BASIC SERIAL COMMAND SPECIFICATIONS
PLC-XC50/55
Ver.1.00
SANYO Electric Co., Ltd
DS Company
Projector Division

PLC
-
XC50/55 Basic Serial Command Specifications
2/25
−CONTENTS −
1. Overview .........................................................................................................................4
2. Serial Interface Specifications......................................................................................4
2.1. Transfer Specifications ..........................................................................................4
2.2. Connection ..............................................................................................................4
3 Notes for Communication.............................................................................................5
4 Functional Execution Command Table........................................................................6
5 Status Read Command Table........................................................................................8
6 Functional Execution Command..................................................................................9
6.1. Format......................................................................................................................9
6.2. Command Pipelining..............................................................................................9
6.3. Transfer Example....................................................................................................9
6.4. Operation Requirements..................................................................................... 10
6.5. POWER ON Command .........................................................................................11
6.6. POWER OFF Command （Quick Power OFF）................................................11
6.7. POWER OFF Command........................................................................................11
6.8. Computer 1 Command .........................................................................................11
6.9. Computer 2 Command .........................................................................................11
6.10. Video Command................................................................................................... 12
6.11. VOLUME + Command.......................................................................................... 12
6.12. VOLUME – Command.......................................................................................... 12
6.13. AUDIO MUTE ON Command............................................................................... 12
6.14. AUDIO MUTE OFF Command ............................................................................. 12
6.15. VIDEO MUTE ON Command ............................................................................... 13
6.16. VIDEO MUTE OFF Command.............................................................................. 13
6.17. Screen Normal size Command........................................................................... 13
6.18. Screen Wide size Command............................................................................... 13
6.19. Image Standard Command ................................................................................. 13
6.20. Image Real Command ......................................................................................... 13
6.21. Image Cinema Command.................................................................................... 14
6.22. Image1 Command................................................................................................ 14
6.23. Image2 Command................................................................................................ 14
6.24. Image3 Command................................................................................................ 14
6.25. Image4 Command................................................................................................ 14
6.26. Image Blackboard (Green) Command ............................................................... 14
6.27. Image Dynamic Command.................................................................................. 14
6.28. MENU ON Command ........................................................................................... 15
6.29. MENU OFF Command.......................................................................................... 15
6.30. DISPLAY CLEAR Command................................................................................ 15
6.31. BRIGHTNESS + Command.................................................................................. 15

PLC
-
XC50/55 Basic Serial Command Specifications
3/25
6.32. BRIGHTNESS – Command.................................................................................. 15
6.33. Computer 2 Component Command................................................................... 15
6.34. Computer 2 RGB Command ............................................................................... 16
6.35. Computer 2 SCART Command........................................................................... 16
6.36. IMAGE (Toggle) Command.................................................................................. 16
6.37. ON START Setting Command............................................................................. 16
6.38. ON START Cancel Command ............................................................................. 16
6.39. Power Management Ready Command .............................................................. 16
6.40. Power Management OFF Command.................................................................. 17
6.41. Power Management Shut down Command....................................................... 17
6.42. D.ZOOM + Command........................................................................................... 17
6.43. D.ZOOM – Command........................................................................................... 17
6.44. Video Auto Command.......................................................................................... 17
6.45. Video Video Command........................................................................................ 17
6.46. Video S-Video Command .................................................................................... 18
6.47. Image Colorboard Command ............................................................................. 18
6.48. POINTER RIGHT Command................................................................................ 18
6.49. POINTER LEFT Command .................................................................................. 18
6.50. POINTER UP Command ...................................................................................... 18
6.51. POINTER DOWN Command................................................................................ 18
6.52. ENTER Command ................................................................................................ 19
6.53. FREEZE ON Command........................................................................................ 19
6.54. FREEZE OFF Command...................................................................................... 19
6.55. Computer 1 Analog RGB Command.................................................................. 19
6.56. Computer 1 DVI (PC Digital) Command............................................................. 19
6.57. Computer 1 DVI (AV HDCP) Command.............................................................. 19
6.58. AUTO PC ADJ. Command................................................................................... 20
6.59. PRESENTATION TIMER Command .................................................................... 20
6.60. KEYSTONE ↑Command....................................................................................... 20
6.61. KEYSTONE ↓Command....................................................................................... 20
7. Status Read Command............................................................................................... 21
7.1. Format................................................................................................................... 21
7.2. Transfer Example................................................................................................. 21
7.3. Status Read Command........................................................................................ 22
7.4. Input Mode Read Command ............................................................................... 24
7.5. Lamp Time Read Command................................................................................ 24
7.6. Setting Read Command ...................................................................................... 24
7.7. Temp Read Command ......................................................................................... 25
7.8. Lamp Mode Read Command .............................................................................. 25

