EXPAND SERIAL COMMAND
FUNCTIONAL SPECIFICATIONS
PDG-DXL2000
Ver. 1.00
SANYO Electric Co., Ltd
DS Company
Projector Division

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
1/72
- CONTENTS –
1. Overview .........................................................................................................................7
2. Serial Interface Specification........................................................................................7
2.1Transfer Specification...............................................................................................7
2.2Connection.................................................................................................................7
3. Notes for communication..............................................................................................8
4. Name Definition..............................................................................................................8
5. Functional Execution Command Table........................................................................9
5.1 Image Command Table...........................................................................................9
5.2 PC Adjust Control Command Table......................................................................9
5.3 Input Control Command Table ..............................................................................9
5.4 Screen Command Table.......................................................................................10
5.5 Lamp Command Table..........................................................................................10
5.6 Sound Command Table........................................................................................10
5.7 Setting Command Table.......................................................................................10
5.8 Other Command Table..........................................................................................11
6. Status Read Command Table......................................................................................12
6.1 Image Status Read Command Table...................................................................12
6.2 PC Adjust Status Read Command Table............................................................12
6.3 Video Status Read Command Table....................................................................12
6.4 Input Status Read Command Table.....................................................................12
6.5 Screen Status Read Command Table .................................................................13
6.6 Lamp Status Read Command Table....................................................................13
6.7 Sound Status Read Command Table..................................................................13
6.8 Setting Status Read Command Table.................................................................13
6.9 Other Status Read Command..............................................................................14
7. Error Code Table ..........................................................................................................15
8. Functional Execution Command................................................................................16
8.1 Format....................................................................................................................16
8.2 Transfer Example..................................................................................................16
8.3 Operation Requirements......................................................................................16
8.4 Image Command...................................................................................................17
8.4.1 CF_BRIGHT Command .................................................................................17
8.4.2 CF_CONT Command.....................................................................................17
8.4.3 CF_COLOR Command ..................................................................................17
8.4.4 CF_TINT Command .......................................................................................17
8.4.5 CF_SHARP Command...................................................................................18
8.4.6 CF_GAMMA Command .................................................................................18
8.4.7 CF_WBAL - Command ..................................................................................18
8.4.8 CF_COLTEMP Command..............................................................................19

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
2/72
8.4.9 CF_PROGV Command ..................................................................................19
8.4.10 CF_NZRED Command...................................................................................19
8.4.11 CF_IMAGE Command ...................................................................................20
8.4.12 CF_IMAGEADJ Command............................................................................20
8.5 PC Adjust Control Command ..............................................................................21
8.5.1 CF_FSYNC Command...................................................................................21
8.5.2 CF_TDOTS Command...................................................................................21
8.5.3 CF_CLAMP Command...................................................................................21
8.5.4 CF_H – POS Command.................................................................................22
8.5.5 CF_V – POS Command .................................................................................22
8.5.6 CF_PCSTORE Command..............................................................................22
8.5.7 CF_PCMODEFREE Command......................................................................23
8.6 Input Control Command.......................................................................................24
8.6.1 CF_INPUT Command ....................................................................................24
8.6.2 CF_SOURCE Command................................................................................24
8.6.3 CF_INPUT1 Command ..................................................................................25
8.6.4 CF_INPUT2 Command ..................................................................................25
8.6.5 CF_INPUT3 Command ..................................................................................25
8.6.6 CF_INPUT4 Command ..................................................................................25
8.6.7 CF_INPUT5 Command ..................................................................................25
8.6.8 CF_INPUT_%1_%2 Command......................................................................26
8.6.9 CF_SYSTEM Command ................................................................................26
8.7 Screen Control Command ...................................................................................27
8.7.1 CF_SCREEN Command ................................................................................27
8.7.2 CF_DZCENT Command.................................................................................27
8.7.3 CF_KEYSTONE Command ...........................................................................28
8.7.4 CF_KYSTNMODE Command........................................................................28
8.7.5 CF_VSCALE Command.................................................................................28
8.7.6 CF_VPOS Command .....................................................................................29
8.7.7 CF_HSCALE Command ................................................................................29
8.7.8 CF_HPOS Command.....................................................................................30
8.7.9 CF_CEIL Command.......................................................................................30
8.7.10 CF_REAR Command.....................................................................................30
8.7.11 CF_COLBOARD Command ..........................................................................31
8.8 Lamp Command....................................................................................................32
8.8.1 CF_LAMPH Command ..................................................................................32
8.8.2 CF_LAMPMODE Command ..........................................................................32
8.9 Sound Command ..................................................................................................33
8.9.1 CF_VOLUME Command................................................................................33
8.9.2 CF_MUTE Command.....................................................................................33

