INSTRUCTION MANUAL VCB-3424
B/W CCD Camera
About this manual
Before installing and using the camera, please read this manual
carefully. Be sure to keep it handy for later reference.
L73T4/US GB 1999, 8, 3

SANYO INDUSTRIAL VIDEO
B/W VIDEO CAMERA LIMITED WARRANTY
OBLIGATIONS
In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s expense, unless specifically stated otherwise in this warranty. The names and
addresses of Authorized Sanyo Service Centers may be obtained by writing to SFS Corporation, SFC’s warranty administrator, at any of the addresses listed below, or by calling (toll-free) 1-800-421-5013.
New Jersey Office
210 Riser Road
Little Ferry, NJ 07643
201-641-3000
California Office
1200 W. Artesia Blvd.
Compton, CA 90220
310-537-5830
Illinois Office
900 N. Arlington Heights Rd.
Itasca, IL 60143
708-775-1414
THIS WARRANTY IS VALID ONLY ON SANYO PRODUCTS PURCHASED OR RENTED IN THE UNITED STATES OF AMERICA, EXCLUDING HAWAII AND ALL U.S. TERRITORIES AND PROTECTORATES. THIS
WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL USER. THE ORIGINAL DATED BILL OF SALE, SALES SLIP OR RENTAL AGREEMENT MUST BE SUBMITTED TO THE AUTHORIZED SANYO SERVICE CENTER
AT THE TIME WARRANTY SERVICE IS REQUESTED.
Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER (USA) CORPORATION warrants this SANYO product against defects in materials and workmanship for the periods specified below. SFC
will repair or replace (at its option) the product and any of its parts which fail to conform to this warranty. The warranty period commences on the date the product was first purchased or rented at retail.
LABOR PARTS IMAGE DEVICE
3 YEARS 3 YEARS 3 YEARS
EXCLUSIONS
This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model’s instruction manual, or (B) the repair of any product whose serial number has been altered, defaced
or removed.
This warranty shall not apply to the cabinet or cosmetic parts, antenna, knobs, batteries or image burns to projection or picture tubes caused by electronic devices or games.
This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the product after repair.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including, but not limited to, any malfunction, defect or failure caused by or resulting from unauthorized
service or parts, improper maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user, abuse, misuse, neglect, accident, incorrect power line voltage, fire,
flood or other Acts of God, or normal wear and tear.
The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it any other obligation or liability.
THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT
SHALL SFC BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THIS PRODUCT, OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGATIONS
UNDER THIS WARRANTY DUE TO CAUSES BEYOND ITS CONTROL.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
ATTENTION
For your protection in the event of theft or loss of this product, please fill in the information below for you own personal records.
Model No._____________________________________________________________________ Serial No. _____________________________________________________________________
(Located on back or bottom side of unit.)
Date of Purchase _______________________________________________________________ Purchase Price _________________________________________________________________
Where Purchased _________________________________________________________________________________________________________________________________________________
L73T4/US GB 1999, 8, 3
14 English

Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If
you need help with installation and/or settings, please consult your
dealer.
CONTENTS
INFORMATION TO USER .................................................................... 2
PRECAUTIONS..................................................................................... 3
PARTS NAMES..................................................................................... 4
MOUNTING THE LENS........................................................................ 7
CONNECTIONS.................................................................................... 9
SETTINGS............................................................................................. 10
TROUBLESHOOTING........................................................................... 12
SPECIFICATIONS.................................................................................. 13
ACCESSORIES
1C mount adaptor 5 mm).....................1 pc.
The C mount adaptor must be used to be able to install a C mount
lens on the camera.
2Lens iris plug 4-pin).............................1 pc.
12
FEATURES
•Built-in interline transfer method 1/3" CCD, approx. 270,000
picture elements
•Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
•100% solid state components giving excellent immunity to shock
and vibration
•Not subject to interference from magnetic or electrostatic fields
•High sensitivity, minimum required illumination of 0,07 lux with
F1.2 lens
•Horizontal resolution, more than 400 TV lines
•New backlight compensation function Active when using an
auto-iris lens)
•Externally adjustable flange back mechanical focus)
•Low power consumption and quick start
•24 V AC operation
Commarcially available 24 V AC adaptor)
•Built-in Mirror image effect function.
L73T4/US GB 1999, 8, 3
English 1

