Sanyo CA21XS2S User manual

Instruction Manual
Colour Television
Flat Screen
Multi System
CATV Hyper Band
256 Programmes with Automatic Tuning
AV Stereo Sound System
DVD Input with Video Component
CA21XS2S
CP21XS2S
CA21YS2S
CP21YS2S
CA21YS22
CP21YS22
CA21YS22B
CP21YS22B
CA21YS2BS
CP21YS2BS
CA21KS2
CP21KS2
CA21KS2K
CP21KS2K
CA21KS22
CP21KS22
CA21KS22K
CP21KS2K(S)
CA21SF1
CP21SF1
CA21VF1S
CP21VF1S
CA21MS22
CP21MS22
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 1

2
IMPORTANT INFORMATION
If a television is not positioned in a sufficiently stable location, it can be
potentially hazardous due to falling. Many injuries, particularly to children,
can be avoided by taking simple precautions such as:
●Using cabinets or stands recommended by the manufacturer of the
television.
●Only using furniture that can safely support the television.
●Ensuring the television is not overhanging the edge of the supporting
furniture.
●Not placing the television on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television to
a suitable support.
●Not standing the televisions on cloth or other materials placed between
the television and supporting furniture.
●Educating children about the dangers of climbing on furniture to reach the
television or its controls.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 2

3
WarningandCaution
If the televi-
sion is to be
built into a
compartment
or similarly
enclosed, the
minimum dis-
tances must
be maintained.
Heat build-up can reduce the service life of your televi-
sion, and can also be dangerous.
Never stand on, lean on or push sud-
denly the television or its stand.
You should pay special attention to
children. Serious injury may result if
it should fall.
Do not place your television on an
unstable cart, stand, shelf or table.
Serious injury to an individual, and
damage to the television, may result
if it should fall.
High voltages are used in the operation of this television receiver. Do not
remove the cabinet back from your set. Refer servicing to qualified service
personnel.
To prevent fire or electrical shock hazard, do not expose the television
receiver to rain or moisture. The television shall not be exposed to dripping
or splashing and that no objects filled with liquids, such as vases, shall be
placed on the television.
Do not drop or push objects into the television cabinet slots or openings.
Never spill any kind of liquid on the television receiver.
At installation of the unit, the plug
of power cord shall remain
accessible and readily operable
to disconnect the unit from the
wall outlet.
When the television receiver is
not used for an extended period
of time, it is advisable to discon-
nect the AC power cord from the
AC outlet.
Avoid exposing the television
receiver to direct sunlight and
other source of the heat.
Do not stand the television
receiver directly on other prod-
ucts which give off heat. E.g.
video cassette players, audio
amplifiers.
Do not block the ventilation holes in
the back cover.
Adequate ventilation is essential to
prevent failure of electrical compo-
nents.
Do not squash power supply
cord under the television
receiver.
5cm
10cm
10cm
20cm
Minimum distances
Warning
Caution
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 3

4
Contents
Important Information . . . . . . . . . . . . . . . 2
Warnings and Cautions . . . . . . . . . . . . . . 3
Contents . . . . . . . . . . . . . . . . . . . . . . . . . 4
Plug & Play . . . . . . . . . . . . . . . . . . . . . . . 4
Front Control . . . . . . . . . . . . . . . . . . . . . 5-6
Remote Control Transmitter . . . . . . . . . . 7
Battery Installation of
the Remote Control Transmitter . . . . . . . 7
General Operation
Remote Control Operation . . . . . . . . . 8
OFF TIMER . . . . . . . . . . . . . . . . . . . . 9
ON TIMER . . . . . . . . . . . . . . . . . . . . . 9
Colour and Sound System
Setting of the Colour System . . . . . . . 9
Setting of the Sound system . . . . . . . . 9-10
Picture Adjustment . . . . . . . . . . . . . . . . . 10-11
Audio Adjustment . . . . . . . . . . . . . . . . . . 11
Tuning of the Channels
Automatic Tuning . . . . . . . . . . . . . . . 12
Semi-Auto Tuning and Manual Tuning
. .12
Channel Copy . . . . . . . . . . . . . . . . . . 13
Channel Swapping . . . . . . . . . . . . . . 13
Skip Channel Set and Cancel . . . . . . . . . . .13-14
Setting of the Private Position . . . . . . . . 14
Setting of the OSD Language . . . . . . . . . 15
Connecting Other Equipment . . . . . . . . . 15
Connecting to the Rear AV1 Input
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . .15-16
Selecting the Colour System in AV
Mode . . . . . . . . . . . . . . . . . . . . . . . .16
Connecting to a DVD Player with AV1(DVD)
Video Component output terminal . . .16
Connection to the Front AV2 Input
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting to the Monitor Output
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
AV Connection to the Aerial Socket . . . . 17
Aerial Connection . . . . . . . . . . . . . . . . . . 18
Care and Cleaning . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . 19
Helpful
Hints-Problems/Solutions . . . . . . . . . . . 20
Plug&Play
I AM SEARCHING.
AUTO SET-UP
COMPLETED.
HAPPY VIEWING !
1
ALL PROGRAMMES.
PLEASE WAIT.
This TV set provides a self-automatic tuning and
sorting system function called “Plug & Play”. It
automatically begins searching and storing of all
available channels when switching-on the TV set
for the first time.
2Press any of the control buttons to make the
ending message disappear. Or will
automatically return to normal TV display
after 10 seconds.
After completing this procedure, the programme
position 1 is selected and the ending messages on
the screen.
Note: The Plug & Play can be cancelled at any
time by pressing the MENU button.
✐ This procedure only appears at the first
switch-on time.
1Connect power cord of the TV set to a wall
outlet, and turn on the TV set by pressing the
Mains ON/OFF button. Self-automatic tuning
system will be started as follows;
NO STATION.
PLEASE CONNECT
ANTENNA PLUG.
■ If no TV stations are found, the display shown
below will appear. Please check if the antenna
is connected properly.
If it isn’t connected properly, connect antenna and
Automatic Tuning will be reset.
❒Automaticsettingupchannels
❒Let’sStart!
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 4

