K
LA6358NM
4.7K
10K
10K 0.01;B
120K
0.1;B
0
0
2.7K
0
0
0
0
0
0
0
0
0
0
0
10;J
10;6.3-T
10;6.3-T
10;J
0
0
0.1;B
33
33
0.1;B
*
TC7S08FU
0.1;B
47K
0.1;B
470P;B
0.1;B
10;10-T
0.1;B
0.1;B
0.1;B
10;10-T
10;10-T
*
DTC115EU
DTC115EU
33
0.1;B
1.2K
100K
100K
5.6K
5.6K
390
390
10K
10K
0.1;B
0.1;B
10;6.3-T
0.1;B
0.1;B
10;6.3-T
10;J
10;10-T
0.1;B
2.7K
2.2K
10;J
10;6.3-T
0.1;B
0.1;B
CSTCW20M0S1
30P
2SA1576A(R)
2SA1576A(R)
0
1.2K
10;J
560
4.7K 4.7K
0.1;B
*
10K
10;J
0
0
0.1;B
10;6.3-T
10;6.3-T
0.1;B
HY57V161610DTC-7
*
0
0
*
*
0
0
100
100
0
56
0.1;B 10;10-T
68
22;6.3-T
100;6.3 1;25-T
1M
10;10-T
*
TIMZ1
6.8K
10;10-T
0.1;B
33
0
10K
2.2K
100
4.7K
22K
1.5K
1.5K
100
6P
*
0.01;B
8.2K
5.6;J
10P
BA7664FV
10;J
TC7S04FU
12P
TC7SU04FU
30P
1M
0.1;B
*
uPD16879uPD16879
0
0
0
0
0
0
0
0
0
4.7
4.7
0
0
0
100K
100K
68P;CH
1000P;B
1000P;B
1000P;B
1000P;B
0
0
0
1000P;B
1000P;B
1000P;B
1000P;B
68P;CH
0
0
0
0
0
0
0
0
10;10-T
0.1;B
0.1;B
100K
100K
*
4.7
4.7
4.7
4.7
0
0 0
0
1K
4.7
4.7
*
UMH10N
0
0
RESET
14MHZ VCO LPF
14MHZ OSC
14MHZOSC
CT-A
EEPROM
14.18750MHZ
14MHZ
GND
YC-MIX,75DRIVER
17MHZOSC
17.734475MHZ
321
1
2
3
45
6
7
8
VCC
GND
1
2
3
5
4
4
5
3
2
1
GND
VCC
VCC
GND
4
5
3
2
1
VCC
GND
1
2
3
5
4
GND
VCC
116 61 60 59 115 58 164 114 163 57 113 162 112 56 161 55 111 160 54 176 159 174 175 53 52 110 158 109 51 157 108 50
8889302987281408613927851388426137258313624170135168169232282134812113380201327919131781301291877171676
62
1
2
63
3
117
118
64
119
4
65
120
5
66
121
6
67
122
68
7
8
165
166
123
167
9
124
69
10
125
70
11
126
71
12
127
72
128
13
73
14
15
74
75 31
90
141
91
33
32
142
92
143
34
93
144
35
94
145
36
95
146
96
37
38
171
172
147
173
39
148
97
40
149
41
98
150
99
42
151
100
152
43
101
44
45
103
102
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
12345678910111213141516171819202122232425
51525354555657585960616263646566676869707172737475
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
156 107 49 155106 154 153 48 105 47 46 104
5
6
7
8
4
3
2
1
1234
8765
1234
8765
123
654
5678
4321
1
2
3
4
5
