1100 ANSI LUMENS zTRUE XGA zMULTIMEDIA PROJECTOR
Issued 1/03
PLC-XW20AR
XGA Micro-mobile Multimedia Projector
10-BIT DIGITAL GAMMA CORRECTION FUNCTION
Through the gamma correction function, fine tone reproduction
is achieved without annoying white and black spots. In addition
to the Standard mode, the PLC-XW20AR also offers a Cinema
mode for movies and Real mode for graphics. Plus, the
projector has four user memory settings for fine picture
adjustments.
3D AUTOMATIC UNIFORMITY CORRECTION CONTROL
With the 3D-AUCC circuit, color shading resulting from
differences in brightness can be corrected to an accuracy ten
times greater than using conventional methods. This produces
more natural looking color gradations.
AUTOMATIC FLESHTONE CONTROL
Flesh color portions of the source image (including approximate
colors) are automatically detected and extracted, providing
much more natural flesh colors with no interference with other
color portions of the source material.
AUTOMATIC GRAYSCALE CONTROL
When activated, this function automatically adjusts contrast to
best suit the input source, improving gradations and producing
sharper, more solid images.
FRONT EXHAUST MECHANISM
The air exhaust vent of the PLC-XW20AR is positioned on the
front of the projector for more effective absorption and
dissipation of heat, while at the same time creating a more
comfortable environment for presentations.
COMPONENT VIDEO INPUTS
The PLC-XW20AR comes with component video inputs and a
newly developed Digital RGB Matrix IC that makes projection of
DVD (Y/Cb/Cr) and HDTV (Y/Pb/Pr) possible.
HDTV COMPATIBLE
The SANYO PLC-XW20AR is High Definition Television
Compatible, accepting the 1080i, 1035i, 720p, 575p, 575i, 480p
and 480i HDTV resolution standards.
DIGITAL KEYSTONE CORRECTION
SANYO s digital keystone correction feature compensates for
angled projector placement by digitally altering the pixels to
produce undistorted images.
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax [phone]
www.sanyolcd.com
Specifications
Resolution XGA (1024 x 768)
Brightness (typical) 1100 ANSI Lumens
Uniformity 90%
LCD Panel System 0.7” TFT Poly x 3
Number of Pixels 2,359,296 (786,432 x 3)
Contrast Ratio 300:1 (full on/off)
Projection Image
(diagonal) 34”-200”
Aspect Ratio 4:3
Throw Distance 5.3’-26.5’
Zoom/Focus Manual (1:1.2 zoom)
Up/Down Ratio 19:1
Digital Keystone
Correction +/- 20°
Projection System Polarized Beam Splitter optical system
Projection Lens F1.6-1.78 / f1.13”-1.36”
Lens Throw Ratio 2.0-2.4:1
Projection Lamp 132W UHP
Scanning Frequency H 15-100kHz; V 50-100Hz
Dot Clock 140 MHz
Color System PAL/PAL-M/PAL-
N/SECAM/NTSC/NNTSC4.43
Computer Compatibility SXGA, XGA, SVGA, VGA
Sound Output One-piece, 1-watt Mono
Voltage 100-240V AC; 50/60/Hz (auto sense/select)
BTU Rating 853 BTU
Power Consumption 250W
Dimensions (WxHxD) 10.1”x3.0”x9.1”
Net Weight 6.2 lbs.
User Maintenance Clean air filters, replace lamp assembly
PC Input Terminals D-Sub15 zAudio Mini-jack (stereo)
Video Input Terminal zComposite / Component RCA x 3
(Video/Y, Pb/Cb, Pr/Cr)
zS-Video (mini-DIN 4-pin)
zAudio Mini-jack (stereo)
Output Terminal Audio Mini-jack (stereo)
Control Port Terminal Mini DIN 8-pin zUSB type B
Included Accessories zWireless I/R Remote Control w/ Mouse
Pad & Laser pointer zAC power supply cord
zOwner’s manual zVGA computer cablez
Lens cap
zSoft carry bag z2 “AA” batteries
zPS/2 Control Cable
Optional Accessories zSerial Control Cable (POA-MCSRL)
zADB Control Cable (POA-MCMAC)
zMAC/VGA adapter (POA-MACAP)
Warranty Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.

1100 ANSI LUMENS zTRUE XGA zMULTIMEDIA PROJECTOR
Issued 1/03
PLC-XW20AR Terminal Input Panel
