Sauter Components flexotron 300 User manual

46.102/1
flexotron
®
300
Sauter Components
RDT 300: Electronic controller for ventilation and air-conditioning
How energy efficiency is improved
Top quality algorithm for generation of c/o signal for changeover between heating and cooling mode,
and therefore ensuring energy saving operation of the system.
Areas of application
Weather-compensated flow temperature control in 2- and 4-pipe systems for heating/cooling. Activa-
tion of intelligent unitary controllers.
Features
•Clearly-laid-out operating unit with large LCD display and generously proportioned keypad
•6 controller models
•Plug-in memory for copying and documenting system parameters
•Fast commissioning thanks to preset parameters
•Room user panel with display available as accessory
•Weekly and annual switching program
•Automatic summertime/wintertime changeover
•Sealable sliding switch for selection of operating mode
Technical description
•Housing 144 x 96 mm made of flame-retardant, pure white thermoplastic (RAL 9010)
•4 universal inputs and 2 analogue inputs
•2 independent PI controllers
•3 continuous outputs and 6 relay outputs
•Reset, sequencing and limiting functions, as well as alarm and time functions
•Suitable for fitting on walls, in panels and on top-hat rails
•Electrical connection in base with screw terminals for wires up to 2.5 mm²
PI
Y06366
Type
1)
Setting range
°C Control modes Power supply Weight kg
RDT 300 F001 –30...150 P, PI 230 V~ 0,67
Ranges (depend-
ing on transmitter) Temperature
°C or K Percentage % Rel. humidity %rh Abs. humidity g/kg Enthalpy kJ/kg No unit of
measurement
Setpoint Xs–30...150 °C 0...100 0...100 0.0...20 0...100 –4999...4999
P-band 0.1...180 K 0.1...200 0.1...100 0.1...100 0.1...100 10...4999
4 universal inputs
3)
2 analogue inputs
Temperature Ni1000 (DIN 43760) 2×temperature
2) 3)
Ni1000 (DIN 43760)
Voltage 0(2)...10 V; R
i
= 100 kΩ
0...1 V, R
i
= 500 kΩOutputs
3)
Current 0(4)...20 mA, R
i
= 50 Ω3 continuous 0(2)...10 V, load > 5 kΩ
Potentiometer 2 kΩ(min.1 kΩ) 4 relays 5(2) A, 250 V~
2 relays 5(2) A, 24/250 V~
Power supply 230 V~ +10/–15%; 50...60 Hz Degree of protection IP 30 (EN 60529)
Power consumption 5 VA Protection class F001 230V II (IEC 60730)
P-band X
p
0,1....180 K
Integral action time T
n
0....9990 s Wiring diagram A09432
Dimension drawing M368900
Cycle time 1 s Fitting instructions MV 505711
Permissible ambient temp. 0...45 °C Operating instructions
Ambient humidity 5...80 %rh For end users 7000927 (Part 1)
non-condensing Commissioning 7000928 (Part 2)
Accessories
RDB 300 Remote-control unit see Section 46
0313516 . . . Additional operating instructions (7000927 and 7000928)
German 001, French 002, English 003, Italian 004.
0369746 001 Cover plate for the whole front; of transparent thermoplastic; sealable
0226187 002* Plug-in dummy for memory slot
0226187 003* Plug-in memory for flexotron
*) Dimension drawing or wiring diagram are available under the same number
1) Since several languages are available, please order the operating instructions as an accessory.
2) Can also be used as a binary input (gold contacts).
3) Protected against short-circuiting and excess voltage up to 24 V a.c. Current input for max 70 mA.
7146102003 04

46.102/2 RDT 300
Sauter Components
Operation
The RDT 300 controller has software modules with fixed configurations and captive standard parameters. The
software modules have definite links given by the control model. There are also modules for min./max. limitation.
All user parameters can be stored in the optional memory for documentation purposes or for copying when
installations are similar. All parameters are captive. The sliding switch (Hand/Automatic/Service) controls the
operating modes.
Service
In this mode, the controller can be matched to the control task by selecting the appropriate control model, and the
inputs, outputs and additional functions can be configured.
Automatic
Control mode with setpoints as per weekly programme.
Manual
The current positioning signals are adopted on entering this mode. They can be set by hand between 0 and 100%.
Any necessary adjustments to the control parameters and to the time programme can be made in this mode.
Additional technical data
Radio suppression EN 55014 and 55022 Storage and transport temp. –25...+65 °C
EMC EN 50082 -1 Conformity EN 12098 and CE
Complies with:-
Directive 2006/95/EC EN 60730-1/ EN 60730-2-9
EMC directive 2004/108/EC EN 61000-6-1/ EN 61000-6-3
EN 61000-6-4
Wiring diagram
Printed in Switzerland
Right of amendment reserved
N.B.: A comma between cardinal
numbers denotes a decimal point
© Fr. Sauter AG, CH-4016 Basle
7146102003 04