Safety Guard
THIS SYMBOL INDICATES THAT THERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THE LITERATURE ACCOMPANYING
THIS UNIT
WARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK , DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
This installation should be made by a qualified service person and
should conform to all local codes.
INFORMATION TO USER
For the customers in Canada
This Class B digital apparatus complies with Canadian ICES-003.
Pour la clientèle canadienne
Cet appareil numerique de la Classe B est conforme a la norme
NMB-003 du Canada.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: 1) This device may not
cause harmful interference, and 2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by Sanyo may
void the user’s authority to operate this camera.
L73T4/US GB 1999, 8, 3
2 English

PRECAUTIONS
In case of problem
Do not use the camera if smoke or a strange odour comes from the
unit, or if it seems not to function correctly. Disconnect the power
cord immediately, and consult your dealer or a Sanyo Authorized
Service Centre).
Do not open or modify
Do not open the cabinet, as it may be dangerous and cause damage
to the unit. For internal settings and repairs, consult your dealer or a
Sanyo Authorized Service Centre).
Do not put objects inside the unit
Make sure that no metal objects or flammable substance get inside
the camera. If used with a foreign object inside, it could cause a fire,
short-circuits or damages.
If water or a liquid gets inside the camera, disconnect the power cord
immediately, and consult your dealer or a Sanyo Authorized Service
Centre). Be careful to protect the camera from rain, sea water, etc.
Be careful when handling the unit
To prevent damages, do not drop the camera or subject it to strong
shock or vibration.
Install away from electric or magnetic fields
If installed close to a TV, radio transmitter, magnet, electric motor,
transformer, audio speakers the magnetic field they generate will
distort the image.
Protect from humidity and dust
To prevent damages to the camera, do not install it where there is
greasy smoke or steam, where the dampness may get too high, or
where there is a lot of dust.
Protect from high temperatures
Do not install close to stoves, or other heat generating devices, such
as spotlights, etc., or where it could be subject to direct sunlight, as
that could cause deformation, discoloration or other damages.
Be careful when installing close to the ceiling, in a kitchen or boiler
room, as the temperature may raise to high levels.
Install where the temperature range will stay between –10˚C and 50˚C.
no condensation)
Cleaning
•Dirt can be removed from the cabinet by wiping it with a soft
cloth. To remove stains, wipe with a soft cloth moistened with a
soft detergent solution and wrung dry, then wipe dry with dry soft
cloth.
•Do not use benzine, thinner or other chemical product on the
cabinet, as that may cause deformation and paint peeling. Before
using a chemical cloth, make sure to read all accompanying
instructions. Make sure that no plastic or rubber material comes in
contact with the cabinet for a long period of time, as that may
cause damage or paint peeling.
L73T4/US GB 1999, 8, 3
English 3

PARTS NAMES
1Video output connector (VIDEO OUT: BNC type)
Connect this connector to a device such as a VCR or monitor with a VIDEO IN connector.
2Line phase adjustment volume (LINE PHASE)
When using two cameras or more, the image on the monitor may roll vertically when switching sources. This
rolling can be minimized by turning this volume.
3Power indicator (POWER)
Comes on when the power to the camera is on.
424 V AC input terminal (24 V AC, GND)
Connect to 24 V AC UL listed class 2 power supply.
5Camera setup section (under the cover)
These settings are for when using a 1/3 inch CS mount DC without EE internal amplifier) type lens. However,
if due to installation conditions or environment the settings may need to be modified for best results see
"SETTINGS").
To access the controls, loosen the cover fixing screw A, then remove the cover
6Lens iris output connector (LENS)
This 4-pin connector is used to send the DC control signal and power supply to an auto-iris type lens.
1
2
3
4
5
6
A
L73T4/US GB 1999, 8, 3
4 English

