Sanyo PLC-XU50 User manual

REFERENCE NO. SM5110516-07
FILE NO.
Notice
CORRECTION ●PRODUCTION CHANGE
SERVICE FLASH ADD INFORMATION
REVISION-7
Please add this notice to the Service Manual listed below.
Category : Multi-media Projector Issued Date : July / 2004
Model : PLC-XU50 Effective from : Chassis No. MW3-XU5003
Canada, U.S./Europe,
Destination : Asia, Africa, U.K. REF. NO. : SM5110516
NOTE: Match the Chassis No. on the unit’s back cover with the Chassis No. in the Service
Manual.
If the Chassis. No. does not match the unit’s, additional Service Literature is required.
Only the difference service information is given in this manual. For detailed service infor-
mation, refer to the original service manual SM5110516-00, issued in September 2003,
for Model PLC-XU50.
FILE WITH ORIGINAL SERVICE MANUAL (SM5110516)
PRODUCT CODE
1 122 213 40 (MW3AY)
1 122 214 40 (PW3AY)
1 122 214 42 (PW3CY)
Differences:
The outline of the differences are as follows;
- The LCD panels are changed.
According to the above, the main board, electrical adjustment, service data table and diagrams are
changed.

-2-
■Safety Instructions
WARNING:
The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of
the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is iden-
tified with the line ( ) in the schematic diagram. For continued product safety and protection of personnel
injury, servicing should be made with qualified personnel.
The following precautions must be observed.
SAFETY PRECAUTIONS
1: An isolation transformer should be connected in the
power line between the projector and the AC line
before any service is performed on the projector.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, etc.
DO NOT OPERATE THIS PROJECTOR WITHOUT
THE PROTECTIVE SHIELD IN POSITION AND
PROPERLY SECURED.
4: Before replacing the cabinet cover, thoroughly
inspect the inside of the cabinet to see that no stray
parts or tools have been left inside.
Before returning any projector to the customer, the
service personnel must be sure it is completely safe to
operate without danger of electric shock.
SERVICE PERSONNEL WARNING
Eye damage may result from directly viewing the light produced by the Lamp used in this equipment. Always turn
off Lamp before opening cover. The Ultraviolet radiation eye protection required during this servicing.
Never turn the power on without the lamp to avoid electric-shock or damage of the devices since the stabilizer
generates high voltages(15kV - 25kV) at its starts.
Since the lamp is very high temperature during units operation replacement of the lamp should be done at least
45 minutes after the power has been turned off, to allow the lamp cool-off.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of the projector.
Components indicated by mark !in the parts list and the schematic diagram designate components in which
safety can be of special significance. It is, therefore, particularly recommended that the replacement of there parts
must be made by exactly the same parts.
DO NOT ATTEMPT TO SERVICING THE REMOTE CONTROL UNIT.
Laser Beam may be leaked out when in disassemble the Unit. As the Laser Beam used
in this Remote control unit is harmful to the eyes.

-3-
■Specifications
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.
0.8" TFT Active Matrix type, 3 panels
Multi-media Projector
6.2 lbs (2.8 kg)
11.73" x 2.8" x 8.58" (298mm x 71mm x 218mm)
(not including raised portions)
1024 x 768 dots
2,359,396 (1024 x 768 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N
H-sync. 15 ~ 100 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 40” to 300”
1 speaker, ø1.1" (28mm)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Projector Type
Net Weight
Dimensions (W x H x D)
Panel Resolution
Number of Pixels
Color System
Scanning Frequency
Projection Image size (Diagonal)
Built-in Speaker
Operating Temperature
Storage Temperature
LCD Panel System
●The specifications are subject to change without notice.
F 1.7 ~ 2.5 lens with f 20.0 mm ~ 30.0 mm with manual zoom and focus
3.3’ ~ 25.3’ (1.0 m ~ 7.7 m)
200 W
RCA Type x 1 (Video) and Mini DIN 4 pin x 1 (S-Video)
Projection Lens
Throw Distance
Projection Lamp
Video Input Jacks
RCA Type x 2
Audio Input Jacks
DVI-I Terminal (Digital/Analog) (HDCP compatible)
Mini Jack (stereo) x 1
Mini DIN 8 pin x 1
Mini Jack (stereo) x 1 (variable with volume)
1.0 W RMS
Computer Input 1 Terminal
Computer / Component Audio Input Jack
Service Port Connector
Audio Output Jack
Internal Audio Amp
0˚ to 11.8˚
Feet Adjustment
Power Source : AA, UM3 or R06 Type x 2
Operating Range : 16.4’ (5m) / ±30˚
Dimensions : 2.0” x 1.0” x 7.1” (50mm x 27mm x 181mm)
Net Weight : 0.34 lbs (154 g) (including batteries)
Laser Pointer : Class II Laser (Max. Output : 1mW / Wave length : 640 ~
660nm)
Remote Control
480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
High Definition TV Signal
USB Series B receptacle x 1
USB Connector
AC 100 ~ 120 V (3.6 A Max. Ampere), 50 / 60 Hz
(The U.S.A and Canada)
AC 200 ~ 240 V (1.8 A Max. Ampere), 50 / 60 Hz (Continental Europe and The U.K.)
Voltage and
Power Consumption
Computer Input 2 / Component Input /
Monitor Output Terminal
(VGA) HDB 15 Terminal x 1 (switch to use this terminal)
●LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny
fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.

-4-
●Lamp cover switch
The lamp cover switch (SW901) cuts off the drive signal to the
lamp circuit when the lamp cover is removed or not closed com-
pletely. After opening the lamp cover for replacing the lamp ass’y,
place the lamp cover correctly otherwise the projector can not
turn on.
●Thermal switch
There is the thermal switch (SW902) inside of the projector to
detect the internal temperature rising abnormally. When the inter-
nal temperature reaches near 90˚C, it cuts off the AC main power
supply .
The thermal switch cannot be reset itself automatically even if the
internal temperature becomes normal. Reset the thermal switch
following to the below procedure.
How to reset the thermal switch
1. Insert the sharp tool like a screwdriver into a hole on the cabi-
net bottom.
2. Press the reset button on the thermal switch with the screw-
driver.
CAUTION:
Before press the reset button, make sure that the AC cord must
be disconnected from the AC outlet.
This projector provides the following circuit protections to operate in safety. If the abnormality occurs inside the pro-
jector, it will automatically turn off by operating one of the following protection circuits.
●Fuse
A fuse is located inside of the projector. When the POWER indica-
tor is not lightning, the fuse may be opened. Check the fuse as fol-
lowing steps.
The fuse should be used with the following type;
Fuse replacing steps
1. Remove the cabinet top and cabinet front following to
“Mechanical Disassemblies”.
2. Replace the new one with the specified type.
Fuse Part No.: 423 021 7801
TYPE T6.3AH 250V FUSE
LITTLE FUSE INC. TYPE 21506.3
Thermal switch (SW902)
Fuse
■Circuit Protections

