Sartorius Master Pro Series User manual

W--5032-e03013
Q
U
A
L
I
T
Y
S
Y
S
T
E
M
C
E
R
T
I
F
I
E
D
Q
U
A
L
I
T
Y
S
Y
S
T
E
M
R
e
g
.
N
o
.
1
9
4
4
0
-
0
2
C
E
R
T
I
F
I
E
D
DIN EN ISO 9001
Sartorius AG, Weighing Technology
Sartorius AG, Weighing Technology
Sartorius Master pro Serie
Electronic Precision Balances
Service Manual
for LP / LA Models

2
General Information 4
Repairs 4
Models 4
Auxiliary Tools 4
Accompanying Literature 4
Operating the Balance 5
Key Functions 5
Password Levels 5
Setting the Language 5
SETUP Program 6
INFO Mode 6
INPUT Mode 7
MENU - Balance Operating Menu 8
Overview of the User / Service SETUP Program 9
Service Switches 10
Access Switch 10
Activating the BPI Mode / Deactivating the Write Protection 10
Activating the Service Mode 11
Calibration/Adjustment in the Service Mode 11
External Linearization 12
External Linearization with Manual Input of Weight Values 12
Manual Input of the Linearization Weights 12
Performing External Linearization 13
Internal Span Adjustment 14
External Span Adjustment 14
External Span Adjustment with Manual Input of Weight Values 14
External Span Adjustment with Stored Weight 15
Overwriting the Internal Calibration Weight 15
Calibration with a User-defined Weight 15
reproTEST 16
High Resolution - Display * 10 16
Operating the Balance 17
Key Functions 17
SETUP Program 17
Setting the Language 18
CONFIG Mode 18
APPLICATION Mode 18
INFO Mode 18
INPUT Mode 19
MENU - Balance Operating Menu 20
Activating the Service Mode 21
Calibration/Adjustment in the Service Mode 21
External Linearization 22
External Linearization with Manual Input of Weight Values 22
Manual Input of the Linearization Weights 22
Performing External Linearization 23
Internal Span Adjustment 24
External Span Adjustment 24
External Span Adjustment with Manual Input of Weight Values 24
External Span Adjustment with Stored Weight 25
Overwriting the Internal Calibration Weight 25
Calibration with a User-defined Weight 26
reproTEST 26
High Resolution - Display * 10 26
Servicing the Weighing Cell 27
Removing the Display and Control Unit from the Weighing Cell 27
Opening the Weighing Cell
(Small Single-Casting Block System, Brass System) 27
Opening the Weighing Cell (Large Single-Casting Block System) 27
Page

Contents
3
Accessing the Main PCB 28
Opening the Display and Control Unit 28
Calibration/Adjustment 29
Calibration/Adjustment Sequence 29
Prerequisites for Calibration/Adjustment 29
Ambient Conditions 29
Operating Conditions 29
Preload 30
Checking the Preload 30
1. Checking the Preload with the Service Software 30
2. Adjusting the Preload with a Digital Voltmeter 30
Adjustment Specifications 31
Adjusting the Preload 32
Reproducibility 33
Off-center Load 33
Checking the Off-center Load 33
Adjusting the Off-center Load 34
Masterpro Balances with the Small Single-Casting Block System 34
Masterpro Balances with the Brass System 34
3-Point Adjustment (rough) 34
Masterpro Balances with the Large Single-Casting Block System 35
Span Accuracy 36
Checking the Span Accuracy 36
Linearity 37
Checking the Linearity 37
Checking the Linearity on Balances with Less Than 1,000,000 Digits 37
Checking the Linearity on Balances with More Than 1,000,000 Digits
and PolyRange Balances 38
Repairing the Balance 39
Repairing the Weighing System 39
Repairing the Electronics 39
Replacing the PCB in the Display and Control Unit 39
Replacing the Display and Control Unit, Backlighting Module,
Keypad Overlay 40
Replacing the Balance PCB 40
Masterpro Balances with the Small Single-Casting Block System
or Brass System 41
Masterpro Balances with the Large Single-Casting Block System 41
Pin Assignments 42
Balance Operating Menu Codes Masterpro LP 43
Balance Operating Menu Codes Masterpro LA 46
Service Specifications 48
Service Specifications Sheet 1 48
Service Specifications Sheet 2 49
Spare part list LP / LA 50
LP / LA - Exploded-View Diagram 1 50
LP / LA - Exploded-View Diagram 2 52
LP / LA - Exploded-View Diagram 3 54
LP / LA - Exploded-View Diagram 4 56
LP / LA - Exploded-View Diagram 1a 58
LP / LA - Exploded-View Diagram 2a 60
LP / LA - Exploded-View Diagram 3a 62
Page

