Sanyo VDC-C1572FP User manual

INSTRUCTION MANUAL
COLOUR CCD CAMERA
B/W CCD CAMERA
This Instruction Manual applies to the following four models.
Diese Bedienungsanleitung ist für die folgenden vier Modelle.
Ce manuel d’instructions s’applique aux quatre modèles suivants.
SURFACE TYPE
NORMALE AUSFÜHRUNG
TYPE EN SURFACE
VDC-C1572FP (Colour High Resolution)
VDC-C1572FP (Farbe, hohe Auflösung)
VDC-C1572FP (Haute résolution en couleurs)
VDC-C1572FP
VDC-B1512FP (Black & White)
VDC-B1512FP (Schwarzweiß)
VDC-B1512FP (Noir et blanc)
VDC-B1512FP
IN-CEILING TYPE
AUSFÜHRUNG FÜR DECKENEINBAU
TYPE ENCASTRÉ
VDC-C2572FP (Colour High Resolution)
VDC-C2572FP (Farbe, hohe Auflösung)
VDC-C2572FP (Haute résolution en couleurs)
VDC-C2572FP
VDC-B2512FP (Black & White)
VDC-C2572FP (Schwarzweiß)
VDC-C2572FP (Noir et blanc)
VDC-C2572FP
About this manual
•Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for later reference.
Über diese Bedienungsanleitung
•Lesen Sie bitte vor der Montage und dem Inbetriebnehmen der Kamera
zuerst diese Bedienungsanleitung sorgf ltig durch und bewahren Sie sie
zum sp teren Nachschlagen auf.
A propos de ce manuel
•Avant d’installer et d’utiliser la caméra, veuillez lire ce manuel
attentivement. Gardez-le à portée de main pour toute référence ultérieure.
4
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10

CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4, 5
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ACCESSORY
•
••
•Hexago al Wre ch for dome cover. . . . . . . . . . . . 1 pc.
•
••
•Hexago al Wre ch for le s replaceme t . . . . . . . 1 pc.
•
••
•Focal le gth 8 mm le s . . . . . . . . . . . . . . . . . . . . . 1 pc.
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10
English 1

PRECAUTIONS
I case of problem
Do not use the camera if smo e or a strange odour comes from the
unit, or if it seems not to function correctly. Disconnect the power
cord immediately, and consult your dealer (or a Sanyo Authorized
Service Centre).
Do ot ope or modify
Do not open the cabinet, as it may be dangerous and cause
damage to the unit. For internal settings and repairs, consult your
dealer (or a Sanyo Authorized Service Centre).
Do ot put objects i side the u it
Ma e sure that no metal objects or flammable substance get inside
the camera. If used with a foreign object inside, it could cause a
fire, short-circuits or damages.
If water or a liquid gets inside the camera, disconnect the power
cord immediately, and consult your dealer (or a Sanyo Authorized
Service Centre). Be careful to protect the camera from rain, sea
water, etc.
Be careful whe ha dli g the u it
To prevent damages, do not drop the camera or subject it to strong
shoc or vibration.
I stall away from electric or mag etic fields
If installed close to a TV, radio transmitter, magnet, electric motor,
transformer, or audio spea ers the magnetic field they generate will
distort the image.
Protect from humidity a d dust
To prevent damage to the camera, do not install it where there is
greasy smo e or steam, where the dampness may get too high, or
where there is a lot of dust.
Protect from high temperatures
Do not install close to stoves, or other heat generating devices, such
as spotlights, etc., or where it could be subject to direct sunlight, as
that could cause deformation, discoloration or other damage.
Be careful when installing close to the ceiling, in a itchen or boiler
room, as the temperature may rise to high levels.
Install where the temperature range will stay between –10°C and
50°C. (no condensation)
Clea i g
Dirt can be removed from the housing by wiping it with a soft cloth. To
remove stains, wipe with a soft cloth moistened with a soft detergent
solution and wrung dry, then wipe dry with a dry soft cloth.
Do not use benzine, thinners or other chemical products on the
housing, as they may cause deformation and paint peeling. Before
using a chemical cloth, ma e sure to read all accompanying
instructions. Ma e sure that no plastic or rubber material comes in
contact with the housing for a long period of time, as that may
cause damage or paint peeling.
Mou ti g Surface
The mounting surface material must be strong enough to secure
the camera.
Plaster- board without a bac ing plate is not recommended.
ENGLISH
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10
2 English

INSTALLATION
Mai u it i stallatio
•Preparatio
Ma e four or more holes in the ceiling or wall for the screws that
are to be used to secure the main unit. If embedding the input
power wire and video out cable, ma e a hole for these cables to be
passed through also.
•Mai u it i stallatio
1Use the accessory Allen ey to remove the four screws (B) that
are securing the dome assembly (A).
2Insert the foam gas et (C) in between the housing and the
installation surface.
3Pass the input power wire (E) and video out cable (D) through
the hole made for that purpose.
4Align the housing assembly (F) with the screw holes that have
been prepared, and then secure it by tightening the four or
more screws (G) (4 mm diameter screws recommended).
5Determine the lens position in accordance with the location of
the objects to be viewed, and then tighten it in that position.
(Refer to page 4 for lens adjustment details.)
6Align the viewing window (H) with the lens position.
7Return the dome assembly (A) to its original position and secure it.
*(E) Input power wires: 12 V DC 50 Hz
Mou ti g Screws (4)
Video Out
Cable
Electrical
Box
Foam
Gasket
I put Power
Wires
Housi g
assembly
I -ceili g Type
Housi g
assembly
Security
Screws (4)
Dome
assembly
Viewi g
Wi dow
Dome assembly i stallatio
Camera/VRB
assembly
Surface Type
Electrical Box
Foam Gasket
Housi g
assembly
Mou ti g Screws (4)
(A)
(F)
(C)
(F)
(B)
(C)
(E)
(D)
(F)
(H)
(G)
72 mm φ
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10
English 3