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
3/72
8.10 Setting Command .................................................................................................34
8.10.1 CF_LANG Command.....................................................................................34
8.10.2 CF_MENUPOSITION Command ...................................................................34
8.10.3 CF_AUTOSETUPPCADJ Command.............................................................35
8.10.4 CF_INPUTSEARCH Command.....................................................................35
8.10.5 CF_AUTOSETUP Command.........................................................................35
8.10.6 CF_3D SET Command...................................................................................35
8.10.7 CF_3DSYNC Command.................................................................................36
8.10.8 CF_3DSIDE2D Command..............................................................................36
8.10.9 CF_3DPHASE Command..............................................................................36
8.10.10 CF_ZOOM Command.................................................................................36
8.10.11 CF_BACKGND Command .........................................................................37
8.10.12 CF_DISP Command ...................................................................................37
8.10.13 CF_LOGO Command.................................................................................38
8.10.14 CF_ HDMI SETUP Command ....................................................................38
8.10.15 CF_HDMI SOUND Command ....................................................................38
8.10.16 CF_TERMINAL Command.........................................................................39
8.10.17 CF_STANDBYMODE Command................................................................39
8.10.18 CF_P-MANE Command .............................................................................39
8.10.19 CF_P-MANETIME Command.....................................................................39
8.10.20 CF_ON-STACommand ..............................................................................40
8.10.21 CF_CCAPTIONDISP Command ................................................................40
8.10.22 CF_CCAPTIONCOLOR Command............................................................40
8.10.23 CF_RCODE Command...............................................................................41
8.10.24 CF_KEYDIS Command ..............................................................................41
8.10.25 CF_PJPINCODE Command.......................................................................41
8.10.26 CF_FANMODE Command..........................................................................42
8.10.27 CF_FANCONTROL Command...................................................................42
8.10.28 CF_FILTIMER Command...........................................................................42
8.10.29 CF_FILH Command....................................................................................42
8.10.30 CF_FDEFAULT Command.........................................................................43
8.11 Other Command....................................................................................................44
8.11.1 CF_KEYENU Command ................................................................................44
8.11.2 CF_MENU Command.....................................................................................44
8.11.3 CF_POWER Command..................................................................................44
8.11.4 CF_FREEZE Command.................................................................................45
8.11.5 CF_VMUTE Command...................................................................................45
8.11.6 CF_PTIMER Command..................................................................................45
9. Status Read Command................................................................................................46
9.1 Format....................................................................................................................46

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
4/72
9.2 Transfer Example..................................................................................................46
9.3 Operation Condition.............................................................................................46
9.4 Image Status Read Command.............................................................................47
9.4.1 CR_BRIGHT Command.................................................................................47
9.4.2 CR_CONT Command.....................................................................................47
9.4.3 CR_COLOR Command..................................................................................47
9.4.4 CR_TINT Command.......................................................................................47
9.4.5 CR_SHARP Command ..................................................................................47
9.4.6 CR_GAMMA Command.................................................................................48
9.4.7 CR_WBAL – R Command .............................................................................48
9.4.8 CR_WBAL – G Command .............................................................................48
9.4.9 CR_WBAL – B Command .............................................................................48
9.4.10 CR_COLTEMP Command..............................................................................48
9.4.11 CR_NZRED Command ..................................................................................49
9.4.12 CR_PROGV Command..................................................................................49
9.4.13 CR_IMAGE Command...................................................................................49
9.4.14 CR_IMGGMD Command................................................................................49
9.5 PC Adjust Status Read Command ......................................................................50
9.5.1 CR_FSYNC Command...................................................................................50
9.5.2 CR_TDOTS Command...................................................................................50
9.5.3 CR_CLAMP Command..................................................................................50
9.5.4 CR_H – POS Command.................................................................................50
9.5.5 CR_V – POS Command.................................................................................50
9.5.6 CR_PCSTORE Command .............................................................................51
9.6 Video Status Read Command..............................................................................52
9.6.1 CR_SERSYS Command................................................................................52
9.7 Input Status Read Command...............................................................................53
9.7.1 CR_INPUT Command....................................................................................53
9.7.2 CR_SOURCE Command ...............................................................................53
9.7.3 CR_SRCINP1 Command ...............................................................................53
9.7.4 CR_SRCINP2 Command ...............................................................................53
9.7.5 CR_SRCINP3 Command ...............................................................................53
9.7.6 CR_SRCINP4 Command ...............................................................................54
9.7.7 CR_SRCINP5 Command ...............................................................................54
9.7.8 CR_SYSTEM Command................................................................................55
9.7.9 CR_SYSLIST Command................................................................................56
9.7.10 CR_MODELIST Command ............................................................................56
9.8 Screen Status Read Command............................................................................57
9.8.1 CR_SCREEN Command................................................................................57
9.8.2 CR_ KYSTNMODE Command.......................................................................57