-5-
Circuit Protections
●Warning temperature and power failure protection
The projector will be automatically turned off when the internal temperature of the projector is abnormally high, or
the cooling fans stop spinning, or the power supplies in the projector are failed.
- If the WARNING indicator is flashing, it may detect the abnormal temperature inside the projector. Check the fol-
lowing possible causes and wait until the WARNING indicator stops flashing, and then try to turn on the projector.
- If the WARNING indicator lights red, it may defect the cooling fans or power supply circuits. Check fans operation
and power supply lines referring to the chapter “Power supply & protection circuit” in the Chassis Block Diagram
section.
Possible causes
- Air filters are clogged with dust particles. Remove dust from the air filters by following instructions in the “Air filter
care and cleaning” below.
- Ventilation slots of the projector are blocked. In such an event, reposition the projector so that ventilation slots are
not obstructed.
- Check if projector is used at higher temperature place (Normal operating temperature is 5 to 35 ˚C or 41 to 95˚F)
Air filter care and cleaning
The removable air filter prevents dust from accumulation on the surface of the projection lens and projection mirror.
Should the air filter become clogged with dust particles, it will reduce the cooling fan’s effectiveness and may result
in internal heat build up and reduce the life of the projector.
To clean up the air filters, follow the cleaning procedure
below:
1. Turn the power off, and disconnect the AC power cord
from the AC outlet.
2. Turn the projector up side down and remove air filters
by pulling the latches of it upward.
3. Clean the air filters with brush or wash out the dust and
particles.
4. Replace the air filters properly. Make sure that the air fil-
ters are fully inserted.
CAUTION:
Do not operate the projector with the air filters removed.
Dust may accumulate on the LCD panel and the projection
mirror degrading picture quality.
Do not put small parts into the air intake vents. It may result
in malfunction of the projector.
RECOMMENDATION
We recommend not to use the projector in dusty, smoky places. Using it in dusty place may cause the poor picture
quality.
When using under the dusty or smoky conditions, dust may accumulate on the LCD panel and lens inside it, and
may resultantly be projected on the screen together with the picture.
When the above symptoms are noticed, please clean up the LCD panel and lens following to the “Cleaning
Method”.
Air filter

-6-
■Lamp Replacement
WARNING:
- For continued safety, replace with a lamp assembly of the same
type.
- Allow the projector to cool for at least 45 minutes before you open
the lamp cover. The inside of the projector can become very hot.
- Do not drop the lamp module or touch the glass bulb! The glass can
shatter and cause injury.
Procedure
1Turn off the projector and disconnect the AC cord. Allow the projector
to cool for at least 45 minutes.
2Loosen 1 screws with a screwdriver and remove the lamp cover.
3Loosen 2 screws and pull out the lamp assembly by grasping the
handle.
4Replace the lamp with a new one and tighten the 2 screws back into
position. Make sure that the lamp is set properly. Replace the lamp
cover and tighten the screw.
5Connect the AC cord to the projector and turn on.
6Reset the Lamp Replace Counter, see below explanation.
Note:
- The projector cannot be turned-on with lamp cover removed,
because when the lamp cover is removed, the lamp cover switch is
also released to switch off the lamp circuit.
1Turn the projector on, press the MENU button and the
On-Screen Menu will appear. Press the Point
Left/Right button to move the red frame pointer to the
Setting Menu icon.
2Press the Point Down button to move the red frame
pointer to the Lamp counter reset item and then press
the SELECT button. The message "Lamp replace
counter Reset?" is displayed. Move the pointer to
[Yes] and then press the SELECT button.
3Another confirmation dialog box appears and select
[Yes] to reset the Lamp replace counter.
Recommendation
Should the air filter become clogged with dust particles,
it will reduce the cooling fan’s effectiveness and may
result in internal heat build up and short lamp life. We
recommend cleaning the air filter after the projection
lamp is replaced.
Refer to “Air Filter Cleaning”.
How to reset Lamp Replace Counter
Lamp
Lamp Cover Screw
Screw
Handle
Screw
ORDER REPLACEMENT LAMP
Type No.Service Parts No.
POA-LMP65 610 307 7925
The LAMP REPLACE indicator will light yellow when
the total lamp used time reaches 2000 hours. This is
to indicate that lamp replacement is required.
The total lamp used time is calculated by using the
below expression,
Total lamp used time = Teco + Tnormal x 2
Teco:used time in the Eco mode
Tnormal :used time in the Normal mode
You can check the lamp used time following to the
below procedure.
1Press and hold the POWER ON-OFF button on the
projector for more than 20 seconds.
2 The projector used time and lamp used time will be
displayed on the screen briefly as follows.
Counter
Projector 525H
Lamp
Normal 150H
Eco 375H
Total 675H
Total lamp used time
How to check Lamp used time
Projector used time

-7-
To enter the service mode
To enter the “Service Mode”, press and hold the MENU and INPUT buttons on the projector at the same time for
more than 3 seconds. The service menu appears on the screen as follows.
To adjust service data
Select the adjustment group no. by pressing the MENU (+) or KEYSTONE (-) button, and select the adjustment
item no. by pressing the pointer UP or DOWN button, and change the data value by pressing the VOLUME – or
VOLUME + button.Refer to the “Service Adjustment Data Table” for further description of adjustment group no.,
item no. and data value.
To exit the service mode
To exit the service mode, press the POWER ON-OFF button on the projector or remote control unit.
●Service Adjustment Menu Operation
IC1801 on the main board stores the data for the serv-
ice adjustments, and should not be replaced except for
the case of defective device.
If replaced, the re-adjustments are required following to
the “Electrical Adjustments”.
The data of lamp replacement counter is stored in the
IC1801.
Please note that the lamp replace counter will be reset
when the memory IC (IC1801) is replaced.
(Lamp replace counter cannot be set to the previous
value.)
● Caution to memory IC replacement
When IC1801 is replaced with new one, the CPU
writes down the default data of the service adjustments
to the replaced IC as the mentioned on the service
adjustment table. As these data are not the same data
as factory shipped data, it should be required to per-
form the re-adjustments following to the “Electrical
Adjustments”.
Please note that in this case the lamp replace counter
will be reset.
● Caution of Main Board replacement (in the case
Ic1801 is not defective)
When the main board is replaced, IC1801 should be
replaced with the one on previous main board. After
replacement, it should be required to perform the re-
adjustments following to the “Electrical Adjustments”.
In this case, the lamp replace counter can be kept the
value as before.
● Memory IC Replacement
ON -OFF
POWER
KEYSTONE
INPUT
WARNING
LAMP
REPLACE
MENU
V
O
L
U
M
E
–
V
O
L
U
M
E
+
SELECT
Service Mode
Input Video
Group No. Data
0032
Ver. 1 .00
Data value
Item No.
■Electrical Adjustments
Group No.

-8-
[Adjustment Condition]
●Input signal
Video signal .......................... 1.0Vp-p/75Ωterminated, 16 steps gray
scale (Composite video signal)
Computer signal .................... 0.7Vp-p/75Ωterminated, 16 steps gray
scale pattern
Component Video signal ...... 0.7Vp-p/75Ωterminated, 16 steps gray
scale (Component video signal with
480p, 575p, 720p or 1080i format)
●Picture control mode .............. “STANDARD” mode unless otherwise
noted.
Note:
* Please refer to “Service Adjustment Menu Operation” for entering the service mode and adjusting the service
data.
White 100% Black 100%
●Circuit Adjustments
CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the follow-
ing adjustments except requiring the readjustments in servicing otherwise it may cause loss of per-
formance and product safety.
Electrical Adjustments
16 steps gray scale pattern
After replacing the Power Board readjust the Output
voltage adjustment as follows.
1. Connect a digital voltmeter to pins 1 (+) and 3 (-) of
K6D.
2. Adjust the voltage by using VR611 as following.
AC Input Reading
230V 380V ±2V
Caution:
Be sure to connect the lamp when taking this adjust-
ment.
Output Voltage adjustment
* This adjustment is not required even if the power
board is replaced because this adjustment is carried
out before parts shipment.
1. Set the lamp mode to "Normal" and then enter the
service mode.
2. Select group no. “111”, item no. “5”and set data value
to “1”.
3. Connect a digital voltmeter to test point “TP12V1”(+)
and chassis ground (-). Select item no. “89”and
change data value to adjust voltage to be 6.5 ±0.1V.
4. Connect a digital voltmeter to test point “TP12V2”
(+) and chassis ground (-). Select item no. “91”and
change data value to adjust voltage to be 6.5 ±0.1V.
5. Connect a digital voltmeter to test point “TP12V1”(+)
and chassis ground (-). Select item no. “90”and
change data value to adjust voltage to be 13.5 ±0.1V.
6. Connect a digital voltmeter to test point “TP12V2”(+)
and chassis ground (-). Select item no. “92”and
change data value to adjust voltage to be 13.5 ±0.1V.
7. Select item no. “5”and set data value to “0”.
zFan Control adjustment

