sauter CP P1 User manual

Sauter GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [email protected]
Tel.: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.sauter.eu
Instruction Manual / Data sheet
CP P1
V. 2.0
10/2023
GB
CP P1-BA-e-2320

2 CP P1-BA-e-2320
GB
SAUTER CP P1
V. 1.0 10/2023
Instruction Manual / Data sheet
Summarize:
1Short description........................................................................................... 3
2Available models............................................................................................ 3
3Introduction.................................................................................................... 3
4Warning notes................................................................................................ 3
5Warranty......................................................................................................... 4
6Detailed specifications.................................................................................. 4
7Wiring.............................................................................................................. 5
8Dimensions in mm......................................................................................... 5
9Certificate of Compliance.............................................................................. 5

CP P1-BA-e-2320
3
1 Short description
•Aluminum-alloy IP65 (acc. to EN 60529) single point load cell.
•Colorless anodized
•Suitable for pricing scales, bench scales, etc.
•Maximum platform size: 250 x 350 mm
•Accuracy OIML R60 C3
•Option on request accuracy C4 / C5
•OIML certificated
•RoHS conform
2 Available models
Capacity
Model
Cable length in m
3kg
CP 3-3P1
0,4
3kg
CP 3-2-3P1
2
5kg
CP 5-3P1
0,4
6kg
CP 6-3P1
0,4
8kg
CP 8-3P1
0,4
10kg
CP 10-3P1
0,4
10kg
CP 10-3-3P1
3
15kg
CP 15-3P1
0,4
15kg
CP 15-3-3P1
3
20kg
CP 20-3P1
0,4
30kg
CP 30-3P1
0,4
35kg
CP 35-3P1
0,4
35kg
CP 35-3-3P1
3
40kg
CP 40-3P1
0,4
50kg
CP 50-3P1
0,4
50kg
CP 50-2-3P1
2
3 Introduction
Please pay attention to the notes of the operating manual: read these operating
manual carefully before commissioning, even if you already have experience with
SAUTER measuring cells.
After receiving the measuring cell, it should be checked in advance whether no
transport damage has occurred, whether the outer packaging or other parts or even
the article itself has been damaged. If any damage is evident, please inform
SAUTER GmbH immediately.
4 Warning notes
Observe the national accident prevention regulations.
Not correct executed use of the measuring cell can lead to serious injuries, death,
material damage and personal injuries. Use only by trained and experienced people.

4 CP P1-BA-e-2320
Never load more than the max. capacity to a measuring cell. Overloaded measuring
cells no longer have the required accuracy. Overloaded or deformed measuring cells
are no longer allowed to use and must be changed quickly.
Never step under suspended loads.
Always fasten overload- or break security to your construction.
Pay attention to the allowed static and dynamic loads of the used equipment.
Let the measuring cells calibrate at regular intervals.
Only load the measuring cell in its specified load direction. Avoid lateral forces.
Control the measuring cells to deformations and cracks.
Measuring cells with 4-Conductor cable will change their characteristic value when
shortened or extended the cable length.
5 Warranty
The warranty expires at:
•Disregard of the specifications of the operating manual
•Modification or opening the measuring cell
•Overload
•Mechanical damages
•Damage caused by liquids or media
•Natural loss
•Not correct installation
6 Detailed specifications
Output sensitivity ( = FS )
mV/V
2.0 ± 0.2
Maximum capacity ( Emax )
kg
3, 5, 6, 8, 10, 15, 20, 30, 35, 40, 50
Max.number of load cell
intervals
nLC
3000
Ratio of min. LC verification
interval
Y = Emax
/ vmin
10000
Combined Error
%FS
≤± 0.0230
Minimum dead load
Of Emax
0%
Safe overload
of Emax
150 %
Ultimate overload
of Emax
300 %
Zero balance
of FS
< ± 2.0 %
Excitation, recommended
voltage
V
5 ~ 12
Excitation maximum
V
18
Input resistance
Ω
409 ± 6
Output resistance
Ω
350 ± 3
Insulation resistance
MΩ
≥5000 ( at 50VDC )
Compensated temperature
°C
-10…+40
Operating temperature
°C
-35…+65
Storage temperature
°C
-40…+70
Recommended torque on
fixation bolts
Nm
< 30kg: 6 >30kg: 10
> 30kg: 10

CP P1-BA-e-2320
5
7 Wiring
Shielded, 4 conductor cable. Shield not connected to element.
Cable diameter: Ø3.8mm. Standard cable length: look at available models chapter 2
Cable jacket in PVC.
4-wire diagram
Input(+)
Output(-)
Input (-)
Output(+)
Red
White
Black
Green
8 Dimensions in mm
9 Certificate of Compliance
The Certificate of Compliance can be downloaded from the website www.sauter.eu
