SAPIRHOME Z-1115-QBM User manual

STAND MIXER
Z-1115-QBM
INSTRUCTION MANUAL
Read all instructions before use this product.

APPLIANCE DESCRIPTION
1 2 345678
9
10
11 12 13 14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
32
1.
Ring nut
2.
Fine mincing disk
3.
Medium mincing disk
4.
Coarse mincing disk
5.
Cutter
6.
Silicon coupling
7.
Scroll
8.
Meat grinder body
9.
Meat tray
10.
Tamper
11.
Protective cover
12.
Accessory socket
13.
Swivel arm
14.
Blender protective cover
15.
Upper coupler
16.
Safety micro-switch
17.
Release button
18.
Speed control knob
19.
Motor house
20.
Foot pad
21.
Motor spindle
22.
Lid
23.
Bowl cover
24.
Whisk
25.
Flat beater
26.
Kneading hook
27.
Mixing bowl
28.
Spatula
29.
Middle cap
30.
Blender lid
31.
Jar
32.
Cutting blade
33.
Cup base

IMPORTANT SAFETY PRECAUTIONS
When using this electrical appliance, basic safety precautions should always be followed
including the following:
Read all instructions.
To protect against risk of electrical shock do not put the appliance, power cord or plug in
water or other liquid.
Close supervision is necessary when the appliance is used by or near children.
Unplug the appliance when not in use, changing accessory and before cleaning.
Avoid contacting moving parts.
If the supply cord is damaged, it must be replaced by manufacturer or its service agent or
a similarly qualified person in order to avoid a hazard.
The use of attachments not recommended or sold by the manufacturer may cause fire,
electrical shock or injury.
Do not use outdoors.
Do not let cord to hang over edge of table or counter.
Keep hands and utensils away from moving blades or discs while processing food to
reduce risk of severe injury to person or damage to the food mixer.
Blades are sharp, handle carefully.
To reduce the risk of injury, never place cutting blades or discs on base.
Be certain it is securely locked in place before operating the appliance.
Never feed food by hand, always use food pusher.
Do not attempt to defeat the lid interlock mechanism.
Always operate the blender with the cap in place.
When blending non-liquid food, remove the centerpiece of the two-piece cap.
Turn off the machine before replace attachment.
Use the product and assembly the accessory as mentioned on user manual only.
Switch off the appliance before changing accessories or approaching parts, which move in
use.
This appliance is not intended for use by children or other persons without assistance or
supervision if their physical, sensory or mental capabilities prevent them from using it
safely.
Children should be supervised to ensure that they do not play with the appliance.
For Europe countries:
This appliance shall not be used by children. Keep the appliance and its cord out of reach
of children.
Appliances can be used by persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they understand the hazards involved.
Children shall not play with the appliance.
Always disconnect the appliance from the supply if it is left unattended and before
assembling, disassembling or cleaning.
Save these instructions!

CONTROL PANEL SPEED SETTING
0 - Stop
Setting 1-6 - Operating speed
Setting 1 - Minimum speed - slow
Setting 6 - Maximum speed - fast
Setting P –Pulse function
SPEED SELECTION GUIDE
Accessories
Speed
setting
Time
Capacity
Kneading
Hook
1, 2
1sec at speed
1; 3-5min at
speed 2
1500g flour and
900ml water
Flat beater
2-4
5-7min
Whisk
5-6
5-7min
At least egg white
of 3 eggs
No more than 18
eggs
Meat grinder
5-6
5-7min
Blender
5-6,P
1min
OPERATING POSITIONS
Warning!
Operate the appliance only when the accessory/tool is attached according to this table and is
in the operating position.

Item
Position
Accessory
1.
2.
3.
Risk of injury from the rotating tools!
While the appliance is operating, keep fingers clear of the mixing bowl.
Do not change tools until the appliance is at a standstill and have been unplugged. When
switch off, the drive continues running briefly.
HOW TO USE KNEADING HOOK, FLAT BEATER AND WHISK
1.
1. Place the appliance on a flat surface, e.g.
a kitchen counter, and make sure it is
standing firmly.
2. Ensure that the protective cover (11) is
fitted to the Accessory socket (12)
3. Place the blender protective cover (14)
into the upper coupler of swivel arm (13)
(see illustration).

