Sanyo MS6A User manual

Multimedia Projector
SERVICE MANUAL
PRODUCT CODE
(MS6A) 1 122 094 00
(PS6A) 1 122 114 00
(PS6C) 1 122 114 02
(MS6G) 1 122 094 06
(PS6G) 1 122 114 06
(PS6J) 1 122 114 08
Original Version
REFERENCE NO. SM5110253
FILE NO.
Model No. PLC-XU30
PLC-XU35
U.S.A., Canada,
Europe, Asia, Africa
U.K
Chassis No. MS6-XU3000
MS6-XU3500
NOTE: Match the Chassis No. on the unit’s
back cover with the Chassis No. in the
Service Manual.
If the Original Version Service
Manual Chassis No.does not match
the unit’s, additional Service
Literature is required.You must refer to
“Notices” to the Original Service
Manual prior to servicing the unit.

2
■Contents
■Safety instructions ________________________________________________3
■Specifications __________________________________________________ 4
■Note on Servicing ______________________________________________ 5
■Adjustments after parts replacement ________________________________ 5
■Circuit protections ______________________________________________ 6-7
● Fuse ____________________________________________________ 6
● Thermal switch ____________________________________________ 6
● Interlock switch ____________________________________________ 6
● Warning temperature and power failure protection ________________ 7
■Mechanical disassemblies ______________________________________ 8-13
■Optical parts disassemblies ____________________________________ 14-17
■LCD panel/prism ass’y replacement ________________________________ 19
■Lamp replacement ______________________________________________ 20
■Optical adjustments __________________________________________ 21-24
●Contrast adjustment ________________________________________ 21
●Condenser lens adjustment __________________________________ 22
●Condenser lens-Out adjustment ______________________________ 23
●Relay lens-Out adjustment __________________________________ 24
■Electric adjustments __________________________________________ 25-30
●Service adjustment menu operation____________________________ 23
●Circuit adjustments ______________________________________ 24-29
●Service adjustment data table______________________________ 30-33
●Test points and locations ____________________________________ 34
■Troubleshooting ______________________________________________ 35-39
●No power______________________________________________ 35-36
●No picture ____________________________________________ 37-38
●No sound ________________________________________________ 39
●Lens motor problems ______________________________________ 39
■Control port functions ________________________________________ 40-43
■Waveforms __________________________________________________ 44-45
■Cleaning ______________________________________________________ 46
■IC block diagrams ____________________________________________ 47-54
■Service parts lists ____________________________________________ 55-73
●Electrical parts list ______________________________________ 55-65
●Mechanical parts list ____________________________________ 66-70
●Optical parts list ________________________________________ 71-73
Drawings & Diagrams __________________________________________ A1
■Parts description and reading in schematic diagram____________________ A2
■Circuit block diagram ____________________________________________ A3
■Power supply lines ______________________________________________ A4
■Schematic diagrams ________________________________________ A5-A11
■Printed wiring board diagrams ________________________________ A12-A14
■Pins description of ICs, transistors, diodes __________________________ A15

3
■Safety Instructions
WARNING:
The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of
the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is iden-
tified with the line ( ) in the schematic diagram. For continued product safety and protection of personnel
injury, servicing should be made with qualified personnel.
The following precautions must be observed.
SAFETY PRECAUTIONS
1: An isolation transformer should be connected in the
power line between the projector and the AC line
before any service is performed on the projector.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, etc.
DO NOT OPERATE THIS PROJECTOR WITHOUT
THE PROTECTIVE SHIELD IN POSITION AND
PROPERLY SECURED.
4: Before replacing the cabinet cover, thoroughly
inspect the inside of the cabinet to see that no stray
parts or tools have been left inside.
Before returning any projector to the customer, the
service personnel must be sure it is completely safe to
operate without danger of electric shock.
SERVICE PERSONNEL WARNING
Eye damage may result from directly viewing the light produced by the Lamp used in this equipment. Always turn
off Lamp before opening cover. The Ultraviolet radiation eye protection required during this servicing.
Never turn the power on without the lamp to avoid electric-shock or damage of the devices since the stabilizer
generates high voltages(15kV - 25kV) at its starts.
Since the lamp is very high temperature during units operation replacement of the lamp should be done at least
45 minutes after the power has been turned off, to allow the lamp cool-off.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of the projector.
Components indicated by mark in the parts list and the schematic diagram designate components in which
safety can be of special significance.It is, therefore, particularly recommended that the replacement of there parts
must be made by exactly the same parts.
DO NOT ATTEMPTTO SERVICING THE
REMOTE CONTROL UNIT.
Laser Beam may be leaked out when in disassemble
the Unit. As the Laser Beam used in this Remote con-
trol unit is harmful to the eyes.
LASER RADIATION
DO NOT STARE INTO BEAM
MAX. OUTPUT: 1mW
WAVE LENGTH: 650 ±20nm
CLASS II LASER PRODUCT
This product is complied with 21 CFR
part 1040.10
CAUTION LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
LASER-STRAHLING
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
IEC60825-1, Am. 1 1997
MAX OUTPUT ( ) : 1 mW
WAVE LENGTH ( ) : 650±20nm

Projector Type Multi-media Projector
Dimensions (W x H x D) 13.11”x 3.52”x 9.07”(333mm x 89.5mm x 230.5mm)
Net Weight 8.6 lbs (3.9 kg)
LCD Panel System 0.9”TFT Active Matrix type, 3 panels
Panel Resolution 1024 x 768 dots
Number of Pixels 2,359,296 (1024 x 768 x 3 panels)
Color System 6 color system (PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N)
High Definition TV SIgnals 480i, 480p, 575i, 575p, 720p. 1035i and 1080i
Scanning Frequency H-sync. 15 ~ 100kHz, V-sync. 50 ~ 100Hz
Projection Image Size (diagonal) Adjustable from 31”to 300”
Horizontal Resolution 800 TV lines
Projection Lens F 1.7 ~ 2.0 lens with f 37.4mm ~ 48.3mm with motor zoom and focus
Throw Distance 5.3’~ 40.0’(1.6m ~ 12.2m)
Projection Lamp 200watts
AV Input Jacks RCA Type x 3 (Video/Y, Cb/Pb, Cr/Pr) and Mini DIN 4 pin x 1(S-Video)
AV Audio Input Jacks RCA Type x 2
Computer Input Jacks (VGA) HDB15 Terminal x 1 and DVI 24 pin x 1
Computer Audio Jack Mini Jack (stereo)
Control Port Connector Mini DIN 8 pin x 1
USB Connector USB B-plug for upstream, 4 pin
Audio Output Jacks RCA Type x 2
Internal Audio Amp. 1.0watt RMS (monaural)
Built-in Speaker 1 speaker, 1.18”x 1.57”(30mm x 40mm)
Feet Adjustment 0˚to 15.6˚
Voltage and AC 100 ~ 120V (3.6A Max. Ampere), 50/60Hz (The U.S.A and Canada)
Power Consumption AC 200 ~ 240V (1.8A Max. Ampere), 50/60Hz (Continental Europe and The U.K.)
Operating Temperature 41˚F ~ 95˚F (5˚C ~ 35˚C)
Storage Temperature 14˚F ~ 140˚F (-10˚C ~ 60˚C)
Remote Control Transmitters Wireless Remote Control, batteries AA, UM3 or R06 Type x 2
4
■Specifications
●The specifications are subject to change without notice.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.

5
Condenser lens adjustment ❍●
Condenser lens-out adjustment ❍●
Relay lens-out adjustment ❍●
Contrast Adjustment
R-Contrast adjustment ●
G-Contrast adjustment ●
B-Contrast adjustment ●
Output voltage adjustment ●
Fan voltage adjustment ●
Pedestal adjustment ●
NRS adjustment ●
Signal center adjustment ●
Black level adjustment ●
PC offset adjustment ●
PC gain adjustment ●
AV gain adjustment ●
Common center adjustment ● ●
Gamma shift adjustment ❍ ●
White balance adjustment ❍ ❍
Disassembly / Replaced Parts
LCD/
Prism
Ass’y
Condenser
Lens
Polarized glass
RGB
Optical Adjustments
Electrical Adjustments
● : Adjustment necessary ❍ : Check necessary
P. F.
Board Main
Board
Condenser
Lens-Out
■Adjustments after Parts Replacement
Relay
Lens-Out Power Board

-6-
●Interlock switch
The interlock switch (SW904) cuts off the AC mains power supply
when the lamp cover is removed. After opening the lamp cover for
replacing the lamp ass’y, place the lamp cover correctly otherwise
the projector can not turn on.
●Thermal switch
There is the thermal switch (SW902) inside of the projector to
prevent the internal temperature from rising abnormally. When the
internal temperature reaches near 100˚C, turn off the AC main
power supply automatically.
The thermal switch is not reset to normal automatically even if the
internal temperature becomes normal. Reset the thermal switch
following procedure.
Check the resistance between terminals of thermal switch by
using the tester. If it has high impedance, thermal switch may be
in operative.
How to reset the thermal switch
1. Remove the cabinet top following to “Mechanical
Disassemblies”.
2. Press the reset button on the thermal switch.
CAUTION:
Before press the reset button, disconnect the AC cord from the
projector.
■Circuit Protections
This projector is equipped with the following circuit protections to operate in safety. If the abnormality occurs inside
the projector, it will automatically turn off by operating one of the following protection circuits.
●Fuse
The fuse is located inside of the projector. When either the LAMP
indicator or the READY indicator is not illuminated, fuse may be
opened. Check the fuse as following steps.
It should be used the specified fuse as follows;
How to replace the fuse
1. Remove the cabinet top following to “Mechanical
Disassemblies”.
2. Remove the fuse from fuse holder.
To install the fuse, take reversed step in the above.
Fuse Part No.: 423 022 2102
TYPE T4.0AH 250V FUSE
LITTLE FUSE INC.TYPE 215004
Fuse
Thermal switch (SW902)
Reset Button
Line Filter Board

-7-
Circuit Protections
●Warning temperature and power failure protection
The TEMP WARNING indicator flashes red and the projector will automatically turn off when the internal tempera-
ture of the projector exceeds the normal temperature or when stopping cooling fans or when the internal power
supply lines are failed.
Check the following possible causes and wait until stopping the TEMP WARNING indicator flashing.
Possible causes
- Air filter is clogged with dust particles. Remove dust from the air filter by following instructions in the “Air filter
care and cleaning”below.
- Ventilation slots of the projector are blocked. In such an event, reposition the projector so that ventilation slots are
not obstructed.
- Check if projector is used at higher temperature place (Normal operating temperature is 5 to 35 ˚C or 41 to 95˚F)
If the TEMP WARNING indicator still continues to flash, there may be defects on cooling fans or power supply cir-
cuits. Please check fan operation and power supply lines referring to the “Power Supply Lines Chart”.
Air filter care and cleaning
The removable air filter prevents dust from accumulation on the surface of the projection lens and projection mirror.
Should the air filter become clogged with dust particles, it will reduce the cooling fan’s effectiveness and may result
in internal heat build up and reduce the life of the projector.
To clean up the air filter, follow the cleaning procedure
below:
1. Turn the power off, and disconnect the AC power cord
from the AC outlet.
2. Turn the projector up side down and remove an air filter
by pulling the latches of them upward.
3. Clean the air filter with brush or wash out the dust and
particles.
4. Replace the air filter properly. Make sure that the air fil-
ter is fully inserted.
CAUTION:
Do not operate the projector with the air filter removed.The
dust is stuck on the LCD panel and the mirror, and it may
spoil the fine picture image.
Do not put the small parts into the air intake vents. It may
result in the malfunction of the projector.The air filter is
small parts.Take care that children don’t eat or swallow it.
RECOMMENDATION
We recommend to avoid dusty, smoky place for operating the projector. Using in dusty place may cause the picture
of poor quality.
When using under the dusty or smoky conditions, dust may accumulate on the LCD panel and lens inside it, and
may resultantly be projected on the screen together with the picture.
When the above symptoms are noticed, please clean up the LCD panel and lens following to the “Cleaning
Method”.
Air filter