6
7
8
1
2
3
5
4
GND
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
61
62
63
64
65
66
67
68
69
70
456
321
4
3
2
18
7
6
5
GND
YIN
CIN
MUTEA
MUTEB
OUT2
OUT1
Vcc
4
5
3
2
1
VCC
GND
1
2
3
5
4
GND
VCC
1
2
3
4
5
6
22
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
2020
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
456
321
CKI2
CKI1
PCOHD
3.3V
A15V
PCOVD
PLLCTL2
CCDI0
CCDI1
CCDI2
CCDI3
CCDI4
CCDI5
CCDI6
CCDI7
CCDI8
CCDI9
MDAO_DATA
MDAO_CLK
AGC_CS
ADCK_B
V4
V3
V2
V1
XSG2
XSG1
VSUB
VDO2
CCDI9
CCDI8
CCDI7
CCDI6
CCDI5
CCDI4
CCDI3
CCDI2
CCDI1
CCDI0
ADCK
CLP
V1
V2
V3
V4
XSG2
VSUB
XSG1
CAOUT
YAOUT
A5V
RDATA0
RDATA1
RDATA2
RDATA3
RDATA5
RDATA4
RDATA6
RDATA7
RDATA8
RDATA9
RDATA10
RDATA12
RDATA11
RDATA13
RDATA14
ADR0
RDATA15
ADR1
ADR3
ADR2
ADR4
ADR5
ADR7
ADR6
ADR8
ADR9
ADR11
ADR10
RCLK
ZRASR
ZWER
ZCASR
ZCSR
DQMR
YAOUT
CAOUT
ADRB7
SWRG
ADRB6
ADRB5
ADRB3
ADRB4
ADRB2
ADRB1
DB7
ADRB0
DB6
DB5
DB3
DB4
DB2
DB0
DB1
ASTB
ZDSTB
RZW
FLDO
LINE
CKI2
CKI1
PCOVD
PCOHD
OSD1
OSD2
VSYNC
HSYNC
VDO1
MDAO_DATA
MDAO_CLK
RS232_IN
RS232_OUT
OSD_CS
REWR_0
ZOOM_SENS
FOCUS_SENS
M_RESET
M_LATCH
OSD_CS
MDAO_DATA
MDAO_CLK
ADRB0
ADRB1
ADRB2
ADRB4
ADRB3
SWRG
ADRB7
ADRB6
ADRB5
DB1
DB0
DB2
DB3
DB7
DB6
DB4
DB5
ASTB
RZW
ZDSTB
HSYNC
VSYNCOSD1
OSD2
LSI_RESET
REWR_3
AGC_CS
ADCK_B ADCK
CLPCLP_B
3.3V
3.3V
3.3V
3.3V
3.3V
LSI_RESET
3.3V
FLDO
VDO1
REWR_0
REWR_1
REWR_3
REWR_4
REWR_5
REWR_6
REWR_7
REWR_7
REWR_5
REWR_6
REWR_4
REWR_1
3.3V
M6.5V
AFB+
AFB-
AFA-
AFA+
ZOOMA-
ZOOMB-
ZOOMB+
ZOOMA+
IG_DRIVE+
IG_DRIVE-
IG_DRIVE-
IG_DRIVE+
HALL_OUT-
HALL_OUT+
HALL_OUT+
HALL_OUT-
3.3V
3.3V
IRIS_CTL
PLLCTL1
A5V
3.3V
VIDEO_OUT
IRIS_CTL
RCLK
RCLKE
ADR11
3.3V
DQMR
DQMR
ADR10
ZWER
ZCASR
ZRASR
ZCSR
ADR0
ADR1
ADR2
ADR3
RDATA7
RDATA6
RDATA5
RDATA4
RDATA3
RDATA2
RDATA1
RDATA0
ADR4
ADR5
ADR6
ADR7
ADR8
ADR9
RDATA8
RDATA9
RDATA10
RDATA11
RDATA12
RDATA13
RDATA14
RDATA15
FOCUS_SENS
ZOOM_SENS
PLLCTL2
PLLCTL1
A15V
CLP_B
3.3V
3.3V
A5V
M6.5V
M6.5V
M6.5V
M6.5V
A15V
A5V
RS232_IN
AGND
MGND
AGND AGND AGND AGND
AGND
AGNDAGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND AGND AGND
AGND
AGND AGND
MGND
MGND
AGND
AGND AGND
AGND
AGND
AGND
AGND
AGND AGND
AGND
AGND
AGNDAGND
AGND
AGND
AGND
OSDCK
AGND
OSDCK
AGND
AGND AGND
VDO2
VIDEO_OUT
LINE
RS232_OUT
FILTERA-
FILTERA+
FILTERB+
FILTERB-
M_RESET
M_OSC
MDAO_CLK
MDAO_DATA
DN_LATCH
M_RESET
M_OSC
M_OSC
MDAO_CLK
MDAO_DATA
M_LATCH
ZOOMA+
ZOOMA-
ZOOMB+
ZOOMB-
AFA+
AFA-
MGND
FILTERB+
FILTERB-
FILTERA-
FILTERA+
MGND
MGND
MGND
MGND
AFB+
AFB-
MGND
MGNDMGND
VDO1 VDO1
MGND
MGND
DN_LATCH
DN_SENS
DN_SENS
AGNDAGND
MGND MGND
MGND
MGND
MGND
MGND
MGND
MGND
MGNDMGND
MGND
MGND
MGND
MGNDMGND
MGNDMGND
CT-A
GND
VDD
OUT
CT-A
CT-A
NP-B
(NP-C)
CT-B2
CT-A
(2125)
CT-A
VDD
RAMDATA0
RAMDATA1
RAMDATA2
RAMDATA3
RAMDATA4
RAMDATA5
RAMDATA6
RAMDATA7
RAMDATA8
VDD
GND
RAMDATA9
RAMDATA10
RAMDATA11
RAMDATA12
RAMDATA13
RAMDATA14
RAMDATA15
ADR0
ADR1
VDD
GND
ADR2
ADR3ADR3
ADR4
ADR5
ADR6
ADR7
ADR8
ADR9
VDD
GND
ADR10
ADR11
RAMCK
ZRASR
ZCASR
ZWER
ZCSR
CKER
DQM
GND
VDD
GND
GND
CCDI0
CCDI1
CCDI2
CCDI3
CCDI4
CCDI5
CCDI6
CCDI7
CCDI8
CCDI9
AMC
GND
VDD1
ADCK
SHD
SHP
CLP
CLPOB
PBLK
GND
VDD1
V1
V2
V3
V4
XSG1
XSG2
VSUB
GNDGND
H1
H2
RG
GND
VDD1
GND
PLLMODE
GND
AVDD
AGND
DPVDD
GND
GND
VDD
CKI1
SCK
CKI2
GND
HRST
VRST
PCOHD
PCOVD
GND
DMYHD
FLDO
VDO
GND
ZCS
RZW
ZDSTB
ASTB
CPUCK
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
VDD
GND
ADRB0
ADRB1
ADRB2
ADRB3
ADRB4
ADRB5
ADRB6
ADRB7
OSD1
OSD2
HSYNC
VSYNC
BUNRI
VDD
SWRG
GND
GND
GND
VDD2
CKSCICKSCI
CKSCO
GND
SCO
EXTSCI
ADJSCI
PCOSC
VDD2
GND
GND
AGND
CAOUT
AVDD
GND
ATSMD0
ZRST
DYC0
DYC1
DYC2
DYC3
DYC4
DYC5
DYC6
DYC7
DYCCKDYCCK
VDD
AGND
YAOUT
AVDD
GND
VDD
ATSMD1
BUNRI
TESTO
SIN
SMC
TMC2
TMC1
GND
GND
MPU
RC1
GND
MTR/DNMTR/AGC/OSD_CLK
RS232_OUT
VDD
VSS
MTR_OSC(5MHz)
DN_SENS
OSD_CS
IRIS_CTL
IC/VPP
AD5
MTR/DNMTR/AGC/OSD_DATA
AD0
AD1
AD3
DB4
DB5
DB7
VDD
PLLCtrl2
ZOOM_SENS
FOCUS_SENS
M_RESET
M_LATCH
VSS
ALARM_IN
HOLE IN
RESET_IN
OPEN
VDD
XIN
XOUT
VSS
OPEN
RZW
DSTB
ASTB
DB0
DB1
DB2
DB3
OP1(NTSC/PAL)
OP2
GND
GND
GND
GND
GND
GND
GND
VDO
FLDO
C/BW_SW
REWR_4
REWR_5
REWR_6