-9-
Electrical Adjustments
1. Receive the 16-step grey scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+) and
chassis ground (-).
4. Select group no. “0”, item no. “0”and change data
value to adjust the pedestal level and black level to be
the same level.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select item no. “1”and change data value to adjust the
pedestal level and black level to be the same level.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select item no. “2”and change data value to adjust the
pedestal level and black level to be the same level.
Pedestal Lebel
Black Lebel
xClamp adjustment [PC]
1. Receive the 16-step grey scale component signal
with Computer2 [Component] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+) and
chassis ground (-).
4. Select group no. “0”, item no. “0”and change data
value to adjust the pedestal level and black level to be
the same level.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select group no. “0”, item no. “1”and change data
value to adjust the pedestal level and black level to be
the same level.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select group no. “0”, item no. “2”and change data
value to adjust the pedestal level and black level to be
the same level.
Pedestal Lebel
Black Lebel
vClamp adjustment [COMPONENT]
1. Receive the 16-step gray scale composite video sig-
nal with Video [Video] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+) and
chassis ground (-).
4. Select group no. “0”, item no. “0”and change data
value to adjust the pedestal level and black level to be
the same level.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select item no. “1”and change data value to adjust the
pedestal level and black level to be the same level.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select item no. “2”and change data value to adjust the
pedestal level and black level to be the same level.
Pedestal Lebel
Black Lebel
cClamp adjustment [AV]

-10-
Electrical Adjustments
1. Receive the 16-step grey scale composite video sig-
nal with Video [Video] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “9”, item no. “1”and adjust the ampli-
tude “a” to be minimum by changing the Data value.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select item no. “2”and adjust the amplitude “a” to be
minimum by changing the Data value.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select item no. “3”and adjust the amplitude “a” to be
minimum by changing the Data value.
(a)
White Level
nSub Gain adjustment [Video]
1. Receive the 16-step grey scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “9”, item no. “1”and adjust the ampli-
tude “a” to be minimum by changing the Data value.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select item no. “2”and adjust the amplitude “a” to be
minimum by changing the Data value.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select item no. “3”and adjust the amplitude “a” to be
minimum by changing the Data value.
(a)
White Level
bSub Gain adjustment [PC]
1. Receive the 16-step grey scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode
3. Connect a digital voltmeter to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “10”, item no. “0”and change data
value to adjust the voltage to be 7.50 ±0.05V.
5. Connect a digital voltmeter to test point “TPR1”(+)
and chassis ground (-).
6. Select item no. “1”and change data value to adjust
the voltage to be 7.50 ±0.05V.
7. Connect a digital voltmeter to test point “TPB1”(+)
and chassis ground (-).
8. Select item no. “2”and change data value to adjust
the voltage to be 7.50 ±0.05V.
mVideo Center adjustment
1. Receive the 16-step gray scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPPSIG”(+)
and chassis ground (-).
4. Select group no. “10”, item no. “14”and adjust the
amplitude “a” to be 10.0 ±0.1V by changing the Data
value.
5. Select item no. “17”and adjust the amplitude “b” to be
3.8 ±0.1V by changing the Data value.
3. Connect an oscilloscope to test point “TPZPSIG”(+)
and chassis ground (-).
4. Select group no. “10”, item no. “12”and adjust the
amplitude “a” to be 10.0 ±0.1V by changing the Data
value.
5. Select item no. “15”and adjust the amplitude “b” to be
3.8 ±0.1V by changing the Data value.
(a)
(b)
,PSIG adjustment

-11-
Electrical Adjustments
1. Receive the 1 line black/white pattern computer sig-
nal with Computer2 [RGB] mode.
2. Enter the service mode.
3. Project only green light component to the screen.
4. Select group no. “10”, item no. “9”and change data
value to obtain the minimum flicker on the screen.
5. Project only red light component to the screen.
6. Select item no. “10”and change data value to obtain
the minimum flicker on the screen.
7. Project only blue light component to the screen.
8. Select item no. “11 and change data value to obtain
the minimum flicker on the screen.
⁄0 Common Center adjustment
[PC WHITE BALANCE ADJUSTMENT]
1. Receive the 16-step gray scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode, select group no. “9”item no.
“11”(Red) or “12”(Blue), and change Data values
respectively to make a proper white balance.
[AV WHITE BALANCE ADJUSTMENT]
1. Receive the 16-step gray scale composite video sig-
nal with Video [Video] mode.
2. Enter the service mode, select group no. “9”item no.
“11”(Red) or “12”(Blue), and change Data values
respectively to make a proper white balance.
Confirm that the same white balance is obtained in
video and computer input.
⁄2 White Balance adjustment
If you find the color shading on the screen, please
adjust the white uniformity by using the proper comput-
er and “Color Shading Correction” software supplied
separately.
The software can be ordered as follows;
COLOR SHADING CORRECTION ver. 3.03
Service Parts No.645 066 7428
[PC-GAMMA ADJUSTMENT]
1. Receive the 16-step grey scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “9”, item no. “10”and change data
value to adjust amplitude “a” to be 1.8 ±0.1V.
[AV-GAMMA ADJUSTMENT]
1. Receive the 16-step grey scale video signal with
Video [Video] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “9”, item no. “10”and change data
value to adjust amplitude “a” to be 1.8 ±0.1V.
(a)
white level
white level
⁄1 Gamma adjustment
NOTE ON WHITE UNIFORMITY
ADJUSTMENT
1. Receive the 16-step grey scale computer signal with
Computer2 [RGB] mode.
2. Enter the service mode.
3. Connect an oscilloscope to test point “TPG1”(+)
and chassis ground (-).
4. Select group no. “10”, item no. “3”and change data
value to adjust amplitude “a” to be 9.8 ±0.1V.
5. Connect an oscilloscope to test point “TPR1”(+) and
chassis ground (-).
6. Select item no. “4”and change data value to adjust
amplitude “a” to be 9.8 ±0.1V.
7. Connect an oscilloscope to test point “TPB1”(+) and
chassis ground (-).
8. Select item no. “5”and change data value to adjust
amplitude “a” to be 9.8 ±0.1V.
(a)
black level
black level
.Black Reference adjustment

-12-
K6K K6M
K8F
IC201
IC3101
TPVS
TP52G TP52B
K8N
IC2101
TPZPSIG
IC3801
TP52R
K5G IC3851
TPG1
IC5201
IC1201
TP12V1
IC1381
IC5341
K5R
IC5351
TPB1
K5B
K8X
TP12V2
K8P
IC801
IC6211
K8A
IC1851
IC1451
K8H
TPR1
K6L K8D
IC401
TPPSIG
TP21R
TP21G
TP21B
TPHS
Electrical Adjustments
MAIN BOARD
●Test Points and Locations