4
General Information
Repairs
Note: Prerequisites for working on the Sartorius Masterpro Balances include
considerable experience, completion of a Service Course at the main
office in Goettingen, and the special tools and equipment described
below. Please do not attempt or permit any unauthorized repair work!
If you remove the seal (warranty sticker), the balance is no longer cov-
ered under the warranty.
How to change the battery:
upright flat Important Note!
When exchanging the battery (if available), be sure that
– you use a new battery that is identical to the old one or equivalent to
the battery recommended by the manufacturer.
– the poles are correctly positioned when soldering in the battery.
Warning: If you use the wrong battery, this may result in an explosion.
Be sure to dispose of the defective battery properly according to your
country‘s environmental protection laws!
Models
The LA/LP balance consists of a weighing cell (LA/LP) and a display and
control unit.
LA/LP balances with brass systems:
LA/LP1200S, LA/LP3200D, LA/LP4200S, LA/LP5200P, LA/LP6200S
LA/LP balances with small single-casting block systems:
LA/LP420, LA/LP220S, LA/LP620S, LA/LP620P, LA/LP820,
LA/LP2200, LA/LP2200S, LA/LP2200P, LA/LP4200, LA/LP6200,
LA/LP12000S, LA/LP12000P
LA/LP balances with large single-casting block systems:
LA/LP16000S, LA/LP34000P, LA/LP34, LA/LP34001
Auxiliary Tools
All calibration/adjustment tasks can be performed without the service
software, with the following exceptions:
- Span adjustment when the error is greater than 2%
- Calibration/adjustment after replacing a PCB
In addition to standard tools, you will need the following special tools:
Qty. Designation Order no.
1 SARTOCAS service software or 6740-33
1 PSION Server, complete 6739-98
1 RS-232 cable for connecting the 7357 312
balance to a PC
Accompanying Literature
Spare Parts List for the Masterpro (LA/LP) Balances
Operating Instructions for Electronic Precision (LA/LP) Balances
Sartorius SARTOCAS program description
Sartorius PSION Server program description
Sartorius Tool List - Status: 9/91
AUT_5006a.JPG AUT_5007a.JPG

SARTORIUS Masterpro
5
4
Max5200 g d= 0.01 g
0.00 g
isoCAL
Max5200 g d= 0.01 g
LP_bedie.EPS
da97
CODE
202122
S-ID
40414243
info menu input
202122
S-ID
202122
info menu input
Operating the Balance
Key Functions
eOn/off. Turns the display on/off. The balance remains in the
standby mode.
cClear function. Used to interrupt/cancel functions; e.g., delete
data from memory, cancel calibration/adjustment functions, etc.
tTare. Zeros the display.
pPrint. The displayed data is output to the printer.
wToggle. Toggles the readout between weight and calculated
value when using the counting, weighing in percent or calculation
programs; otherwise, toggles between two weight units.
vFunction. Starts an application program
öSETUP. For accessing the SETUP program menu, storing menu
codes, exiting the menu.
[Calibration/adjustment.
-../Numeric input (e.g., ID number).
}Decimal point for numeric input.
aToggle to alphabetic input.
è é Arrow (cursor) keys.
ú õ
Password Levels
There are 3 different levels of password-protected access:
1. The user can assign a password to protect memory data
2. 40414243 is the “dealer password;” this can be given to the user if the
user password is lost
3. 202122 is to be used only by service technicians; when this password is
entered, the data entered using the INPUT mode can be changed and the
qkey functions are expanded.
Setting the Language
– When 0.00 g is displayed (depending on balance model), you can select
the language by entering the corresponding number (use the numeric keys).
1 German
2 English (factory setting)
3 English with US date/time format
4 French
5 Italian
– Press öto save the setting.
Example: French: Press 4 and then press öto store.

6
SETUP Program
– Press ]to turn on the balance.
– Wait until the power-up routine is completed (delayed power-on, display
segment test, function test).
– When 0.00 g is displayed (depending on the balance model), press ö.
– The 3 soft key functions are displayed.
– Press cto access the “info” mode.
– Press wto access the “menu.”
– Press vto access the “input” mode.
– If the password prompt (enter passw.) is displayed, a user password has
been stored.
– Enter the service password (202122) and press öto confirm.
– An “S” is displayed in the lower left corner to indicate that the service
mode is active.
Note: The input options available in the MENU and in the INPUT mode are ex-
panded when the balance is switched to the service mode (see “Overview of
the User/Service SETUP Program,” page 9).
INFO Mode
Select the INFO mode to display information about the balance.
– Press qwhile running the SETUP program.
– The version number of the display and control unit is displayed (in this ex-
ample, 01 is the display and control unit, 30 the hardware and 03 the
software).
– Press ú.
– The version number of the processor for the weighing platform is displayed
(in this example, 00 is the weighing platform, 20 the hardware and 06
the software).
– Press ú.
– The model name is displayed (QQQQ>>) indicates that you can scroll the
readout by pressing X).
– Press ú.
– The balance serial number is displayed.
– Press p to display information about the data output port.
– Press Mto exit the INFO mode.
– The balance returns to the weighing mode.
Note: The data shown here are examples only; the data displayed on the balance
you are working with will depend on the series, version and model of the bal-
ance.
01-30-03
Ver.-No.
00-20-06
Ver.-No. ofbalance
LP5200P
MODEL___>>
60406913
sER. No.
0.000 g
S isoCAL
Max5200 g d= 0.01 g
202122
S-ID
202122
info menu input
info menu input
LP_anzei.EPS

SARTORIUS Masterpro
7
INPUT Mode
Press INPUT and then p to output the current settings to the data output port.
Select the INPUT mode to enter data in the balance.
The input options available in the INPUT mode are expanded when the bal-
ance is switched to the service mode (e.g., for entering an external lineariza-
tion weight).
– Press wwhile running the SETUP program.
Note: You can input up to 20 characters in an input field; use the left and right ar-
row keys (é /õ) to scroll the display for input longer than 8 characters.
– Enter an ID number (e.g., inventory or laboratory number).
– Press úto select the individual positions.
– Enter a lot number (e.g., test series number)
– Press ú
– Enter a calibration weight ID number (e.g., number of the weight set)
– Press ú
– The calibration/adjustment weight is displayed. The weight shown can be
changed, including the number of digits following the decimal point.
– Press ú
– The password is displayed (user password).
– Press ú
Note: “ S“ is displayed if the service mode was activated before the INPUT mode
was selected.
The following settings can only be changed in the service mode.
– Input for the 1st linearization weight. The weight shown can be changed,
including the number of digits following the decimal point.
– Press ú
– Input for the 2nd linearization weight. The weight shown can be
changed, including the number of digits following the decimal point.
– Press ú
– Input for the 3rd linearization weight. The weight shown can be changed,
including the number of digits following the decimal point.
– Press ú
– Input for the 4th linearization weight. The weight shown can be changed,
including the number of digits following the decimal point.
– Press ú
– Input for the password (user password)
This password protects the MENU and the INPUT mode.
The service password has higher priority than the user password.
m15v-234
ID________
a123
cal. Wt.ID_____
1096aaa1
lot-ID____
2000.00 g
CAL./adJ.-WeIgHT
da97
password
1000.00 g
S LIN. WeIgHT 1
3000.00 g
S LIN. WeIgHT 2
5000.00 g
S LIN. WeIgHT 3
6000.00 g
S LIN. WeIgHT 4
da97
password

8
– Press öto exit the INPUT mode.
– The balance returns to the weighing mode.
MENU - Balance Operating Menu
– Press wwhile running the SETUP program.
– The 1st menu level is displayed.
– Use the arrow keys (è é ú õ) to select the desired menu level
and code digits.
– Press Xto confirm a digit setting and move to the next digit.
– Press Mto store new code settings and exit the operating menu.
– The balance returns to the weighing mode.
Note: See the section entitled “Balance Operating Menu Codes” starting on page
43 for an overview of the balance operating menu.
0.00 g
Max5200 g d= 0.01 g
1
balance functions
1 1
adapt filter
1 1 2 o
normal vebration
0.00 g
Max5200 g d= 0.01 g

SARTORIUS Masterpro
9
User Service User Service
202122
INFO MENU INPUT
S
User
SETUP
An "S " is displayed when the
service mode is active.
Select
display:
CAL key
Press CF in the selection mode to exit the service mode.
Service mode activated
Service mode
remains on
if activated
User
Service CAL menu::
Def.ext.adj.
auto ext.adj.
ext. adjust
int. adjust
def.ext.lin.
ext.linear
REPROTEST
det.int.wt.
det.ext.wt.
disp. X 10
User CAL menu:
Ext. calibr.
Int. calibr.
REPROTEST
Quick-CAL:
Depends on
menu code setting
1 9 x
SETUP
CF
Exit the select display
Press SETUP to exit the service mode
Menu items
accessible
for the
user
Menu items
accessible
for service
9- 1 - 1
9- 1 - 10
9- 1 - 11
9 -1 - 12
(Load factory settings)
Menu items:
ID________
<<__Lot ID____
CAl. Wt. ID_____
CAL./adj. Weight
Password
Menu items:
Ver. No.
SER. No.
MODEL___>>
Ver. No. of Balance
Menu items:
ID________
<<__Lot ID____
CAl. WT. ID_____
CAL./Adj. Weight
LIN. Weight 1
LIN. Weight 2
Password
LIN. Weight 3
LIN. Weight 4
(Reset all parameters
incl. INPUT Mode)
SETUP
40414243
Generalcodeword
Service
User / Service
Flussd1e.EPS
Overview of the User / Service SETUP Program

10
Service Switches
The Masterpro balances are equipped with a service mode; in this mode, both
the SETUP functions and the calibration/adjustment functions are expanded.
Note: Open the access switch (B) to calibrate/adjust the balance in the service
mode (with the PSION Server or SARTOCAS Service Program for PCs).
Access Switch
The access switch (B) and the BPI switch (A) are located under the cap on the
raer panel of the balance, under a protective cap on the right side. On veri-
fied balances, this protective cap is sealed.
On high-capacity LP balances (≥16 kg), the access switch is located on the
left, behind screw (217), and the BPI switch is behind the two-hole screw
(216); both screws are next to the DC power jack (212).
Activating the BPI Mode / Deactivating the Write Protection
You must activate the BPI mode / deactivate the write protection:
– to calibrate/adjust the balance with the PSION Server, or
– to replace the balance PCB.
– Turn on the balance.
– When 0.00 g is displayed (depending on the balance model) remove the
protective cap or the two-hole screw (216) and move the BPI switch (A).
– The display goes blank; the line for metrological data begins flashing.
Wait for this line to flash at least 3 times, and then return the BPI switch to
the original position.
– Wait for the display to return to the weighing mode.
– Turn the balance off and then turn it back on again.
– The balance is now ready to operate in the BPI mode (the write protection
on the EEPROM has been deactivated).
Note: When the balance is in the BPI mode, it is not possible to operate peripheral
devices that use the RS-232 protocol.
“Err30” is displayed when you press p.
Note: If the balance does not communicate with the service software in the BPI
mode, you must remove the display and control unit (see page 17,
“Removing the Display and Control Unit from the Weighing Cell”).
WA_BPI01.TIF
WA_BPI02.TIF
BPI SwitchBPI Switch
BPI SwitchBPI Switch
BPI Switch Access SwitchAccess Switch
Access SwitchAccess Switch
Access Switch
closed open closed open
closed
open
BPIsch-f.EPS
Schalt-f.EPS