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
5/72
9.8.3 CR_VSCALE Command ................................................................................57
9.8.4 CR_VPOS Command.....................................................................................57
9.8.5 CR_HSCALE Command................................................................................58
9.8.6 CR_HPOS Command.....................................................................................58
9.8.7 CR_ CEIL Command......................................................................................58
9.8.8 CR_ REAR Command....................................................................................58
9.8.9 CR_ COLBOARD Command.........................................................................58
9.9 Lamp Status Read Command..............................................................................59
9.9.1 CR_LAMPREPL Command...........................................................................59
9.9.2 CR_LAMPH Command..................................................................................59
9.9.3 CR_LAMPCORRESPH Command................................................................59
9.9.4 CR_LAMPMODE Command..........................................................................59
9.9.5 CR_LAMPMSTS Command...........................................................................60
9.9.6 CR_PROJH Command ..................................................................................60
9.9.7 CR_HMLAMP Command...............................................................................60
9.10 Sound Status Read Command ............................................................................61
9.10.1 CR_VOLUME Command ...............................................................................61
9.10.2 CR_MUTE Command.....................................................................................61
9.11 Setting Status Read Command ...........................................................................62
9.11.1 CR_LANG Command.....................................................................................62
9.11.2 CR_AUTOSETUPPCADJ Command ............................................................62
9.11.3 CR_INPUTSEARCH Command.....................................................................62
9.11.4 CR_３DSET Command..................................................................................63
9.11.5 CR_3DSYNC Command ................................................................................63
9.11.6 CR_3DSIDE2D Command.............................................................................63
9.11.7 CR_3DPHASE Command..............................................................................63
9.11.8 CR_ZOOM Command ..................................................................................63
9.11.9 CR_BACKGND Command ............................................................................64
9.11.10 CR_DISP Command...................................................................................64
9.11.11 CR_LOGO Command.................................................................................64
9.11.12 CR_HDMI SETUP Command.....................................................................64
9.11.13 CR_HDMI SETUPSOUND Command........................................................64
9.11.14 CR_TERMINAL Command.........................................................................65
9.11.15 CR_STANDBYMODE Command...............................................................65
9.11.16 CR_P-MANE Command.............................................................................65
9.11.17 CR_P-MANETIME Command ....................................................................65
9.11.18 CR_ON-STACommand..............................................................................65
9.11.19 CR_CCAPTIONDISP Command................................................................66
9.11.20 CR_CCAPTIONCOLOR Command ...........................................................66
9.11.21 CR_RCODE Command ..............................................................................66

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
6/72
9.11.22 CR_SECURITY Command.........................................................................66
9.11.23 CR_KEYDIS Command..............................................................................66
9.11.24 CR_PJLOCKNOW Command....................................................................67
9.11.25 CR_PJLOCKMENU Command..................................................................67
9.11.26 CR_FANMODE Command.........................................................................67
9.11.27 CR_FANCONTROL Command..................................................................67
9.11.28 CR_FILH Command ...................................................................................67
9.11.29 CR_FILREPL Command ............................................................................68
9.11.30 CR_FILTIMER Command...........................................................................68
9.12 Other Status Read Command..............................................................................69
9.12.1 CR_STATUS Command.................................................................................69
9.12.2 CR_SIGNAL Command .................................................................................69
9.12.3 CR_VMUTE Command ..................................................................................69
9.12.4 CR_FREEZE Command.................................................................................69
9.12.5 CR_ PTIMER Command ................................................................................70
9.12.6 CR_TEMPWARN Command..........................................................................70
9.12.7 CR_TEMP Command.....................................................................................71
9.12.8 CR_TEMPFAIL Command.............................................................................72
9.12.9 CR_ SERIALNO Command...........................................................................72

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
7/72
1. Overview
1.1 This Functional Specification defines communication functions for PDG-DXL2000.
1.2 Compatible to Firmware Ver. 1.x of the projector.
1.3 Most commands can be used to control projector remotely from PC by RS-232C. Therefore, the
commands are defined as Expand Serial Commands.
2. Serial Interface Specification
2.1Transfer Specification
Item Specification
Synchronous System Asynchronous
Transmission Speed 9600 / 19200
Data Length 8 bit
Parity N/A
Stop Bit 1
Flow Control N/A
Note1) Transmission Speed : initial setting value is 19200
Note2) Transmission Speed can be changed in service mode.
2.2Connection
Dedicated serial cable must be used for a connection to a computer and a projector.
PC     Projector
COM 1    Control Port
(D-Sub 9 Pin) (D-Sub 9 Pin)

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
8/72
3. Notes for communication
1. Expand Serial Command is defined as one command / one line that starts with “C” and ends
with carriage return (0x0D)
2. There are two types of commands: Functional Execution Command and Status Read
Command.
- Example of Functional Execution Command:”CF_BRIGHT_032”[CR]
- Example of Status Read Command: “CR_RIGHT”[CR]
Note) ”_” means a space
3. When it takes more than one second to receive one command, it is not executed.
When it takes more than one second to receive carriage return (0X0D) after the projector
receives the first data “C”, it clears the information of buffer.
4. On command pipelining, wait for the interval of 100ms till sending next command after receiving
a response.
                                 (More than 100ms)
Command
PC →Projector    “CF_BRIGHT_032” CR Next Command
Projector →PC  “000” CR
Response
(A few ms - 5s)
When a computer sends next command before receiving a response, the projector may not operate
properly, except when there is no response for more than 5 seconds.
5. It takes about 5 seconds for internal initialization after plugging in AC power. During this time
commands cannot be processed. Do not issue any command.
4. Name Definition
1. Data from a controller to a projector is represented as COMMAND, and data from a projector to
a controller for the incoming command is represented as RESPONSE.
2. [CR] : Carriage Return Code
Command ends with cartridge return code.
Response also ends with carriage return code.
3. _ : Space Code
A space Code is indicated by (_).
4. %1 : Parameter in Command
When there are several parameters, they are defined as %2, %3…
5. %%% : Error code returned from a projector
Acceptable: “000”.
Unacceptable: See [7. Error Code Table].
6. %a : Parameter in Response Command
When there are several parameters, they are defined as %b, %c…

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
9/72
5. Functional Execution Command Table
5.1 Image Command Table
Execute command Item
CF_BRIGHT_%1[CR] Set Brightness value
CF_CONT_%1[CR] Set Contrast value
CF_COLOR_%1[CR] Set Color value
CF_TINT_%1[CR] Set Tint value
CF_SHARP_%1[CR] Set Sharpness value
CF_GAMMA_%1[CR] Set Gamma value
CF_WBAL-R_%1[CR] Set White Balance Red value
CF_WBAL-G_%1[CR] Set White Balance Green value
CF_WBAL-B_%1[CR] Set White Balance Blue value
CF_COLTEMP_%1[CR] Set Color Temp. value
CF_PROGV_%1[CR] Set /Cancel Progressive Scan
CF_NZRED_%1[CR] Set/Cancel Noise reduction
CF_IMAGE_%1[CR] Set Image mode
CF_IMAGEADJ_%1[CR] Reset/Store for Image Adjustment
5.2 PC Adjust Control Command Table
Execute command Item
CF_FSYNC_%1[CR] Set Fine Sync value
CF_TDOTS_%1[CR] Set Total Dots value
CF_CLAMP_%1[CR] Set Clamp Value
CF_H-POS_%1[CR] Set Horizontal Position value
CF_V-POS_%1[CR] Set Vertical Position value
CF_PCSTORE_%1[CR] Store the setting value of PC Adjust menu to Mode 1-10
CF_PCMODEFREE_%1[CR]
Delete the registered value in Mode 1-10 and return it to
Free status
5.3 Input Control Command Table
Execute command Item
CF_INPUT_%1[CR] Select Input
CF_SOURCE_%1[CR] Select Input Source
CF_INPUT1 _%1[CR] Select computer-1 and source selected in %1
CF_INPUT2_%1[CR] Select computer-2 and source selected in %11
CF_INPUT3_%1[CR] Select HDMI and source selected in %1
CF_INPUT4_%1[CR] Select Video and source selected in %1
CF_INPUT5_%1[CR] Select S-video and source selected in %1
CF_INPUT_%1_%2[CR] Select Input and Source
CF_SYSTEM_%1[CR] Select System

