Sanyo PLC-XF60 User manual

Multimedia Projector
SERVICE MANUAL
PRODUCT CODE
1 122 237 00 (MM7A)
1 122 238 00 (PM7A)
1 122 238 02 (PM7C)
Original Version
REFERENCE NO. SM5110680-00
FILE NO.
Model No. PLC-XF60
U.S.A., Canada,
Europe, Asia, Africa
Chassis No. MM7-XF6000
NOTE: Match the Chassis No. on the unit’s
back cover with the Chassis No. in the
Service Manual.
If the Original Version Service
Manual Chassis No. does not
match the unit’s, additional Service
Literature is required. You must refer
to “Notices” to the Original Service
Manual prior to servicing the unit.
* Projection lens is optional.

- 2 -
Contents
SERVICE MANUAL ................................................... 1
Contents ........................................................................ 2
Safety Instructions ......................................................... 3
Safety Precautions ...................................................... 3
Product Safety Notice ................................................. 3
Service Personnel Warning ........................................ 3
Specifications ................................................................ 4
Safety Protections ......................................................... 5
1. Fuse ........................................................................ 5
2. Thermal switches .................................................... 5
3. Mechanical switches ............................................... 6
4. Temp. and airflow sensors ...................................... 7
5. Power failure and fan lock detection ....................... 7
Air filter replacement ...................................................... 8
Lamp Replacement ....................................................... 9
How to Reset the Lamp or Filter Timer ........................ 10
Mechanical disassemblies ........................................... 11
Optical Parts Disassemblies ........................................ 23
LCD Panel Replacement ............................................. 30
Adjustments ................................................................. 31
PIN Code Reset ........................................................ 31
Adjustments after Parts Replacement ...................... 31
Optical Adjustments ..................................................... 32
1. Optical Center adjustment .................................... 32
2. Contrast adjustment .............................................. 38
3. Convergence service adjustment .......................... 39
4. Back focus adjustment .......................................... 41
Electrical Adjustments ................................................. 42
1. Service Adjustment Menu Operation .................... 42
2. Circuit Adjustments ............................................... 43
3. Test points and locations ....................................... 47
4. Service Adjustment Data Table ............................. 48
Chassis Description & Troubleshooting ....................... 65
1. Chassis Overview ................................................. 65
2. Signal Input and Decoding Stage ......................... 66
3. Audio Signal Processing Stage ............................ 68
4. LCD Drive Stage ................................................... 70
5. Lamp Control ........................................................ 72
6. Fan Control ........................................................... 74
7. Motor Control ........................................................ 76
8. System Control .................................................... 78
9. Power Supply and Failure Detection ..................... 81
10. Diagnosis of Failure with LED indication ............. 83
11. Diagnosis of Power Failure with RS-232C port ... 85
Control Port Functions ................................................. 89
Cleaning .................................................................... 100
IC Block Diagrams ..............................................101-106
Electrical Parts List ............................................. 107-150
Electrical Parts Location ......................................... 108
Electrical Parts List ................................................. 111
Mechanical Parts List .........................................151-164
Cabinet Parts Location ........................................... 151
Chassis Parts Location ........................................... 152
Optical Parts Location ............................................ 154
Mechanical Parts List ............................................. 164
Diagrams & Drawings .......................................... A1-A25
Parts description and reading in schematic diagram .......A2
Schematic Diagrams ........................................... A3-A14
Printed Wiring Board Diagrams ......................... A15-A24
Pin description of diode, transistor and IC .................A25

- 3 -
Safety Instructions
WARNING:
The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of
the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is identi-
fied with the line ( ) in the schematic diagram. For continued product safety and protection of personnel injury,
servicing should be made with qualified personnel.
The following precautions must be observed.
Safety Precautions
1: An isolation transformer should be connected in the
power line between the projector and the AC line be-
fore any service is performed on the projector.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, etc.
DO NOT OPERATE THIS PROJECTOR WITH-
OUT THE PROTECTIVE SHIELD IN POSI-
TION AND PROPERLY SECURED.
4: Before replacing the cabinet cover, thoroughly in-
spect the inside of the cabinet to see that no stray
parts or tools have been left inside.
Before returning any projector to the customer, the ser-
vice personnel must be sure it is completely safe to op-
erate without danger of electric shock.
Service Personnel Warning
Eye damage may result from directly viewing the light produced by the Lamp used in this equipment. Always turn
off Lamp before opening cover. The Ultraviolet radiation eye protection required during this servicing.
Never turn the power on without the lamp to avoid electric-shock or damage of the devices since the stabilizer
generates high voltages (15kV - 25kV) at its starts.
Since the lamp is very high temperature during units operation replacement of the lamp should be done at least
45 minutes after the power has been turned off, to allow the lamp cool-off.
Product Safety Notice
Product safety should be considered when a component replacement is made in any area of the projector. Com-
ponents indicated by mark ! in the parts list and the schematic diagram designate components in which safety
can be of special significance. It is, therefore, particularly recommended that the replacement of there parts must
be made by exactly the same parts.

- 4 -
Specifications
Mechanical Information
Projector Type Multi-media Projector
Dimensions (W x H x D) 20.39" x 9.92" x 23.86" (518mm x 252mm x 606mm) (Not including adjustable feet)
Net Weight 54.3 lbs (24.7kgs)
Feet Adjustment 0˚ to 3.65˚
Panel Resolution
LCD Panel System 1.4" TFT Active Matrix type, 3 panels
Panel Resolution 1024 x 768 dots
Number of Pixels 2,359,296 (1024 x 768 x 3 panels)
Signal Compatibility
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, PAL-N
High Definition TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
Scanning Frequency H-sync. 15 ~ 120 KHz, V-sync. 48 ~ 120 Hz
Optical Information
Projection Image Size (Diagonal) Subject to Optional lens
Projection Lens Option
Throw Distance Subject to Optional lens
Projection Lamp 300W
Interface
Input 1 terminals DVI-D Terminal (Digital in) (HDCP Compatible) x1, (VGA) HDB15 Terminal X 2 (Analog In/
Analog Out) and Mini Jack (stereo) x 1
Input 2 terminals BNC Type x 5 (G/ VIDEO/Y, B/ Cb/Pb, R/ Cr/Pr, H/V, V) and Mini Jack (stereo) x 1
Input 3 terminals RCA Type x 3 (VIDEO/Y, Cb/Pb, Cr/Pr), Mini DIN 4 pin x 1 (S-Video) and RCA Type x 2
(Audio R and L(mono))
Input 4 terminals DVI-D Terminal (Digital in) (HDCP Compatible) x1, Serial port In (DB9) x 1 and
Serial port Out (DB9) x1
Other Terminals
SERIAL PORT IN DB9 pin x 1
SERIAL PORT OUT DB9 pin x 1
USB Connectors USB Series A receptacle x 1 and USB Series B receptacle x 1
R/C Jack Mini Jack x 1
Audio
Internal Audio Amp 3.0W RMS
Built-in Speaker 2 speaker, ø2.05" (52mm)
Power
Voltage and Power Consumption AC 100 ~ 120 V (9.5 A Max. Ampere), 50 / 60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (4.5 A Max. Ampere), 50 / 60 Hz (Continental Europe and The U.K.)
Operating Environment
Operating Temperature 41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
Storage Temperature 14 ˚F ~ 140 ˚F (-10˚C ~ 60 ˚C)
Remote Control
RF Remote Standard 2.4 GHz Low Power Radio
Frequency Band 2.472GHz (CH1: default setting), 2.403GHz (CH2), 2.446 GHz (CH3), and 2.421GHz (CH4)
Battery AA, UM3 or LR6 1.5V ALKALINE Type x 2
Operating Range Within 32.8' (10m)
Dimensions 2.0” x 1.2” x 7.1” (50mm x 30mm x 181mm)
Net Weight 0.33 lbs (150 g) (including batteries)
● The specifications are subject to change without notice.
● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the
pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.
● The On-Screen Menu and figures in this manual may differ slightly from the product.