-8-
1Remove 4 screws Ato take the Cabinet Top Ass’y upward off.
2Remove the Control Panel off from the Cabinet Top by lifting the edge of
control panel.
■Mechanical Disassemblies
Mechanical disassemble should be made following procedures in numerical order.
Following steps show the basic procedures, therefore unnecessary step may be ignored.
Caution:
The parts and screws should be placed exactly the same position as the original otherwise it may cause loss of
performance and product safety.
Fig.1
1Remove 8 screws to take the Main Board upward off.
Fig.2
Cabinet Top and Control Panel removal
1
Main Board removal
2
A
A
A
A
Main Board
Control panel
Cabinet top

-9-
Mechanical Disassemblies
1Remove 1 screw Ato release grounding wires.
2 Pull the Rear Panel ass’y upward.
3Remove 4 screws Bfor AV Board.
4Remove 3 screws Cfor DVI Board.
5Remove 4 screws Dfor Speaker.
Fig.3
Fig.4
1Remove 4 screws A and unhook 2 hooks Bat the both of left and right
side, and the take the Front Panel ass’y off.
2Remove 1 screw Cto take the R/C Board off.
AV, DVI Board and Speaker removal
3
Front Panel and R/C Board removal
4
A
B
B
B
C
A
A
A
A
B
C
DVI board
AV board
Speaker
R/C board
B
C
C
D
D

-10-
Mechanical Disassemblies
1Remove 1 screw Aand disconnect the Lamp Socket.
2Remove 2 screws Bto take the Lamp Ballast ass’y upward off.
3Remove 4 screws Cto take the Lamp Ballast Board off.
Fig.5
1Remove 3 screws Aand pull the Filter Board ass’y upward.
2Remove 1 screw Bto take the grounding lead from the cabinet bottom.
3Remove 4 screws Cto take the Filter Board off.
Fig.6
Lamp Ballast Unit removal
5
Filter Board removal
6
A
Lamp ballast board
BB
C
CC
C
A
A
A
B
C
C
C
CFilter board

-11-
1Remove 4 screws Ato take the Fan(FN901) off.
2Remove 4 screws Bto take the Fan(FN905) off.
3Remove 3 screws Cto take the Power Box Cover upward off.
Mechanical Disassemblies
1Remove 1 screw Ato take the Lamp Cover off.
2Loosen 3 screws Bto take the Lamp assembly by
pulling the handle.
Step to next procedure.
Fig.8-1
Fig.7
Power Box Cover and Fans(FN901, FN906) removal
7
Optical Unit removal
8-1
A
A
A
A
B
BB
B
CC
C
FN901
FN906
Power box cover
Lamp cover
Lamp ass’y
A
B
BB

Step from previous procedure.
3Remove 6 screws C to take the Optical Unit upward upward off.
To mount optical unit, mount optical unit first then mount the Lamp assembly
and Lamp Cover.
-12-
Mechanical Disassemblies
1Remove 8 screws Ato take the Power Board ass’y
upward off.
2Remove 4 screws Bto take the P. F. Board from the
Power Board.
3Remove 3 screws Cto take the Power Board holder
from the Cabinet Bottom.
Fig.9
Power and P.F. Board removal
9
A
Power board
A
A
A
AA
A
A
BBBB
C
C
C
P. F. board
Fig.8-2
Optical Unit removal
8-2
Optical unit
C
C
C
C
C
C

1Remove 1 screw Aand take a Washer, Spring and
Interlock Switch lever.
2Pull the Fan and duct ass’y upward, then remove the
2 screws B to take the Fan (FN906) off.
-13-
Mechanical Disassemblies
Fig.10
1Remove 1 screw Ato take the Temp. Board off.
2Remove 8 screws Band to take the Fan Duct
Top off and remove the Fans (FN902, FN903,
FN904).
3Remove 4 screws Cto take the Fan Duct Bottom
off from the Cabinet Bottom.
Fig.11
Fan (FN905) removal
10
Temp Board and Fans (FN902, FN903, FN904) removal
11
Interlock switch lever
A
B
B
FN905
A
BB
B
B
B
B
B
CC
C
C
FN904
FN903 FN902
Temp board
Fan duct top

