PLC
PLC- -HP7000L HP7000L
1080P, HIGH BRIGHTNESS OF 7,000 LUMENS
The new projector PLC-HP7000L supports Full HD resolution without any
image compression. Advanced optical QuaDriveTM engine achieves the high
brightness of 7000 lumens with just one high-output lamp in the compact
black long-lasting body.
QUADRIVETM ENGINE ALLOWS RICH COLOR AND HIGH CONTRAST
SANYO’s Unique QuaDriveTM engine evolves into a new generation
standard. The color control device in the QuaDriveTM optical engine allows
the PLC-HP7000L to automatically control the amount of yellow light in the
image, producing higher luminosity with improved color accuracy and clarity.
SUPER HIGH CONTRAST DESIGN
This advanced optical system and Durable Inorganic Optical System
(D.I.O.S.) achieve high contrast to project high-quality images with rich
black reproduction, maximizing the quality of the video signals.
ACTIVE MAINTENANCE FILTER (AMF) FOR EASY MAINTENANCE
Minimal maintenance and repair was essential for the PLC-HP7000L, so it
was outfitted with SANYO’s exclusive Active Maintenance Filter (AMF).
AMF is a single filter cartridge that contains the equivalent of 10 filters,
reducing the burden of maintenance. It also has an airflow sensor to detect
when the airflow is obstructed by dust, the filter automatically advances.
NETWORK CONNECTIVITY
A built-in LAN allows for simple control and management of projectors via a
CAT5 network connection. The administrator is able to centrally control all
built-in LAN projectors in the network. Besides built-in network, optional PJ-
Net Camera (POA-PN03C) and PJ Master Software are available.
CRESTRON ROOMVIEWTM /AMX DEVICE DISCOVERY COMPATIBILITY
PLC-HP7000L supports Crestron RoomViewTM and AMX Device Discovery
which facilitates the remote management and centralized control.
VARIOUS FEATURES FOR VERSATILE INSTALLATION
When blending 2 or more projectors, the projector has versatile functions.
‘Edge Blending’ function allows lifelike boundary-less images with multi-
image displays. And built-in ‘Color Matching’ function corrects variations in
color reproduction for multiple projector usage.
BUILT IN MECHANICAL SHUTTER
A special mechanical shutter has been included behind the lens, open/close
controllable with the remote control, which darken the screen in a moment.
Resolution 1080p (1920 x 1080)
Brightness (typical) 7000 Lm
Contrast Ratio 2700:1
Image Size Dependent on Lens
Aspect Ratio 16:9
Projection Lamp 380W
Scanning Frequency H:15-120kHz, V:48-100Hz
Fan Noise 42.0 / 38.0 (Normal / Eco)
Voltage 100-240V
Power Consumption 520W / 430W (Normal / Eco)
Input signal compatibility WUXGA, UXGA, WSXGA+, SXGA/+, WXGA/+, XGA, SVGA, VGA, MAC
1080p/psf, 1080i, 1035i, 720p, 575p, 575i,480p, 480i
Color System PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
Up / Down Ratio Dependent on lens
Digital Keystone Correction Vertical & Horizontal
Speaker Output No
Weight (lbs) 25.6 Lbs
Dimensions (inch) W,H,D 14.6"x7.4"x17.3"
Replacement Lamp # 610 357 0464
Replacement Remote # 645 105 0809
Replacement AMF Cartridge POA-FIL131
Lamp Life * (hour) 3000h
Input PC/Video
HDMI(1.3b) x 1 (HDCP)
DVI-D x1(Digital RGB, HDCP)
D-sub 15 x 1 (RGB, Scart RGB)
5BNC x1 (G B R H/V V) (Video/Y Pb/Cb Pr/Cr)
Mini DIN 4pin x 1 (S-Video)
RCA x 1 (Composite Video, Y)
RCA x 2 ( Pb/Cb, Pr/Cr)
Audio N/A
Output PC/Video D-sub 15 x 1 (Monitor out)
Audio N/A
Other Feature D-sub 9-pin x 1 (Control port)
RJ-45 x 1 (Wired LAN)
Mini jack x 1 (Wired R/C)
USB (type B) x 1
Included Accessories
Power cord
VGA cable
Lens mount cover
Lens attachment
Remote control
AAA battery x2
Quick reference guide
Owner’s Manual (CD-Rom)
Network Owner’s Manual
PIN code label
Light block sheet
USB cable (for mouse)
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
* Lamp/filter life may vary due to room conditions, usage, and maintenance. The replacement time is a
general estimate. The brightness of a lamp usually decreases over time and use.
7000 ANSI LUMENS z1080P HD zQUADRIVETM PROJECTOR
1080P HD QuaDriveTM PROJECTOR
QuaDriveTM PJ-Net
Organizer
Plus
Optional
Lens System X-Y Power Len Shift
Active
Maintenance
Filter System
Built-In
Network
2.0-2.82.3-4.2:110:0 - 1:1
40”-600”
(x1.8)Long
LNS-T34
1.7-2.11.8-2.3:110:0 - 1:1
40”-600”
(x1.3)Standard
LNS-S32
2.1-2.8
1.3-1.8:1
10:0 - 1:1
40”-600”
(x1.4)Short
LNS-W33
2.30.8:11:1
40”-600”
(Fixed)On-Axis Short
LNS-W34
60”-400”
40”-400”
Image Size
2.2-2.75.7-8.9:17:-1 - 1:1
(x1.5)Ultra Long
LNS-T33
2.0-2.74.2-5.7:17:-1 - 1:1
(x1.4)Ultra Long
LNS-T32
Model Type (Zoom) U/D Ratio Throw Ratio F Stop
LENS OPTIONS