-13-
Electrical Adjustments
●Service Adjustment Data Table These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjust-
ment items indicated with “✻”are required to readjust following
to the “Electrical adjustments”. Other items should be used with
the initial data value.
Group: 0 AD9882
0ADC G-OFFSET 70/75/72 0 ~ 127 ✻Clamp Adjustment [G]
1ADC R-OFFSET 69/79/78 0 ~ 127 PC/AV30KHz/AV15KHz ✻Clamp Adjustment [R]
2ADC B-OFFSET 68/82/81 0 ~ 127 ✻Clamp Adjustment [B]
3ADC R-GAIN 78/78/78 0 ~ 255 PC/AV30KHz/AV15KHz
4ADC G-GAIN 78/78/78 0 ~ 255 PC/AV30KHz/AV15KHz
5ADC B-GAIN 78/78/78 0 ~ 255 PC/AV30KHz/AV15KHz
6ADC BandWidth PC 1 0 ~ 1
7ADC BandWidth AV 0 0 ~ 1
8ADC BandWidth DVI 1 0 ~ 1
9ADC BandWidth HDCP 1 0 ~ 1
10 ADC BandWidth YCbCr 0 0 ~ 1 Only 1080i/1035i/720p, others are contained in AV
Group: 2 TB1274
0Y_OUT_LEVEL_CONTROL 0 -63 ~ 63 (YCbCr 480i)
1C_OUT_LEVEL_CONTROL 0 -63 ~ 63 (YCbCr 480i)
2TINT 30/32 0 ~63 CVBS/YC
3SHP_EQ 2 0 ~ 3
4SHP_FO 0 0 ~ 3
5SHP_GAIN 13/13/13/13/13/11/11/13 0 ~15 VideoNT/ PAL,PALM,PALN/SECAM,BW60,BW50/ NT443/ PAL60/ S-Video/YCbCr/Scart
6Y_OUT_LEVEL 27/27/27/27/29 0 ~ 63 VideoNT/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM,BW
0.7V 26/26/26/26/26/28/28 S-VideoNT,BW/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM/ YCbCr/Scart
7C_OUT_LEVEL 12/13/15/13/22 0 ~ 63 VideoNT/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM,BW
0.6V 12/13/15/13/22/17/17/21 S-VideoNT,BW/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM/480i/575i/Scart
8Y_DELAY 5/5/4/4/4 0 ~ 15 Video NT,BW60/ PAL,PALM,PALN,BW50/ SECAM/NT443/PAL60
4/4/3/3/4 S-Video NT,BW60/PAL,PALM,PALN,BW50/ SECAM/ NT443/ PAL60
9COL_SYS - - Read Only
10 X'TAL - -
11 NOISE_DET - -
12 V_FREQ - -
13 Vert. Std - -
14 CID - -
15 V_SIG - -
16 MVM 0 0 or 1
17 AFC_GAIN 1 0 ~ 3
18 SECAM_GP,SECAM_ID 7 0 ~ 15
19 LPF 1/1 0 or 1 Scart/not Scart
20 Cb OFFSET1 8 0-15
21 Cr OFFSET1 8 0-15
Group: 3 TA1370
0SEP.LEVEL 1 0 ~ 3
1HD1 OUT SET 1 0 ~ 1
2HD PHASE 29/29/36/38/36 0 ~ 63 1080i/1035i/720p/575p/480p
3VD1 INV 0 0 ~ 1
4V-FREQ 0 ~ 127 read only
5HD-IN 0 ~ 1 read only
6H-FREQ 0 ~ 127 read only
Group: 7 TC90A69F
0Y-EQ_GAIN 3 0 ~ 3
1Y-EQ_N_C_LIM 1 0 ~ 3
2V-ENH_GAIN 1 0 ~ 7
3V_ENH_CORING 2 0 ~ 3
4NTSC443_SW 1 0 ~ 1 Set for Input system 0:NTSC4.431:PAL60(Effective only NTSC input)
Group: 8 LP05
0LP05_R_GAIN_ud 128 0 ~ 255 Turbo R Gain (128 at through)
1LP05_G_GAIN_ud 128 0 ~ 255 Turbo G Gain (128 at through)
2LP05_B_GAIN_ud 128 0 ~ 255 Turbo B Gain (128 at through)
3LP05_TURBO_GAIN_ud 0 0 ~ 255 Turbo mixture ratio (0 at through)
4LP05_SHP_EN_SET_ud 162/262 0 ~ 4095 Set Aperture Compensation effective period SVGA/XGA
5LP05_SHP_EN_RST_ud 958/1281 0 ~ 4095 Set Aperture Compensation effective period SVGA/XGA
6LP05_AB_ON_ud 3 0 ~ 3 Set Aperture Comp. period selection (points) 3: 3, 1: 2, 0: 1, 2: not selectable
7LP05_EGE_ud 2 0 ~ 3 Selection Data for Frequency Characteristics
Group: 9 CXD3536R (Panel Drive System)
0DCK_CDAT Read Only [Addr:0x1043]
1G_SUB_GAIN 71/70/61/61 0 ~ 255 [Addr:0x2007] PC/AV/DVI/HDCP ✻Sub Gain Adjustment [G]
2R_SUB_GAIN 71/70/61/61 0 ~ 255 [Addr:0x2006] PC/AV/DVI/HDCP ✻Sub Gain Adjustment [R]
3B_SUB_GAIN 71/70/61/61 0 ~ 255 [Addr:0x2008] PC/AV/DVI/HDCP ✻Sub Gain Adjustment [B]
4G_SUB_BRT 0 0 ~ 2047 [Addr:0x200B-200C] Signed 11bit
5R_SUB_BRT 0 0 ~ 2047 [Addr:0x2009-200A] Signed 11bit
6B_SUB_BRT 0 0 ~ 2047 [Addr:0x200D-200E] Signed 11bit
7G_GAM_GAIN 128 0 ~ 255 [Addr:0x202C]
8R_GAM_GAIN 128 0 ~ 255 [Addr:0x202B]
9B_GAM_GAIN 128 0 ~ 255 [Addr:0x202D]
No. Adjustment Item Initial Value Range Input source / Description