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
10/72
5.4 Screen Command Table
Execute command Item
CF_SCREEN_%1[CR] Select Screen size
CF_DZCENT_%1[CR] Cancel Digital Zoom mode
CF_KEYSTONE_%1[CR] Set Keystone
CF_KYSTNMODE_%1[CR] Set Keystone Store mode
CF_VSCALE_%1[CR] Set value of Vertical scale
CF_VPOS_%1[CR] Set value of Vertical position
CF_HSCALE_%1[CR] Set value of Horizontal scale
CF_HPOS_%1[CR] Set value of Horizontal position
CF_CEIL_%1[CR] Set Ceiling function
CF_REAR_%1[CR] Set Rear function
CF_COLBOARD_%1[CR] Set Colorboard mode
5.5 Lamp Command Table
Execute command Item
CF_LAMPH_%1[CR] Reset Lamp use time
CF_LAMPMODE_%1[CR] Select Lamp mode
5.6 Sound Command Table
Execute command Item
CF_VOLUME_%1[CR] Set Volume value
CF_MUTE_%1[CR] Control ON/OFF of Sound Mute
5.7 Setting Command Table
Execute command Item
CF_LANG_%1[CR] Select language for OSD
CF_MENUPOSITION_%1[CR] Move menu position.
CF_AUTOSETUPPCADJ_%1 [CR]
Set Auto PC in Auto Setup
CF_INPUTSEARCH_%1[CR] Set Input search function
CF_AUTOSETUP_%1[CR] Execute Auto Setup
CF_3DSET_%1[CR] Set3Dfunction
CF_3DSYNC_%1[CR] Set3DSync
CF_3DSIDE2D_%1[CR] Set3D→2D
CF_3DPHASE_%1[CR] Set3DPhase。
CF_ZOOM_%1[CR] SelectZoomstoremode
CF_BACKGND_%1[CR] Set screen mode for the case of no signal
CF_DISP_%1[CR] Set Display function
CF_LOGO_%1_%2[CR] Set Logo function
CF_HDMISETUP_%1[CR] Set Imagemode of HDMI menu.
CF_HDMISOUND_%1[CR] Set Sound mode of HDMI menu.
CF_TERMINAL_%1[CR] Select mode of Terminal menu
CF_STANDBYMODE_%1[CR] Set Standby Mode
CF_P-MANE_%1[CR] Set Power management function
CF_P-MANETIME_%1[CR] Set Power management time
CF_ON-STA_%1[CR] Set Direct on function
CF_CCAPTIONDISP_%1[CR] Set channel of Closed caption
CF_CCAPTIONCOLOR_%1[CR] Set color of Closed caption
CF_RCODE_%1[CR] Select Remote Control Reception Code
CF_KEYDIS_%1[CR] Disable RC/Projector keys
(Only available to models with top panel button)
CF_PJPINCODE_%1[CR] Input PIN code to release PJ Lock
CF_FANMODE_%1[CR] Select Fan mode
CF_FANCONTROL_%1[CR] Select Fan control mode
CF_FILTIMER_%1[CR] Set time when Filter warning OSD is displayed
CF_FILH_%1[CR] Reset Filter used time

