Sanyo DC-MX40i User manual

INSTRUCTION MANUAL
DC-MX40i
Micro Hi-Fi System for iPod

TABLE OF CONTENTS
SAFETY PRECAUTIONS..........................................................................................................................................1
PUTTING THE BATTERIES INTO THE REMOTE CONTROL UNIT..................................................................................5
FEATURES AND CONTROLS............................................................................................................................................3
LCD DISPLAY WINDOW...........................................................................................................................................4
REMOTE CONTROL................................................................................................................................................4
INSTALLING THE SPEAKER WIRE TO THE SPEAKER TERMINALS
.........................................................5
OPERATING THE UNIT.......................................................................................................................................................5
STANDBY/ON......................................................................................................................................................................5
CLOCK SETTING................................................................................................................................................................6
TIMER SETTING.................................................................................................................................................................6
FUNCTION SELECT............................................................................................................................................................6
RADIO OPERATION...........................................................................................................................................................6
CD/MP3/WMA OPERATION...............................................................................................................................................7
ID3 OPERATION ........................................................................................................................8(on the remote control)
USB/SD CARD OPERATION..............................................................................................................................................8
REPEAT PLAY FUNCTION ........................................................................................................9(on the remote control)
PROGRAM FUNCTION.......................................................................................................................................................9
RANDOM PLAY ........................................................................................................................10(on the remote control)
INTRO PLAY(on the remote control)..............................................................................................................................10
iPod OPERATION.............................................................................................................................................................11
AUX IN PLAY.....................................................................................................................................................................12
TO SET SLEEP FUNCTION .....................................................................................................12(on the remote control)
EQ CONTROL ...........................................................................................................................12(on the remote control)
MUTE SETTING .........................................................................................................................12(on the remote control)
LISTEN TO THE MUSIC BY USING HEADPHONE.........................................................................................................12
COMPACT DISC...............................................................................................................................................................13
SPECIFICATION...............................................................................................................................................................14
MAINTENANCE................................................................................................................................................................14
TROUBLESHOOTING......................................................................................................................................................15

1
To achieve the utmost in enjoyment and performance, please read this manual carefully before attempting
to operate the unit in order to become familiar with its features, and assure you years of faithful, trouble
free performance and listening pleasure.
Important Notes
* Read instructions - All the safety and operating instructions should be read before the apparatus is operated
* Retain instructions - The safety and operating instructions should be retained for future reference.
* Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
* Attachment Do not use attachment not recommended by the product manufacturer as they may cause hazards.
* Power Sources -The apparatus should be connected to a power supply only of the type described in the
operating instructions of as marked on the apparatus.
* “To be completely d the power input, the mains plug of apparatus shall be disconnected
from the mains.” as the disconnect devices is the mains plug of apparatus.
* Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on
or pinched by items placed upon or against them, paying particular attention to cords at plugs,
convenience receptacles and the point where they exit from the apparatus
* During lntended Use - The mains plug of apparatus should be easily accessed.
* Nonuse Periods - The power cord of the apparatus should be unplugged from the outlet when left
unused for a long period of time.
* This apparatus shall not be exposed to dripping or splashing water and that no object filled with liquids
such as vases shall be placed on the apparatus.
* The apparatus should be situated so that its location or position does not interfere with its proper
ventilation. The ventilation should not be impeded by covering the ventilation openings with items
such as newspaper, table-cloths, curtains etc.
* Do not install this apparatus in a confined space, such as a book case or built-in cabinet. Minimum
distance (about 100mm) around the apparatus for sufficient ventilation.
* No naked flame sources such as lighted candles should be placed on the apparatus.
* Do not use where there are extremes of temperature (below or exceeding 35 C).
* Sudden changes in the ambient temperature may cause condensation to form on the optical lens inside
the unit. lf this happens, take out the disc, leave the unit for about 1 hour, and then proceed to operate.
* Because of the CD player’s extremely low noise and wide dynamic range, there might be a tendency to
set the volume on the amplifier unnecessarily high.
* Excessive sound pressure from earphones and headphones can cause hearing loss.
* Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
* Attention should be drawn to the environmental aspects of battery disposal.
* The caution marking was located at the back enclosure of the apparatus.
* The nameplate marking was located at the back enclosure of the apparatus.
* The use of apparatus in moderate climates.
isconnected
5°C °
ESD Remark: In case of malfunction due to electrostatic discharge, just reset the product
(reconnect of power source may be required) to resume normal operation.
Should any trouble occur, remove the power source and refer servicing to qualified personnel.
For safety reasons, do not remove any covers or attempt to gain access to the inside of the product.
Refer any servicing to qualified personnel.
Do not attempt to remove any screws, or open the casing of the unit; there are no user serviceable parts
inside, refer all servicing to qualified service personnel.
Note:
- This unit will become warm when used for a long period of time. This is normal and does not indicate a
Problem with the unit.
- The CD player includes micro-processors which may malfunction as a result of external electrical Interference
or noise. If the CD player is not working properly, disconnect the power source and then reconnect it.
- Excessive sound pressure from earphones and headphones can cause hearing loss.
- If an unusual conditions occurs in the display window or key button, switch the unit off, then turn on the unit
again.
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
DRIPPING OR SPLASHING.
SAFETY PRECAUTIONS