-14-
1Remove the Front Panel following to “Front Panel Removal”on “Mechanical
Disassemblies”.
2Remove 4 screws to take the Projection Lens ass’y off.
1Remove 2 screws Aand pull the Integrator Lens-In ass’y upward.
2Remove 1 stopper Band then take the Lens off from the holder.
Fig.1
■Optical Parts Disassemblies
Before taking this procedure, remove Cabinet Top and Main Board following to the “Mechanical Disassemblies”.
Disassembly requires a 2.0mm hex wrench and a screwdriver.
Integrator Lens
* Should be placed the lens as
the rugged surface side of it
comes to the holder side.
Fig.2-1Fig.2-2
Projection Lens removal
Integrator Lens-In disassembly
Stopper B
AA

-15-
1Remove 2 screws Aand pull the Condenser Lens ass’y upward.
2Remove 4 screws Bto take the Lens off from the holder.
1Remove 2 screws Aand pull the Condenser Lens-Out ass’y upward.
2Remove 2 screws Bto take the Lens off from the holder.
Note:
Should be place the lens as shown in the figure.
A
Optical Pats Disassemblies
BCondenser Lens
Fig.3-2
Fig.3-1
* Should be place the lens as the
flat surface side comes to the
holder side.
Holder
A
A
Fig.4-2
Fig.4-1
B
B
Holder
Condenser Lens-Out
A
Condenser lens disassembly
Condenser Lens-Out disassembly
B
B
B
Side View

-16-
Optical Parts Disassemblies
1Remove 2 screws Aand pull the Relay Lens-Out ass’y upward.
2 Remove 2 screws Bto take the Lens off from the holder.
Note:
There is no mounting direction of the lens.
1Remove each screw and pull the Polarized Glass-In ass’y upward.
2Unhook the stoppers and take the glass off upward.
Hooks
Polarized Glass-In
Fig.6-2
Fig.6-1
* Should be places the glass as the
film attached side come to the
prism side.
Phase Sheet
A
Fig.5-2
Fig.5-1
B
B
Holder
Relay Lens-Out
A
Relay Lens-Out disassembly
Polarized Glass-In removal

-17-
1Remove 4 screws Aand take the LCD/Prism ass’y off upward from the
optical unit.
2Remove each screw B and take the glass off upward.
Polarized
Glass-Out
LCD Panel/Prism
Ass’y
LCD Panel/Prism Ass’y
Fig.7-2
* Should be place the glass as the
film attached side comes to the
LCD panel side.
LCD Panel
Note:
Do not replace the LCD panel
separately otherwise it can
not obtain proper picture.
1Remove 9 screws to take the Optical Unit Top off upward.
Fig.7-1
Fig.8
Polarized Glass-Out removal
Optical Unit Top removal
Optical Parts Disassemblies
B
A
A
A
Optical Unit Top

-18-
Optical Parts Disassemblies
When mounting or assembling the optical parts in the optical unit, the
parts must be mounted in the specified location and direction as
shown in figure below.
5
8
9
Fig.9
2
4
1
The printed marker
comes this side. 13
3
7
10
Locations and Directions
6
12
1 Mirror (W)
2 Integrator lens (OUT)
3 Prism beam splitter (PBS)
4 Dichroic mirror (B)
5 Condenser lens (OUT)
6 Dichroic mirror (G)
7 Relay lens (IN)
8 Mirror (R)
9 Condenser lens (R)
10 Condenser lens
11 Condenser lens (B)
12 Optical filter (UV cut)
13 Mirror (B)
Key No. Description
The printed marker
comes this side.
11