5
Model CA21XS2S, CP21XS2S
FrontControl
Each button listed in this section has the same function as it’s corresponding
button on the remote control.
Model CA21YS2S, CP21YS2S, CA21YS2BS, CP21YS2BS, CA21YS22, CP21YS22,
CA21YS22B, CP21YS22B
123
6789
VIDEO
TV/AV MENU - + CH
L-AUDIO-R
4510
VIDEO
AV2 IN
TV/AV MENU - + CH
L-AUDIO-R
Press to open
Press to open
123
67 45
8910
1. Mains ON/OFF Button
2. Remote Control Detector
3. Stand-by and Power Indicator
4. Programme UP/DOWN
5. VOLUME
6. MENU
7. TV/AV Selector
8. Audio Input Jack-Right (AV2)
9. Audio Input Jack-Left (AV2)
10. Video Input Jack (AV2)
MENU
TV/AV
POWER
CH
- +
Model CA21SF1, CP21SF1
123
4
5
67
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 5

6
Model CA21KS2, CP21KS2, CA21KS2K, CP21KS2K, CA21KS22, CP21KS22,
CA21KS22K, CP21KS2K(S)
FrontControl
Each button listed in this section has the same function as it’s corresponding
button on the remote control.
Model CA21VF1S, CP21VF1S
MENU
TV/AV
POWER
CH
- +
L - AUDIO - R
VIDEO
123
4
5
67
8910
1. Mains ON/OFF Button
2. Remote Control Detector
3. Stand-by and Power Indicator
4. Programme UP/DOWN
5. VOLUME
6. MENU
7. TV/AV Selector
8. Audio Input Jack-Right (AV2)
9. Audio Input Jack-Left (AV2)
10. Video Input Jack (AV2)
Pull to open
MENU
TV/AV
POWER
CH
- +
L-AUDIO-R
VIDEO
1
2
3
4
5
67
8
910
Model CA21MS22, CP21MS22
1
23
6789
VIDEO TV/AV MENU - + CH L-AUDIO-R
4510
Press to open
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 6

7
RemoteControlTransmitter
-/- -
-/- -
PP
BASS SOUND S. SYS
SURROUND
A•B
SWAP CH SCAN
TIMER
JXPSG
TV / AV
MENU
CH
CH
Power ON/OFF button
ALTERNATE button
VOLUME + button
TIMER button
MUTE button
CHANNEL SCAN button
SURROUND button
PICTURE MODE button
Programme UP button
RECALL/COLOUR SYSTEM button
MENU button
TV / AV Selector button
Programme Selector button
SWAP button
VOLUME - button
STEREO/MONO button
Programme DOWN button
BASS EXPANDER button
SOUND MODE button SOUND SYSTEM button
DIGIT button
❒BatteryInstallationoftheRemoteControlTransmitter
1. Open the battery cover.
2. Install two “AA” 1.5 volt batteries so that the “+” and “-” marks on the batteries match the “+” and
“ - ” marks inside the unit.
3. Close the battery cover.
Note: Replace the batteries when the TV set is showing the following symptoms:
Operation is unsteady or erratic, sometimes the TV set does not work with transmitter.
Discharged batteries may leak and damage the unit. The normal life of batteries should be from
nine to ten months.
Do not expose batteries (battery pack or batteries installed) to excessive heat such as sunshine,
fire or the like.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 7