POWER CONSUMPTION: 23W
AC ~ 240V 50Hz
FREQUENCY RANGE: AM 522~1620 KHz
FM 87.5~108.0 MHz
Model No.:DC-MX40i
Micro Hi-Fi System for iPod
SANYO Electric Co.,Ltd. MADE IN CHINA AU
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the information
accompanying this unit.
CAUTION
CLASS 1 LASER PRODUCT
Operating the unit in a way other than specified herein,or
making adjustments to the unit may result in hazardous
radiation exposure
LASER SAFETY
This unit employs a laser. Only qualified service personnel should attempt to repair.
WARNING: RISK OF INVISIBLE LASER RADIATION WHEN CD LID IS
OPEN OR INTERLOCKS FALL.AVOID DIRECT EXPOSURE TO THE
BEAM.
You can see this
label in the CD
compartment.
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS:RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CLASS 1 LASER PRODUCT
KLASS 1 LASER APPARAT
LUOKAN 1 LASER LAITE
KLASSE 1 LASER PRODUKT
You can see this label on the
back of the main unit.
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
CUIDADO: PRODUTO LASER DE CLASSE 1 RADIAÇÃO
LASER INVISÍVEL CUANDO ABERTO E SE O DE SEGURANÇA
ESTIVER DEFEITUOSO A EXPOSIÇÃO AOS RAIOS.
ADVARSEL: USYNLIG LASERSTRALING VED ÃBNING NÃR
SIKKERHEDSAFBRYDERE ER UDEAF FUNKTION UNDGA
UDSÆTTELSE FORSTRÃLING,
VARO: AVATESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE
ÄLÄ KATSO SÄTEESEENI
VARNING: OSYNLIG LASERSTRÄLNING NÄR DENNA DEL
ÄR ÖPPNAD OCHSPÄRREN ÄR URKOPPLAD. BETRAKTA
EJSTRÄLENI
This label sticks inside of the unit.
2
You can see this carved picture on the
bottom of the main unit.
You can see this carved picture on the
bottom of the main unit.

FEATURES AND CONTROLS
3
15
16
17 18
19
20
14
2
11
6
4
3
7
9
12
5
10
8
23
24
21
1
13
22
1. SPEAKER
2. LCD DISPLAY WINDOW
3. IR SENSOR
4. STANDBY LED INDICATOR
5. STANDBY/ON
6. SKIP/TUNE SEARCH UP BUTTON
7. SKIP/TUNE SEARCH DOWN BUTTON
8. VOLUME KNOB
9. EARPHONE OUTPUT JACK
10. STOP/MENU BUTTON
11. PLAY/PAUSE/ENTER BUTTON
12. BAND BUTTON
13. FUNCTION BUTTON
14. CD DOOR
15. SD/MMC MEMORY CARD IN SLOT
16.
17. iPod CONNECTOR DOCK
18. MEM/C-ADJ./iPod BUTTON
19. TIMER BUTTON
20. CD DOOR OPEN BUTTON
21. SPEAKER TERMINALS
FM ANTENNA
BUTTON
USB DEVICE IN PORT
AC CORD
22.
23.
24. AUX IN JACK
25. AC POWER SWITCH
25
Universal Dock
adapter connection

