Instruction Manual / Data sheet
SAUTER CO Y5
V. 1.0
06/2021
GB
CO Y5-BA-e-2120.docx

2 CO Y5-BA-e-2120.docx
GB
SAUTER CO Y5
V. 1.0 06/2021
Instruction Manual / Data sheet
Summarize:
1Short description........................................................................................... 3
2Available models............................................................................................ 3
3Introduction.................................................................................................... 3
4Warning notes................................................................................................ 3
5Warranty......................................................................................................... 4
6Detailed specifications.................................................................................. 4
7Wiring.............................................................................................................. 5
8Dimensions in mm......................................................................................... 5
9Certificate of Compliance.............................................................................. 5

CO Y5-BA-e-2120.docx 3
1 Short description
•Stainless steel IP66 (acc. to EN 60529) tension / compression load cell
•Suitable for test stands, force gauges, automation plants, etc.
•Accuracy OIML R60 G1
•Very low height
•Option on request accuracy C4
•RoHS conform
2 Available models
Capacity
Model
0,5 kg (≈5N)
CO 0.5-Y5
1 kg (≈10N)
CO 1-Y5
5 kg (≈50N)
CO 5-Y5
10 kg (≈100N)
CO 10-Y5
3 Introduction
Please pay attention to the notes of the operating manual: read these operating manual
carefully before commissioning, even if you already have experience with SAUTER
measuring cells.
After receiving the measuring cell, it should be checked in advance whether no
transport damage has occurred, whether the outer packaging or other parts or even
the article itself has been damaged. If any damage is evident, please inform SAUTER
GmbH immediately.
4 Warning notes
Observe the national accident prevention regulations.
Not correct executed use of the measuring cell can lead to serious injuries, death,
material damage and personal injuries. Use only by trained and experienced people.
Never load more than the max. capacity to a measuring cell. Overloaded measuring
cells no longer have the required accuracy. Overloaded or deformed measuring cells
are no longer allowed to use and must be changed quickly.
Never step under suspended loads.
Always fasten overload- or break security to your construction.
Pay attention to the allowed static and dynamic loads of the used equipment.
Let the measuring cells calibrate at regular intervals.
Only load the measuring cell in its specified load direction. Avoid lateral forces.
Control the measuring cells to deformations and cracks.
Measuring cells with 4-Conductor cable will change their characteristic value when
shortened or extended the cable length.

4 CO Y5-BA-e-2120.docx
5 Warranty
The warranty expires at:
•Disregard of the specifications of the operating manual
•Modification or opening the measuring cell
•Overload
•Mechanical damages
•Damage caused by liquids or media
•Natural loss
•Not correct installation
6 Detailed specifications
Output sensitivity ( FS )
mV/V
1.0 ± 10%
2.0 ± 10%
Maximum capacity ( Emax )
N
5, 10
50, 100
kg
0,5; 1
5, 10
Combined Error
%FS
≤± 0.1
Temp. effect on span
%F.S/10°C
± 0.05
Temp. effect on Zero
%F.S/10°C
± 0.05
Minimum dead load
Of Emax
0%
Safe overload
of Emax
200 %
Ultimate overload
of Emax
500 %
Zero balance
of FS
< ± 2 %
Excitation, recommended
voltage
V
10 ~ 15
Input resistance
Ω
680 ± 10
Output resistance
Ω
680 ± 10
Insulation resistance
MΩ
≥5000 ( at 100VDC )
Compensated temperature
°C
-10 ~+60
Operating temperature
°C
-20 ~ +80

CO Y5-BA-e-2120.docx 5
7 Wiring
Shielded, 4 conductor cable. Shield not connected to element.
4-wire diagram
8 Dimensions in mm
9 Certificate of Compliance
To have a look at the CE Declaration of Conformity, please click onto the following link:
