ProAV Video over IP
PAV-VIM8S-xx, PAV-VIM4S-xx, PAV-VOMVP1F-xx, PAV-VOMVP1C-xx
Deployment Guide
Document Number:
009-1551-00
Document Date:
November 2017
Document Supports:
da Vinci 8.7
!

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
2of 28
Contents
To access the link to the topics in this document, click the topic page
1!Introduction....................................................................................................4!
1.1!Before You Begin ...............................................................................................5!
2!Deployment Steps .......................................................................................6!
3!ProAV Video over IP Equipment Overview....................................... 7!
3.1!Box Contents and Specifications ................................................................. 7!
3.2!ProAV Video Input IP Transmitter............................................................... 7!
3.3!ProAV Video Output IP Receiver.................................................................9!
4!Wiring and Connections............................................................................11!
4.1!HDMI Cables .........................................................................................................11!
4.2!10G Ethernet.........................................................................................................11!
4.3!1G Ethernet/LAN.................................................................................................11!
4.4!IR Wiring ...............................................................................................................12!
4.5!RS-232 Wiring.....................................................................................................12!
4.6!Network.................................................................................................................13!
4.7!AC Power Connection .....................................................................................13!
4.8!Checking and Replacing the Fuse ..............................................................13!
5!Installation..................................................................................................... 14!
5.1!Install a Video Input IP Transmitter........................................................... 14!
5.2!Install a Video Output IP Receiver............................................................. 14!
6!Blueprint Configuration ............................................................................15!
6.1!Basic Blueprint Layout ....................................................................................15!
6.2!Adding a Video Input IP Transmitter to a Configuration ................. 16!
6.3!Adding a Video Output IP Receiver to a Configuration ....................17!
6.4!Source Profiles................................................................................................... 18!
6.5!Expansion ............................................................................................................ 18!
7!Best Practices.............................................................................................. 19!
8!System Monitor.......................................................................................... 20!
8.1!Video/Audio Status........................................................................................ 20!
8.2!Video/Audio Setting ........................................................................................21!
Appendix A: 10G Network Requirements................................................22!
Appendix B: Accessories................................................................................23!
Appendix C: UPS Recommendations ....................................................... 24!
Appendix D: EDID Optimization..................................................................25!

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
3of 28
Important Safety Information - Read First
Before installing, configuring, and operating Savant equipment and other
vendor equipment, Savant recommends that each dealer, integrator,
installer, etc. access and read all the required technical documentation.
Savant technical documentation can be located by visiting Savant.com.
Vendor documentation is supplied with the equipment.
Read and understand all safety instructions, cautions, and warnings in
this document and the labels on the equipment.
Safety Classifications in this Document
NOTE:
Provides special information for installing,
configuring, and operating the equipment.
IMPORTANT!
Provides special information that is critical to
installing, configuring, and operating the
equipment.
CAUTION!
Provides special information for avoiding
situations that may cause damage to
equipment.
WARNING!
Provides special information for avoiding
situations that may cause physical danger to
the installer, end user, etc.
Electric Shock Prevention
ELECTRIC SHOCK!
The source power poses an electric shock hazard that has the
potential to cause serious injury to installers and end users.
ELECTRICAL DISCONNECT:
The source power outlet and power supply input power sockets
should be easily accessible to disconnect power in the event of an
electrical hazard or malfunction.
Weight Injury Prevention
WEIGHT INJURY!
Installing some of the Savant equipment requires two installers to
ensure safe handling during installation. Failure to use two installers
may result in injury.
Safety Statements
Follow all of the safety instructions listed below and apply where
applicable. Additional safety information will be included where
applicable.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
15. To completely disconnect this equipment from the AC mains,
disconnect the power supply cord plug from the AC receptacle.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
4of 28
1 Introduction
The Savant ProAV Video over IP is a scalable UHD (4K) Video Matrix using a Savant verified 10G network switch. This document will guide the installer
through the process of installing, configuring, and adding Savant ProAV Video over IP devices to a RacePoint Blueprint® configuration.
The figure below shows the basic application the audio path can either come from the PAV-VIM8S as shown below, or it can be a separate output (Not
HDMI) into an audio switch like the SSA-3220. If a source was only going to be used with a TV and you are using the TV Speakers, then we will also support
HDMI audio through that entire path.