-14-
10 G_GAM_BRT 0/0/0/0 0 ~ 2047 [Addr:0x2030-2031] Signed 11bit Ignore lower 2bit PC/AV/DVI/HDCP ✻Gamma Adjustment
11 R_GAM_BRT 0/0/0/0 0 ~ 2047 [Addr:0x202E-202F] Signed 11bit Ignore lower 2bit PC/AV/DVI/HDCP ✻White Balance Adjustment
12 B_GAM_BRT 0/0/0/0 0 ~ 2047 [Addr:0x2032-2033] Signed 11bit Ignore lower 2bit PC/AV/DVI/HDCP ✻White Balance Adjustment
13 CSC_ON 1 0 ~ 1 [Addr:0x3000 bit6]
14 CSC_XH 0 0 ~ 1 [Addr:0x3000 bit5]
15 CSC_DWN 0 0 ~ 1 [Addr:0x3000 bit4]
16 CSCRRGT 1 0 ~ 1 [Addr:0x3000 bit3]
17 CSCGRGT 1 0 ~ 1 [Addr:0x3000 bit2]
18 CSCBRGT 1 0 ~ 1 [Addr:0x3000 bit1]
19 SHP 10/12 0 ~ 63 [Addr:0x1015 bit5-0] SVGA/XGA
20 DCK1F 0/1 0 ~ 63 [Addr:0x101C bit5-0] SVGA/XGA
21 DCK2F 0/1 0 ~ 63 [Addr:0x101E bit5-0] SVGA/XGA
22 DCK3F 0/2 0 ~ 63 [Addr:0x1020 bit5-0] SVGA/XGA
23 DCK4F 0/2 0 ~ 63 [Addr:0x1022 bit5-0] SVGA/XGA
24 DCK5F 0/2 0 ~ 63 [Addr:0x1024 bit5-0] SVGA/XGA
25 DCK6F 0/2 0 ~ 63 [Addr:0x1026 bit5-0] SVGA/XGA
26 DFT_ON 0/1 0 ~ 1 [Addr:0x103B bit6] SVGA/XGA
27 G_HPC_DAT 0/283 0 ~ 2047 [Addr:0x103E-103F] 11bit SVGA/XGA
28 R_HPC_DAT 0/283 0 ~ 2047 [Addr:0x103C-103D] 11bit SVGA/XGA
29 B_HPC_DAT 0/283 0 ~ 2047 [Addr:0x1040-1041] 11bit SVGA/XGA
30 CSC_RGP3(R Threshold MID2) 450/552 0 ~ 1023 [Addr:0x300A + 0x300D] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
31 CSC_RGP2(R Threshold MID1) 600/656 0 ~ 1023 [Addr:0x300A + 0x300C] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
32 CSC_RGP1(R Threshold MAX) 700/736 0 ~ 1023 [Addr:0x300A + 0x300B] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
33 CSC_GGP3(G Threshold MID2) 450/552 0 ~ 1023 [Addr:0x3013 + 0x3016] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
34 CSC_GGP2(G Threshold MID1) 600/656 0 ~ 1023 [Addr:0x3013 + 0x3015] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
35 CSC_GGP1(G Threshold MAX) 700/736 0 ~ 1023 [Addr:0x3013 + 0x3014] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
36 CSC_BGP3(B Threshold MID2) 450/552 0 ~ 1023 [Addr:0x301C + 0x301F] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
37 CSC_BGP2(B Threshold MID1) 600/656 0 ~ 1023 [Addr:0x301C + 0x301E] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
38 CSC_BGP1(B Threshold MAX) 700/736 0 ~ 1023 [Addr:0x301C + 0x301D] Signed 10bit (Effective upper 9 bit9) SVGA/XGA
Group: 10 CXA7005R
0G_SIG_CNTR 33 0~63 [IC531 Addr:0x01] ✻Video Center Adjustment [G]
1R_SIG_CNTR 33 0~63 [IC501 Addr:0x01] ✻Video Center Adjustment [R]
2B_SIG_CNTR 33 0~63 [IC561 Addr:0x01] ✻Video Center Adjustment [B]
3G_GAIN_CTRL 152 0 ~ 255 [IC531 Addr:0x02] ✻Black Reference Adjustment [G]
4R_GAIN_CTRL 153 0 ~ 255 [IC501 Addr:0x02] ✻Black Reference Adjustment [R]
5B_GAIN_CTRL 152 0 ~ 255 [IC561 Addr:0x02] ✻Black Reference Adjustment [B]
6G_BRT_CTRL 128 0 ~ 255 [IC531 Addr:0x03]
7R_BRT_CTRL 128 0 ~ 255 [IC501 Addr:0x03]
8B_BRT_CTRL 128 0 ~ 255 [IC561 Addr:0x03]
9G_VCOM_CTRL 96 0~127 [IC531 Addr:0x04] ✻Common Center Adjustment [G]
10 R_VCOM_CTRL 97 0~127 [IC501 Addr:0x04] ✻Common Center Adjustment [R]
11 B_VCOM_CTRL 93 0~127 [IC561 Addr:0x04] ✻Common Center Adjustment [B]
12 G_PSIGA 20 0~127 [IC531 Addr:0x05] ✻PSIG Adjustment [ZPSIG]
13 B_PSIGA 20 0~127 [IC561 Addr:0x05]
14 R_PSIGA 20 0~127 [IC501 Addr:0x05] ✻PSIG Adjustment [PSIG]
15 G_PSIGB 86 0~127 [IC531 Addr:0x06] ✻PSIG Adjustment [ZPSIG]
16 B_PSIGB 86 0~127 [IC561 Addr:0x06]
17 R_PSIGB 86 0~127 [IC501 Addr:0x06] ✻PSIG Adjustment [PSIG]
Group: 11 Gamma
0Standard GAMMA 0 0/0 0 ~ 1023
1Standard GAMMA 1 100/66 0 ~ 1023 PC,DVI Standard / AV Standard
2Standard GAMMA 2 180/132 0 ~ 1023 Read Only
3Standard GAMMA 3 308/286 0 ~ 1023
4Standard GAMMA 4 442/454 0 ~ 1023
5Standard GAMMA 5 522/544 0 ~ 1023
6Standard GAMMA 6 647/634 0 ~ 1023
7Standard GAMMA 7 703/689 0 ~ 1023
8Standard GAMMA 8 743/729 0 ~ 1023
9Standard GAMMA 9 776/764 0 ~ 1023
10 Standard GAMMA 10 807/795 0 ~ 1023
11 Standard GAMMA 11 840/822 0 ~ 1023
12 Standard GAMMA 12 874/854 0 ~ 1023
13 Standard GAMMA 13 902/880 0 ~ 1023
14 Standard GAMMA 14 948/905 0 ~ 1023
15 Standard GAMMA 15 1023/980 0 ~ 1023
16 Real/Cinema GAMMA 0 512/512 0 ~ 1023
17 Real/Cinema GAMMA 1 562/551 0 ~ 1023 PC,DVI Real / AV Cinema(Difference from Standard)
18 Real/Cinema GAMMA 2 602/590 0 ~ 1023
19 Real/Cinema GAMMA 3 630/620 0 ~ 1023
20 Real/Cinema GAMMA 4 594/564 0 ~ 1023
21 Real/Cinema GAMMA 5 560/538 0 ~ 1023
22 Real/Cinema GAMMA 6 529/522 0 ~ 1023
23 Real/Cinema GAMMA 7 513/509 0 ~ 1023
24 Real/Cinema GAMMA 8 506/505 0 ~ 1023
25 Real/Cinema GAMMA 9 505/500 0 ~ 1023
26 Real/Cinema GAMMA 10 501/497 0 ~ 1023
27 Real/Cinema GAMMA 11 497/502 0 ~ 1023
28 Real/Cinema GAMMA 12 498/505 0 ~ 1023
29 Real/Cinema GAMMA 13 490/503 0 ~ 1023
30 Real/Cinema GAMMA 14 469/497 0 ~ 1023
31 Real/Cinema GAMMA 15 424/497 0 ~ 1023
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