- 5 -
This projector provides the following safety protections to operate in safety. If the abnormality occurs inside the projec-
tor, it will automatically turn off by operating one of the following protection circuits.
1. Fuse
The fuse is located inside of the projector. When both of
LAMP and the READY indicators are not lighting, the fuse
may be opened. Check the fuse as following steps.
It should be used the specified fuse as right;
How to replace the fuse
1 Turn the projector upside down and remove the cabinet bottom cover following to “Mechanical Disassemblies [19]”.
2 Remove the fuse from fuse holder.
Safety Protections
2. Thermal switches
There are some thermal switches inside of the projector to detect the internal temperature rising abnormally. When
the internal temperature around the lamps reaches a specified value, the projector turns off immediately for product
safety.
- Lamp1 thermal switch (SW911)
- Lamp2 thermal switch (SW912)
FUSE PART NO. : 423 028 4209
TYPE 15A 300V FUSE
SOC TYPE SHV14 15A N4
Fuse
SW912
SW911

- 6 -
Safety Protections
3. Mechanical switches
There are some mechanical switches inside of the projector to detect that the covers, filters or lamps are mounted
correctly. When one of following switches detects an error (open), the projector cannot turn on.
This projector provides 4 mechanical switches and 4 lamp selection switches as follows;
- Lamp1 cover switch (SW902)
- Lamp2 cover switch (SW905)
- Bottom cover switch (SW904)
- Air filter switch (SW903)
- Lamp selection switches (SW906, SW907, SW908, SW909)
LED indication on the Error
FILTER LED blinking SW903 open
LAMP1/LAMP2
REPLACE LED blinking SW902 or S905 open
SW903
SW904
SW908
SW909
SW906
SW907
SW902
SW905

- 7 -
4. Temp. and airflow sensors
The projector provides 2 temperature sensor ICs and an airflow sensor. The temperature sensor ICs monitor internal
temperature and external temperature (around the intake duct ) respectively. The airflow sensor monitors intake air-
flow through the airfilter to detect the airfilter clogged.
- Internal temperature sensor A (IC8821)
- Internal temperature sensor B (IC8841) (around the intake duct)
- Airflow sensor (SS901)
- Panel (Polarized glass) thermistor (SW913)
- Shutter thermostat switch (SW914)
5. Power failure and fan lock detection
The projector provides the detection circuits of the power failure and the fan lock. When the detection circuit detects
an error at the power supply line or the fan lock detection line, the projector will turn into the standby mode to protect
the other circuits defective.
- If the all of LEDs are blinking, the projector may defect the failure on the fan or the power supply lines. Check fan
operation and power supply lines referring to the chapter “Power supply and Failure Detection” in the Chassis Block
Diagram section.
Safety Protections
LED indication on the Error
SHUTTER LED blinking Temp. Error detected by SW914
WARNING TEMP LED
blinking
Temp. Error detected by IC8821,
IC8841, SW913
LED indication on the Error
All of LEDs blinking Power failure or Fan lock de-
tected
IC8841
SS901
SW913
SW914
IC8821

- 8 -
Air filter replacement
RECOMMENDATION
We recommend avoiding dusty/smoky environments
when operating a projector. Usage in these environments
may cause poor image quality.
When using under dusty or smoky conditions, dust may accu-
mulate on liquid crystal panel, lens, or optical elements inside
it. This condition may degrade quality of projected image.
When above symptoms are noticed, contact your authorized
dealer or service station for proper cleaning.
Filter cover
CAUTION
Do not operate a projector with Air Filter removed.
Dust may accumulate on LCD Panel and Mirror de-
grading picture quality.
Do not put small parts into Air Intake Vents. It may
result in malfunction of a projector.
Air filter
Air filters prevent dust from accumulating on the surface of the optical elements inside the projector. Should the air
filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat
build up and adversely affect the life of the projector. Replace the air filter following the steps below.
TOP CONTROL
WARNING FILTER
lights red
This projector can monitor the filter condition. When the filter
is clogged with dust and the performance is degraded, the
WARNING FILTER indicator lights red and let you know the
filter replacement is required.
If the indicator is lighting red, turn off the projector and clean
the air filter immediately.
Using the projector with the WARNING FILTER indicator light-
ing may result in internal heat build up and cause damage to
the optical elements inside the projector. The projector will
shutdown automatically to protect itself when the projector's
inside temperature is abnormally high.
After replacing the air filter, reset "Filter Counter" in the Spe-
cial menu. Otherwise, monitor function for the air filter may
not work properly. Refer to "How to reset the Filter Timer".
WARNING FILTER Indicator
1
Turn off the projector, and disconnect the AC power cord
from the AC outlet.
2 Pulling down the tabs on both sides top of the filter cover,
open the projector cover.
3
Pull out the air filter from the projector.
4
Clean the air filter cover with a vacuum cleaner.
5
Replace the new air filter properly onto the projector and
close the filter cover.
Note:
The projector cannot be operated with the filter removed.

