Sanyo Think GAIA PLC-XE45 Installation guide

■Short Throw Projector, 80” @ 98cm
■P N Code Security
■Audio Alarm
■Smooth Cabinet (No Buttons)
■2 Data, 2 Video nputs
■Customisable Start up Screen
PLC-XE45

TECHNICAL DETAILS PLC-XE45
Category Education
Panel 3 x0.63” Polysilicon TFT (4:3
Lamp 200W
Brightness ANS lumens 1500 (Normal Mode), 2000 (High Brightness Mode)
Lamp Service Life 3000 h (Normal Mode), 1500 h (High Brightness Mode)
Fan Noise 31dBA (Normal Mode), 38dBA (High Brightness Mode)
Standard Lens F1.85, f=8.1mm
Throw Distance Ratio 80” mage @ 98cm
Throw Distance 72.7cm ~ 98.1cm
Contrast Ratio 450:1
Resolution in pixels 786,432 x 3 (1024 x 768)
mage size min–max (diagonal) 60” – 80”
Uniformity 80 %
Bandwith/Frequency 140MHz, horizontal 15kHz ~ 100kHz, Vertical 50Hz ~ 100Hz
Colour Systems NTSC / PAL / SECAM / NTSC4.43 / PAL-M&N
Connections nput 1: Dsub15 (RGB / Component / Scart / RGB), Mini Jack
nput 2: Dsub15 (RGB in or Monitor out)
nput 3: RCA x 1 (Composite), Mini D N 4 pin (S-video), RCA x 2 (L,R-Mono)
Audio Out : Mini Jack
Mouse control: USB type B
Control Port: mini D N8-pin (Serial)
Keystone Correction Vertical ±20°
Computer Compatibility UXGA / WXGA / SXGA / XGA / SVGA / VGA
Zoom/Focus 1.0x / Manual Focus
Power Consumption/Voltage 230W (Normal Mode), 275W (High Brightness Mode), 9W (Standby Mode)
Warranty 3 years
Dimensions (W x H x D) 320 x 148 x 292mm
Weight 3.3 kg
Standard Accessories Remote Control, Owner Manual, Computer Cable (Dsub15-Dsub15), Power Cord
Optional Accessories Component(3x RCA) –Dsub15 cable (POA-CA-COMPVGA), Scart-Dsub15 Cable (POA-CA-SCART)
* You can use the distance calculator at www.sanyo.co.uk to determine exact image sizes and distances
PLC-XE45
Technical specifications subject to change without notice. Status 09/2007