2.
Turn the arm release button (17)
clockwise, at the same time lift the swivel
arm (13) with hand so that it locks into
place with a click. The swivel arm tilts up.
3.
Fit the bowl cover (23) onto the swivel arm
(13) and turn it clockwise, so that it locks
into position securely.
4.
1. Place the food in the mixing bowl (27).
2. Fit the mixing bowl in the recess on the
motor house (19).
3. Turn the mixing bowl clockwise, so it
locks into position.
5.
1. Put the splashguard (23) onto the
kneading hook (26) as shown in the
picture. Turn and fix the hook. The
splashguard (23) can prevent the dough
from climbing to the top of the hook.
2. Fit the required accessory (25 with 24,
23 or 26) onto the motor spindle (21) on
the underside of the swivel arm (13).
3. A. The kneading hook (26) is used for
heavy dough, minced meat or other
demanding kneading jobs.
B. The flat beater (25) is used to mix
lighter types of dough.
C. The whisk (24) is used for whisking
cream, egg whites, etc.
4. Turn the accessory, so the pins on the
spindle are aligned with the depressions on
the accessory top edge. Press the accessory

against the swivel arm and turn it
anti-clockwise at the same time until the
pins engage and the accessory locks into
position securely. The accessory must not
be loose nor should you be able to pull it
free.
6.
1. Lower the swivel arm so that it locks
into place with a click. The lid (23) must
fit tightly with the mixing bowl (27),
otherwise it is fitted incorrectly. The
appliance is now ready for use.
2. Plug the power cord into main power
outlet and switches it ON. The “ON”
indicator light on the control panel (15)
will now be illuminated.
3. Select the speed you want by using the
speed control knob. Speed 1 is the slowest
and speed 6 is the fastest speed.
Recommended speeds, time and capacity
are shown in the table above.
4. If you need to scrape inside the mixing
bowl, wait until the accessory has stopped
completely. Use the spatula, never your
fingers.
7.
1. Switch off the appliance by pressing the
OFF button when you have finished
mixing. Switch off the appliance at the
switch and unplug it before you change the
accessories, or before you take the
appliance apart or when not in use.
2. Turn the swivel arm release button (17)
clockwise, at the same time lift the swivel
arm with hand so that it locks into place
with a click. The swivel arm (13) tilts up.
8.
8.1 8.2
1. Detach the accessory by turning it
clockwise.
2. Remove mixing bowl with prepared
food anti-clockwise.

IMPORTANT!
The temperature of water, which will be added into dough, should be at 40+/-5°C when
preparing for dough is on progress.
HOW TO USE THE MEAT GRINDER
1.
1. Place the appliance on a flat surface, e.g.
a kitchen counter, and make sure it is
standing firmly.
2. Ensure that the protective cover (11) is
fitted to the Accessory socket (12)
3. Place the blender protective cover (14)
into the swivel arm (13)(see illustration)
2.
2.1
1. Fit the scroll (7) in the meat grinder body
(8) with the thin metal connection outwards,
and press firmly into place.
2. Fit the silicon coupling (6) onto the scroll
connection (see illustration).
3. Fit the cutter (5) onto the scroll
connection (see illustration). The sharp
edges of the cutter should point towards the
mincing disk.
4. Fit one of the three mincing disk (2,3,4)
on top of the cutter (see illustration). Turn
the mincing disk so the two indentations are
aligned with the pins on the meat grinder

body. Select the mincing disk for the
required consistency. You can choose fine,
medium and coarse.
5. Fit the ring nut (1) over the mincing disk
on the meat grinder body (see illustration).
Turn clockwise to lock. The ring nut must
hold the mincing disk securely in place, but
do not over tighten.
3.
Fit the meat grinder body (8) in the
accessory socket (12), so that the arrow is
aligned with the circle. Turn it to the
vertical position, so the arrow is aligned
with the arrow.
4.
1. Fit the meat tray (9) onto the meat grinder
body (8) so that the wide part is positioned
over the motor house of the appliance.
2. Place the mixing bowl (27) or similar
under the meat grinder body opening.
3. The appliance is now ready for use.
5.
1. Plug the power cord into main power
outlet and switches it ON. The “ON”
indicator light on the control panel will now
be illuminated.
2. Cut your meat into smaller pieces, so the
pieces fit into the feeding tube. Dice or cut
into strips with a width of approx. 2.5 cm.
2. Put the pieces onto the tray (9).
3. Select the speed you want using the speed
control knob. Recommended speeds are
shown in the table above.
5. The meat pieces travel down the feeding

tube. Push down carefully with the tamper
(10). Do not press too hard; otherwise, you
may damage the appliance.
6.
1. Switch off the appliance by pressing the
OFF button when you have finished
grinding the meat. Switch off the appliance
at the switch and unplug it before you
change the accessories, or before you take
the appliance apart or when not in use.
2. Remove pusher and meat tray.
77.
To detach the meat grinder, turn the body so
the arrow is aligned with the circle and then
remove.