PAV-VIM8S
IP VIDEO SWITCH RECEIVERS
AUDIO SWITCH
AMPLIFIER
SSA-3220D
AMP-8125
10GbE Switch PAV-VOMVP1F
RECEIVER
PAV-VOMVP1C
RECEIVER
PAV-VOMVP1C
HDMI 2.0
Direct Attach
Duplex OM3 Fiber
CAT-6A
RCA Stereo
Speaker Wire
UP TO 8
DIGITAL SOURCES
UP TO 4K60 4:4:4 HDR
(FIBER)
(COPPER)

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
5of 28
1.1 Before You Begin
Read through this document in its entirety and ensure that the following required items are available:
1. Savant ProAV Video Input IP Transmitter 4K UHD with Control ..................................................................
(PAV-VIM8S or PAV-VIM4S)
2. Savant ProAV Single Port 4K UHD Video Output IP Receiver .......................................................................
(PAV-VOMVP1F or PAV-VOMVP1C)
3. 10G Network Switch that meets Savant requirements......................................................................................
(see Network Requirements)
4. Unique IDs (UID) of the ProAV Video over IP devices ......................................................................................
(located on the back of the units)
5. Savant Pro Host licensed and running da Vinci 8.7 or higher.........................................................................
(Mac based Pro Host only)
6. Savant Development Environment (SDE/MacBook®)........................................................................................
RacePoint Blueprint da Vinci 8.7 or higher
7. Source equipment that will be used in the system .............................................................................................
8. Displays that will be used in the system..................................................................................................................

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
6of 28
2 Deployment Steps
Follow these steps to successfully deploy Savant ProAV Video over IP devices. This page can be used as a checklist to record which steps have been
completed.
1. Review product specifications and connection details .....................................................................................
See ProAV Video over IP Equipment Overview
2. Install the Savant ProAV Video over IP devices...................................................................................................
See Installation
3. Install Savant qualified 10G Network Switch .........................................................................................................
See the Video over IP Network Configuration Guide
4. Add the Savant ProAV Video over IP devices into a RacePoint Blueprint® configuration..................
See Blueprint Configuration

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
7of 28
3 ProAV Video over IP Equipment Overview
3.1 Box Contents and Specifications
Refer to the Quick Reference Guide for these products located on the Savant Customer Community for Box Contents and Specifications.
3.2 ProAV Video Input IP Transmitter
Front Panel
On / Off Button
Reboots the main board (mcu) and power cycles the
IP Video transmit (Tx) cards
Reset Button
Press and Release - Resets the IP Video transmit
(Tx) cards.
Press and hold – Clears the network settings. Press
and hold button for 5 seconds until Status LED
blinks red rapidly; then release.
Power LED
Off – Device is off. No power applied.
Green – Main board is powered
Status 1 LED
Blinks Twice – Provisioned to the local network and is currently connecting to the Host
Rapid Blink (green) – The reset button was pressed and held for five seconds and the A/V over IP unit is
performing a factory reset. All network settings are cleared.
Short Off Blink – Firmware is updating
Status 2 LED
Reserved for future use.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
8of 28
Rear Panel
1 Gigabit
Ethernet
1G of reserved network data bandwidth commonly
used to connect any network compliant device to
transmit its data onto the Ethernet network by
sharing the 10G network link. 8-Pin RJ-45 female
connection.
This is a courtesy port it will not work for all network
functions. Example: Spanning tree devices are not
supported by this port.
IMPORTANT! Do not connect these ports to a
network switch.
10 Gigabit
Ethernet
SFP+ Housing; Used for connectivity to the 10G
Ethernet Network Switch
IMPORTANT! For all 10G connections, use only
Savant certified SFP+ Direct-Attach Copper (DAC)
cables, or Savant certified fiber and fiber connectors
along with Savant certified SFP+ modules.
Rx/Tx LEDs (10 GbE)
Rx – Link Activity LED indicator for all data received on the 10G connection
Tx – Link Activity LED indicator for all data transmitted from the 10G connection
HDMI In
19-Pin Type A HDMI female digital audio/video input.