4
REMOTE CONTROL
1. STANDBY/ON BUTTON
2. MUTE BUTTON
3. PRESET/FOLDER UP BUTTON
4. PRESET/FOLDER DOWN BUTTON
5. RANDOM BUTTON
6. SKIP/TUNE SEARCH DOWN BUTTON
7. INTRO BUTTON
8. VOLUME DOWN BUTTON
9. FUNCTION BUTTON
10. BAND BUTTON
11. ID3/MONO/STEREO BUTTON
12. REPEAT BUTTON
13. PLAY/PAUSE/ENTER (only in ) BUTTON
14. EQ BUTTON
15. SKIP/TUNE SEARCH UP BUTTON
16. STOP/MENU (only in ) BUTTON
17. /MEM/C- ADJ. BUTTON
18. TIMER BUTTON
19. SLEEP BUTTON
20. NUMBER SEARCH BUTTON
21. VOLUME UP BUTTON
iPod
iPod
iPod
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
A. TIMER INDICATOR
B. ALBUM/RADIO MEMORY NUMBER
INDICATOR
C. REPEAT 1 & ALL INDICATOR
LCD DISPLAY WINDOW
D. STEREO INDICATOR
E. VOLUME HIGH/LOW INDICATOR
F. SLEEP INDICATOR
G. TRACK/NUMBER/TIME INDICATOR

PUTTING THE BATTERIES INTO THE REMOTE CONTROL UNIT
Press down the compartment cover, and slide the
cover off to open the compartment. Place the two
(UM4), (AAA), (R03) batteries in the remote control
according to the polarity markings ("+" and "-”) inside
the compartment and on the batteries.
Place the cover over the compartment, press down
lightly, and push it upward until it snaps on.
BATTERY PRECAUTIONS
Follow these precautions when using a battery in this device:
1. Warning -Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
2. Use only the size and type of battery specified.
3. Be sure to follow the correct polarity when installing the battery
as indicated in the battery compartment.
A reversed battery may cause damage to the device.
4. If the device is not to be used for a long period of time, remove
the battery to prevent damage or injury from possible battery
leakage.
5. Do not try to recharge a battery not intended to be recharged;
it can overheat and rupture. (Follow battery manufacturer's directions.)
6. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
**BATTERIES NOT INCLUDED**
INSTALLING THE SPEAKER WIRE TO THE SPEAKER TERMINALS
OPERATING THE UNIT
Before operating the unit for the first time, make sure the AC power cord is properly connected to a 240V 50Hz
AC outlet, then press the power ON switch on the rear of the unit, the unit will be in standby mode, The STANDBY
indicator will light on. You can now press the STANDBY/ON button on the unit or press the STANDBY/ON button
on remote control to switch the unit ON. The STANDBY indicator will be off. Pull the AC plug out of the wall socket
if you want to switch off completely.
STANDBY/ON
1. Press the STANDBY/ON button on the unit or remote control to switch the unit on.
2.
3. Adjust the volume with the (+ or -) knob on the unit or VOLUME (+ or -) button on the remote control.
4. Press the STANDBY/ON button on the unit or remote control again to turn off the unit.
Note: 1. During in standby mode, press any button/key can make the display light for 10 seconds.
2. Please turn the main switch off to save energy, when you do not use the unit.
Select the sound source (CD, USB, CARD, iPod, AUX or TUNER) by pressing FUNCTION button. The
corresponding display will light up.
VOLUME
1. Speakers Connection
Extend the SPEAKER WIRES and connect them
to the SPEAKER TERMINALS.
2. Power Cord Connection
Before using, connect the AC Power Cord to
240V AC outlet. Then turn on the main switch
on the rear of the unit. The STANDBY indicator
will light on.
AC CORD
AC MAIN POWER SWITCH
5