PLC
-
XC50/55 Basic Serial Command Specifications
4/25
1. Overview
1.1. These specifications define projector control commands for PLC-XC50/55.
1.2. The projector control commands are used to remotely control a projector through RS-232C from a
computer.
2. Serial Interface Specifications
2.1. Transfer Specifications
Item Specifications
Synchronous system Asynchronous
Transmission Speed 9600 / 19200
Data Length 8 bit
Parity N/A
Stop Bit 1
Flow Control N/A
1) Transmission speed: initial setting value is 19200.
2) Transmission speed can be changed in service mode.
2.2. Connection
Dedicated serial cable must be used for connection to a computer and a projector.
PC Projector
COM 1  Control Port
（D‑Sub9Pin）（D‑Sub9Pin）

PLC
-
XC50/55 Basic Serial Command Specifications
5/25
3 Notes for Communication
3.1The projector control command is defined as one command/one line that starts with “C” and
ends with carriage return (0x0D).
3.2There are two types of Commands: Functional Execution Commands and Status Read
Commands.
Example of Functional Execution Command: “C05” [CR]
Example of Status Read Command: “CR0” [CR]
3.3 When it takes more than one second to receive one command, it does not operate.
The information of buffer is cleared when it takes more than one second to receive carriage
return (0x0D) after the projector receives the first data “C”.
3.4 For Command pipelining, wait for the interval of 100ms after receiving a response.
More than 100ms
Command
PC →Projector “C” “0” “7” CR Next Command
Projector →PC ACK CR
Response
（Afew ms 〜5s）
3.4.1. When a command is issued before receiving a response, the function is not executed
properly.
3.4.2.Except for when there is no Response for more than 5 seconds.
3.5 It takes about 5 seconds for internal initialization after plugging in AC power. During this time,
it cannot process commands.Do not issue any command.
3.6 The number of characters of response to Status Read Commands depends on commands.
Please see [7. Status Read Commands].
3.7 Characters for commands must be Capital (A - Z).

PLC
-
XC50/55 Basic Serial Command Specifications
6/25
4 Functional Execution Command Table
Command
Item
Command
Item
C00 POWER ON C20 BRIGHTNESS +
C01
POWER OFF
（Quick Power OFF）C21 BRIGHTNESS -
C02 POWER OFF C22 ―――
C03 ――― C23 ―――
C04 ――― C24 Computer 2 Component
C05 Computer 1 C25 Computer 2 RGB
C06 Computer 2 C26 Computer 2 Scart
C07 Video C27 IMAGE （Toggle）
C08 ――― C28 ON START Enable
C09 VOLUME + C29 ON START Disable
C0A VOLUME - C2A Power Management Ready
C0B AUDIO MUTE ON C2B Power Management OFF
C0C AUDIO MUTE OFF C2C ―――
C0D VIDEO MUTE ON C2D ―――
C0E VIDEO MUTE OFF C2E Power Management Shut down
C0F Screen Normal size（4：3）C2F ―――
C10 Screen Wide size（16：9）C30 D.ZOOM +
C11 Image Standard C31 D.ZOOM -
C12 Image Real C32 Video Auto
C13 Image Cinema C33 Video Video
C14 Image 1 C34 Video S-video
C15 Image 2 C35 ―――
C16 Image 3 C36 ―――
C17 Image 4 C37 ―――
C18 Blackboard C38 ―――
C19 Dynamic C39 Image Colorboard
C1A ――― C3A POINTER RIGHT
C1B ――― C3B POINTER LEFT
C1C MENU ON C3C POINTER UP
C1D MENU OFF C3D POINTER DOWN
C1E DISPLAY CLEAR C3E ―――
C1F ――― C3F ENTER
――― means no function.