- 9 -
ORDER REPLACEMENT LAMP
Type No. Service Parts No.
POA-LMP60 610 315 7689
Lamp Replacement
CAUTION :
DO NOT OPERATE A PROJECTOR WHILE ANY OF LAMPS
IS REMOVED. IT MAY RESULT IN MALFUNCTIONS, FIRE
HAZARD, OR OTHER ACCIDENTS.
When the life of the projection lamp of this projector draws
to an end, the LAMP1/2 REPLACE indicator lights yellow. If
this indicator lights yellow, replace the lamp with a new one
promptly.
Handle
Lamp covers
For continued safety, replace with a lamp of the
same type. Do not drop a lamp or touch a glass
bulb! The glass can shatter and may cause injury.
Allow a projector to cool, for at least 60 minutes be-
fore you open the Lamp cover. The inside of the
projector can become very hot.
Top Control
CAUTION
Screws
Handle
Screws
Notes on Lamp Replacement:
To maintain quality of picture (better balance of color
and brightness in the entire screen), we recommend
replacing all 2 lamps at a time.
These indicators light yellow
when the life of the projection
lamp draws to an end.
Lamps
Follow these steps to replace the lamp.
1
Turn off the projector and disconnect the AC plug. Allow
the projector to cool for at least 60 minutes.
2
Loosen each screws on the lamp covers with a screw-
driver, and remove them.
3
Loosen 4 screws of the lamps with a screwdriver and pull
out one lamp and another with grasping the handle.
4
Replace the lamps with new ones and tighten the 4 screws
back into position. Make sure that the lamps are set prop-
erly. Replace the lamp covers and tighten the screws.
5
Connect the AC power cord to the projector and turn on
the projector.
6
Reset the Lamp replace counter.
See "How to reset the Counter Timer".

- 10 -
Special Menu (Filter time)
How to Reset the Lamp or Filter Timer
Special Menu (Lamp)
How to reset the Lamp Time
1
Press the MENU button to display On-Screen Menu. Spin
the menu icons with the Control pad and press the SE-
LECT button when the SPECIAL icon comes right in front.
2
Move the yellow frame pointer with the Control pad to an
item "Lamp" and then press the SELECT button. The cor-
responding dialog box for the item appears.
This feature displays total time of the lamps being used. When
selecting Lamp 1 / Lamp 2, the dialog box shows wattage and
hours of each lamp.
To reset the lamp time, move the pointer to "Reset" and then
press the SELECT button. The message "Lamp time reset?"
is displayed. Move the pointer to [Yes] and then press the SE-
LECT button. Another confirmation dialog box appears and
select [Yes].
Note:
Be sure to reset the Lamp replace counter only after replacing
the lamp.
How to reset the Filter Time
1 Press the MENU button to display On-Screen Menu. Spin
the menu icons with the Control pad and press the SE-
LECT button when the SPECIAL icon comes right in front.
2 Move the yellow frame pointer with the Control pad to an
item "Filter" and then press the SELECT button. The cor-
responding dialog box for the item appears.
This feature displays total time of the filter on the projector
and the Option box (separately provided) being used.
To reset the filter time, move the pointer to "Reset" and then
press the SELECT button. A confirmation box appears. Move
the pointer to [Yes] and then press the SELECT button.