SARTORIUS Masterpro
11
Activating the Service Mode
The LP balances are equipped with a service mode that enables expanded
calibration/adjustment functions. With these expanded functions, you do not
need to use the PSION Server or SARTOCAS Service Program for PCs to cali-
brate/adjust the balance.
The service mode only remains active until:
1. you press Mto exit the menu, or
2. cis pressed when the “Service CAL Selection” menu is displayed (see
the overview on page 9).
The weighing mode is active (0.00 g is displayed - depending on the balance
model)
– Enter the service password: 202122.
– Press M.
– The SETUP menu is displayed and an “S” is shown in the lower left corner.
– The service mode is now active.
– Press cto exit the SETUP menu; press qto activate the calibration/
adjustment menu.
Calibration/Adjustment in the Service Mode
Adjustment options in the service mode:
1. int. adjust * – Span adjustment with internal weight
2. def. ext.lin. – External linearization with default weight
3. ext. linear. – External linearization (enter weight value in the IN-
PUT mode)
4. reprotest * – Reproducibility test of the internal adjustment
5. det. int. wt. – Overwrite the internal calibration weight
6. det. ext. wt. – Determine and store the external weight (user-defined
weight)
7. disp. *10 – 10-fold increased display resolution; SuperRange
resolution
8. def. ext.adj. * – External span adjustment with default weight
9. auto ext.adj.* – External span adjustment with automatic recognition
of calibration weight
10. ext.adj. * – External span adjustment with stored (user-defined)
weight (entered in the INPUT mode)
Note: In most cases it is not necessary to use service software programs (PSION or
Sartocas) to adjust the LP balances, because all necessary adjustment func-
tions are accessible when the balance is in the service mode.
You only need to use the adjustment software if the current adjustment error is
greater than 2% or if multiple adjustment steps are necessary due to unfavor-
able ambient conditions.
0.00 g
Max5200 g d= 0.01 g
202122
S-ID
Max5200 g d= 0.01 g
202122
Sp. ID
S INFO MENU INPUT
*Can also be adjusted without activating the service mode

12
External Linearization
There are two ways to perform external linearization:
1. with the Sartorius service software (PSION Server or SARTOCAS Service
Software for PCs) - if the adjustment error is greater than ±2%, or
2. as described in this manual, with the balance in the service mode.
External Linearization with Manual Input of Weight Values
If the weights available differ greatly from the weights defined in the factory
settings, you can precisely define the weights to be used:
(use only calibration weights!)
Manual Input of the Linearization Weights
– Press ]to turn on the balance.
– The balance performs a self-test.
–0.00 is displayed (depending on balance model)
– Activate the service mode:
– Enter the service password: 202122
– Press ö.
– Press vto activate the INPUT mode.
– Press Y (several times) to select the “lin. weight 1” menu item and use
the numeric keys to enter the calibration weight for the first linearization
weight in accordance with the calibration certificate.
– Press Xto store the weight value entered, and then press Yto pro-
ceed to the “lin. weight 2” menu item.
– Use the numeric keys to enter the calibration weight for the second linear-
ization weight, press Xto store, and then press Yto proceed to the
“lin. weight 3” menu item.
– Use the numeric keys to enter the calibration weight for the third lineariza-
tion weight, press Xto store, and then press Yto proceed to the “lin.
weight 4” menu item.
– Use the numeric keys to enter the calibration weight for the fourth lineariza-
tion weight and press Xto store.
– After defining all 4 linearization weights, press ö to exit the INPUT
mode.
– The balance returns to the weighing mode.
0.00 g
Max5200 g d= 0.01 g
202122
S-ID
Max5200 g d= 0.01 g
202122
S info menu input
1000.01 g
S LIN. WeIgHT 1
3000.03 g
S LIN. WeIgHT 2
0.00 g
Max5200 g d= 0.01 g
5000.02 g
S LIN. WeIgHT 3
6000.03 g
S LIN. WeIgHT 4
S Sp. ID