8
GeneralOperation
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
Standby/Power-on
To switch the TV on and off. For shutting off a power supply completely, Press the Mains
ON/OFF button on the front control of TV set.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
Soundmute
To switch the sound from the speakers. The sound changes as follows; normal→mute ().
-/- -
-/- - -/- - -/- -
-/- -
-/- -
TIMER
-/- -
Timer
To Adjust Timer function OFF-TIMER→ONTIMER→ONPROGRAM
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
Recall/Coloursystemselector
To display the programme information on the screen.
It also operates as Colour system selector if the clear picture cannot be obtained even when
the broadcasting or AV signal is received.
Colour System and Sound System (SIF) could be changed in SEMI-AUTO and MANUAL TUN-
ING operation.
-/- -
-/- - -/- - -/- -
-/- -
-/- --/- -
-/- -
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
Directprogrammeselector
For direct access to programmes using the (0-9)numericbutton. For selection of analogue
programme position 10 - 255, Example: for programme position 17, Press the Digit button,
press “1”button. Press “7”button. For programme position 125 Press the Digit button twice. Press “2”button.
Press “5”button. For programme position 225 Press the Digit button 3 times. Press “2” button. Press
“5”button.
-/- -
-/- - -/- - -/- -
-/- -
-/- - PP
-/- -
Alternate
To select the previous position and the present position.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
VolumeUp/Down
To adjust the sound volume level . Also operates as left ( ) and right ( ) cursor.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
CH
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
CH Programmedown/up
To select the next programme number or previous programme number. Also operates as up
()and down ( ) cursor.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
SWAP
Swap
To swap the channels between two stored programme positions
-/- -
-/- - -/- - -/- -
-/- -
-/- -
SOUND
-/- -
SoundMode
To select Sound mode; PERSONAL, MUSIC, TALK, NORMAL.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
PictureMode
To select Picture mode; PERSONAL, DYNAMIC, NATURAL, ECO, GAME.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
BASS
-/- -
BassExpander
To activate bass expander function.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
S. SYS
-/- -
SoundSystem
To select optimum sound system (BG →I →DK →M).
-/- -
-/- - -/- - -/- -
-/- -
-/- -
SURROUND
-/- -
Surround
To activate Surround function.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
MENU
-/- -
Menu
To Call up the TV MENU.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
A•B
Stereo/Mono Button
❒RemoteControlOperation
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 8

9
GeneralOperation
■
■If no operation is performed after the TV has
been switched on by the ON TIMER, such as if
you are not at home, the TV will be
automatically switched off after approximately
2 hours
■
■If the TV is already switched on when the time
set for the ON TIMER has been reached, only
the programme position will be changed to the
set programme position.
■
■Cancelling ON TIMER. To cancel the ON
TIMER, press the VOLUME (+or -) button to
set it to “ON 0:00” while the ON TIMER screen is
shown. Switching off the TV by pressing the
Mains ON/OFF button will also cancel the ON
TIMER settings.
The OFF TIMER will switch off the TV automatical-
ly after 30 minutes, 1 hour, 1 hour and 30 minutes,
or 2 hours.
■Just one minute before switching off the TV,
“OFF 0:01” will be display on the screen.
■To cancel the OFF TIMER, select “OFF 0:00”
by pressing the VOLUME (+ or - ) button.
■The OFF TIMER cancels when the TV set is
turned off or if a power failure occurs.
When the ON TIMER is set. TV will automatically
be switched On to the selected programme position
when the specified time has elapsed.
Programme position for when TV is
switched ON by ON TIMER.
❒OffTimer
1Press the TIMER button. OFF 0:00
2Press the VOLUME (+or -) button to select
the time period.
❒OnTimer
1Press the TIMER button twice.
ON 0:00 2 (ON TIMER setting mode)
2Press the VOLUME ( + or -) button. The set
time will be increased or decreased by 10
minutes each time the button is pressed ; the
maximum time which can be set is 24 hours.
3Use Direct Programme Selection to insert
programme position for when TV is switched
on by ON TIMER. (see page 7.)
❒OnTimer(Continued)
Normally, set the colour system to “AUTO”, if the
clear picture cannot be obtained even when the
broadcasting or AV signal is received, press the
RECALL/COLOUR SYSTEM button repeatedly
until the optimum image can be produced.
(Refer to Broadcast Transmission System List
indicated by the last of this page in a setup of
Colour System.)
Each time the RECALL/COLOUR SYSTEM but-
ton is pressed, colour system changes as follows;
To set the sound system, make it during Semi-Auto
Tuning or Manual Tuning mode.
When the sound is not clear or no sound is pro-
duced on a programme number position, select
sound system repeatedly until the optimum sound
is obtained.
(Refer to Broadcast Transmission System List
indicated by the last of this page in a setup of
Sound System.)
To select sound system:
■Press the SOUND SYSTEM button to select the
sound system directly. The sound system will be
memorized automatically.
Note:Colour system is displayed according as
Colour system option.
6
AUTO
6
PAL
6
NTSC
6
NTSC4.43
ColourandSoundSystem
❒SettingoftheColourSystem ❒SettingoftheSoundSystem
or:
1) Select “SIF” with the Programme UP or
DOWN button in the Semi-auto or Manual
Tuning mode. Then press the VOLUME (+ or
- ) button to select a optimum sound system.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 9