8.
Fit the protective cover over the accessory
socket again.
SAFETY INSTRUCTIONS
Always remove bone, gristle, tendons, and rind before grinding the meat.
Frozen food must be thoroughly defrosted before grinding.
The meat grinder must only be used to grind meat. Avoid grinding pasty foods, e.g.
food containing breadcrumbs, as this could damage the appliance.
Never run the meat grinder continuously for more than 10 minutes. Running the meat
grinder continuously for too long without a break may reduce the life span of the
appliance. After having used the appliance for 10 minutes, take a break and wait at
least 30 minutes before using it again.
HOW TO USE THE BLENDER
1.
1. Place the motor section on a flat
surface, e.g. a kitchen counter, and make
sure it is standing firmly.
2. Ensure that the protective cover (11) is
fitted to the accessory socket (12).
2. Remove the blender protective cover
(14) from the swivel arm (see illustration).

2.
1. Place the foodstuff you wish to process
into the jar (31).
2. Put the blender lid (30) on the jar so the
pins on the lid are aligned with the
depressions on the jar top edge. Press the
button (31) at the same time put the
blender lid into the jar.
3. Place the middle cap (29) into the hole
in the blender lid.
3.
1. Place the jar assembly in the motor
house, so that the arrow is aligned with
the circle. Turn it clockwise, so the arrow
is aligned with the arrow.
2. Plug the power cord into main power
outlet and switch it ON. The “ON”
indicator light on the control panel will
now be illuminated.
3. Select the speed you want using the
four speed buttons. Recommended speeds
are shown in the table above.
4.
1. Switch off the appliance by pressing the
OFF button after use. Switch off the
appliance at the switch and unplug it
before you change the accessories, or
before you take the appliance apart or
when not in use.
2. To detach the jar assembly, turn the jar
so the arrow is aligned with the circle and
then remove.
3. Press the button at the same time take
out the blender lid. You may put processed
food out.

5.
Fit the blender protective cover to the
swivel arm again.
SAFETY INSTRUCTIONS
To achieve the best results when pureeing solid ingredients, place small portions into
the jar one by one instead of placing a large quantity all at once.
If you are processing solid ingredients, cut them into small pieces (2-3cm) first.
When mixing solid ingredients start first with a small amount of liquid. Gradually add
more and more liquid through the opening in the lid.
Always place your hand on top of the blender when you are operating the device.
For stirring solid or very thick liquid ingredients, we recommend that you use the
blender in impulse mode to prevent the blades from becoming stuck.
Operate the motor for a maximum of 2 minutes to prevent overheating or consequent
damage.
It is advisable to wash appliance before using it for the first time.
Clean the appliance after each use, thereby avoiding liquid incrustations.
The switch does not permanently engage in the ‘P’ setting. You have to hold the switch
in the ‘P’ setting
Jar capacity: 1500ml
CLEANING AND MAINTENANCE
When cleaning the appliance, you should pay attention to the following points:
Remove plug from the mains socket, and allow the appliance to cool down before
cleaning it.
Do not immerse the motor section of the appliance in water and make sure no water enters
the appliance.
Clean the motor section by wiping it with a damp cloth. A little detergent can be added if
the appliance is heavily soiled.
Do not use scouring pads, steel wool or any form of strong solvents or abrasive cleaning
agents to clean the appliance, as they may damage the outside surfaces of the appliance.
Take the appliance apart and clean all of the accessories separately. All of the accessories
can be cleaned in warm soapy water.
Be careful not to touch the blades or sharp parts during use and cleaning.
IMPORTANT! Allow to dry fully after cleaning before using again. Do not use the
appliance if it is damp.

We recommend you lubricate the meat screens with vegetable oil after cleaning, and store
them in grease-proof paper to minimize the risk of rust and discoloration.
After washing and drying, immediately place attachment into the protective sleeve for
storage.
CAPABILITY OF BOWL
1.5kg flour and 900ml water
APPLICATION EXAMPLES
Mayonnaise
2 eggs, 2 tablespoon of vinegar, 250g of oil.
Blend speed 5 and slowly pour oil through the middle cap. Blend as long as the mayonnaise
emulates.
Carrots
400g carrots, appropriate water
Chopping of almonds
200g of almonds.
Ice-cubes
Weight of one ice-cube: ~12g-16g/piece; 140g = ~9 pieces
Beating of egg-white
8 egg-whites in the bowl with the whisk at speed 6.

Beating of cream
600g cream with the flat beater in the bowl at speed 4.
Kneading of dough
1000g flour
200g chopped almonds
15g salt
28g butter
28g sugar
Approx. 500g water (temperature 40+/-5°C)
TECHNICAL SPECIFICATION
Operating voltage: AC 220-240V, ~50Hz
Power: 1900W