PLC
-
XC50/55 Basic Serial Command Specifications
7/25
Command
Item
Command
Item
C40 ――― C80 ―――
C41 ――― C81 ―――
C42 ――― C82 ―――
C43 FREEZE ON C83 ―――
C44 FREEZE OFF C84 ―――
C45 ――― C85 ―――
C46 ――― C86 ―――
C47 ――― C87 ―――
C48 ――― C88 ―――
C49 ――― C89 Auto PC ADJ.
C4A ――― C8A PRESENTATION TIMER
C4B ――― C8B ―――
C4C ――― C8C ―――
C4D ――― C8D ―――
C4E ――― C8E KEYSTONE ↑
C4F ――― C8F KEYSTONE ↓
C50 Computer 1 Analog RGB C90 ―――
C51 ――― C91 ―――
C52 Computer 1 DVI (PC Digital) C92 ―――
C53 Computer 1 DVI (AV HDCP) C93 ―――
C54 ――― C94 ―――
C55 ――― C95 ―――
C56 ――― C96 ―――
C57 ――― C97 ―――
C58 ――― C98 ―――
C59 ――― C99 ―――
C5A ――― C9A ―――
C5B ――― C9B ―――
C5C ――― C9C ―――
C5D ――― C9D ―――
C5E ――― C9E ―――
C5F ――― C9F ―――
――― means no function.

PLC
-
XC50/55 Basic Serial Command Specifications
8/25
5 Status Read Command Table
Command Item Memo
CR0 Status Read
CR1 Input Mode Read
CR2 ―――
CR3 (Corresponding)LampTimeRead
CR4 Setting Read
CR5 ―――
CR6 Temp Read
CR7 Lamp Mode Read
CR8 ―――
CR9 ―――
CRA ―――
CRB ―――
CRC ―――
――― means no function.

PLC
-
XC50/55 Basic Serial Command Specifications
9/25
6 Functional Execution Command
6.1. Format
6.1.1 PC issues a command in format as below.
“C” COMMAND [CR]
Command: two characters (See Basic Functional Execution Command Table)
6.1.2 A projector changes received data to decode and returns a result after being ready to
receive next command.
[ACK]［CR］：（0x06、0x0D）When received Functional Execution Commands.
6.1.3 “？”［CR］：When the received data cannot be decoded.
6.2. Command Pipelining
When some functions need the command pipelining, the performance is the same as that of the
remote control;
6.2.1. System: issues any command every 100 ms.
6.2.2. When receiving the appropriate command, the function is executed for 120 ms from the
moment.
6.2.3. When receiving the same command continuously within 120 ms, the function is executed
for another 120 ms from the moment.
6.2.4. When there is no incoming command after 120 ms, the execution of pipelining is stopped.
6.2.5. When the projector receives other incoming commands within 120ms, the execution of
pipelining is stopped.
6.3. Transfer Example
Switch the projector to video mode with Basic Command.
Command
PC →Projector C07CR
Projector →PC ACK CR
Processing
（Afewms 〜5s）

PLC
-
XC50/55 Basic Serial Command Specifications
10/25
6.4. Operation Requirements
When the projector status is any of below, Functional Execution Commands are limited.
Projector Status Available Functional Execution Commands
Standby Mode C00：POWER ON
Countdown in process C00：POWER ON →Countdown is terminated C01：POWER OFF
C02：POWER OFF →Countdown is terminated
Cooling Down in process NONE (No Execution)
Cooling Down due to Abnormal
Temperature NONE (No Execution)
Abnormal Temperature Status NONE (No Execution)
Abnormal Power Status NONE (No Execution)
Power Save / Cooling Down
in process
NONE
(No Execution)
Power Save Status C00：POWER ON
C01：POWER OFF
Input search：On1/On2 setting
A
lthough transmit Input source commands, Input
search does no operate.
Note) When the status is as above, even if the projector receives other commands, it returns
[ACK] [CR].