10
ColourandSoundSystem
❒SettingoftheSoundSystem
BG
(5.5MHz)
DK
(6.5MHz)
I
(6.0MHz)
M
(4.5MHz)
2) To enter a sound system selection into the
memory, select “MEMORY” and press the
VOLUME + or - button.
(Semi-Auto or Manual Tuning mode )
SEARCH
SYSTEM
MODE
POSITION
SEMI
START
2
AUTO
SKIP
MEMORY
OFF
--
SIF BG
SELECT ADJUST BACK
EXIT
SEARCH
SYSTEM
MODE
POSITION
SEMI
START
2
AUTO
SKIP OFF
SIF BG
MEMORY OK
SELECT ADJUST BACK
EXIT
Broadcast Transmission System List
Area Country
Sound
System
Colour
System
Middle
East
Asia
Oceania
PAL B/G
Australia,
New Zealand, etc.
Union of Arab Emirates,
Kuwait, Oman, Qatar,
Yemen, Bahrain, etc.
Indonesia, Malaysia,
Singapore, Thailand, etc.
PAL B/G
China, etc.
PAL D/K
Hong kong
PAL I
Saudi Arabia,
Iraq, Iran, Lebanon,etc.
B/G
SECAM
Russian Federation,etc.
D/K
SECAM
Myanmar, etc.
M
NTSC
PictureAdjustment
The 2nd page is not displayed when there is no
TINT adjustment.
BRIGHTNESS
TINT
CONTRAST
SHARPNESS
40
COLOUR
SELECT ADJUST BACK
EXIT
Page 1 Page 2
FINE TUNING
WHITE TONE
SELECT ADJUST BACK
EXIT
❒PictureAdjustmentMenu
SHARPNESS : Adjusts picture detail.
WHITE TONE : Adjusts white balance.
FINE TUNING : Fine tuning in case of weak
broadcast signal or poor reception. Only
displayed in TV mode. Will not be displayed in
AV mode.
Picture Adjustment Item
COLOUR :Adjusts colour intensity.
BRIGHT : Adjusts picture brightness.
CONTRAST : Adjusts picture contrast.
TINT : Adjust colour tints. (Displayed only on
NTSC or NTSC4.43 system signal
reception.)
(MAIN MENU)
AUDIO
LANGUAGE
PRESET
SELECT ENTER
EXIT
❒BasicPictureAdjustmentOperation
1Press the MENU button for MAIN menu
display.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 10

11
PictureAdjustment
❒BasicPictureAdjustmentOperation(Continued)
■To return to the normal TV mode, press the
MENU button. ( Or will automatically return to
the normal TV mode after 20 seconds.)
AUDIO
LANGUAGE
PRESET
BRIGHTNESS
SHARPNESS
CONTRAST
WHITE TONE
FINE TUNING
25
COLOUR
SHARPNESS
CONTRAST
WHITE TONE
FINE TUNING
30
COLOUR
BRIGHTNESS
2When “PICTURE” is not selected, select
“PICTURE” with the Programme UP or
DOWN button.
3Press the VOLUME + or
- button to display
Picture Adjustment menu.
4Select desired control by pressing the
Programme UP or DOWN button
5Press the VOLUME + or
- button to alter
settings.
■To return to Main menu, press the
ALTERNATE button.
Audio Adjustment Item
BASS : Bass Adjustment
TREBLE :Treble Adjustment
BALANCE : Left/right speaker volume balance
adjustment
BASS EXPANDER :Operates BASS EXPANDER
on and off
SURROUND :Operates SURROUND on and off.
Note: When the stereo signal is inputted from the
right and left audio input terminals in the AV mode,
surround mode is changed as follows;
“SURROUND” ON and “SURROUND OFF”.
■
■To return to Main menu, press the ALTERNATE
button.
■
■To return to normal TV mode, press the MENU
button. (Or will automatically return to normal
TV mode after 20 seconds.)
TREBLE
BASS EXPANDER
BALANCE
SURROUND
OFF
OFF
27
BASS
SELECT ADJUST BACK
EXIT
LANGUAGE
PRESET
AUDIO
TREBLE
BASS EXPANDER
BALANCE
SURROUND
OFF
OFF
27
BASS
AudioAdjustment
❒AudioAdjustmentMenu ❒AudioAdjustmentOperation
1Press the MENU button for MAIN menu
diplay.
2Select “AUDIO “ by pressing the Programme
UP or DOWN button.
3Press the VOLUME + or
- button for Audio
Adjustment menu display.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 11