PARTS NAMES
7Lens mount cap
The cap is installed to protect the lens mount section.
Remove the lens mount cap before installing a lens sold separately).
8Flange-back adjustment screw (FLANGE BACK ADJ )
9Flange-back lock screw (FLANGE BACK LOCK)
FCamera installation bracket
The bracket can be fixed at the top or bottom of the camera. When fixing the bracket, be sure to use the
longer screws and install the shorter screws on the opposite side to seal the openings.
1Shorter screws: M3 x 4
2Longer screws: M3 x 6
3Camera mounting screw hole: 1/4"-20 UNC
CAUTION:
When installing the camera support, select a location that can support the total weight of the
camera and accessories
1232
1
F
78
9
L73T4/US GB 1999, 8, 3
English 5

PARTS NAMES
Concerning auto-iris lenses
DC type auto-iris lens
A lens without amplifier circuit that operates only on a DC power source. In general, this type of lens is
referred to as DC type coil lens or DC type non-amplifier lens.
Set the A I LENS switch to the DC position.)
VIDEO type auto-iris lens
A lens with amplifier circuit that operates on video signal and DC power source. In general, this type of lens is
referred to as EE amplifier type lens.
ALC and LEVEL volume level controls are available on the lens for iris adjustments.
Set the A I LENS switch to the VIDEO position.)
Compatible auto-iris lenses
1/3 inch Sanyo DC type lens VIDEO type lens
VCL-CS8LY: Standard angle, f= 8 mm Standard angle, f= 9 mm
VCL-CS4LY: Wide angle, f= 4 mm Telephoto angle, f= 12 mm
VCL-CS2LY: Ultra-wide angle, f= 2.8 mm More telephoto angle, f= 16 mm
If using a VIDEO type auto-iris lens
•Set the ALC and LEVEL controls on the lens to adjust the iris. Normally the ALC volume should be turned
all the way to Av Average).
•Depending on the type of lens used, the lens may not perform properly. In such a case, adjust the LEVEL
volume on the lens casing to correct.
DC
VIDEO
A. I.
LENS
L73T4/US GB 1999, 8, 3
6 English

MOUNTING THE LENS
Please use a DC type auto-iris lens (sold separately)
Checking the lens mount
Do not use a lens if length “L” is more than 7 mm. If not, that may damage the camera and prevent
proper installation.
1Remove the lens mount cap from the camera
2Install the auto-iris lens
CS mount type lens
Carefully align the lens mount with the camera opening, then turn the lens slowly to install it.
C mount type lens
To allow for flange-back adjustment, install the supplied C-mount adaptor on the lens mount, then
carefully align the lens mount with the camera opening and turn the lens slowly to install it.
3Connect the lens plug to the lens iris output connector (LENS) on the side of the camera
When using lenses from other makers, the plug shape may not correspond to the terminal on the camera.
In such a case, remove the original plug and using a soldering iron, connect the supplied lens iris plug
according to the diagram. Refer to page 8.)
L
C mount type lens
1
2
2
3
CS mount type lens
L73T4/US GB 1999, 8, 3
English 7

MOUNTING THE LENS
Rewiring the lens cable in the lens iris plug
1Prepare the lens cable
Cut the cable at the plug, then remove approx. 8 mm of the cable sheath and strip about 2 mm from each wire.
2Install the lens iris plug
Solder the cable to the pins following the correct pin layout refer to the table and illustrations), then close
the plug cover.
Pin layout
DC type lenses VIDEO type lenses
1Brake coil –) +12 V DC 50 mA max.)
2Brake coil +) Not used
3Drive coil +) Video output 1.0 Vp-p, high impedance)
4Drive coil –) Ground for video signal and DC power)
Flange-back adjustment
If the pick-up surface is not correctly positioned with relation to the lens focal point, the picture will be out of
focus in particular when using auto-iris power zoom lenses, sold separately). If that is the case, adjust the
flange-back position as described below.
1Using a + screwdriver, loosen the FLANGE BACK LOCK screw M2:+).
Set the zoom lens to the maximum telephoto position, set the focus using the focus ring on the lens.
2Set the zoom lens to the maximum wide angle position, set the focus using the FLANGE BACK ADJ screw.
3Repeat steps 2 and 3, until the image stays in focus when changing from a telephoto shot to a wide angle shot.
When the setting is complete, tighten the FLANGE BACK LOCK screw.
1
2
43
1
43
1
22
1
1
3
LOCK
2
ADJ.
L73T4/US GB 1999, 8, 3
8 English