6
During in the STANDBY mode.
1. Press and hold the MEM/C-ADJ./iPod button until the time displays will change to 24-hour digit
and flash.
2. Press or button to select 12-hour or 24-hour.
3. Press the MEM/C-ADJ./iPod button again, the HOUR digit will flash on the display, press or
button to adjust HOUR digit.
4. Press the MEM/C-ADJ./iPod button once more, the MINUTE digit will flash on the display, press
or button to adjust minute digit.
5. Press the MEM/C-ADJ./iPod button again to confirm the time.
6. Each enable state as shown above will be cleared if the key is not pushed in10 seconds.
CLOCK SETTING
TIMER SETTING
FUNCTION SELECT
The function is that when FUNCTION button, the mode is changed. Display changes as below:pressing
TUNER
AUX
CD USB IPODCARD
RADIO OPERATION
Press the FUNCTION button to select “TUNER”.
1. Press the BAND button to select AM or FM.
2. Press or button to tune the desired station.
Manual Tuning
To tune for weak stations, use manual tuning by pressing or button continuously until you read the
correct frequency or the reception is at its best.
Automatic Tuning
1. Press or button for a second or more, then release the button. The tuner will automatically search
the first station of sufficient signal strength.
2. Repeat above procedure if you wish to select another station.
1. After adjusting the clock, press the TIMER button for a few seconds, " ON" and "00:00" appear on the display and
the HOUR digit flashes.(F1)
2. Press or on the unit or press or button on the remote control to adjust it.
3. Press the TIMER button again, the MINUTE digit will start flashing, adjust it by pressing or on the unit or
pressing or button on the remote control.
4. Press the TIMER button once more to confirm and order TIMER ON time.
5. After adjusting "TIMER ON", " OFF" appears on the display and the HOUR digit flashes.(F2)
6. Repeat the above steps 2 to 3, and then press the TIMER button once more to confirm and order TIMER OFF time.
7. Now the "TUNER" appears on the display with flashing, and then select the alarm mode of the “TUNER, CD, USB,
CARD or IPOD" by pressing or on the unit.
8. Press the TIMER button again, the timer "VOL" indicator appears on the display and flashes, adjust the timer
volume high or low by pressing or on the unit or pressing the or button on the remote control.
9. Each enable state as shown above will be cleared if the button is not pushed in 10 seconds.
10.After adjusting "TIMER ON" and "TIMER OFF", press the TIMER button, " “ appears on the display.
11.The main unit will be switched on automatically at "TIMER ON" order and start playing, the main unit will be
switched off automatically at "TIMER OFF" order.
Note: If the display shows "ERROR" while you set the “TIMER ON”, it means both “TIMER ON” and “TIMER OFF” is
the same. In this case, please go to “TIMER OFF” to set the off time first. To switch TIMER function ON or OFF,
press TIMER button.