-15-
Group 100 H8 Option
0Lamp Time Monitor 0~8738 Read Only
1RS232C Baudrate 0 ~ 1 0: 19200bps1: 9600bps
2
3Cooling Time 3 1 ~ 15 Cooling time1:30 sec.3:90 sec.15:450 sec.
4Hi-Land SW 0 0 ~ 3 0: Normal Mode1~3: High-Land Mode 1-3
5
6Lamp Total Time 0~65535 Read only
7Net Board RESET 0 ~ 1 Not used
8
9Reset SW 0 ~ 10 Resets User Setting data when this value is set to 10
10 Color Shading SW 0 ~ 1 0:Color Compensation Off, 1:Color Compensation On
11 RC Enable/Disable 0 0 ~ 3 0:Enable 1:Disable
12 Lamp Dim Level 10 0 ~ 15
13 Lamp Warning Time 0~65535
14
15 Video Mute Forced Off 0 ~ 1 0:VideoMuteOn(Normal) 1:Video Mute Forced Off
16 Safety FAN Control Fix SW 0 ~ 5 0:Normal 1:Normal Min2:Normal Max3:Eco Min4:Eco Max
17 HDCP Option 0 0 ~ 3 0: XGA 1; other than XGA
18 HDCP Reset 0 0 ~ 10
19
Group: 101PW Option
0Shootout Mode 0 0 ~ 1 1: Shoot Out Mode Enable0: Disable
1
2NOBRAND 0 0 ~ 1 0:Normal1:NOBRAND
3
4HDCP OverScan Rate 0 0 ~ 5
Group: 110 Dimmer Processing
0DIMMER_CTRL_LEVEL1 7 0~255 Dimmer Brightness Level1 Data: Dimmer Level1 when less than this value.
1DIMMER_CTRL_LEVEL2 14 0~255 Dimmer Brightness Level2 Data: Dimmer Level2 when less than this value.
2DIMMER_CTRL_LEVEL3 21 0~255 Dimmer Brightness Level3 Data: Dimmer Level3 when less than this value.
3DIMMER_CTRL_LEVEL4 28 0~255 Dimmer Brightness Level4 Data: Dimmer Level4 when less than this value.
4DIMMER_CTRL_LEVEL5 35 0~255 Dimmer Brightness Level5 Data: Dimmer Level5 when less than this value.
5DIMMER_CTRL_LEVEL6 42 0~255 Dimmer Brightness Level6 Data: Dimmer Level6 when less than this value.
6DIMMER_CTRL_LEVEL7 49 0~255 Dimmer Brightness Level7 Data: Dimmer Level7 when less than this value.
7DIMMER_CTRL_LEVEL8 56 0~255 Dimmer Brightness Level8 Data: Dimmer Level8 when less than this value.
8DIMMER_CTRL_LEVEL9 63 0~255 Dimmer Brightness Level9 Data: Dimmer Level9 when less than this value.
9DIMMER_CTRL_LEVEL10 70 0~255 Dimmer Brightness Level10 Data: Dimmer Level10 when less than this value.
10 DIMMER_CTRL_LEVEL11 77 0~255 Dimmer Brightness Level11 Data: Dimmer Level11 when less than this value.
11 DIMMER_CTRL_LEVEL12 84 0~255 Dimmer Brightness Level12 Data: Dimmer Level12 when less than this value.
12 DIMMER_CTRL_LEVEL13 91 0~255 Dimmer Brightness Level13 Data: Dimmer Level13 when less than this value.
13 DIMMER_CTRL_LEVEL14 98 0~255 Dimmer Brightness Level14 Data: Dimmer Level14 when less than this value.
14 DIMMER_CTRL_LEVEL15 105 0~255 Dimmer Brightness Level15 Data: Dimmer Level15 when less than this value.
15 DIMMER_AVERAGE_POINT 4 1 ~ 16 Average count for Dimmer Brightness Data
16 DIMMER_AVERAGE_DATA - 0 ~ 255 Average Value for Dimmer Brightness Data * Read Only(8 bit)
17 DIMMER_LEVEL_AUTO - 0 ~ 15 Dimmer Level effective in auto-dimmer mode. 0 fixed other than auto mode (Read Only)
18 DIMMER_LEVEL_NONAUTO - 0 ~ 15 Dimmer Level effective other than auto-dimmer mode
Group: 111 Fan Control
0FAN_TEMP_A_WARNING 72/74 30 ~ 100 Temperature A to judge the abnormal temperature, for surrounding temperature SVGA/XGA
1FAN_TEMP_B_WARNING 59/58 30 ~ 100 Temperature B to judge the abnormal temperature, for Panels SVGA/XGA
2FAN_TEMP_C_WARNING 71/73 30 ~ 100 Temperature C to judge the abnormal temperature, for Lamp SVGA/XGA
3FAN_TEMP_B-A_WARNING 100 0 ~ 100 Temperature B-A to judge the abnormal temperature, for detecting clogged filter
4FAN_TEMP_C-A_WARNING 100 0 ~ 100 Temperature C-A to judge the abnormal temperature, for detecting clogged filter
5FAN_CONTROL_SW 1 0 or 1 0: Auto Fan Control 1:Manual Control ✻Fan Control adjustment
6FAN_1_SPEED_CTRL 135 0 ~ 255 Manual Adjustment Mode when FAN_CONTROL_SW=1
7FAN_2_SPEED_CTRL 135 0 ~ 255
8
9FAN_1_SPEED_MONI - 0 ~ 255 Fan Speed Monitor when FAN_CONTROL_SW=0, Read Only
10 FAN_2_SPEED_MONI - 0 ~ 255
11
12 FAN_TEMP_A_MONI - - Read Only
13 FAN_TEMP_B_MONI - -
14 FAN_TEMP_C_MONI - -
15
16 TEMP_UPWARNING_TIME 0 0 ~ 5 +15 degrees is added to Abnormal Temperature Value during x min after power on.
17 NOR_TEMP_FAN1_MIN 44/48 Control Start Temperature for FAN1 at Normal Mode SVGA/XGA
18 NOR_TEMP_FAN1_MAX 52/54 Control End Temperature for FAN1 at Normal Mode SVGA/XGA
19 NOR_TEMP_FAN2_MIN 44/48 0~255 Control Start Temperature for FAN2 at Normal Mode SVGA/XGA
20 NOR_TEMP_FAN2_MAX 52/54 Control End Temperature for FAN2 at Normal Mode SVGA/XGA
21
22
23 NOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
24 NOR_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Normal Mode
25 NOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Normal Mode
26 NOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Normal Mode
27
28
29 ECO_TEMP_FAN1_MIN 43/47 Control Start Temperature for FAN1 at Eco Mode SVGA/XGA
30 ECO_TEMP_FAN1_MAX 51/54 Control End Temperature for for FAN1 at Eco Mode SVGA/XGA
31 ECOTEMP_FAN2_MIN 43/47 0~255 Control Start Temperature for FAN2 at Eco Mode SVGA/XGA
32 ECO_TEMP_FAN2_MAX 51/54 Control End Temperature for for FAN2 at Eco Mode SVGA/XGA
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

-16-
33
34
35 ECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Eco Mode
36 ECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Eco Mode
37 ECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Eco Mode
38 ECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Eco Mode
39
40
41 HINOR_TEMP_FAN1_MIN 44/48 Control Start Temperature for FAN1 at Highland Normal Mode
42 HINOR_TEMP_FAN1_MAX 52/54 Control End Temperature for FAN1 at Highland Normal Mode
43 HINOR_TEMP_FAN2_MIN 44/48 0~255 Control Start Temperature for FAN2 at Highland Normal Mode
44 HINOR_TEMP_FAN2_MAX 52/54 Control End Temperature for FAN2 at Highland Normal Mode
45
46
47 HINOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Highland Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
48 HINOR_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Highland Normal Mode
49 HINOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Highland Normal Mode
50 HINOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Highland Normal Mode
51
52
53 HIECO_TEMP_FAN1_MIN 43/47 Control Start Temperature for FAN1 at Highland Eco Mode
54 HIECO_TEMP_FAN1_MAX 51/53 Control End Temperature for FAN1 at Highland Eco Mode
55 HIECOTEMP_FAN2_MIN 43/47 0~255 Control Start Temperature for FAN2 at Highland Eco Mode
56 HIECO_TEMP_FAN2_MAX 51/54 Control End Temperature for FAN2 at Highland Eco Mode
57
58
59 HIECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Highland Eco Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
60 HIECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Highland Eco Mode
61 HIECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Highland Eco Mode
62 HIECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Highland Eco Mode
63
64
65 CLNOR_TEMP_FAN1_MIN 44/48 Control Start Temperature for FAN1 at Ceiling Normal Mode
66 ClNOR_TEMP_FAN1_MAX 52/54 Control End Temperature for FAN1 at Ceiling Normal Mode
67 CLNOR_TEMP_FAN2_MIN 44/48 0~255 Control Start Temperature for FAN2 at Ceiling Normal Mode
68 CLNOR_TEMP_FAN2_MAX 52/54 Control End Temperature for FAN2 at Ceiling Normal Mode
69
70
71 CLNOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Ceiling Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
72 CLNOR_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Ceiling Normal Mode
73 CLNOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Ceiling Normal Mode
74 CLNOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Ceiling Normal Mode
75
76
77 CLECO_TEMP_FAN1_MIN 43/47 Control Start Temperature for FAN1 at Ceiling Eco Mode
78 CLECO_TEMP_FAN1_MAX 51/54 Control End Temperature for FAN1 at Ceiling Eco Mode
79 CLECOTEMP_FAN2_MIN 43/47 0~255 Control Start Temperature for FAN2 at Ceiling Eco Mode
80 CLECO_TEMP_FAN2_MAX 51/54 Control End Temperature for FAN2 at Ceiling Eco Mode
81
82
83 CLECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Ceiling Eco Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
84 CLECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Ceiling Eco Mode
85 CLECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Ceiling Eco Mode
86 CLECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Ceiling Eco Mode
87
88
89 FAN1_ADJUST_VOLT_MIN 1 DAC Adjustment Value at minimum driving voltage for FAN1 ✻Fan Control Adjustment
90 FAN1_ADJUST_VOLT_MAX 230 DAC Adjustment Value at maximum driving voltage for FAN1 ✻Fan Control Adjustment
91 FAN2_ADJUST_VOLT_MIN 1 0~255 DAC Adjustment Value at minimum driving voltage for FAN2 ✻Fan Control Adjustment
92 FAN2_ADJUST_VOLT_MAX 230 DAC Adjustment Value at maximum driving voltage for FAN2 ✻Fan Control Adjustment
93
94
Group: 112 PC Real/ AV Cinema
0PC Real Contrast 32 0 ~ 63
1PC Real Brightness 32 0 ~ 63
2PC Real Red 34 0 ~ 63
3PC Real Green 32 0 ~ 63
4PC Real Blue 31 0 ~ 63
5PC Real Gamma 8 0 ~ 15
6AV Cinema Contrast 32 0 ~ 63
7AV Cinema Brightness 32 0 ~ 63
8AV Cinema Color 32 0 ~ 63
9AV Cinema Tint 32 0 ~ 63
10 AV Cinema Red 32 0 ~ 63
11 AV Cinema Green 30 0 ~ 63
12 AV Cinema Blue 29 0 ~ 63
13 AV Cinema Sharpness 8 0 ~ 31
14 AV Cinema Gamma 8 0 ~ 15
15
16 AV Cinema PROGRESSIVE 1 0 or 1
Group: 300 I/P
0L1 LWDIFFTH 10 0 ~ 255 L1 For motion movie
1L1 HIDIFFTH 48 0 ~ 255
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