Supports HDMI 2.0a
HDMI 2.0 compliant cable is required for 4K
content.
Power Input Module
100-240V AC 5A 50/60Hz power input module with On/Off switch.
I – Applies power to the device.
O – Removes power to the device.
NOTE: Includes a field replaceable 5A 250V Fast acting fuse.
RS-232 Control Port
3-pin Screw down plug-in connection.
Transmits and receives serial data to and from serial controllable devices. For pin-out information, refer
to the RS-232 Wiring section below
IR Control Port
3-pin Screw down plug-in connection.
Transmits IR signals via an IR Flasher
(5V tolerant) to devices with an IR input or IR receiver. For pin-out information, refer to the IR Wiring
section below.
Analog Audio Out
RCA Analog Audio Output.
Requires HDMI input PCM audio format.
Direct Line Level 2.1-VRMS Output
Push Buttons
Reserved for future use.
Ethernet
8-Pin RJ-45 female connection. Used to communicate with the Savant System Host.
Reserved
8-Pin RJ-45 female connection; Reserved for future use
Grounding
Chassis Ground (optional)

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
9of 28
3.3 ProAV Video Output IP Receiver
Front Panel
RSVD LED
Reserved for future use.
Blue - LED on by default.
Link TX LED
Off - No valid connection
Blue - Valid link
Blinking - Sending Ethernet Data
Link RX LED
Off - No valid connection
Blue - Valid link
Blinking - Receiving Ethernet
Video LED
Off - No video signal detected.
Blue - Video signal detected.
Power LED
Off - Device is off. No power applied.
Red - Main board is powered
P1
Reserved for future use.
RSVD
Reserved for future use.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
10 of 28
Rear Panel
Power Input
12V DC
HDMI Out
19-Pin Type A HDMI female digital audio/video
output.
Supports HDMI 2.0a
HDMI 2.0 complaint cable required for 4K
content.
Optical In
or
10 GbE
10G input from the Audio/Video over IP 10G
network switch.
SFP+ (PAV-VOMVP1F)
RJ-45 (PAV-VOMVP1C)
RS-232
4-pin Control Connector. Transmits and receives serial data to and from serial controllable devices. For
pin-out information, refer to the
RS-232 Wiring section below.
IR OUT
3.5 mm IR Emitter connection. Transmits IR signals via an IR Flasher (5V tolerant) to devices with an IR
input or IR receiver
IR IN
Not used.
LAN (C)
1G of reserved network data bandwidth commonly used to connect any network compliant device to
transmit its data onto the Ethernet network by sharing the 10G network link. 8-pin RJ-45 female
connection.
This is a courtesy port it will not work for all network functions. Example: Spanning tree devices are not
supported by this port.
IMPORTANT! Do not connect this port to a network switch.
Link LED
Solid Orange - Link is established.
Off – No link established
Link Activity LED
Green Blinking - Indicates data activity.
Off – No Activity
Audio Out
Reserved for future use.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
11 of 28
4 Wiring and Connections
4.1 HDMI Cables
Important items to consider when planning or installing a system using Video over IP devices.
– High quality HDMI cables are very important when passing UHD. Adding deep color and HDR raises the need for high quality cables.
– Long HDMI cables can introduce signal degradation so Savant recommends using the shortest possible HDMI cables.
4.2 10G Ethernet
Fiber (SFP+)
Enhanced small form-factor pluggable connection. Use a Savant certified Direct Access Copper (DAC) SFP+ cable to connect the chassis to the 10G
switch, or Savant certified fiber and fiber connectors along with Savant certified SFP+ modules.
Transport Distance
DAC cable
10 ft (3 m)
OM3 multi-mode Fiber
1000ft (300 m)
Copper (RJ-45)
RJ-45 10G Ethernet connection.
Transport Distance
Cat6
100ft (30m)
Cat6a
300ft (100m)
Cat7
300ft (100m)
4.3 1G Ethernet/LAN
Standard RJ-45 port that uses 1G reserved data bandwidth commonly used to connect any network compliant device to transmit its data onto the
Ethernet network by sharing the 10G network link. This is a courtesy port it will not work for all network functions. Example: Spanning tree devices are
not supported by this port.