PLC
-
XC50/55 Basic Serial Command Specifications
11/25
6.5. POWER ON Command
Command
“C
00
”
[CR]
Detail
Power ON
When already Power is ON, nothing is done.
When sending this command during processing Countdown, Countdown is
terminated.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.6. POWER OFF Command （Quick Power OFF）
Command
“C
01
”
[CR]
Detail
Power OFF (Standby)
When Power is OFF with ON/STAND-BY button of the projector and remote
control, “Power OFF?” is displayed. However, as soon as this command is sent,
Quick Power OFF is executed.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.7. POWER OFF Command
Command
“C
02
”
[CR]
Detail
Power OFF (Standby).
The command operates the same Power OFF function as ON/STAND-BY button
of the projector and remote control.
Once this command is sent, “Power OFF?” is displayed. If this command is sent
again while it is displayed, Power OFF is executed.
When sending this command during Countdown, Countdown is terminated.
Response
Acceptable
[ACK] [CR]
Unacceptable
？[CR]
6.8. Computer 1 Command
Command
“C
05
”
[CR]
Detail
Select Computer 1 Input
.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.9. Computer 2 Command
Command
“C
06
”
[CR]
Detail
Select
Computer2 Input
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
12/25
6.10. Video Command
Command
“
C07
”
[CR]
Detail
Select Video Input
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.11. VOLUME + Command
Command
“
C09
”
[CR]
Detail
Volume Up.
This command operates the same way as “VOLUME+” button of the projector and
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.12. VOLUME – Command
Command
“
C0A
”
[CR]
Detail
Volume Down
This command operates the same way as “VOLUME-” button of the projector and
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.13. AUDIO MUTE ON Command
Command
“
C0B
”
[CR]
Detail
Sound Mute ON.
This command works the same way as “MUTE” button of the remote control for
Mute ON, but does not work for Mute OFF.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.14. AUDIO MUTE OFF Command
Command
“C0C” [CR]
Detail
Sound Mute OFF.
This command works the same way as “MUTE” button of the remote control for
Mute OFF, but does not work for Mute ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
13/25
6.15. VIDEO MUTE ON Command
Comman
d
“C0D”[CR]
Detail
Video Mute
ON.
This command works the same way as “NO SHOW” button of the remote control
for No Show ON, but does not work for No ShowOFF.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.16. VIDEO MUTE OFF Command
Command
“C0E” [C
R]
Detail
Video Mute OFF.
This command works the same way as “NO SHOW” button of remote control for
No Show OFF, but does not work for No Show ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.17. Screen Normal size Command
Command
“C0F” [CR]
Detail
Set screen
mode
to
Regular (
4:3)
.
This command is valid even while D.Zoom is in operation.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.18. Screen Wide size Command
Command
“C10” [CR]
Detail
Set screen
mode
to
Wide (
16:9)
.
This command is valid even while D.Zoom is in operation.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.19. Image Standard Command
Command
“C11” [CR]
Detail
Set
to Standard mode
.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.20. Image Real Command
Command
“
C12” [CR]
Detail
Set
to Real mode.
Response
Acceptable
[ACK] [CR]
Unacceptable
？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
14/25
6.21. Image Cinema Command
Command
“C13” [CR]
Detail
Set
to Cinema mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.22. Image1 Command
Command
“C
14” [CR]
Detail
Set image to Image1 mode.
Response
Acceptable
[ACK] [CR]
Unacceptable
？[CR]
6.23. Image2 Command
Command
“C15” [CR]
Detail
Set image to Image2 mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.24. Image3 Command
Command
“C16” [C
R]
Detail
Set image to Image3 mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.25. Image4 Command
Command
“C17” [CR]
Detail
Set image to Image4 mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.26. Image Blackboard (Green) Command
Comm
and
“C18” [CR]
Detail
Set image to Blackboard (Green)mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.27. Image Dynamic Command
Command
“C19” [CR]
Detail
Set image to Dynamic mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
15/25
6.28. MENU ON Command
Command
“C1C” [CR]
Detail
Display On
-
Screen Display Menu.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.29. MENU OFF Command
Command
“C1D” [CR]
Detail
Hide
On
-
Screen Display Menu.
Response
Acceptable
[ACK] [CR]
Unacceptable
？[CR]
6.30. DISPLAY CLEAR Command
Command
“C1E” [CR]
Detail
Hide
On
-
Screen Display.
Hide On-Screen Display unconditionally.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.31. BRIGHTNESS + Command
Command
“C20” [CR]
Detail
Turn up
Brightness of User Control
by
1 point.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.32. BRIGHTNESS – Command
Command
“C21” [CR]
Detail
Turn down
Brightness of User Control
by 1 point
.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.33. Computer 2 Component Command
Command C24[CR]
Detail
Select Component input in Computer2.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
16/25
6.34. Computer 2 RGB Command
Command C25[CR]
Detail
Selec
t RGB input in Computer2.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.35. Computer 2 SCART Command