12
TuningoftheChannels
Up to 256 broadcast stations in your reception
area can be stored in the electronic memory.
There are three ways of tuning as follows;
1. Automatic Tuning (the basic way):
All receivable channels are automatically tuned
in and memorized in consecutive programme
position.
2. Semi-Auto Tuning:
Use to preset a receivable channel in any
desired programme position, e.g. the position
with the same number as the channel.
3. Manual Tuning:
Manually tune a channel if it cannot be
automatically tuned, such as when the signal is
poor.
■
■The Automatic Tuning operation can be
cancelled at any time by pressing the
Programme UP or DOWN button.
After all receivable channels have been found and
stored, the TV set automatically returns to pro-
gramme position “1”.
-/- -
-/- - -/- - -/- -
-/- -
-/- -
-/- -
MENU
CH
CH
1
AUDIO
LANGUAGE
PRESET
SYSTEM
POSITION 1
AUTO
SIF BG
MODE AUTO
SEARCH START
SEARCH
SYSTEM
POSITION
START
1
AUTO
SIF BG
MODE AUTO
❒AutomaticTuning
1Press the MENU button for MAIN menu
display.
2Select “PRESET” by pressing the Programme UP or DOWN button.
3Press the VOLUME + or
- button for
PRESET menu display. On entering PRESET
display, Automatic Tuning will be selected
initially.
4Select “SEARCH” by pressing the
Programme UP or DOWN button.
5Press the VOLUME (+) button to start channel tuning.
The VOLUME + button will move tuning toward the
higher frequencies, and the VOLUME - button will
move tuning toward the lower frequencies.
Semi-Auto Tuning:
Press and release the VOLUME + or - button
to search for required TV station. Once a station
is located, tuning will automatically stop.
Continue till desired channel is located.
Manual Tuning :
Press and hold the VOLUME + or - button to
search for required TV station.
To pr e set other Programme Positions, repeat steps
5
- 7.
SYSTEM
POSITION 6
AUTO
MODE SEMI
SEARCH START
SYSTEM
POSITION 6
AUTO
MODE SEMI
SEARCH
SYSTEM
POSITION 6
AUTO
MODE MANUAL
SEARCH
SKIP OFF
MEMORY OK
SELECT ADJUST BACK
EXIT
❒Semi-AutoTuningandManualTuning
1Press the MENU button for MAIN menu
display.
2Select “PRESET” by pressing the
Programme UP or DOWN button.
3Press the VOLUME + or
- button for
PRESET menu display. On entering
PRESET display, Automatic Tuning will be
selected initially.
4Select “SEMI” or “MANUAL” by pressing the
VOLUME + or
- button.
5Select “SEARCH” by pressing the
Programme UP or DOWN button.
6Once desired channel is located, select
“MEMORY” by pressing the Programme UP
or DOWN button.
7Press the VOLUME + or
- button to enter the
desired channel into memory.
8Press the MENU button to return to normal
TV display.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 12

13
This function can be utilized after Automatic
Tuning.
For example, to copy a TV channel on pro-
gramme position “2” onto programme position
“6”;
2
Use this channel swapping feature to swap the
channels between two stored programme position.
This feature is particularly useful after automatic
tuning.
For example, to swap the channel between pro-
gramme position “6” and programme position
“12”.
612
SEARCH
SYSTEM
MODE SEMI
START
AUTO
SIF BG
POSITION 6
❒ChannelCopy
1Select programme position “2”
2Enter to SEMI-AUTO or MANUAL tuning
mode. (Refer to page 12.)
3Select “POSITION” with the Programme UP
or DOWN button.
4Select position “6” with the VOLUME + or
-
button.
5Select “MEMORY” by pressing the
Programme UP or DOWN button.
6Press the VOLUME + or
- button to
memorize.
7Press the MENU button to return to normal
TV display.
❒ChannelSwapping
1Select programme position “6”.
6
2Press the SWAP button.
SWAP 6 AND -
The two TV channels will now have changed
places.
6
12
SWAP 6 AND 12
6
SWAPPING
3Press the DIGIT button, “ 1“ button and then
“ 2” button on the remote control to enter
programme number 12. (For example, to
enter programme number “ 3 “, press “ 3”
button only. )
When there is a position you do not use, Position 4
for example, by setting the SKIP Channel function it
is possible to jump over this position, when you are
selecting a channel using the Programme
UP/DOWN or CHANNEL SCAN button.
345
Skip
For example, to set programme position “4” as
Skip channel ;
SEARCH
SYSTEM
MODE SEMI
START
AUTO
SKIP
MEMORY
OFF
--
SIF BG
POSITION 4
❒SkipChannelSetandcancel
1Enter to SEMI-AUTO or MANUAL tuning
mode. (Refer to page 12.)
2Select “POSITION” with the Programme UP
or DOWN button.
3Press remote control “4” button to select
programme position 4. Use the DIGIT button
and Programme Selector (Number buttons)
to enter programme number. Do not use the
VOLUME + or
- button to enter programme
position in this settings.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 13