SARTORIUS Masterpro
13
Performing External Linearization
After defining the linearization weights, the linearization procedure can be
started.
Note: If linearization weights of sufficient accuracy are available (at least one digit
greater than the display accuracy), it is not necessary to define the lineariza-
tion weights (in the INPUT mode).
In this case, you can start linearization by selecting the “def. ext.lin.” menu
item.
The procedure is described below.
– Activate the service mode again (see page 11).
– Press q.
– Press v (several times) to select the “ext. linear” menu item, tare the
balance if necessary and press qto start the linearization routine.
– The first linearity weight is displayed.
Center the corresponding weight on the weighing pan.
Note: Depending on the menu code setting (under 1 10 X), either calibration/ad-
justment is performed automatically (code 1 10 1: calibrate, then auto-ad-
just), or the deviation from the last calibration is displayed, but no adjust-
ment is made until you press a key (code 1 10 2: calibrate, then manual
adjust).
– The deviation from the last adjustment is displayed.
– If the error exceeds the tolerance limits, either press qto make the corre-
sponding adjustment, or press cto cancel the adjustment procedure.
– The second linearity weight is displayed.
– Center the corresponding weight on the weighing pan and press qto
confirm.
– Repeat this procedure until all linearity weights have been adjusted.
– After concluding the linearization routine, the service mode remains active
until you press c.
Note: Always perform internal or external span adjustment after external lineariza-
tion.
0.00 g
S ext. linear. selec.
- 1000.01 g
S ext. linear.
202122
Max5200 g d= 0.01
g
Max5200 g d= 0.01
g
- 0.03 g
S diff.
- 6000.03 g
S ext. linear.
- 3000.03 g
S ext. linear.
- 5000.02 g
S ext. linear.
0.00 g
S ext. linear. selec.
Max5200 g d= 0.01 g

14
Internal Span Adjustment
All LP balances are equipped with a built-in motorized calibration weight.
– Turn on the balance and allow it to warm up.
– Zero the balance, if necessary (press t).
– Press q; press vto select “int. calibr.” or “int. adjust” and press
qto start the internal span adjustment.
– The built-in calibration weight is applied automatically, the weight is
stored, and the deviation from the last span adjustment is displayed.
Note: Depending on the menu code setting (under 1 10 X), either calibration/ad-
justment is made automatically (code 1 10 1: calibrate, then auto-adjust), or
the deviation from the last calibration is displayed, but no adjustment is
made until you press a key (code 1 10 2: calibrate, then manual adjust).
– If the error exceeds the tolerance limits, press qto make the correspond-
ing adjustment, or press cto cancel the adjustment procedure.
– The balance then returns to the SELECT mode.
External Span Adjustment
There are two ways to perform external span adjustment:
1. with the Sartorius service software (PSION Server or SARTOCAS Service
Software for PCs) - if the adjustment error is greater than ±2%, or
2. with the balance in the service mode, as described in this manual.
External Span Adjustment with Manual Input of Weight Values
Note: You only need to input the calibration weight for span adjustment if:
1. the available weight is not sufficiently accurate (at least one digit greater
than the display accuracy), or
2. you are working with a weight other than the recommended weight (e.g.,
with a heavier weight, close to the maximum capacity).
– Press eto turn on the balance.
– The balance performs a self-test.
– When 0.00 g is displayed (depending on balance model), enter the ser-
vice password “202122” and press M.
– Press v to activate the INPUT mode.
– Press Y (several times) to select the “cal./adj. weight” menu item.
– Enter the conventional weight value, including all decimal places, using
the numeric keys.
– Press Mto store the adjustment and exit the SETUP menu.
0.00 g
Max5200 g d= 0.01 g
0.00 g
int. adjust wahl
Max5200 g d= 0.01 g
c
int. adjust
0.09 g
int. adjust end
202122
S-ID
Max5200 g d= 0.01 g
202122
S info menU input
2000.02 g
S cal./adj. weight