AGC_CS
DB6
VSS
VDD
VDDRS232_IN
AD2
SWRG
(NC)
AD4
AD6
AD7
PLLCtrl1
ALARM_OUT
(NC)
(NC)
(NC)
(NC)
(NC)
REWR_7
CLK
CS
DATA
PCL
VDD
CKOUT
OSCOUT
OSCIN
TEST
GND
HSYNC
VSYNC
VB
VG
VR
VC2
BLNK2
VBLNK
VC1
BLNK1
CE-C
CT-A
CT-A
CT-A
SDA
SCL
VCC
TEST
GND
A2
A0
A1
Vcc
GND
Vcc
GND
GND
Vcc
REWR_1(VDD)
GND
REWR_4
REWR_6
REWR_5
REWR_3(RESET)
REWR_0(IC/VPP)
REWR_7
FOCUS_SENSE
DRIVE+
HALL_IN+
HALL_OUT+
HALL_IN-
HALL_OUT-
DRIVE-
IR_SW_A
IR_SW_B
ZOOM_LED
ZOOM_SENSE
ZOOM_VCC
ZOOM_A
ZOOM_A-
ZOOM_B-
ZOOM_B
FOCUS_A-
FOCUS_A
FOCUS_B-
FOCUS_B
(NC)
(NC)
(NC)
(NC)
MTR_VD
(NC)
EEPROM_DATA
EEPROM_CLK
LSI
RESET
(NC)
(NC)
(NC)
(NC)
(NC)
GND
CCDI02
CCDI06
GND
VSUB
AGC_CS
GND
V3
XSG2
GND
A15V
M6.5V
GND
GND
AGND
GND
3.3V
XSG1
V2
AGC_CLK
VSS
A4
A5
A6
A7
A8
A9
NC
CKE
CLK
UDMQ
NC
VDDQ
DQ8
DQ9
VSSQ
DQ10
DQ11
VDDQ
DQ12
DQ13
VSSQ
DQ14
DQ15
VSS
VDD
A3
A2
A1
A0
A10
A11
CS
RAS
CAS
WE
LDQM
VDDQ
DQ7
DQ6
VSSQ
DQ5
DQ4
VDDQ
DQ3
DQ2
VSSQ
DQ1
DQ0
VDD
VD
CLP
GND
GND
CCDI09
CCDI07
CCDI05
CCDI03
CCDI01
GND
GND
GND
GND
V4
GND
GND
GND
3.3V
GND
A5V
A15V
AGND
AGND
AGND
RS232IN
M6.5V
M6.5V
MGND
MGND
MGND
MGND
M6.5V
RS232OUT
LINE
AGND
VIDEO OUT
AGND
GND
AGND
A5V
GND
3.3V
3.3V
GND
V1
AGC_DATA
ADCK_B
CCDI00
CCDI04
CCDI08
CT-A
(NC)
C/BW_AUTO
(NC)
(NC)
NC
FILTER_B-
FILTER_B+
FILTER_A+
FILTER_A-
NC
FOCUS_VCC
FOCUS_LED
LGND
COSC
FILA
FILB
FILC
FILD
VREF
VDD
VM3
D2
FBD
RESET
OSCOUT
OSCIN
SCLK
SDATA
LATCH
VD
VD
B2
FBB
D1
VM4
C2
FBC
C1
EXP0
EXP1
VREFS
B1
VM2
A2
FBA
A1
VM1
EXTB
EXTA
PGNDPGND
EXTA
EXTB
VM1
A1
FBA
A2
VM2
B1
VREFS
EXP1
EXP0
C1
FBC
C2
VM4
D1
FBB
B2
VD
VD
LATCH
SDATA
SCLK
OSCIN
OSCOUT
RESET
FBD
D2
VM3
VDD
VREF
FILD
FILC
FILB
FILA
COSC
LGND
DN_LATCH
C/BW_OUT
(NC)
(1608)
(1608)
(1608)
(1608)
(1608)
(1608)
(1608)
(1608)
(1608)
(1608)
AF/ZOOM CTLDAY/NIGHT CTL
(1608)
(1608)
(1608)
(NC)
(NC)
(1608)
(1608)
(1608)
(1608)
2.5
3.1
1.5
4.4
1.0
2.0
2.2
5.0
2.0
2.4
3.3
3.3
ASIC
ON-SCREEN
SDRAM
TO CA-1
CN105
TO LENS UNIT
TO LENS UNIT
CA-2
C2-11800/L5AD2-XE
Other manuals for VCC-ZM400P
1
Table of contents
Other Sanyo Color Camera manuals