IMPORTANT! Do not connect this port to a network switch.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
12 of 28
4.4 IR Wiring
PAV-VIMxS
IR connections are made using a 3-pin Control
Connector supplied with the device. The wire slips into
the hole and locks with a screw located at the top of
the connector.
PAV-VOMVP1x
IR connection are made using 3.5 mm IR Emitter
supplied with the device.
IMPORTANT: IR Wiring Precautions
Ensure that all IR emitters are within 15 feet (4.6 meters) from the controller’s location.
Use of 3rd party blinking IR emitters with Talk Back is not recommended. These types of emitters can draw voltage away from the IR signal that can
degrade IR performance.
4.5 RS-232 Wiring
PAV-VIMxS
Serial control connections are made using a 3-pin Control Connector
supplied with the device. The wire slips into the hole and locks with a
screw located at the top of the connector.
PAV-VOMVP1x
Serial control connection are made using a 4-pin Control Connector
supplied with the device. The wire slips into the hole and locks with a
screw located at the top of the connector.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
13 of 28
4.6 Network
The PAV-VIMxS uses a standard RJ-45 port complying with IEEE 802.3 Ethernet standards. This port is used for communication with the Savant Host.
The VOMVP1x uses a shared Ethernet connection from its 10G connection.
4.7 AC Power Connection
SURGE PROTECTION!
Use a surge-protected circuit for all components and power supplies requiring 100/240V (AC 50/60 Hz) source power.
ELECTRICAL DISCONNECT!
The source power outlet and power supply input power sockets should be easily accessible to disconnect power in the event of an electrical hazard or
malfunction.
Power Management Recommendations
Savant recommends a pure sine wave uninterruptible power supply (UPS) with the ability to shut down the Savant Host before the battery runs out of
power. Never remove power from the Savant Video over IP devices before shutting it down. See Appendix C: UPS Recommendations for more
information.
4.8 Checking and Replacing the Fuse
Only the PAV-VIMxS has a field replaceable fuse. For fuse information please see the products Quick Reference Guide.
ELECTRIC SHOCK HAZARD:
Disconnect the unit from AC power by removing the power cord from the AC outlet and the unit before replacing the fuse.
IMPORTANT: The orientation of the cartridge within the unit and location of the fuse within the cartridge are crucial to proper operation. Make note of the
orientation of the cartridge and the fuse location within the cartridge before removing.
1. Disconnect the unit from AC power by removing the power cord.
2. Open the fuse cover on the AC power input using a flat head
screwdriver or similar thin flat head tool. This will allow access to
the fuse cartridge.
3. Using a flat head screwdriver or similar thin flat head tool, gently
loosen the cartridge and pull the cartridge out of the unit slowly. As
the cartridge is removed, make note of the orientation, as it is
important to proper operation.
TIP: Mark the chassis and fuse holder with a marker in order to align
when replacing.
4. Remove the old fuse from the cartridge and discard.
5. Gently place the new fuse in the cartridge and place the cartridge
part way into the receptacle aligning it as defined in the diagram.
6. Gently press on the cartridge the rest of the way until it seats into
the terminals at the rear of the slot.
NOTE: If any resistance is encountered during seating the cartridge, DO NOT apply more pressure. Stop pressing on the cartridge, remove it, verify the
orientation, and repeat step.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
14 of 28
5 Installation
5.1 Install a Video Input IP Transmitter
The ProAV Video Input IP Transmitter can be mounted in a 3U rack style enclosure and is compatible with all standard 19-inch NEMA rack mounts. The
rack ears need to be attached prior to placing in a rack
5.2 Install a Video Output IP Receiver
The ProAV Video Output IP Receiver can be placed on a solid flat surface or can be mounted on a wall with the included mounting brackets. If
installing this unit behind a display, ensure enough air can pass though the grooves on the top of the unit. This will maximize heat dissipation. Savant
recommends aligning the grooves vertically as shown below.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
15 of 28
6 Blueprint Configuration
Required Devices
– Savant Host
– ProAV Video over IP Transmitter
– ProAV Video over IP Recevier
– 10G Network Switch
– Video Sources
– HD/UHD Displays
6.1 Basic Blueprint Layout

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
16 of 28
6.2 Adding a Video Input IP Transmitter to a Configuration
In an open Blueprint configuration
1. Click Show Library.
2. Click the All Manufacturers.
3. Select Savant.
4. In the Search bar type VIM.
5. Select the Video Input IP Transmitter that is needed and drag it into a Shared Equipment zone.
HELPFUL INFO:
It is recommended to place any type of A/V switch in a Shared Equipment zone. If placed in a User zone the outputs cannot leave that zone.