SARTORIUS Masterpro
15
External Span Adjustment with Stored Weight
– Activate the service mode (see page 11).
– Press qand then press vto select the “user ext.adj.” menu item.
– Tare the balance, if necessary, and then press qto start external span
adjustment.
– Center the prompted calibration weight on the weighing pan.
Note: Depending on the menu code setting (under 1 10 X), either calibration/ad-
justment is made automatically (code 1 10 1: calibrate, then auto-adjust), or
the deviation from the last calibration is displayed, but no adjustment is
made until you press a key (code 1 10 2: calibrate, then manual adjust).
– If the error exceeds the tolerance limits, press qto make the correspond-
ing adjustment, or press cto cancel the adjustment procedure.
– The balance then returns to the SELECT mode.
Overwriting the Internal Calibration Weight
Note: As a rule, this procedure is only necessary after the balance has been opened
for service/repair work.
– Activate the service mode (see page 11).
– Perform external span adjustment (make sure you use a precise weight).
– Press v(several times) to select the “det. int. wt.” menu item.
– Tare the balance, if necessary, and press qto overwrite the calibration
weight.
– The built-in calibration weight is applied automatically, measured and writ-
ten to the EEPROM in the balance processor.
– Press cif you need to cancel this routine.
– The balance then returns to the SELECT mode.
Calibration with a User-defined Weight
You can define any weight as the calibration weight.
Activate the INPUT mode to enter the weight value and then store it under the
“cal./adj. wt.” menu item.
– Activate the service mode (see page 11).
– Perform external or internal span adjustment.
– Press vto select the “det. ext. wt.” menu item.
– Tare the balance if necessary, and then press qto start the calibration
routine.
– The last calibration weight that was entered in the INPUT mode is dis-
played.
– Center the calibration weight you wish to define on the weighing pan.
– The weight value is displayed and stored.
– The balance returns to the SELECT mode.
0000.00 g
S user EXT.adj selec.
Max5200 g d= 0.01 g
- 1000.00 g
S user EXT.adj
Max5200 g d= 0.01 g
0000.00 g
S user EXT.adj selec.
Max5200 g d= 0.01 g
0000.00 g
S BEt. int. wt. selec.
Max5200 g d= 0.01 g
0000.00 g
S BEt. .EXt. wt. selec.
- 1000.00 g
S BEt. .EXt. wt.

16
reproTEST
– Activate the service mode (see page 11).
– Press v(several times) to select the “reprotest” menu item.
This tests the reproducibility of the automatic application of the built-in calibra-
tion weight.
The internal weight is applied, measured and removed 6 times.
At the end of the routine, the reproducibility value is displayed.
High Resolution - Display * 10
– Activate the service mode (see page 14).
– Press v(several times) to select the “disp x10” menu item.
The balance switches to SuperRange resolution and an additional digit is dis-
played (for test purposes and initial verification).
Max5200 g d= 0.01 g
0000.00 g
S Reprotest selec.
Max5200 g d= 0.01 g
0000.00 g
S disp. x 10 selec.

SARTORIUS Masterpro
17
Operating the Balance
Key Functions
eOn/off. Turns the display on/off. The balance remains in the
standby mode.
cClear function. Used to interrupt/cancel functions; e.g., delete
data from memory, cancel calibration/adjustment functions, etc.
tTare. Zeros the display.
pPrint. The displayed data is output to the printer.
wToggle. Toggles the readout between weight and calculated
value when using the counting, weighing in percent or calculation
programs; otherwise, toggles between two weight units.
N6 function keys that are defined individually depending on the
program setting
öSETUP. For accessing the SETUP program menu, storing menu
codes, exiting the menu.
-../Numeric input (e.g., ID number).
}Decimal point for numeric input.
aToggle to alphabetic input.
SETUP Program
– Press ]to turn on the balance.
– Wait until the power-up routine is completed (delayed power-on, display
segment test, function test).
– If the symbol to the left is displayed, press ö.
– The symbol to the left appears.
– The 6 function keys are automatically programmed with different functions.
The function keys are numbered from right to left from 1 to 6, i.e. function
key 1 is the key next to the Dkey.
– Press F1 to access the “input” mode.
– Press F2 to access the “menu.”
– Press F3 to access the “info” mode.
-– Press F4 to access the “Applic(ation)” menu
– Press F5 to access the “Config(uration)” menu
– Press F6 to return to the “Weighing” mode
(the ö key has the same function).
– If the symbol to the left is display after pressing a function key, a user pass-
word has been stored.
– This can be avoided by inputting a service password.
– In this case, input » 202122 « and press F1 to confirm.
Note: Except for the INFO mode, all other menus are stored by means of the user
password.
Note: The input options available in the MENU and in the INPUT mode are
expanded when the balance is switched to the service mode (see “Overview
of the User/Service SETUP Program,” page 9).
F6 F5 F4 F3 F2 F1
TARE TARE
ABC1234567890
SETUP CF
D
La_bedie.EPS