Command
C26[CR]
Detail
Select RGB(Scart) input in Computer
2.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.36. IMAGE (Toggle) Command
Command C27[CR]
Detail
Switch Image Setting status.
This command works the same as “IMAGE” button of the projector and the remote
control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.37. ON START Setting Command
Command
“C28” [CR]
Detail
Enable
Power ON Start.
This status is stored in EEPROM and retained regardless of Power OFF/ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.38. ON START Cancel Command
Command
“C29” [CR]
Detail
Disable
Power ON Start.
This status is stored in EEPROM and retained regardless of Power OFF/ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.39. Power Management Ready Command
Command
“C2A” [CR]
Detail
Set Power Management to Ready mode.
This status is stored in EEPROM and retained regardless of Power ON/OFF.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
17/25
6.40. Power Management OFF Command
Command
“C2B” [CR]
Detail
Set Power Management
to
OFF
mode
.
This status is stored in EEPROM and retained regardless of Power ON/OFF.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.41. Power Management Shut down Command
Command
“C2E” [CR]
Detail
Set Power Management to Shut down mode.
This status is stored in EEPROM and retained regardless of Power OFF/ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.42. D.ZOOM + Command
Command
“C30” [CR]
Detail
Enter Digital Zoom mode and expand
im
age
size
.
This command works the same as “D.ZOOM ▲” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.43. D.ZOOM – Command
Command
“C31” [CR]
Detail
Enter Digital Zoom mode and reduce
size
.
This command works the same as “D.ZOOM ▼” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.44. Video Auto Command
Command
“C3
2
” [CR]
Detail
Select
Auto input
in Video.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.45. Video Video Command
Command
“C3
3
” [CR]
Detail
Select
Video input
in Video.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK]
[CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
18/25
6.46. Video S-Video Command
Command
“C3
4
” [CR]
Detail
Select
S
-
Video input
in Video.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.47. Image Colorboard Command
Command
“C3
9
” [CR]
Detail
Set
image to Colorboard mode.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.48. POINTER RIGHT Command
Command
“C3A” [CR]
Detail
Move the Pointer of
O
n
-
S
creen
D
isplay
Menu
to the right.
This command works differently from the pointer “>” of the projector, and has no
function of Volume +.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.49. POINTER LEFT Command
Command
“C3B” [CR]
Detail
Move the Pointer of
O
n
-
S
creen
D
isplay
Menu
to the
lef
t.
This command works differently from the pointer “<” of the projector,and has no
function of Volume +.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.50. POINTER UP Command
Command
“C3C” [CR]
Detail
Move up the Pointer of
O
n
-
S
creen
D
isplay
Menu
.
This command works the same way as the pointer “▲” of the projector.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.51. POINTER DOWN Command
Command
“C3D” [CR]
Detail
Move
down
the Pointer of
O
n
-
S
creen
D
isplay
Menu
.
This command works the same as the pointer “▼” of the projector.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
19/25
6.52. ENTER Command
Command
“C3F” [CR]
Detail
This command works the same
as “SELECT” button of the projector and remote
control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.53. FREEZE ON Command
Command
“C43” [CR]
Detail
Freeze
on
-
screen image.
This command works the same as “FREEZE” button of the remote control for
Freeze ON, but does not work for Freeze OFF.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.54. FREEZE OFF Command
Command
“C44” [CR]
Detail
Cancel Freeze
mode
.
This command works the same way as “FREEZE” button of the remote control for
Freeze OFF, but does not work for Freeze ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.55. Computer 1 Analog RGB Command
Command
“C5
0
” [CR]
Detail
Select Analog
RGB
in
Computer 1 input.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable
？[CR]
6.56. Computer 1 DVI (PC Digital) Command
Command
“C5
2
” [CR]
Detail
Select
DVI
(PC Digital)
in
Computer 1 input 1.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.57. Computer 1 DVI (AV HDCP) Command
Command
“C5
3
” [CR]
Detail
Select
DVI
(AV HDCP)
in
Computer 1 input.
Although Input search mode is On1/On2, the operation does not start with this
command.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC
-
XC50/55 Basic Serial Command Specifications
20/25
6.58. AUTO PC ADJ. Command
Command
“C89” [CR]
Detail
Execute Auto PC Adj. function.
This command terminates Auto PC Adj. operation if it is being processed.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.59. PRESENTATION TIMER Command
Command
“C8A” [CR]
Detail
Execute P
resentation Timer
.
This command works the same way as “P-TIMER” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.60. KEYSTONE ↑Command
Command
“C8E” [CR]
Detail
Correctkeystone distortion by reducing upper part of image.
Response
Acceptable
[ACK
] [CR]
Unacceptable ？[CR]
6.61. KEYSTONE ↓Command
Command
“C8F” [CR]
Detail
Correctkeystone distortion by reducing down part of image.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
