Sanyo PDG-DWL100 - WXGA DLP Projector User manual

PDG-DXL100
PDG-DWL100
DLP®Super Short Throw
Projector
Using a conventional projector, a shadow
of the presenter or teacher may appear on
the screen.
The SANYO PDG-DXL100 or PDG-DWL100
prevents shadows from appearing on the
screen.
Projected image comparison
Screen
Projector
Projector
Screen
Shadow
Super short throw projection lens
80.8-inch image from 39 inches away (DXL100)
91.4-inch image from 39 inches away (DWL100)
Enhanced signal input choice
HDMI x 1, Computer IN x 2, Monitor OUT x 1
Built-in powerful speaker
8W speaker x 1
39”
Super short throw projection
allows positioning anywhere

Approximate throw distance/picture size
Terminals
Both models can project a large image from a short
distance of only 39-inches. As a result, the projector can
be located closer to the screen than with conventional
projectors, reducing light in the presenter’s eyes and
avoiding shadows of the presenter shown on the
screen. This makes these models ideal for business
presentations or educational applications even in limited
spaces such as small meeting rooms, retail stores or
trade shows.
Both models are equipped with 3 D-sub 15 pin terminals:
2 for computer input and 1 for monitor output. An HDMI
terminal is also provided to accommodate digital video
signal inputs.
The 8W speaker built into both models offers enough
output for locations such as typical classrooms. This
saves the expense of installing external speakers.
An RJ45 connector for wired LAN control offers easy
control and management of multiple projectors from
a remote location.
Approximate throw distances shown above were calculated on lens design
specifications. Please note that up to 5% deviation may result due to lens variation.
Built-in high-performance speaker
Networkable for easy control
and management
Enhanced signal input choice
Low stand-by power consumption
Less than 1W (with Eco stand-by power on)
Closed captioning
Supports CC1, CC2
Auto computer input search
Replacement Lamp: CHSP8EM01GC01
*1 Measurement, measuring conditions, and method of notation all coply with ISO 21118 international standards.
All product names and company names are trademarks or registered trademarks of their respective companies.
Design of the product, specifications are subject to change without notice.
Screen size
4:3 aspect ratio
40”
64”
77”
100”
150”
200”
250”
300”
ft
1.6
2.6
3.1
4.1
6.1
8.1
10.2
12.2
DXL100 Screen size
16:10 aspect ratio
46”
87”
95”
100”
150”
200”
250”
300”
ft
1.7
3.1
3.4
3.6
5.4
7.2
9.0
10.8
DWL100
DLP®Super Short Throw Projector
DLP®and the DLP logo are registered trademarks of Texas Instruments.
Specifications
Model name PDG-DXL100 PDG-DWL100
Panel “0.55 DLP x 1 “0.65 DLP x 1
Resolution 1024 x 768 (XGA) 1200 x 800 (WXGA)
Brightness (typical)*1 2700 lm 2600 lm
Contrast *1 750:1 1750:1
Uniformity *1 80%
Projection lens F2.6, f=6.97mm F2.6, f=7.198mm
Zoom / Focus Digital zoom max 2x, Manual focus
Lamp UHP 225 W
Screen Size 40-300-inches diagonally
(4:3)
46-338-inches diagonally
(16:10)
Throw ratio 0.609 distance / width 0.508 distance / width
U/D ratio 20:-3
SD/HDTV signals 480i, 480p, 575i, 575p, 720p, 1080i, 1080p
Color systems PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
Video Signal Composite, S-Video, Dsub-15pin for Component
Terminals
D-Sub 15 pin x 3 : 2 for input, 1 for monitor out
HDMI ver. 1.3 : for input
RCA: Video
Mini-DIN 4-pin: S-Video input
Audio Mini-jac for input and output (variable)
Communication Terminals Service Port (RS-232C), RJ-45 for LAN
Presentation Tool Freeze / Digital Zoom / No Show
Other Features Closed Captioning (CC1, CC2)
Scanning frequency H/V Sync 31, 35K-79.98kHz, 50-75Hz Dot Clock 170MHz
Sound output 8.0Watt Monoaural
Fan Noise 34 dBA / 29 dBA (Eco mode)
Voltage AC100-240 V, 50/60Hz, Auto voltage
Power consumption 320W (240W: Eco mode on)
Stand-by power 2.0W (0.9W: Eco stand-by power on)
Dimensions (W x H x D) 120.7 x 47.4 x 99.3 inch
Weight 8.2 lbs 8.4 lbs
On-screen menu Available
Included accessories Power cord, Computer cable (D-sub15-D-sub15), Owner’s
manual, Remote control, AAA type battery x 2, Lens cap
SANYO Presentation Technologies
© 2009 SANYO North America Corporation.
Toll free: 888-337-1215 www.sanyoprojectors.com
Super Short Throw Projection Lens
80.8-inch image from 39-inches away (DXL100)
91.4-inch image from 39-inches away (DWL100)
PDG-DXL100
PDG-DWL100