6. Name the Device.
7. Place the Video IP Transmitter in the layout window.
8. Select the Video Input IP Transmitter.
9. Open Inspector.
10. Enter the UID.
NOTE:
The Ethernet connection is implied in Blueprint.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
17 of 28
6.3 Adding a Video Output IP Receiver to a Configuration
In an open Blueprint configuration
1. Click Show Library.
2. Click the All Manufacturers.
3. Select Savant.
4. In the Search bar type VOM.
5. Select the Video Output IP Receiver that is needed and drag it into the User zone that is will be used.
6. Name the Device.
7. Place the Video IP Transmitter in the layout window.
8. Select the Video Input IP Transmitter.
9. Open Inspector.
10. Enter the UID.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
18 of 28
6.4 Source Profiles
Some device profiles require a “AVoIP” version of the profile to be combatable with the control connections of the Video over IP devices. Below is a
image of one of these profiles with the AVoIP tag highlighted.
This example supports several model numbers. While searching for devices to add to the configuration if two version appear in the search and the
device is going to be controlled by a Video over IP control port use the profile with the AVoIP tag in the profile name.
6.5 Expansion
The Savant ProAV Video over IP system has unlimited scalability. The limit is the amount of ports on the 10G switch. For instance, on a 24 port 10G
Network switch: 1x23, 2x22, and so on up to 23x1. In addition, add as many receivers required in the installation based on the number of displays.
Every source and display require a port on the 10G switch.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
19 of 28
7 Best Practices
Once the system is installed and the configuration has been uploaded to the Host, there are a couple best practices to test and the system ProAV Video
over IP system.
Initial Audio and Video setup/testing should be done using the default EDID. The default EDID has support for PCM audio up to 8 channels and video
resolutions up to 4k 60hz 4:2:0 8-bit.
Testing
Every source should be tested with every A/V zone. Savant recommends testing a single source with one A/V zone at a time.
1. Activate the first Video source to a single Zone.
2. Does Video pass?
a. NO: Check System Monitor for the resolution of the Input and then the output, Scale the VOM to 1080p.
If 1080p passes there may be an issue with either the TV or cabling. Replace HDMI cable and test again.
b. YES: Check Audio
3. Does Audio pass?
a. NO: In System Monitor select the Audio downmix check box on the VOM. If audio is still not present verify audio is enabled on the source.
b. YES: Continue to the next Zone.
4. Repeat with the same source until all Video zones have been tested. Repeat with all other Video sources in the same manner as shown above.
After this testing is complete. Add more advanced EDIDs and test again.

ProAV Video over IP Deployment Guide
Copyright © 2017 Savant System, LLC
009-1551-00 | 171130
20 of 28
8 System Monitor
In System Monitor, there is a AVoIP Info tab for information gathering and changing settings. This System Monitor tab will only display in a system that has
the Video over IP devices in the configuration.
Chassis
List of Video over IP devices in the configuration.
Logical IOs
List of inputs or outputs on the device selected in the
Chassis window.
Settings
Video and Audio settings, down mixing audio or
video scaling settings can be changed in this section.
See Video/Audio Settings section below for more
information.
Status
Displays the current status of selected I/O. See
Video/Audio Status section below for more
information.
8.1 Video/Audio Status
Video Format – Displays active video resolution and frame rate.
HDCP Protected – Displays if HDCP is enabled
HDMI 2.0 Supported – Displays if the connected device supports HDMI 2.0.
Source HDCP Version – Displays the HDCP version from the source content.
Color Space – Displays the color format used in the current Video
Color Depth – Displays the active number of bits for color data.
Source Stable – Displays if video is received from the connected source.
Multi Channel Downmix – Displays the status of Audio down mixing. Not all devices have audio down mixing.