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
11/72
CF_FDEFAULT_%1[CR] Set the value to Factory Default
5.8 Other Command Table
Execute command Item
CF_KEYEMU_%1[CR] Behave the same as corresponding key of the projector /
remote control.
CF_MENU_%1[CR] Switch ON/OFF of each Menu.
CF_POWER_%1[CR] Switch ON/OFF of Power.
CF_FREEZE _%1[CR] Set Freeze function.
CF_VMUTE _%1[CR] Set No show function.
CF_PTIMER_%1[CR] Set P-Timer function


PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
12/72
6. Status Read Command Table
6.1 Image Status Read Command Table
Status read command Item
CR_BRIGHT[CR] Get Brightness value
CR_CONT[CR] Get Contrast value
CR_COLOR[CR] Get Color value
CR_TINT[CR] Get Tint value
CR_SHARP[CR] Get Sharpness value
CR_GAMMA[CR] Get Gamma value
CR_WBAL-R[CR] White Balance Red value
CR_WBAL-G[CR] White Balance Green value
CR_WBAL-B[CR] White Balance Blue value
CR_COLTEMP[CR] Get setting value of Color temperature
CR_NZRED[CR] Get setting status of Noise reduction
CR_PROGV[CR] Get setting status of Progressive scan
CR_IMAGE[CR] Get Selected Image status
CR_IMGGMD[CR] Get setting value of Image Gamma
6.2 PC Adjust Status Read Command Table
Status read command Item
CR_FSYNC[CR] Get setting value of Fine Sync
CR_TDOTS[CR] Get setting value of TotalDots
CR_CLAMP[CR] Get setting value of Clamp
CR_H-POS[CR] Get setting value of Horizontal Position
CR_V-POS[CR] Get setting value of Vertical Position
CR_PCSTORE[CR] Get Free or Stored status for PC Adj. Mode 1-10
6.3 Video Status Read Command Table
Status read command Item
CR_SERSYS[CR] Get selected current signal. When in Auto mode, it returns a
result by Auto detect.
6.4 Input Status Read Command Table
Status read command Item
CR_INPUT[CR] Get selected Input No.
CR_SOURCE[CR] Get selected source of currently selected Input
CR_SRCINP1[CR] Get selected source of Computer 1
CR_SRCINP2[CR] Get selected source of Computer 2
CR_SRCINP3[CR] Get selected source of HDMI
CR_SRCINP4[CR] Get selected source of Video
CR_SRCINP5[CR] Get selected source of S-video
CR_SYSTEM[CR] Get selected system status in Input mode
CR_SYSLIST[CR] Get selectable System table
CR_MODELIST[CR] Get selectable Mode table 

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
13/72
6.5 Screen Status Read Command Table
Status read command Item
CR_SCREEN[CR] Get selected screen size
CR_KYSTNMODE[CR] Get setting status of Keystone Store mode
CR_VSCALE[CR] Get setting status of Vertical Scale
CR_VPOS[CR] Get setting status of Vertical Position
CR_HSCALE[CR] Get setting status of Horizontal Scale
CR_HPOS[CR] Get setting status of Horizontal Position
CR_CEIL [CR] Get setting status of Ceiling
CR_REAR[CR] Get setting status of Rear
CR_COLBOARD[CR] Get Selected Colorboard mode
6.6 Lamp Status Read Command Table
Status read command Item
CR_LAMPREPL[CR] Get the information for Lamp replacement time
CR_LAMPH[CR] Get lamp total running time
CR_LAMPCORRESPH[CR] Get corresponding lamp use time
CR_LAMPMODE[CR] Get Lamp Mode status
CR_LAMPSTS[CR] Get lamp lighting status
CR_PROJH[CR] Get projector total running time
CR_HMLAMP[CR] Get lamp number
6.7 Sound Status Read Command Table
Status read command Item
CR_VOLUME[CR] Get Volume value
CR_MUTE[CR] Get Sound Mute setting status
6.8 Setting Status Read Command Table
Status read command Item
CR_LANG[CR] Get selected language
CR_AUTOSETUPPCADJ Get setting status of Auto PC in Auto setup
CR_INPUTSEARCH[CR] Get setting status of Input search
CR_3DSET[CR] Get setting status of3Dfunction
CR_3DSYNC[CR] Get setting status of 3DSync
CR_3DSIDE2D[CR] Get setting status of 3D→2D
CR_3DPHASE[CR] Getthevalueof3DPhase
CR_ZOOM[CR] Get setting status of Zoom store mode
CR_BACKGND[CR] Get setting status screen mode for the case of no signal
CR_DISP[CR] Get setting status of Display
CR_LOGO[CR] Get setting status of Logo
CR_HDMISETUP[CR] Get status of Image mode of HDMI setup.
CR_HDMISOUND[CR] Get status of Sound mode of HDMI setup.
CR_TERMINAL[CR] Get setting status of Terminal.
CR_STANDBYMODE[CR] Get setting status of Standby Mode
CR_P-MANE[CR] Get setting status of Power management
CR_P-MANETIME[CR] Get setting time for Power management
CR_ON-STA[CR] Get setting status of Direct on
CR_CCAPTIONDISP[CR] Get setting status of channel of Closed caption
CR_CCAPTIONCOLOR[CR] Get setting status of color of Closed caption
CR_RCODE[CR] Get selected Remote Control Code
CR_SECURITY[CR] Get setting status of Security
CR_KEYDIS[CR] Get RC/KEY disability status
(Only available to models with top panel button)
CR_PJLOCKNOW[CR] Get if PJ Lock is actually in operation
CR_PJLOCKMENU[CR] Get setting status of PJ Lock
CR_FANMODE[CR] Get selected Fan mode