14
Any number of channels maybe set as Skip
Channels.
SEARCH
SYSTEM
MODE SEMI
START
AUTO
MEMORY
--
SIF BG
POSITION 4
SKIP ON
SELECT ADJUST BACK
EXIT
SEARCH
SYSTEM
MODE
POSITION
SEMI
START
4
AUTO
SKIP ON
SIF BG
MEMORY OK
4Select “SKIP” by pressing the Programme UP
or DOWN button,then press the VOLUME +
or - button to set SKIP to ON. To cancel Skip
Channel function, set to OFF.
❒SkipChannelSetandcancel(Continued)
5Select “MEMORY” by pressing the
Programme UP or DOWN button, then press
the VOLUME + or - button for memory.
6Press the MENU button to return to normal
TV display.
SettingofthePrivatePosistion
For example, to set the programme position
“15” as the private position.
The programme number “15” will shift to centre of
the screen.
The picture will disappear, and “ 15” will be dis-
play on the screen.
The private position setting is now completed.
Private position is used to restrict of pro-
gramme positions that you do not want others
to watch. Any position can be set as the Private
position.
15
15
15
AUTO
BG
BG AUTO
15
❒HowToSetthePrivatePosition
1Select programme position “15”.
2Press and hold the RECALL/COLOUR
SYSTEM button for more than 2 seconds
3Press the MENU button.
15
Note: The position “15” is still in the private position.
15
AUTO
BG
The private position is now cancelled.
15
❒ToViewaProgrammeonPrivatePosition
1Select private position (In this case position “15”).
2Press and hold the RECALL/COLOUR
SYSTEM button for more than 2 seconds.
3Press the RECALL/COLOUR SYSTEM
button for watching a TV programme.
❒CancellingofthePrivatePosition
1Select private position (position “15”).
2Press and hold the RECALL/COLOUR
SYSTEM button for more than 2 seconds.
3Press the MENU button.
15
15
AUTO
BG
15
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 14

15
SettingoftheOSDLanguage
AUDIO
LANGUAGE
PRESET
AUDIO
PRESET
LANGUAGE
1Press the MENU button for MAIN menu
display.
2Select “LANGUAGE “ by pressing the
programme UP or DOWN button.
3Press the VOLUME + or
- button for
Language menu display. 4Press the MENU button to return to normal
TV display.
ConnectingOtherEquipment
❒ConnectingTotheRearAV1InputJacks
■ When a monophonic video recorder is
connected to this product, connect the audio
output terminal of the video recorder to the L(left)
audio input terminal of the TV set.
Connecting to a Monophonic Video Recorder (AV1)
■When the audio signal from the VCR is stereo,
be sure to connect the right and left channels to
the respective right and left AUDIO IN terminals.
Then select “STEREO” channel of the audio
channel in the TV set with the remote control
button.Each time the button is
pressed, the AV Stereo mode is changed as follow,
A B
A B
Note: The effect of surround is not obtained
although the switching of surround is displayed
in this monaural connection.
■When the stereo signal is inputted from the right
and left audio input terminals, each time the
SURROUND button is pressed (or selection of
On-screen Menu), surround mode is changed
as follows; “ SURROUND ON” and
“SURROUND OFF”.
■
■To watch
video input
picture,
select AV1
position by
pressing
the TV/AV
Selector.
AV1
Y
MONITOR OUT
AV1/DVD
C R
C B
R
L
(MONO)
VIDEO
R
L
INPUT
V
D
E
O
I
To Audio Input-R (AV1)
To Audio Input-L (AV1)
To Video Input (AV1)
Video/DVD Player
■ To make sure the colour system of the TV set
is consistent with the signal of your video
recorder, if necessary, select a matching
system.
STEREO MONO
You may connect the audio and video output terminals of the DVD player or VIDEO recorder to the input
terminals of the TV set to enjoy the DVD and VIDEO programs.
SURROUND OFF
SURROUND ON
Select“ENGLISH”, “ ”,
“VIETNAMESE”, “ ”, “FRANÇAIS”,
“BAHASA INDONESIA” by pressing the
Programme UP or DOWN button. To return to the
normal TV mode, press the MENU button.
P
C
NN
y
C
FRANCAIS
VIETNAMESE
BAHASA INDONESIA
ENGLISH
PCC
y
NN
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 15

16
■
■When watching a video program input from the AV1 terminal, press the TV/AV button to select AV1.
Whenever the TV/AV button is pressed, the mode will change as follows:
■
■You can select a TV programme while watching a playback from a VCR
For example:
● To select programme position “9” while watching a playback from external VCR, press “9” button of the
remote control. The TV set returns to the TV mode and programme “9” will be selected.
● To select the programme position “26”, press Digit (--/-) button, “2” then “6” button. Then TV set returns
to the TV mode and programme position “26” will be selected.
Note: Pressing either of the PROGRAMME UP or DOWN buttons of the remote control or the TV will
return the TV to the TV mode.
TV mode
AV1 AV1(DVD)
28 AV2
❒ConnectingTotheRearAV1InputJacks(Continued)
Each time the RECALL/COLOUR SYSTEM button is pressed, colour system is changed as follow;
Depending on the type of video tape or connected AV equipment being used, it may be necessary to
select colour system. In this case, press the RECALL/COLOUR SYSTEM button and select a suitable
colour system.
Connect the component output terminal on
your DVD player to the component video input
terminal of this product. (NOTE: When a sig-
nal of Y,Cb,Cr/Y,Pb,Pr is received, the output
signal from monitor output terminal will be cor-
responding but without colour (black and
white image).)
■
■To watch a program in this connection
status, select AV1(DVD).
Y
MONITOR OUT
AV1/DVD
C R
C B
R
L
(MONO)
VIDEO
R
L
INPUT
V
D
E
O
I
Video/DVD Player
To Audio Input-R (AV1)
To Audio Input-L (AV1)
To Input Terminal CR
To Input Terminal CB
To Input Terminal Y
28 AV1 AV1(DVD)
(TV mode)
AV2
(Optional
model)
■
■Make sure the component video terminal (Y, Cbor Cr)
is connected correctly.
❒SelectingtheColourSysteminAVMode
❒ConnectingToaDVDPlayerwithAV1(DVD)VideoComponentInput
Terminal(Y,CborCr)
(Optional
model)
AV1
AUTO
AV1
PAL
AV1
NTSC
AV1
NTSC 4.43
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 16

