Scanning System NTSC Standard: 525 lines, 30 Frames/Sec.
Image Sensor 1/3” (Approx. 4.8mm x 3.6mm) interline transfer method
Effective Picture Elements 768 (H) x 494 (V)
Resolution Horizontal: 520TV lines, Vertical: 350TV lines
Minimum illumination 0.5 lux (GAIN HI) / 1.0 lux (GAIN NORM) @f1.2
Video output level 1.0 Vp-p @ 75 ohms, composite
Video S/N ratio More than 50db (AGC off)
Backlight Compensation ON / OFF – Slide SW (side)
ON = Multi-spot photometry system (64-section) / Center-zone
photometry system; Slide SW (side) (activated when auto iris lens used)
White Balance Auto / Manual – Slide SW (side)
Gain Control Normal / High – Slide SW (side)
Light Control Auto iris / Electronic iris
Lens Mount CS Mount
Flange Back 12.5mm ± 0.5mm adjustment
Auto Iris Lens DC type
Auto Iris Output DC: Drive coil (+,–), Brake (damp) coil (+,–)
Electronic Iris ON (EI) / OFF (AI) – Slide SW (side)
Electronic Iris Range 1.0 lux to 50,000 lux (with f1.2 lens)
Synchronizing System Internal sync / Line lock – Slide SW (side)
V Phase Adjustment LINE PHASE – VR (rear)
Sockets Video Signal VIDEO OUT BNC. (Rear)
Auto Iris Lens LENS 4-pin (Side)
Power Supply 24V AC, GND 3-pin terminal (Rear)
12 to 15V DC 2-pin terminal (Rear)
Environmental Conditions Operating: Temperature: -10˚C to +50˚C / +14˚F to 122˚F
Humidity: Within 90% RH
Storage: Temperature: -20˚C to +70˚C / -4˚F to 158˚F
Humidity: Within 70% RH
Power Requirement 24V AC, 60Hz / 12 to 15 V DC
Power Consumption (approx.) 3.6 W
Camera Mount 1/4" – 20 UNC (top / bottom selectable)
Dimensions (W x H x D) 2.21(w) x 1.77(h) x 3.9(d) inches (56 x 45 x 99mm) (excluding protrusions)
Weight 9.88 oz. (280g) (w/o Lens)
1/3” COLOR CCD DSP
SUPER HIGH-RESOLUTION
CAMERA
Specifications
VCC-6584
(1.0)
Dimensions