CONNECTIONS
Basic co ectio for mo itori g or recordi g
The peripheral devices (VCR, monitor, lens, etc ) and cables are sold separately
1Make the video signal connection between the camera and the monitor or time lapse VCR.
2Connect to 24 V AC UL listed class 2 power supply.
CAUTION:
•To prevent camera and/or power supply failure, pay close attention to polarity when making the
connections.
•To prevent fire hazard any UL listed wire rated VW-1, should be used for the 24 V AC cable input
terminal.
3Insert the plug of this power cord into a wall outlet.
The POWER indicator (A) will light. Adjust the picture on the monitor using the Brightness and Contrast
controls.
Coaxial cable type and maximum length
•Cable type RG-59U 3C-2V), 250 m maximum.
•Cable type RG-6U 5C-2V), 500 m maximum.
•Cable type RG-11U 7C-2V), 600 m maximum.
CAUTION:
•The RG-59U type cable should not be run through electrical conduits or through the air.
•Using CCTV/Video-grade coaxial cable.
(Video signal connections)
: VIDEO IN
: VIDEO OUT
(A)
1
2
24 V 24 V
3
L73T4/US GB 1999, 8, 3
English 9

SETTINGS
Camera setup section
Control name Position
aMirror image switch (MIR) OFF
bBacklight compensation switch (BLC) OFF
cElectronic iris (EI) OFF
dAuto-iris lens switch (A I LENS) (see page 6) DC
eLens iris level volume (LEVEL) about centre
Electronic iris function setting
Use a manual or fixed iris lens and set the lens
aperture to the shortest F stop. Set the EI
switch to ON position.
Note:
Please refer to the specifications for dynamic
range of the electronic iris.
CAUTION:
•The electronic iris is suitable for normal indoor use. When the EI
switch is set to the ON position, do not use an auto-iris lens.
•If used under fluorescent light, the image may flicker. In such a
case, change to incandescent lighting or set the EI switch to the
OFF position and use an auto-iris lens.
•When shooting bright subjects, pay attention to the light angle in
order to avoid or minimize the smear phenomenon effect.
When using an auto-iris lens (for indoor/outdoor use)
Set the EI switch to the OFF position.
CAUTION:
If conditions are outside the electronic iris operation range or more
than the maximum illumination, it will cause saturation of the CCD. In
that case, use a manual iris lens.
L
E
V
E
L
DC
VIDEO
A. I.
LENS
LH
VR401
e
d
c
EI
b
BLC
a
MIR
ON
OFF
EI
L73T4/US GB 1999, 8, 3
10 English

SETTINGS
Lens iris adjustment
If using a DC type auto-iris lens, you will need to set the LEVEL
VR401) volume when shooting in the conditions described below.
L (counterclockwise): To decrease the contrast
H (clockwise): To increase the contrast
•If shooting simultaneously in a dark room
and through a bright window.
•If the subject background is extremely
bright or dark.
•If the brightness of the picture on the
monitor is not correct.
Mirror image setting
If the MIR switch is set to the ON position, the image displayed on
the monitor will be reversed horizontally.
For example, this setting can be used if the camera is installed at the
back of a truck or bus and looking towards the back, the image will
be as seen in the mirrors.
Backlight compensation setting
Use an auto-iris lens and set the BLC switch to the ON position, to
engage the backlight compensation function.
If using a VIDEO type auto-iris lens
•The ALC volume on the lens should be turned all the way to Av
Average).
•If the backlight compensation function does not compensate
properly for the conditions, set using the LEVEL volume on the
lens.
L
E
V
E
L
LH
VR401
ON
OFF
MIR
ON
OFF
BLC
L73T4/US GB 1999, 8, 3
English 11