-17-
2L1 HIMOTHR 1 0 ~ 16
3L1 LWMOTHR 1 0 ~ 16
4L2 LWDIFFTH 32 0 ~ 255 L2 Still picture
5L2 HIDIFFTH 48 0 ~ 255
6L2 HIMOTHR 6 0 ~ 16
7L2 LWMOTHR 6 0 ~ 16
Group: 301 Color Gain
0AV Color 32 0 ~ 63 Color[0-63] on AV menu
1Color Space Converter 70[0-63] 0 ~ 4096 PW463 Extended Input Port CSC
2TB1274F C Out 21/29/20/28 0 ~ 63 Video S-Video Other/SECAM,BW/ YCbCr/Scart
3TB1274AF Sub Color 8/8/8/8 0 ~ 16 Video S-Video Other/SECAM,BW/ YCbCr/Scart
Group: 500 NTSC Gakaku (Composite/Svideo) at I/P OFF
0NTSC TOTAL DOTS 1311 0 ~ 4096
1NTSC DISP DOTS 1025 0 ~ 4096
2NTSC H BACK PORCTH 234 0 ~ 4096
3NTSC V BACK PORCTH 48 0 ~ 4096
4NTSC DISP LINE 459 0 ~ 4096
5NTSC CLAMP 1 0 ~ 127
6NTSC WIDTH 31 0 ~ 63
Group: 501 PAL Gakaku(Composite/Svideo) at I/P OFF
0PAL TOTAL DOTS 1328 0 ~ 4096
1PAL DISP DOTS 1004 0 ~ 4096
2PAL H BACK PORCTH 267 0 ~ 4096
3PAL V BACK PORCTH 63 0 ~ 4096
4PAL DISP LINE 541 0 ~ 4096
5PAL CLAMP 1 0 ~ 127
6PAL WIDTH 31 0 ~ 63
Group: 502 NTSC Gakaku (Composite/Svideo) at I/P ON
0NTSC TOTAL DOTS 959 0 ~ 4096
1NTSC DISP DOTS 748 0 ~ 768
2NTSC H BACK PORCTH 175 0 ~ 4096
3NTSC V BACK PORCTH 49 0 ~ 4096
4NTSC DISP LINE 458 0 ~ 576
5NTSC CLAMP 1 0 ~ 127
6NTSC WIDTH 31 0 ~ 63
Group: 503 PAL Gakaku(Composite/Svideo) at I/P ON
0PAL TOTAL DOTS 990 0 ~ 4096
1PAL DISP DOTS 748 0 ~ 768
2PAL H BACK PORCTH 201 0 ~ 4096
3PAL V BACK PORCTH 64 0 ~ 4096
4PALDISP LINE 536 0 ~ 576
5PAL CLAMP 1 0 ~ 127
6PAL WIDTH 31 0 ~ 63
Group: 510 HDTV 1080i-60 Gakaku (Component)
0HDTV TOTAL DOTS 2243 0 ~ 4096
1HDTV DISP DOTS 1909 0 ~ 4096
2HDTV H BACK PORCTH 245 0 ~ 4096
3HDTV V BACK PORCTH 56 0 ~ 4096
4HDTV DISP LINE 1050 0 ~ 4096
5HDTV CLAMP 7 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
Group: 511HDTV 1080i-50 Gakaku (Component)
0HDTV TOTAL DOTS 2663 0 ~ 4096
1HDTV DISP DOTS 1886 0 ~ 4096
2HDTV H BACK PORCTH 243 0 ~ 4096
3HDTV V BACK PORCTH 56 0 ~ 4096
4HDTV DISP LINE 1050 0 ~ 4096
5HDTV CLAMP 7 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
Group: 512 HDTV 1035i Gakaku (Component)
0HDTV TOTAL DOTS 2244 0 ~ 4096
1HDTV DISP DOTS 1907 0 ~ 4096
2HDTV H BACK PORCTH 251 0 ~ 4096
3HDTV V BACK PORCTH 92 0 ~ 4096
4HDTV DISP LINE 1009 0 ~ 4096
5HDTV CLAMP 7 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
Group: 513 HDTV 720p Gakaku (Component)
0HDTV TOTAL DOTS 1679 0 ~ 4096
1HDTV DISP DOTS 1270 0 ~ 4096
2HDTV H BACK PORCTH 321 0 ~ 4096
3HDTV V BACK PORCTH 34 0 ~ 4096
4HDTV DISP LINE 700 0 ~ 4096
5HDTV CLAMP 7 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

-18-
Group: 514 HDTV 575p Gakaku (Component)
0HDTV TOTAL DOTS 1253 0 ~ 4096
1HDTV DISP DOTS 952 0 ~ 4096
2HDTV H BACK PORCTH 249 0 ~ 4096
3HDTV V BACK PORCTH 61 0 ~ 4096
4HDTV DISP LINE 536 0 ~ 4096
5HDTV CLAMP 35 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
Group: 515 HDTV 480p Gakaku (Component)
0HDTV TOTAL DOTS 1317 0 ~ 4096
1HDTV DISP DOTS 1051 0 ~ 4096
2HDTV H BACK PORCTH 221 0 ~ 4096
3HDTV V BACK PORCTH 48 0 ~ 4096
4HDTV DISP LINE 459 0 ~ 4096
5HDTV CLAMP 35 0 ~ 127
6HDTV WIDTH 58 0 ~ 63
Group: 516 HDTV 575i Gakaku (Component) at I/P OFF
0HDTV TOTAL DOTS 1309 0 ~ 4096
1HDTV DISP DOTS 984 0 ~ 4096
2HDTV H BACK PORCTH 259 0 ~ 4096
3HDTV V BACK PORCTH 60 0 ~ 4096
4HDTV DISP LINE 543 0 ~ 4096
5HDTV CLAMP 1 0 ~ 127
6HDTV WIDTH 31 0 ~ 63
Group: 517 HDTV 480i Gakaku (Component)at I/POFF
0HDTV TOTAL DOTS 1311 0 ~ 4096
1HDTV DISP DOTS 1023 0 ~ 4096
2HDTV H BACK PORCTH 216 0 ~ 4096
3HDTV V BACK PORCTH 49 0 ~ 4096
4HDTV DISP LINE 458 0 ~ 4096
5HDTV CLAMP 1 0 ~ 127
6HDTV WIDTH 31 0 ~ 63
Group: 518 HDTV 575i Gakaku (Component) at I/P ON
0HDTV TOTAL DOTS 991 0 ~ 4096
1HDTV DISP DOTS 748 0 ~ 768
2HDTV H BACK PORCTH 198 0 ~ 4096
3HDTV V BACK PORCTH 60 0 ~ 4096
4HDTV DISP LINE 536 0 ~ 576
5HDTV CLAMP 1 0 ~ 127
6HDTV WIDTH 31 0 ~ 63
Group: 519 HDTV 480i Gakaku (Component) at I/PON
0HDTV TOTAL DOTS 959 0 ~ 4096
1HDTV DISP DOTS 748 0 ~ 768
2HDTV H BACK PORCTH 158 0 ~ 4096
3HDTV V BACK PORCTH 50 0 ~ 4096
4HDTV DISP LINE 455 0 ~ 576
5HDTV CLAMP 1 0 ~ 127
6HDTV WIDTH 31 0 ~ 63
Group: 520 RGB 1080i-60 Gakaku
0RGB TOTAL DOTS 2298 0 ~ 4096
1RGB DISP DOTS 1953 0 ~ 4096
2RGB H BACK PORCTH 264 0 ~ 4096
3RGB V BACK PORCTH 81 0 ~ 4096
4RGB DISP LINE 1050 0 ~ 4096
5RGB CLAMP 40 0 ~ 127
6RGB WIDTH 58 0 ~ 63
Group: 521 RGB 1080i-50 Gakaku
0RGB TOTAL DOTS 2735 0 ~ 4096
1RGB DISP DOTS 1938 0 ~ 4096
2RGB H BACK PORCTH 261 0 ~ 4096
3RGB V BACK PORCTH 55 0 ~ 4096
4RGB DISP LINE 1050 0 ~ 4096
5RGB CLAMP 40 0 ~ 127
6RGB WIDTH 58 0 ~ 63
Group: 522 RGB 1035i Gakaku
0RGB TOTAL DOTS 2261 0 ~ 4096
1RGB DISP DOTS 1920 0 ~ 4096
2RGB H BACK PORCTH 260 0 ~ 4096
3RGB V BACK PORCTH 92 0 ~ 4096
4RGB DISP LINE 1012 0 ~ 4096
5RGB CLAMP 40 0 ~ 127
6RGB WIDTH 58 0 ~ 63
Group: 523 RGB 720p Gakaku
0RGB TOTAL DOTS 2203 0 ~ 4096
1RGB DISP DOTS 1666 0 ~ 4096
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

