2700 ANSI LUMENS zTRUE XGA zULTRA SHORT THROW PROJECTOR
Issued 11/09 ©2009 SANYO
PDG-DXL100
XGA Ultra Short Throw Projector
SHORT THROW PROJECTION FROM ONLY 39 INCHES AWAY
The PDG-DXL100 can project a full 80-inch image from a distance of only 39
inches. Teachers can project images on the blackboard right from their desk. This
means large images even in relatively small rooms.
FLEXIBILITY WITH D-SUB15 VGA INPUT AND MONITOR OUT
The PDG-DXL100 offers excellent versatility via 2 D-Sub 15 input/output terminals.
Using an optional adapter cable, the D-Sub 15 input can even accept component
video signals. One of the D-Sub can be connected and used for monitor output for
greater flexibility.
8-WATT SPEAKER PLUS MANY FEATURES FOR EDUCATION USE
Projectors are increasingly used in more media-rich presentations and become a
truly multi-media device. The PDG-DXL100 has a 8-watt speaker, loud enough for
an average classroom or business meeting room. This eliminates the need for a
separate speaker system.
NETWORKING CAPABILITY
The PDG-DXL100 is equipped with SANYO’s exclusive PJ Network Interface for
wired networking, a common feature among SANYO’s extensive line of commercial
projectors. Networking allows the monitoring of projector functions and operation
from a long distance via a web browser. Emails can be sent automatically to report
the operating status.
SPACE SAVING DESIGN
The use of a short-throw lens makes it possible to move the projector from the
center of the classroom or meeting room, to a spot closer to the screen. This frees
up more room space, and cuts down on the possibility of viewers blocking the
image with their shadows.
CLOSED CAPTION
Closed captioning provides the audio portion of a television signal as printed words
on the projected screen - helpful for hearing impaired individuals.
KEYSTONE CORRECTION
To compensate for keystone (trapezoidal) picture distortion, the PDG-DXL100
provides vertical keystone correction with a correction range up to ±15 degrees.
Specifications
Resolution XGA (1,024 x 768)
Brightness (typical) 2,700 ANSI lumens
Panel System 0.55 inch DMD single chip
Contrast Ratio (Full on / off) 750:1
Image Size 40 - 300 inch diagonal
A
spect Ratio 4:3
Projection Lamp UHP 225W
Scanning Frequency H:31.35k - 79.98kHz V:50 - 75Hz
Fan Noise 34dBA / 29dBA (Normal / Eco)
Voltage 100 - 240V (auto voltage)
Power Consumption 320W / 240W
(Normal / Eco)
Stand-by 2W /0.9W (Normal / Eco)
Input signal compatibility UXGA / WXG
A
/ SXGA / XGA / SVGA / VG
A
,
480i / 480p / 576i / 576p / 720p / 1080i / 1080p
Color System PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
Projection Lens (inch) F2.6 f=0.27"
Throw Ratio 0.61:1
Throw Distance (feet) 1.64’ - 12.47’
Zoom / Focus Fixed/Manual
Zoom Ratio 1 : 1.0
Up / Down Ratio 20 : -3
Digital Keystone Correction V +/- 15°
Digital Zoom 4.0x - 1.0x
Speaker Output 8W
Weight (lbs.) 8.2lbs
Dimensions (inch) W,H,D 12.1"x4.7"x9.9"
Replacement Lamp CHSP8EM01GC01
Replacement Remote CH458EL01G001
Lamp Life *
(hours Normal / Eco) Up to 3000h / 4000h (Normal / Eco)
Video Signal Composite , S-Video , D-sub 15pin for Component
Terminal
D-sub15 pin x 2 for Input
RCA ：Video
Mini-DIN 4-pin ：S-Video
HDMI (v1.3) for Digital signals
D-sub15 pin for Monitor out
Audio Mini-Jack for Input
Mini-Jack for output (variable)
Communication
Terminal Service Port (RS-232C), RJ-45 for LAN
Other Feature
A
uto Input Search, Digital Zoom, Freeze,
Closed caption
Included
Accessories
Owner’s Manual, Power Cord, Computer Cable,
Wireless Remote Controller,
AAA type Batteries x 2pcs,
Lens Cap & Strap
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify product design and
specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a general estimate. The
brightness of a lamp usually decreases over time and use.
DLP® and the DLP logo are registered
trademarks of Texas Instruments.
BrilliantColor™ and DynamicBlack™ are
trademarks of Texas Instruments.
Back Panel