SETTINGS
Line phase adjustment
When using a camera switcher to connect 2 cameras or more to one
monitor, there may be a vertical roll of the images when switched. In
such a case, set as described below.
Switch the display on the monitor from camera 1 to camera 2.
Adjust the LINE PHASE volume on camera 2 until the vertical roll of
the image stops.
If more than two cameras are used, please repeat this procedure for
all the cameras.
CAUTION:
If the vertical roll cannot be corrected by setting the LINE PHASE
volume on camera 2, try setting the LINE PHASE volume on camera
1. If it still cannot be corrected, please check that the polarity of the
power cords of all connected devices is correct.
TROUBLESHOOTING
Before taking the camera for repairs, please check below to make
sure that the camera is used correctly. If it still does not perform
correctly, please consult your dealer or a Sanyo Authorized Service
Centre.
No picture on the monitor screen
•Is the power turned on to all connected devices? Is the voltage correct?
•Are all the signal connecting cables correctly connected?
•Is the lighting sufficient?
•Has the lens cap been removed?
•Is the lens type DC or VIDEO) correctly selected?
Depending on the type of lens, the A I LENS switch must be set
accordingly.
•Is the iris control correctly set?
A: When using a DC type lens, the LEVEL volume inside the
camera casing) should be adjusted.
B: When using a VIDEO type lens, the LEVEL volume on the
lens) should be adjusted.
The picture is not clear
•Is the monitor correctly adjusted?
•Is the flange-back position correctly set?
•Is the lens focus correctly adjusted?
•Are the lens surfaces clean?
If there is dust or finger prints on the lens, the image quality will
deteriorate. To clean the lens use a soft cloth or a commercially
available lens cleaning set.
L73T4/US GB 1999, 8, 3
12 English

SPECIFICATIONS
Scanning system : EIA standard 525 TV lines, 30
frames/sec.)
Interlace : PLL 2:1 interlace
Image device : 1/3 inch solid state image device CCD
Picture elements : 542 H) x 492 V)
Effective picture elements : 512 H) x 492 V)
Synchronizing system : Line lock
Resolution : 400 TV lines horizontally, 350 TV
lines vertically
Video output level : 1.0 Vp-p/75 ohms, composite
Video S/N ratio : More than 50 dB
Minimum required
illumination
(incandescent lighting)
:Approx. 0.07 lux with a F 1.2 lens,
approx. 0.1 lux with a F 1.4 lens
Backlight compensation : Manual ON/OFF switching, zone light
measuring system
Active when using an auto-iris lens)
Electronic iris function : Manual ON/OFF switching
Mirror image : Manual ON/OFF switching
Electronic iris range : 0.07 lux to 42,000 F 1.2, lens)
0.1 lux to 57,000 F 1.4, lens)
Flange-back : 12.5 mm ± 0.8 mm
Gamma correction : γ = 0.45
Lens mount : CS mount or C mount with the
supplied adaptor)
Environmental conditions : Temperature: –10˚C ~ +50˚C
Humidity: less than 90% no
condensation)
Power supply : 24 V AC, 60 Hz
Power consumption : 2.3 W with auto iris lens)
1.4 W without auto iris lens)
Weight : Approx. 330 g without lens)
Dimensions
Features and specifications are subject to change without prior
notice or obligations
SERVICE
This camera is a precision instruments and if treated with care, will
provide years of satisfactory performance. However, in the event of a
problem, the owner is advised not to attempt to make repairs or open
the cabinet. Servicing should always be referred to your dealer or
Sanyo Authorized Service Centre.
VIDEO OUT POWER
LINE
PHASE
12
22
11
1.5
108.5
99.5
1/4”–20 UNC
56
45
28
L73T4/US GB 1999, 8, 3
English 13