- 11 -
Mechanical disassemblies
z Cabinet Front-A , Cover and Lamp Cover removal
A : (M4 x 8) x 5 on cabinet front-A and cabinet front
B : Lamp cover-L and R
Screws Expression
(Type Diameter x Length) mm x pcs
T type M Type
Mechanical disassemblies should be made following to the SEQ No. indicated
on the right of each item. Following steps show the basic procedures, there-
fore unnecessary step may be ignored.
Caution:
The parts and screws should be placed exactly the same position as the orig-
inal otherwise it may cause loss of performance and product safety.
SEQ No. z
Fig.1
A
A
A
A
B
B
A
Cabinet Front-A
Cabinet Front-AV
Cover
Lamp Cover-R
Lamp Cover-L

- 12 -
Mechanical disassemblies
x Cabinet Top removal
A : (M4 x 8) x 8 on cabinet top
B : (M4 x 8) x 2 on holder
c Controls removal
A : (T3 x 10) x 5 on holder
B : (T3 x 6) x 2 on control panel
C : (T3 x 10) x 2 on control board
D : (T2 x 6) x 8 on control board
SEQ No. zx
SEQ No. zxc
Fig.2
Fig.3
A
A
A
A
A
A
A
B
B
A
A
A
A
A
C
C
B
B
D
D
Cabinet Top
Control Board
Control Pad
Control Panel

- 13 -
v Main and LCD Drver Boards removal
A : (M3 x 6) x 6 on main board
B : (M3 x 6) x 6 on LCD drive board
SEQ No. zxv
b Cabinet Front, RF Reciver and SP902 removal
A : (M4 x 8) x 4 on cabinet front
B : (M3 x 6) x 4 on cabinet front
C : (T3 x 8) x 2 on speaker holder
D : (M4 x 4) x 2 on Speaker-R(SP902)
E : (T3 x 8) x 4 on RF receiver module
SEQ No. zxb
Mechanical disassemblies
Fig.4
Fig.5
A
B
E
C
D
B
B
B
B
A
A
A
A
LCD Drive Board
Main Board
Cabinet Front
SP902
RF Receiver

- 14 -
n Airfilter and Filter Cover removal
A : (T3 x 8) x 7 on filter frame
B : (T3 x 8) x 4 on flter frame
C : (T3 x 8) x 1 on senser duct
D : (4 x 15) x 2 (pin) on filter cover
SEQ No. zxn
m Lens Motor, Top Net Boards and Switches removal
A : (T3 x 8) x 4 on motor board
B : (T3 x 8) x 4 on top net board
C : (T3 x 8) x 1 on holder
D : (T3 x 8) x 1 on holder
E : (M3 x 8) x 1 on switch (SW904)
F : (T3 x 12) x1 on switch (SW903)
G: (T4 x 10) x 2 on holder
H : (M3 x 11) x 2 on socket
SEQ No. zxm
Mechanical disassemblies
Fig.6
Fig.7
A
A
A
B
C
D
D
B
A
B
C
D
E
F
G
H
Filter Cover
Airfilter
Motor Board
Top Net Board
SW903
SW904
Socket Holder
Socket for Option

- 15 -
, AV Panel Box and FN913 and SS901 removal
A : (M4 x 6) x 4 on AV panel box
B : (M4 x 8) x 2 on the chassis frame
C : (T4 x 10) x 4 on air duct
D : (T4 x 28) x 2 on fan (FN913)
E : (T3 x 8) x 2
F : (M3 x 12) x 2 on airflow sensor (SS901)
SEQ No. zxvb,
. AV Panel Box disassemblies
A : (M3 x 6) x 2 on warp&wrap board
B : (T3 x 8) x 7 on RS-232C board
C : (T3 x 8) x 4 on holder
D : (M3 x 6) x 8 on holder
E : (T3 x 8) x 6 on mother board
F : (M3 x 6) x 2 on mother board
G : (M3 x 6) x 4 on AV panel
SEQ No. zxvb,.
Mechanical disassemblies
Fig.8
Fig.9
A
B
C
C
D
E
F
A
A
B
DD
D
G
G
E
F
F
E
E
E
E
E
C
D
C
D
C
SS901
AV Panel Box
FN913
Warp&Wrap Board
RS-232C Board
Mother Board
AV Board
DVI Board
AV Panel