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
14/72
CR_FANCONTROL[CR] Get selected Fan Control Mode
CR_FILH[CR] Get Filter used time
CR_FILREPL[CR] Get the information for Filter replacement time
CR_FILTIMER[CR] Get time when Filter warning OSD is displayed
6.9 Other Status Read Command
Status read command Item
CR_STATUS[CR] Get setting status of Projector behavior
CR_SIGNAL[CR] Get Signal Status if there is a signal or not
CR_VMUTE[CR] Get setting status of No Show
CR_FREEZE[CR] Get setting status of Freeze
CR_PTIMER[CR] Get operation status of P-timer
CR_TEMPWARN[CR] Get if temperature is close to abnormal temperature
CR_TEMP[CR] Get current temperature status
CR_TEMPFAIL[CR] Get temperature when sensors approach abnormal
temperature
CR_SERIALNO[CR] Get serial number。

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
15/72
7. Error Code Table
Error Code Details
? -When the received data cannot be decoded -Parameter determination error (digit number error, including invalid
value, etc.)
101 When the function selected is not available under current condition.
ex) When receiving signal-related commands while no signal is entered
102 Selected value is out of range (Not reflected)
103 Command mismatched to Hardware (command for Optional function
which is not installed)
201 When reached upper or lower limit of increasing or decreasing data
301 Command cannot be executed during capturing display.
302 Command cannot be executed during Auto setup operation.
402 Command cannot be executed during PIN code operation.
Note) These error codes are applied to Expand Command, not to Basic Command

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
16/72
8. Functional Execution Command
8.1 Format
1. PC issues commands in format as below:
Pattern1 : “CF_COMMAND” [CR]
Pattern2 : “CF_COMMAND_”%1 [CR]
CF_: Header
COMMAND : Character line
%1 : Parameter (Character line)
_ : Space (To separate COMMAND and Parameter)
2. The projector decodes the received command and when it is ready to receive the next
command, it returns the response.
“000” [CR] : (0x06, 0x0D) When receiving FunctionalExecution Command
“nnn” [CR] : Except “000” , when it is unable to execute command by any specific reason.
See Error Code Table for details
3. When the received data cannot be decoded, the projector returns “?” [CR]
8.2 Transfer Example
When setting projector’s total dots to 1344 by Expand Serial Command
PC →PJ: ”CF_TDOTS_1344” [CR]
PC ←PJ: “000”[CR] - - - - - - - - - - -Acceptable
8.3 Operation Requirements
1) Functional Execution Command is limited when the projector status is as below.
However, Status Read Command is effective even under these conditions.
Projector Status Available Functional Execution Command
In Standby status C00: POWER ON only
Countdown in process
C00: POWER ON
(Terminates Countdown)
C01: POWER OFF
C02: POWER OFF
(Terminates Countdown)
Cooling down in process N/A
Cooling down in process due to Abnormal
Temperature N/A
Abnormal Temperature N/A
Power Failure
(For 60 seconds after Power Failure occurred)
N/A
Power Save /Cooling down in process N/A
Power Save in process C00: POWER ON
C01: POWER OFF
Note:) When the projector receives the other command in this above status, it returns
error code to show the status.
When the projector receives the following functional execution commands, OSD
menu is closed except for pop-up menu
2) Functional Execution Commands are invalid when Eco mode is selected in Standby mode of
Setting menu and projector is in standby

