Sanyo POA-HDTM01 User manual

HD DATA WIRELESS Transmitter Box
Model POA-HDTM01
Owner’s Manual

2
This transmitter POA-HDTM01 can be used on the specified projector with the receiver
board POA-MD26HDWL installed.
The image from the peripheral equipment is transferred to each projector via wireless
network. There is no need for wire connection between the transmitter and the projector.
You can select one of 2 installation modes as follows.
Single Mode
This mode is available only between one transmitter and one receiver.
Broadcast Mode
This mode is available between one transmitter and 2 or more receivers. It is useful to
project the same images to multiple screens.
ID = B
ID = B
Single Mode
Single Mode
ID = A
ID = A
Single Mode
Single Mode
ID = A
ID = A ID = A
ID = A Broadcast Mode
Broadcast Mode
✐When selecting "INPUT 3 HDMI", only Single Mode is available. "INPUT 3 HDMI" cannot be selected in
the Broadcast Mode.
✐The projector in this manual is PLC-XF47 for example.
Features and Design

English
3
HD DATA WIRELESS TRANSMITTER BOX
OWNER'S MANUAL
Table of Contents
FeaturesandDesign........................................................2
TableofContents...........................................................3
TotheOwner...............................................................4
SafetyInstructions..........................................................5
Compliance.................................................................8
Preparation................................................................11
Before use 11
Part Names and Functions 12
Installation ................................................................14
Connection to external equipment 14
Connecting the AC Power Cord 15
Installing the Receiver into the Projector 16
BasicSettingandOperation................................................17
Projector Operation 17
Turning on the Transmitter 18
Turning off the transmitter 18
Input Source Selection 19
How to Operate the Menu 19
Menu Tree 20
Flow of Installation Mode 21
SingleModeOperation ....................................................22
6/6: Mode Select & 1/6: Single Mode Setup 22
BroadcastModeOperation.................................................26
6/6: Mode Select & 4/6: ID Number 26
OtherBasicOperation......................................................30
5/6: Key Lock 30
2/6: Image Adjust 32
3/6: Information 32
Reset Function of the projector 33
MaintenanceandCare.....................................................34
Appendix..................................................................35
Troubleshooting 35
Specifications 36
Compatible Signals Specifications 38
Configurations of Terminals 39

4
To the Owner
Before operating this transmitter, read
this manual thoroughly and operate the
transmitter properly.
Operating the transmitter properly
enables you to manage those features
and maintains it in better condition for a
considerable time.
Improper operation may result in not
only shortening the product-life, but
also malfunctions, fire hazard, or other
accidents.
If your transmitter seems to operate
improperly, read this manual again, check
operations and cable connections and
try the solutions in the "Troubleshooting"
section in the end of this manual. If the
problem still persists, contact the dealer
where you purchased the transmitter or the
service center.
CAUTION
RISK OF ELECTRONIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE CONSTITUTING
A RISK OF ELECTRIC SHOCK IS
PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
Safety Precaution
WARNING: TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR
MOISTURE.
– If the transmitter is unused for an
extended time, unplug the transmitter
from the AC power outlet.
READ AND KEEP THIS OWNER'S
MANUAL FOR LATER USE.
Important Notice
There are restrictions on the channels
and frequencies in the countries and
regions at which you can use the wireless
communication. So it is forbidden to take
the transmitter and the receiver outside
the country or region where you purchased
them.
NOTE:
This symbol and recycle
system are applied only
to EU countries and not
applied to the countries
in the other area of the
world.
Your SANYO product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed of separately from
your household waste.
Please dispose of this equipment at
your local community waste collection/
recycling centre.
In the European Union there are separate
collection systems for used electrical and
electronic products.
Please help us to conserve the
environment we live in!
SANYO FISHER Sales (Europe) GmbH
Stahlgruberring 4, D-81829 München,
Germany
SANYO Electric Co., Ltd.
1-1, Sanyo-cho, Daito City, Osaka
574-8534, Japan

English
5
HD DATA WIRELESS TRANSMITTER BOX
OWNER'S MANUAL
Safety Instructions
All the safety and operating instructions
should be read before the product is
operated.
Read all of the instructions given here
and retain them for later use. Unplug this
transmitter from AC power supply before
cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
Follow all warnings and instructions marked
on the transmitter.
For added protection to the transmitter
during a lightning storm, or when it is left
unattended and unused for long periods
of time, unplug it from the wall outlet. This
will prevent damage due to lightning and
power line surges.
Do not expose this unit to rain or use near
water... for example, in a wet basement,
near a swimming pool, etc...
Do not use attachments not recommended
by the manufacturer as they may cause
hazards.
Do not place this transmitter on an unstable
cart, stand, or table. The transmitter may
fall, causing serious injury to a child or adult,
and serious damage to the transmitter. Use
only with a cart or stand recommended
by the manufacturer, or sold with the
transmitter. Wall or shelf mounting should
follow the manufacturer's instructions, and
should use a mounting kit approved by the
manufacturers.
An appliance and cart
combination should be
moved with care. Quick
stops, excessive force, and
uneven surfaces may cause
the appliance and cart
combination to overturn.
Slots and openings in the back and
bottom of the cabinet are provided for
ventilation, to ensure reliable operation
of the equipment and to protect it from
overheating.
The openings should never be covered with
cloth or other materials, and the bottom
opening should not be blocked by placing
the transmitter on a bed, sofa, rug, or other
similar surface. This transmitter should
never be placed near or over a radiator or
heat register.
This transmitter should not be placed in
a built-in installation such as a book case
unless proper ventilation is provided.
Never push objects of any kind into this
transmitter through cabinet slots as they
may touch dangerous voltage points or
short out parts that could result in a fire or
electric shock. Never spill liquid of any kind
on the transmitter.
Do not install the transmitter near the
ventilation duct of air-conditioning
equipment.
This transmitter should be operated only
from the type of power source indicated
on the marking label. If you are not sure of
the type of power supplied, consult your
authorized dealer or local power company.
Do not overload wall outlets and extension
cords as this can result in fire or electric
shock. Do not allow anything to rest on the
power cord. Do not locate this transmitter
where the cord may be damaged by
persons walking on it.
Do not attempt to service this transmitter
yourself as opening or removing covers may
expose you to dangerous voltage or other
hazards. Refer all servicing to qualified
service personnel.