- 16 -
⁄0 SP901 and AC Unit removal
A : (M4 x 10) x 3 on AC unit
B : (M4 x 6) x 3 on AC unit
C : (M4 x 10) x 2 on speaker holder
D : (M4 x 4) x 2 on speaker-L (SP901)
SEQ No. zxvb,⁄0
⁄1 AC Unit Disassemblies
A : (M4 x 6) x 5 on holder
SEQ No. zxvb,⁄0⁄1
Mechanical disassemblies
Fig.10
Fig.11
A
C
D
B
A
A
A
AC Unit
SP901
SW901
(Mains-Switch)
K901(AC Socket)
LF901(Noise Filter)
F901(Fuse)

- 17 -
⁄2 Optical Unit Assy removal
A : (M4 x 10) x 4 on lens mount
B : (T4 x 12) x 5 on optical unit
C : (T4 x 12) x 2 on optical base lamp
D : (M3 x 12) x 4 on lamp socket
E : (T4 x 10) x 2 on holder
SEQ No. zxvb⁄2
⁄3 Optical Unit Assy Disassemblies
A : (M6 x 18) x 4 on optical base lamp
B : (M4 x 12) x 4 on lens mount
SEQ No. zxvb⁄2⁄3
Mechanical disassemblies
Fig.12
Fig.13
E
C
D
D
A
B
B
B
C
B
B
A
E
A
B
Optical Unit Assy
Lamp 1
Lamp 2
Lamp Socket
Optical Unit
Lens Mount Assy
Optical Base Lamp

- 18 -
⁄4 Lamp Unit Disassemblies
A : (T3 x 14) x 4 on duct
B : (M4 x 35) x 3 on fan (FN908)
C : (M3 x 30) x 4 on fan (FN909)
D : (M3 x 6) x 3 on fan guard
E : (M3 x 6) x 1 on holder
F : (M3 x 8) x 1 each on switch (SW911 & SW912)
G : (M3 x6) x 4 on lamp1& 2 W select board
H : (M4 x 8) x 4 on fan holder
J : (M3 x 6) x 2 on fan duct
K : (M3 x 10) x 1 each on switch (SW902 &SW905)
L : (M3 x 25) x 2 each on fan (FN910 & FN914)
M : (M3 x 6) x 3 on fan duct
SEQ No. zxvb⁄2⁄3⁄4
Mechanical disassemblies
Fig.14
A
A
A
C
C
C
C
D
D
D
E
F
F
G
G
G
J
J
K
K
L
L
L
M
M
L
H
H
H
H
G
B
B
B
A
SW912
FN908
Lamp2 W
Select Board
SW911
Lamp1 W
Select Board
FN909
SW905
SW902
FN910
FN914

- 19 -
⁄5 Lens Mount Disassemblies
A : (M1.6 x 3) x 3 on socket terminal x 2 sets
B : (M3 x 4) x 2 on motors x 2 sets
C : (M2 x 8) x 2, (M2 x 8) x 3 on switches
D : (M2 x 8) x 2 on cover x 2 sets
E : (M2 x 2) x 1 on cover x 2 sets
SEQ No. zxb⁄5
⁄6 Power(DC) and Audio Board removal
A : (M3 x 6) x 4 on power box top
SEQ No. zxv⁄6
Mechanical disassemblies
Fig.15
Fig.16
A
B
C
C
DD
E
E
B
A
A
A
A
A
Lens Shift Motor
Lens Shift Motor
Limit Switches(L,R)
Lens Position VR(H)
Lens Position VR(V)
Limit Switches(U,D)
Audio Amp. Board
Power(DC) Board
Power Box Top

- 20 -
⁄7 Power Box and Fans removal
A : (T4 x 10) x 6 on power box
B : (M4 x 8) x 1 on power box
C : (M3 x 30) x 4 on fan (FN905)
D : (M3 x 20) x 4 on fan (FN907)
SEQ No. zxv⁄6⁄7
⁄8 Handle removal
A : (T4 x 10) x 2 on handle holder x 2 sets
B : (Pin 5 x 35) x 2 on handle
SEQ No. zxv⁄7⁄8
Mechanical disassemblies
Fig.17
Fig.18
B
C
D
A
A
A
A
A
B
B
Power 2(AC)
Board
Power 1(AC)
Board
Isolation
sheet
FN907
FN905
K60D
K16CP
Label (Behind)
Label