18
Setting the Language
– When 0.00 g is displayed (depending on balance model), you can select
the language by entering the corresponding number (use the numeric keys).
1 German
2 English (factory setting)
3 English with US date/time format
4 French
5 Italian
– Press öto save the setting.
CONFIG Mode
Select the CONFIG(uration) mode to print out a record (on an interfaced
printer).
Depending on the settings available in the APPLI(APPLI(
APPLI(APPLI(
APPLI(cation) menu, various con-
figurations are available for printing out the record.
See the Installation and Operating Instructions for LP/LA Balances for a de-
tailed description of the CONFIG mode.
APPLICATION Mode
The APPLI(cation) menu is used to input the settings and configuration for appli-
cation programs.
Up to 3 application programs plus up to 2 additional functions can be acti-
vated at the same time.
See the Installation and Operating Instructions for LP/LA Balances for a de-
tailed description of the setting options.
INFO Mode
Select the INFO mode to display information about the balance.
– Press F3 while running the SETUP program.
– The version number of the display and control unit, the version number of
the processor for the weighing platform, the model name and the balance
serial number are displayed.
– Press F6 to exit the INFO mode or to exit the SETUP program, press ö
(return to weighing mode).
Note: The data shown here are examples only; the data displayed on the balance
you are working with will depend on the series, version and model of the
balance.
F5
F4
F3

SARTORIUS Masterpro
19
INPUT Mode
Select the INPUT mode to enter data in the balance.
The input options available in the INPUT mode are expanded when the bal-
ance is switched to the service mode (e.g., for entering an external lineariza-
tion weight).
– Press F1F1
F1F1
F1 while running the SETUP program.
Note: You can input up to 20 characters in an input field; use the left and right ar-
row keys (é /õ) to scroll the display for input longer than 8 characters.
– The following user data can be displayed, entered or changed:
an ID number (e.g., inventory or laboratory number).
a lot number (e.g., measuring series)
a adjustment weight ID number (e.g., number of the adjustment weight)
The weight value of the calibration/adjustment weight, including the all
necessary number of digits following the decimal point, can be
changed using the numeric keys.
The weight value of the 4 linearization weights, including the all
necessary number of digits following the decimal point, can be
changed using the numeric keys!
Only accessible in the SERVICE mode!
Time
Date
The contrast/angle of the display (input from 0 to 4, factory setting is
2)
Input an access password (user password)
This password stores all the menus except for INFOINFO
INFOINFO
INFO mode that are also
accessible after inputting the password.
The service password has higher priority than the user password.
4 identifier lines are printed out on the record; e.g., name of the
customer’s company.
Three adjustment procedures are repeated automatically at the set times
selected by the user.
These adjustment times are in addition to the adjustment criteria of the
isoCAL function!
These adjustment times are set by inputting hh.mm or hh (without the
minutes).
The settings can be input without a “0” in front (e.g. 7.30, 12.00,
18.15).
Note: “S” is displayed if the service mode was activated before the Input-mode.Input-mode.
Input-mode.Input-mode.
Input-mode.
F1

20
MENU - Balance Operating Menu
– Press F2F2
F2F2
F2 while running the SETUP program.
- The symbol to the left appears.
– Use the keys F1 - F4F1 - F4
F1 - F4F1 - F4
F1 - F4 (cursor function) to select the desired menu level and
code digits.
– Press F1F1
F1F1
F1 to set a new menu item.
– Press Mor F6 to store new code settings and exit the operating menu.
– The balance returns to the weighing mode.
Note: See the section entitled “Balance Operating Menu Settings Masterpro LA” start-
ing on page 47 for an overview of the balance operating menu.
F2