Mono/stereo select (on the remote control)
You can select the MONO/STEREO only in FM mode.
1. When you want to select FM stereo station, press the ID3/MONO/ST. button on the remote control.
When you receive a FM stereo station the " " indicator will appear on the display, you can receive
FM stereo transmission .
2. When you press the ID3/MONO/ST. button on the remote control again, the FM STEREO indicator will
turn off and switch to MONO FM status.
Programming preset stations
You can also preset stations of your choice and store up to10 AM and 30 FM stations in its memory. To
store your selected broadcasting stations:
1. Press the BAND button on the unit(or remote control) to toggle between AM and FM to make your
selection.
2. Tune to the desired station.
3. Press the MEM/C-ADJ./iPod button.
4. Press the PRESET/FOLDER (Up or DOWN) button on the remote control for your desired station
number.
5. Press the MEM/C-ADJ./iPod button again to confirm your selection.
6. To program more stations into memory, repeat the above steps 2 to 5.
7. To change the stored preset stations, repeat the above steps 2 to 5.
Note: Storing a new station into a preset location will erase the previously stored station in that location.
Selecting the Preset Stations
1. Press the BAND button to select the desired band.
2. Press the PRESET/FOLDER (UP or DOWN) button on the remote control to select the desired preset
station number.
3. The location number of preset station is displayed along with the corresponding frequency.
FM Antenna
For better FM reception change the position of FM antenna wire.
7
CD/MP3/WMA OPERATION
Listening To Compact Disc (CD/MP3/WMA)
1. If you want to enjoy CD/MP3, press the CD DOOR OPEN( ) button once on the unit first, and then the
CD door will open automatically.(F3)
2. Insert the CD or MP3 disc into the CD compartment, press the CD door to close it.
3. Press the FUNCTION button to select CD mode. The unit will read the CD/MP3/WMA disc automatically.
Note: (1) This unit can play CD, CD-R, CD-RW, MP3 and WMA discs.
(2) It can read " 8 cm " and " Multi Section " of MP3 DISC.
(3) The "Playback Transfer Rate" in MP3 and WMA.
a. In MP3, transfer bit rate : 8 - 256 kbps.
b. In WMA, transfer bit rate : 8 - 192 kbps.
(4) The "Max Readable 99 folders and 999 tracks".
(5) If no disc or can`t read TOC, NO DISC will be displayed.(F4)
Playing The Entire CD/MP3/WMA
- CD
1. Insert the CD disc into the CD compartment, and then press FUNCTION button to select CD mode, the
main unit will automatically read the total number of the tracks at the same time.
2. Press /ENTER button, the unit will play the first track of the CD disc automatically.(F5)
3. Press /ENTER button once again, the time elapsed indicator will flash.(F6)
4. Press or button once to change Track NO., and press and hold or button to skip
fast backward or forward of each song.
5. To resume playback, press /ENTER button once more again.
6. To stop playback, press /MENU button once.
IMPORTANT INFORMATIONS
- Copyright protection files cannot be played back.
- Copyright protection files on a disc are skipped automatically when played back.
F3 F4

8
F5 F6
- MP3/WMA
1. Insert the MP3/WMA disc into the CD compartment, and then press FUNCTION button to select CD
mode, the main unit will automatically read the total number of the folders and tracks at the same time.
2. Press /ENTER button, the unit will play the first track of the MP3/WMA disc automatically.(F7)
3. Press /ENTER button once again, the time elapsed indicator will flash.(F8)
4. To change Track NO., Press or button once. And press and hold or button to skip
fast backward or forward of each song.
5. To resume playback, press /ENTER button once more again..
6. To change the ALBUM NO., press the PRESET/FOLDER UP or DOWN button on the remote control.
7. To stop playback, press the /MENU button once on the unit (or remote control).
F7 F8
Note: If the main unit is not working properly, disconnect the power source and then reconnect it again.
ID3 OPERATION (on the remote control)
During in the MP3/WMA mode
1. Press the ID3/MONO/ST. button once to open the ID3 function.
2. If the MP3/WMA file is written in “ID3” it will automatically to search the information of “TITLE NAME”,
“ARTIST NAME”and “ALBUM NAME” indicated on the display .
3. Press the ID3/MONO/ST. button on the remote control again. Then the unit will resume to play
normally.
During in the STANDBY mode
1. Insert the USB DEVICE or SD/MMC CARD, and then press the STANDBY/ON button on the main unit
(or remote control) to power"ON" the unit.
2. Press the FUNCTION button on the main unit (or remote control) to select the USB or CARD mode.
The main unit will automatically read the total number of the folders and tracks at the same time. (F9)
3. If the USB memory device more than one folder.
a. Press the PRESET/FOLDER (UP button on the remote control to select each folder.
b. Press or button to select a track in desired folder.
Press
ress
ress
ress
or DOWN)
4. /ENTER on the unit or press the /ENTER button on the remote control, will start playback
from the selected track. The display shows the current track number and its elapsed time.(F10)
5. To pause playback, p /ENTER on the unit or press the /ENTER button on the remote control.
The time elapsed indicator will flash.(F11)
6. To resume playback, p /ENTER on the unit or press the /ENTER button on the remote control
again.
7. To stop playback, p /MENU.
USB/SD CARD OPERATION
F9 F10 F11