-19-
2RGB H BACK PORCTH 410 0 ~ 4096
3RGB V BACK PORCTH 35 0 ~ 4096
4RGB DISP LINE 700 0 ~ 4096
5RGB CLAMP 50 0 ~ 127
6RGB WIDTH 58 0 ~ 63
Group: 524 RGB 575p Gakaku
0RGB TOTAL DOTS 1385 0 ~ 4096
1RGB DISP DOTS 1052 0 ~ 4096
2RGB H BACK PORCTH 263 0 ~ 4096
3RGB V BACK PORCTH 62 0 ~ 4096
4RGB DISP LINE 535 0 ~ 4096
5RGB CLAMP 7 0 ~ 127
6RGB WIDTH 58 0 ~ 63
Group: 525 RGB 480p Gakaku
0RGB TOTAL DOTS 1309 0 ~ 4096
1RGB DISP DOTS 1046 0 ~ 4096
2RGB H BACK PORCTH 211 0 ~ 4096
3RGB V BACK PORCTH 55 0 ~ 4096
4RGB DISP LINE 560 0 ~ 4096
5RGB CLAMP 7 0 ~ 127
6RGB WIDTH 26 0 ~ 63
Group: 526 RGB 575i Gakaku
0RGB TOTAL DOTS 1314 0 ~ 4096
1RGB DISP DOTS 992 0 ~ 4096
2RGB H BACK PORCTH 256 0 ~ 4096
3RGB V BACK PORCTH 65 0 ~ 4096
4RGB DISP LINE 539 0 ~ 4096
5RGB CLAMP 1 0 ~ 127
6RGB WIDTH 32 0 ~ 63
Group: 527 RGB 480i Gakaku
0RGB TOTAL DOTS 1313 0 ~ 4096
1RGB DISP DOTS 1024 0 ~ 4096
2RGB H BACK PORCTH 216 0 ~ 4096
3RGB V BACK PORCTH 48 0 ~ 4096
4RGB DISP LINE 459 0 ~ 4096
5RGB CLAMP 1 0 ~ 127
6RGB WIDTH 32 0 ~ 63
Group: 530 SCART 575i Gakaku at I/P OFF
0SCART TOTAL DOTS 1313 0 ~ 4096
1SCART DISP DOTS 985 0 ~ 4096
2SCART H BACK PORCTH 243 0 ~ 4096
3SCART V BACK PORCTH 70 0 ~ 4096
4SCART DISP LINE 514 0 ~ 4096
5SCART CLAMP 1 0 ~ 127
6SCART WIDTH 32 0 ~ 63
Group: 531 SCART 480i Gakaku at I/P OFF
0SCART TOTAL DOTS 1296 0 ~ 4096
1SCART DISP DOTS 1042 0 ~ 4096
2SCART H BACK PORCTH 211 0 ~ 4096
3SCART V BACK PORCTH 46 0 ~ 4096
4SCART DISP LINE 450 0 ~ 4096
5SCART CLAMP 1 0 ~ 127
6SCART WIDTH 32 0 ~ 63
Group: 532 SCART 575i Gakaku at I/P ON
0SCART TOTAL DOTS 998 0 ~ 4096
1SCART DISP DOTS 748 0 ~ 768
2SCART H BACK PORCTH 187 0 ~ 4096
3SCART V BACK PORCTH 70 0 ~ 4096
4SCART DISP LINE 514 0 ~ 576
5SCART CLAMP 1 0 ~ 127
6SCART WIDTH 32 0 ~ 63
Group: 533 SCART 480i Gakaku at I/P ON
0SCART TOTAL DOTS 940 0 ~ 4096
1SCART DISP DOTS 748 0 ~ 768
2SCART H BACK PORCTH 155 0 ~ 4096
3SCART V BACK PORCTH 44 0 ~ 4096
4SCART DISP LINE 452 0 ~ 576
5SCART CLAMP 1 0 ~ 127
6SCART WIDTH 32 0 ~ 63
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments

MW3-XU5003
-20-
■Electrical Parts List
Product safety should be considered when a component replacement is made in any area of a projector.
Components indicated by a ! mark in this parts list and the circuit diagram show components whose value have spe-
cial significance to product safety. It is particularly recommended that only parts specified on the following parts list be
used for components replacement pointed out by the mark.
Read description in the Capacitor and Resistor as follows:
CAPACITOR CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF E : +0 -1pF F : ±1PF
G : ±2pF H : +0.1 -0pF L : +0 -0.1pF
R : ±0.25 -0pF S : +0-0.25pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC........... Ceramic
MT-PAPER......... Metallized Paper
POLYESTER...... Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID........... Tantalum Oxide Solid Electrolytic
AL-SOLID........... Aluminium Solid Electrolytic
ELECT................ Aluminum Foil Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
POS-SOLID........ Polymerized Organic Semiconductive
DL-ELECT.......... Double Layered Electrolytic
PPS-FILM...........Polyphenylene Sulfide Film
MT-PPS-FILM.....Metalized Polyphenylene Sulfide Film
MT-PEN-FILM.....Metalized Polyethylenenaphthalate Film
CAPACITOR.......Other
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15% Z: 0 ohm
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE......... Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
RESISTOR ........Other
T: ±10ppm/°C U: ±25ppm/°C C: ±50ppm/°C
D: ±100ppm/°C E: ±200ppm/°C F: ±250ppm/°C
G: ±350ppm/°C H: ±1000ppm/°C±10% W: ±1200ppm/°C±10%
Y: ±1400ppm/°C±10% J: ±2000ppm/°C±10% K: ±2400ppm/°C±10%
L: ±2700ppm/°C±10% M: ±3000ppm/°C±10% N: ±3300ppm/°C±10%
P: ±3600ppm/°C±10% Q: ±3900ppm/°C±10% R: ±4200ppm/°C±10%
S: ±4300ppm/°C±10% V: ±4500ppm/°C±10% X: ±8000ppm/°C±10%
RESISTOR
●Read Description in the parts list
