Sanyo PLC-WL2500 - 2500 Lumens User manual

PLC-WL2500
2500 LUMENS zWXGA zULTRA SHORT THROW PROJECTOR
WXGA ULTRA SHORT THROW PROJECTOR Resolution WXGA(1280 x 800)
Brightness(typical) 2500Lm
Contrast Ratio (Full on/ off)
500:1
Contrast Ratio (Full on/ off)
500:1
Image Size 60"-110"
Aspect Ratio 16:10
Projection Lamp 230W
Scanning Frequency H:15-100kHz, V:50-100Hz
Fan Noise 29.0 dBA (Eco)
Voltage 100-240VAC (auto voltage); 50/60 Hz
Power Consumption 227W (Eco)
WUXGA
WSXGA+
WXGA
/
+
UXGA
SXGA/
+
XGA
SHORT THROW PROJECTION FROM ONLY 34 INCHES AWAY
The PLC-WL2500 can project a full 80-inch diagonal image from a
distance of only 34 inches. Teachers can project images onto the white or
screen and no shadow comes up on the screen. This means they can
use large images even in relatively small rooms.
Input signal compatibility
WUXGA
,
WSXGA+
,
WXGA
/
+
,
UXGA
,
SXGA/
+
,
XGA
,
SVGA, VGA
Analog : 480i/p, 575i/p, 720p(50/60),1080i(50/60)
HDMI : 480p, 575p, 720p(50/60), 1080i/p(50/60)
Color System NTSC, PAL, SECAM, NTSC4.43, PAL-M/PAL-N
Projection Lens (inch) F 1.80 f=0.26"
Throw Ratio 0.50 : 1
Throw Distance (feet) 2.1' - 3.9'
Zoom / Focus Fixed/Manual
3LCD Ultra
Short-Throw
Built-in Network Closed Caption
WXGA , FITS A VARIETY OF APPLICATION SITUATIONS
Offering a wide XGA 1280 x 800 (16:10) resolution, the PLC-WL2500
makes it possible to project HD images. This projector is equally
comfortable with displaying HD images from cable/satellite or DVD
sources as it is delivering a PC-based presentation in the class room.
And it is easy to connect your DVD player to the projector via HDMI
terminal.
NETWORKING CAPABILITY
Up / Down Ratio N/A
Digital KeystoneCorrection V +/- 20°(Auto Keystone)
Digital Zoom 16x - 1/4x
Speaker Output 10W
Weight (lbs) 10.1 lbs.
Dimensions (inch) W,H,D 13.8"x5.7"x15.0"
Replacement Lamp # 610 349 0847
Replacement Remote # 645 102 1724
The PLC-WL2500 is equipped with SANYO’s exclusive PJ Network
Interface for wired networking. A common feature among SANYO’s
extensive line of commercial projectors. Networking allows the monitoring
of projector functions and operation from a long distance via a web
browser. Emails can be sent automatically to report operating status.
NEARLY MAINTENANCE FREE
This projector offers long periods of maintenance-free use, without the
need for lamp, and filter replacement only after approximately 4,000 hours.
The PLC
-
WL2500 is equipped with SANYO
’
s proprietary hybrid
filter,
Filter hour* (hour) 4000h(Eco)
Lamp Life * (hour) 4000h (Eco)
Input PC/Video
D-sub 15 x 1 (RGB, Component)
D-sub 15 x 1 (RGB, Monitor out)
Mini DIN 4pin x 1 (S-Video)
RCA x 1 (Composite)
HDMI x 1 (Ver.1.3)
Audio Stereo mini jack x 1
RCA x 2(R/L, mono)
The
PLC
WL2500
is
equipped
with
SANYO s
proprietary
hybrid
filter,
composed of multiple filter layers, and the lamp lifespan has been
improved compared to conventional models. The longer lamp lifespan and
long life filter saves time and money.
EASY ON/OFF FUNCTION
The power turns on as soon as you connect the power cord. No need to
press any buttons on the remote control or projector. You can disconnect
the power cord as soon as the power is turned off.
BLACKBOARD COLOR
BOARD MODE
Output PC/Video D-sub 15 x 1 (in common)
Audio Stereo mini jack x 1
Other Feature D-sub 9pin x 1 (control port)
RJ-45 x 1 (Wired LAN)
Included Accessories Power cord
VGA cable
Lenscap
Quick reference guide
Owner’s manual (CD-ROM)
Remote control
Optional Accessories POA-COMPVGA
POA-CA-SCART (Component – VGA cable)
(
Scart
–
VGA cable
)
BLACKBOARD
,
COLOR
BOARD
MODE
In classrooms and other places where there is no screen available,
images can be projected onto the blackboard or color board. This enables
quick response when making lesson changes or calling a quick meeting.
CLOSED CAPTION
PLC-WL2500 is Closed Caption compatible.
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a
general estimate. The brightness of a lamp usually decreases over time and use.
(
)
Warranty Three yearsparts and labor; 90 days original lamp;
Quick Repair Program under warranty
©2010 SANYO
Back Panel