17
Aerial Socket
The AV apparatus can also be connected to the aerial socket of your TV receiver.
Presetting to watch the video input
1. Playback the VCR .
2. Tune a VCR playback in programme position
that you want. (See Semi-Auto Tuning and
Manual Tuning on pages 12.)
For further details concerning this connection and adjustment, refer to the operating instructions
for the AV equipment.
VCR for
playback
PLAYBACK
■
■To record TV programme, select TV mode by
pressing the TV/AV Selector and record the
desired programme.
15
The picture signal being displayed on the TV screen is
output through the Monitor Output Jacks. Use these
terminals to record TV broadcasts and for video dub-
bing from AV1 or AV2 input terminals.
TV mode
To Audio Input-R (AV2)
To Audio Input-L (AV2)
To Video Input (AV2)
Video/DVD Player
Y
MONITOR OUT
AV1/DVD
C R
C B
R
L
(MONO)
VIDEO
R
L
INPUT
V
D
E
O
I
To Audio Output-R
To Audio Output-L
To Video Output
VCR for Recording
To video and
audio inputs
It is convenient to use the AV input jack on the front panel for equipment
that is often connected and disconnected.
AV2
■
■To watch the Front AV2 video
input picture, select AV2
position by pressing the TV/AV
Selector.
■To dub video from the AV1 terminal input, select
AV1 position and by pressing the TV/AV Selector.
AV1
❒ConnectingTotheFrontAV2InputJacks(OptionalModel)
❒ConnectingTotheMonitorOutputJacks
❒AVConnectionTotheAerialSocket
*Model CA21SF1, CP21SF1 are not equipped with Front AV2 input terminal.
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 17

18
The surface of the cabinet can be damaged if not properly maintained. Many common household aerosol
sprays, cleaning agents, solvents and polishes will cause permanent damage to the fine surface.
1. Unplug the power cord before cleaning the Television.
2. Clean the screen with a soft cloth dampened with glass cleaner or warm water.
3. Clean the cabinet with a soft cloth dampened with a mild household detergent and warm water. Dry
thoroughly.
Note: NEVER spray liquids on the screen because they can run down and drip onto the chassis. This
may cause component failure not covered under Warranty.
Connect the cable with a plug from a UHF (or VHF) aerial to the aerial socket on the cabinet back.
Aerial Cable
Aerial Socket
For all aerial circuit problems please consult your local dealer.
Outdoor Aerial
AerialConnection
❒ConnectingOutdoorAerial
CareandCleaning
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 18