ADJUSTMENT
These adjustme ts are for
color cameras.
•The switch positions in the above
figure are the factory presets for the
color standard model.
(For color high resolution model, the
factory setting position of MIRIS (3)
is ON.)
•B/W cameras have the variable
resister (V.R.) for Line loc and Level
as the color cameras.
ADJUSTMENTS DIP SWITCH
1234 5 678
FLICKERLESS ON (1/100 sec.) ON
FLICKERLESS OFF (1/60 sec.) OFF
BACKLIGHT COMPENSATION OFF ON
BACKLIGHT COMPENSATION ON OFF
MECHANICAL IRIS ON
ELECTRONIC IRIS OFF
120 IRE USER SETTING ON
100 IRE SETTING OFF
AGC 26 dB MAXIMUM ON
AGC 20 dB MAXIMUM OFF
AUTO TRACKING WHITE BALANCE OFF OFF OFF
AUTO WHITE BALANCE OFF ON OFF
PUSH LOCK OFF ON ON
INDOOR (3200°K) ON OFF OFF
OUTDOOR (6500°K) ON ON ON
4200°K ON OFF ON
4700°K ON ON OFF
LINE LOCK Nor available
LEVEL Use the V.R. to adjust if the backlight compe satio is
set to o but compe satio is still ot correct.
•PUSH LOCK MODE: If the push loc switch is pressed, White Balance will be adjusted automatically.
12345678
ON
OFF
18
VIDEO OUT
LINELOCK
GND
DC IN
27
36
45
LEVEL LINE LOCK
PUSH LOCK
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10
4 English

ADJUSTMENT
Le s adjustme t
(I) Horizo tal & Vertical Adjustme t Screw
(J) Tilt Adjustme t Screw
(K) Pa Adjustme t Screw
IMPORTANT (Surface Type)
VDC-C1572FP/VDC-B1512FP
When not using the side conduit opening for wire connections,
verify that the conduit plug and set screw are tight.
(I)
(J)
(K)
A gular Limit
Gimbal Bracket
Horizo tal & Vertical
Adjustme t Screw
Horizo tal &
Vertical
Adjustme t
Tilt Adjustme t Screws
Tilt
Camera Le s -
Perpe dicular Directio
Gimbal Bracket
Adjustme t Screws
for Camera Rotatio
Camera Rotatio
SET SCREW
CONDUIT
PLUG
L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 5, 10
English 5

SPECIFICATIONS
TV format : Compatible with PAL TV format
Sca i g system : 625 TV lines, 50 fields/sec., 2:1 interlaced
Capturi g eleme t : Interline transmission method, 1/3 inch CCD
fixed capturing element
Effective picture eleme t : 440 K (VDC-C1572FP, VDC-C2572FP)
290 K (VDC-B1512FP, VDC-B2512FP)
Sy chro izatio system : Internal sync or line loc
Horizo tal resolutio : 460 TV lines (VDC-C1572FP, VDC-C2572FP)
380 TV lines (VDC-B1512FP, VDC-B2512FP)
Video output level : 1.0 Vp-p/75 Ω (BNC termination)
Video S/N ratio : 50 dB (VDC-C1512FP, VDC-B2512FP)
48 dB (VDC-C1572FP, VDC-C2572FP)
Mi imum required
illumi atio (50IRE) :0.2 Lux (VDC-B1512FP, VDC-B2512FP)
3.0 Lux (VDC-C1572FP, VDC-C2572FP)
White bala ce (color o ly) : Indoor/outdoor/push loc selectable manually
Backlight compe satio
(BLC) fu ctio :ON/OFF selectable manually, center focus
separate photometry method
B/W cameras: ON only
Backlight compe satio
iris level adjustme t :Manual dial
Flickerless fu ctio : ON/OFF selectable manually
B/W cameras: None
Gai co trol : Selectable manually
Built-i le s : Fixed lens F2.0, f= 4 mm
Ma ual a gle of field
adjustme t fu ctio :Horizontal (pan) → 360° , Vertical (tilt) → 80°
Drip preve tio structure : Simplified
Operati g e viro me t : Temperature –10°C – +55°C
Humidity 90% RH or less
Storage e viro me t : Temperature –20°C – +70°C
Humidity 95% RH or less
Power voltage/
Power co sumptio
(Approx.)
:12 V DC 50 Hz
??? W (VDC-B1512FP, VDC-B2512FP)
??? W (VDC-C1572FP, VDC-C2572FP)
Weight (Approx.) : 1.16 g (VDC-C1572FP, VDC-B1512FP)
0.58 g (VDC-C2572FP, VDC-C2512FP)
Dime sio s : 139.7 (W) x 94.5 (H) mm, Dome 79.4 mm φ
Features a d specificatio s are subject to cha ge without
prior otice or obligatio s.