-19-
■LCD Panel/Prism Ass’y Replacement
1Remove the cabinet top and main board following to
“Mechanical Disassemblies”.
2Remove 4 screws by using the 2.0 mm hex driver and
take the LCD Panel/Prism ass’y off upward from the
optical unit. LCD Panel/Prism
Ass’y
After replacing or installing the LCD Panel/Prism ass'y,
please make sure to obtain the best focus in both TELE
and WIDE zoom. If the focus adjustment is required,
please adjust the positioning of LCD Panel/Prism Ass’y by
following below procedure.
Mounting Procedure:
1 Loosen 4 screws Aon the LCD Panel/Prism ass'y with
2.0 mm hex driver.
2Turn the projector on and project the image with WIDE
zoom, and adjust the FOCUS control to obtain the best
focus.
3Turn the ZOOM control to the TELE position.
4Move the LCD Panel/Prism Ass’y backward or forward
(about 0mm ~ 0.8mm) to obtain the proper focus.
Confirm the focus at TELE and WIDE zoom.
5Tighten 4 screws Ato fix the LCD Panel/Prism ass'y.
Top View
A
A
A
A
LCD Panel/Prism Ass’y
Note:
Do not replace the LCD
panel separately otherwise
it can not obtain proper pic-
ture.
IMPORTANT NOTICE on LCD Panel/Prism Ass'y Replacement
LCD panels used for this model can not be replaced separately. Do not disassemble the LCD Panel/Prism Ass’y.
These LCD panels are installed with precision at the factory. When replacing the LCD panel, should be replaced
whole of the LCD panels and prism ass’y at once.
After replacing LCD Panel/Prism ass’y, please check the following adjustments.
- Check the “Condenser Lens Adjustment”, “Condenser Lens-Out Adjustment”and “Relay Lens-Out
Adjustment”following to chapter “Optical Adjustment”.
- Check the “White Balance Adjustment”, “Common Center Adjustment”and “Gamma Shift Adjustment”
following to chapter “Electrical Adjustment”.
- Check the white uniformity on the screen.
If you find the color shading, please adjust the white uniformity by using the proper computer and
“Color Shading Correction”software supplied separately.The software can be ordered as follows;
COLOR SHADING CORRECTION
Service Parts No.645 051 2308
LCD Panel/Prism Ass’y removal
Note on LCD Panel/Prism Ass’y Mounting

-20-
WARNING:
- For continued safety, replace with a lamp assembly of the same type.
- Allow the projector to cool for at least 45 minutes before you open the
lamp cover. The inside of the projector can become very hot.
- Do not drop the lamp module or touch the glass bulb! The glass can
shatter and cause injury.
Procedure
1Turn off the projector and disconnect the AC cord. Allow the projector to
cool for at least 45 minutes.
2Remove a screw with a screwdriver and remove the lamp cover.
3Remove 2 screws and pull out the lamp assembly by grasping the han-
dle.
4Replace the lamp assembly securely and tighten 3 screws.
5Place the lamp cover and tighten a screw.
6Connect the AC cord to the projector and turn on.
Note:
- Do not reset the Lamp Replace Counter, except after lamp is replaced.
- The projector can not be turned-on with lamp cover removed, because
when the lamp cover is removed, the interlock switch is also released to
switch off the mains power for safety.
7Reset the Lamp Replace Counter, see below explanation.
■Lamp Replacement
1Turn the projector on, and press the MENU button
and the on-screen menu will appear.Press the POINT
LEFT/RIGHT buttons to move a red frame pointer to
SETTING menu icon.
2Press the POINT DOWN button to move a red frame
pointer to “Lamp counter reset”and then press the
SELECT button.The message “Lamp replace counter
reset?”is displayed.Move the pointer to [Yes] and the
press the SELECT button.
3Another confirmation dialog box appears and select
[Yes] to reset Lamp Replace Counter .
Please refer to the owners manual for further informa-
tion.
Recommendation
Should the air filter become clogged with dust particles,
it will reduce the cooling fan’s effectiveness and may
result in internal heat build up and short lamp life. We
recommend cleaning the air filter after the projection
lamp is replaced.
Refer to “Air Filter Cleaning”.
The LAMP REPLACEMENT indicator will illuminate
when the Lamp Replace Counter reaches 1000
hours.This is to indicate that lamp replacement is
required.
You can check the lamp replace counter following to
below procedure.
1Press and hold the pointer UP on the projector for
more than 20 seconds.
2 The Lamp replace Counter service menu appears on
the screen. For example, when the value of data indi-
cates “123”, the accumulated operation time is 123
hours. To make this menu disappear, press Power
button on the projector.
Lamp cover
Lamp Assembly
Handle
Service Mode
Input Video
Group No. Data
10 0 123
Ver. 1 .00
Lamp replace counter data
ORDER REPLACEMENT LAMP
Type No.Service Parts No.
POA-LMP35 610 293 2751
How to reset Lamp Replace Counter
How to check Lamp Replace Counter