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
17/72
8.4 Image Command
8.4.1 CF_BRIGHT Command
Command "CF_BRIGHT_%1”[CR]
%1 "000~063” --------------- Directly select Brightness setting value "UP” ----------------------- Current Brightness setting value + 1
"DN” ----------------------- Current Brightness setting value – 1
Details
Set Brightness value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.2 CF_CONT Command
Command “CF_CONT_％1”[CR]
%1 “000~063” --------------- Directly select Contrast setting value
“UP” ----------------------- Current Contrast setting value + 1
“DN” ----------------------- Current Contrast setting value – 1
Details
Set Contrast value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable "Error Code”[CR]
8.4.3 CF_COLOR Command
Command “CF_COLOR_%1”[CR]
%1 “000~063” ---------------- Directly select Color setting value “UP” ------------------------ Current Color setting value + 1
“DN” ------------------------ Current Color setting value - 1
Details
Set Color value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.4 CF_TINT Command
Command “CF_TINT_%1”[CR]
%1 “000~063” --------------- Directly select Tint setting value “UP” ----------------------- Current Tint setting value + 1
“DN” ----------------------- Current Tint setting value – 1
Details
Set Tint value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
18/72
8.4.5 CF_SHARP Command
Command “CF_SHARP_%1”[CR]
%1 “000~015” ---------------- Directly select Sharpness setting value “UP” ------------------------ Current Sharpness setting value + 1
“DN” ------------------------ Current Sharpness setting value - 1
Details
Set Sharpness value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.6 CF_GAMMA Command
Command “CF_GAMMA_%1”[CR]
%1
“DFLT”--------------Set Default
“18” ----------------- Set 1.8
“20”----------------- Set 2.0
“22” ----------------- Set 2.2
“24”----------------- Set 2.4
“26”----------------- Set 2.6
Details
Set Gamma value of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.7 CF_WBAL - Command
Command “CF_WBAL-%1_%2”[CR]
%1 “Ｒ” --------------------- Red
“Ｇ” --------------------- Green
“Ｂ” --------------------- Blue
%2 “000~063” ----------- Directly select Color value specified byWhite Balance%1 “UP” ------------------- Current Color value set by White Balance%1 + 1
“DN” ------------------- Current Color value set byWhite Balance%1 - 1
Details
Set Color value set by White Balance%1 of user control
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]

PDG-DXL2000 Expand Serial Command Functional Specifications
                                       
19/72
8.4.8 CF_COLTEMP Command
Command “CF_COLTEMP_%1”[CR]
%1
“000” ------ Xlow
“001” ------ Low
“002” ------ Mid
“003” ------ High
Details
Set Color Temperature. (Available only in the normal Power ON status)
The value set by this command will not be saved to the projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.9 CF_PROGV Command
Command “CF_PROGV_%1”[CR]
%1
“FILM” -------- Select Progressive Mode FILM
“L1” ----------- Select Progressive Mode L1
“L2” ----------- Select Progressive Mode L2
“OFF” --------- Cancel Progressive scan
“UP” ----------- The same operation as pressing Up key or Left key
“DN” -----------The same operation as pressing Down key or Right key
Details
Set / cancel Progressive scan
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
8.4.10 CF_NZRED Command
Command “CF_NZRED_%1”[CR]
%1
“OFF” ------- Cancel Noise Reduction
“L1” --------- Noise Reduction for moving image
“L2” --------- Noise Reduction for still image
“UP” ------------The same operation as pressing Up key or Left key
“DN” -----------The same operation as pressing Down key or Right key
Details
Noise Reduction based on frame correlation
Select L1 or L2 depending on motion detection
L2 is more effective in reducing noise than L1, however, L2 can have a blur in
moving image
The value set by this command will not be saved to projector. Therefore, when
turning into Standby status or ALL is OFF, the value returns to original setting.
(The value is held in Suspend mode.)
This command is available in normal Power ON status.
Acceptable “000”[CR]
Response
Unacceptable “Error Code”[CR]