19
Power Source AC 127-240 Volts, 50/60Hz
Colour System PAL/NTSC4.43/NTSC/PAL-60Hz
Sound System B/G, I, D/KK’, M/M
Channel Coverage
VHF: E2-E12, A2-A13, R1-R12, J1-J12, K1-K9
UHF: 21-69, A14-A69, J13-J62,
CATV: S1
- S41, X, Y, Z, Z+1, Z+2
Aerial input impedance 75 Ω
Audio output (RMS) Model: CA21YS2S, CP21YS2S, CA21KS2, CP21KS2, CA21SF1,
CP21SF1, CA21KS2K, CP21KS2K, CA21VF1S,
CP21VF1S, CA21YS2BS, CP21YS2BS, CA21YS22, CP21YS22,
CA21YS22B, CP21YS22B, CA21KS22, CP21KS22, CA21KS22K,
CP21KS2K(S), CA21MS22, CP21MS22: 5W + 5W
Model: CA21XS2S, CP21XS2S: 10W + 10W
Speakers Model: CA21YS2S, CP21YS2S, CA21KS2, CP21KS2, CA21SF1, CP21SF1,
CA21KS2K, CA21YS2BS, CP21YS2BS, CP21KS2K, CA21VF1S,
CP21VF1S, CA21YS22, CP21YS22, CA21YS22B, CP21YS22B, CA21KS22,
CP21KS22, CA21KS22K, CP21KS2K(S), CA21MS22, CP21MS22: 5 cmx 9 cm x 2 pcs
Model: CA21XS2S, CP21XS2S: 6 cm x 12 cm x 2 pcs
Ext. terminals
DVD Video Component: Composite/Component Y, CB,CR input
Video Inputs: Phone Jack x 2 (1.0Vp-p, impedance 75 Ω) *
Audio Inputs: Phone Jack (L/R) x 2 (436mVrms, impedance more than 40KΩ) *
Video monitor outputs: Phone Jack x 1 (1.0Vp-p, impedance 75 Ω)
Audio monitor outputs: Phone Jack (L/R) x 1 (436mVrms, impedance less than 600Ω)
*Model CA21SF1, CP21SF1 are not equipped with Front AV2 input terminal.
Dimension: Model CA21SF1, CP21SF1:
580(W) x 465(H) x 381(D) mm
Model CA21KS2, CP21KS2, CA21KS2K, CP21KS2K: 580(W) x 465(H) x 326(D) mm
Model CA21KS22, CP21KS22, CA21KS22K, CP21KS2K(S): 580(W) x 465(H) x 326(D) mm
Model CA21YS2S, CP21YS2S: 598(W) x 465(H) x 396(D) mm
Model CA21YS22, CP21YS22, CA21YS22B, CP21YS22B: 598(W) x 465(H) x 328(D) mm
Model CA21YS2BS, CP21YS2BS: 598(W) x 465(H) x 396(D) mm
Model CA21XS2S, CP21XS2S: 654(W) x 467(H) x 385(D) mm
Model CA21VF1S, CP21VF1S: 580(W) x 460(H) x 468(D) mm
Model CA21MS22, CP21MS22: 580(W) x 465(H) x 328(D) mm
Weight: Model CA21SF1, CP21SF1: approx. 20.0 Kg
Model CA21KS2, CP21KS2, CA21KS2K, CP21KS2K : approx. 19.7 Kg
Model
CA21YS2S, CP21YS2S : approx. 20.1 Kg
Model
CA21YS22, CP21YS22, CA21YS22B, CP21YS22B: approx. 18.0 Kg
Model
CA21YS2BS, CP21YS2BS : approx. 20.1 Kg
Model CA21XS2S, CP21XSS : approx. 19.6 Kg
Model
CA21VF1S, CP21VF1S : approx. 20.5 Kg
Model CA21KS22, CP21KS22, CA21KS22K, CP21KS2K(S), CA21MS22, CP21MS22: approx. 17.9 Kg
Specifications subject to change without notice.
Specifications
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 19

SANYO ELECTRIC Co., Ltd.
Part No. 1AA6P1P5578-C BE4D-C (FC8-A)
Before requesting service check the following chart.
“GHOSTS”
Reflections of signals from mountains or high buildings will cause multiple images, called “Ghosts”.
These abnormal conditions can be reduced to minimum by repositioning aerial or by installing new one
suited for your area.
“INTERFERENCE”
Interference may be caused by electrical appliances, car ignition systems, etc. This should normally be
a temporary condition, but should this interference persist, contact your dealer.
The following faults are not caused by the receiver:
●Check aerial connection on back of TV set.
●Check aerial for broken wires. ● Re-orient aerial.
Problem: Check these Conditions / Try these solutions:
●Check if TV is plugged in.
●Try a different channel, if OK, probably station trouble.
No picture,
no sound
●Adjust Brightness or Contrast control.
●Adjust Fine Tuning. (See page 10.) ● Check aerial connection.
Poor picture,
sound OK
No colour,
Picture OK
●Adjust Colour or Tint control. ●Adjust Fine Tuning. (See page 10.)
●
Check aerial connection. ● Is the programme in colour ? Try a different channel.
● Select other colour system. (See Setting of the Colour System on page 9.)
Weak picture
No sound or poor
sound.
● Sound Mute may be on. Press the SOUND MUTE button on the remote control.
●Adjust Volume. ● May be station trouble. Try a different channel.
● Select other sound system. (See Setting of the Sound System on page 9-10.)
Remote Control
will not work.
●Check batteries. Replace batteries.
●Check if TV set is plugged in. Aim remote control towards front of TV.
Cannot select or
scan some channels.
●Channel may be removed from memory. Add channel to memory manually.
(See “Skip Channel Set and Cancel” on page 13-14.) ●Check aerial connection.
●This is a normal condition during warm-up and cool down of the plastic
cabinet parts.
Blue screen with AV1
or AV1(DVD) or AV2
is displayed.
●Check AV connection. Press the TV/AV Selection button.
● Check external equipment. Switch on external equipment.
●Check to see if channel is set as the Private Position. See “Setting of the
Private Position” on page 14.
Black screen with
and programme
position displayed.
Cabinet makes
popping sound.
Colour Spot On
The CRT
●Keep away your TV set from magnetic source, then turn-off your TV set and
disconnect TV's power cord from AC outlet, keep this condition about 30-60
minutes and turn-on again your TV set if time is reach. If colour spot is not
disappear after this solution have done, please contact your local dealer.
“SLANT”
If the picture of TV set is not properly horizontal (slant), try to change face direction of your TV set. This
case may be caused by geo-magnetic on your place where you live.
HelpfulHints-Problems/Solutions
INST. MANUAL-BE4D-C (AUS)_new 5/11/09 9:30 AM Page 20
