Savewo FreshQ User manual

User Manual
and Warranty Terms
www.savewo.com
Portable
Electrolytic Sterilizer
User Manual
≤
ELIMINATE
COVID-19^ & Bacteria*
in 10 seconds
^EN14476 test
*EN1276 test
DISINFECTION RATE ≥99.999%
FRESH NATURAL DISINFECTION
Latest Update: 20220722

How It Works
Product Structure Diagram
Nozzle Press Handle
Bottle Body Electrolytic Indicator
Electrolytic Electrode Electrolytic Net
Power Button
1
5
2
6
3
7
1
2
3
7
46
5
Product Specification
4
Portable Electrolytic
Sterilizer
Hypochlorous Acid
Mini Spray Bottle
10ml
Table Salt
Measuring Spoon
1g
USB-C
Charge Cable
User Manual &
Warranty Terms

How to use
Fill the bottle with tap water to the
mark. (Do not add more than 300ml
of water. It may not work otherwise)
Use the supplied Spoon to
add an appropriate amount of
table salt. (Please follow “The
Effectiveness of Chlorine Content” )
Tighten the nozzle and
shake the bottle evenly
Press the Power Button once
to switch to Mode 1;
Both the button and electrolytic
indicator will turn blue.
A buzzing sound will be heard
and bubbles will appear.
Press the power button to turn
on the device. The Power
Button turns blue when the
generator is in standby mode.
Press the Power Button twice to
switch to Mode 2. The button will turn
purple and the electrolytic indicator
will stay blue in colour.
A buzzing sound will be heard and
bubbles will appear.
The electrolysis will stop
automatically with the lights
off after 3-5 minutes.
After the buzzing sound
ceases, the disinfectant is
ready to use.
1g
How to measure
The Spoon measures 1g of salt (Table salt is recommended)
300ml Table
Salt
1.
5.
2.
Shake
Gently
3.
4.
Mode 1
Mode 1
Mode 2
Mode 2
5
3mins
mins

Disinfection: Eliminates 99.999% of bacteria and harmful micro-organisms.
Deodorization: Sprays or wipes with a dishcloth can reduce unpleasant odours.
Washing: Removes bacteria from the surface of fruits and vegetables.
* Wash fruits and vegetables with running water after disinfection with hypochlorous acid.
* Use salt-free tap water for electrolysis for the purpose of food washing.
Please refer to the table titled “The Effectiveness of Chlorine Content”.
The bactericidal and deodorization rate of hypochlorous acid disinfectant are
99.999%, it will dissociate back into water after a period of time.
Only table salt and tap water are needed with no harmful chemicals used,
so is safe for human contact.
Function and Effect
Safety of Hypochlorous Acid Disinfectant
Table salt Tap water
Electrolysis
Hypochlorous
Acid
Table salt (NaCl) dissolved in water (H2O) in the bottle of SAVEWO FreshQ
gives a brine solution, which forms sodium hydroxide (NaOH), and chlorine
(Cl2) and hydrogen (H2) gases by electrolysis.
Chlorine (Cl2) dissolves in water (H2O) to form hydrogen chloride (HCl) and
hypochlorous acid (HClO)
Hypochlorous acid (HClO) is a strong disinfectant, but also an unstable
substance. It will decompose into chlorine and water within a short period of
time when it is exposed to light and heat.
FreshQ produces a high performance, low residue disinfectant with just tap
water and table salt. Produces an affordable, safe and effective
multi-purpose hypochlorous acid disinfectant in 3-5 minutes.
* The above processes only reflect a portion of the chemical reactions involved.
2NaCl+2H2O → 2NaOH+Cl2↑+H2↑
Cl2+ H2O⇌HCl + HClO
How It Works
Electrolysis

Suggested Setting
Concentration of
Disinfectant*
(ppm)
Salt (g) Mode Suggested Setting
Ultra-Mild
Concentration
<20ppm
Mild
Concentration
20-50ppm
Medium
Concentration
100-200ppm
Strong
Concentration
200-300ppm
Ultra-Strong
Concentration
300-500ppm
1
0
0
1
3
*The above concentrations of disinfectant are electrolysed with 300ml tap water.
The above data was extracted from Intertek test reports and SAVEWO internal
test data.
(Test Report No.: HKGH0284884303 and HKGH02858841)
3
Mode 1
Mode 2
Mode 1
Mode 2
Mode 1
Mode 2
Disinfecting baby toys and pet products
Suitable for disinfecting clothing and textile
products
Disinfecting electronic products such as
mobile phones, laptops, TV screens and
waterproof watches (Electronic products
should be disinfected with a damp cloth with
disinfectant)
•
•
•
Deodorizing shoe cabinets, toilets and pet
products
Disinfecting floor mats, floors and outer soles
Disinfecting vehicle interior
•
•
•
Washing fruits and vegetables
•
Suitable for disinfecting furnitures and
beddings
•
Suitable for disinfection usage in settings
such as household, office, toilet etc.
•
Disinfecting hands and tableware before
meals
Disinfecting maternal and infant products
•
•

Bactericidal Efficacy
Bactericidal
Rate
≥99.999%
≥99.999%
≥99.999%
≥99.999%
FreshQ passed the COVID-19 test derived from the method of EN14476 test
and is verified to eliminate ≥ 99.999% of COVID-19 in 10 seconds.
FreshQ passed EN 1276 test standard and is verified to kill >99% of bacteria on
hands and surfaces of objects in 10 seconds.
* The above germicidal efficacy was tested with the Ultra Strong formulation of FreshQ.
(Electrolysis with 3g table salt in 300ml tap water under Mode 2)
* According to the requirement of the EN 1276 standard, an effective
disinfectant should reduce a minimum of 99.999% of the tested bacteria within a specified
contact time.
* The above data is extracted from Intertek test reports.
(Test Report No.: HKGH0285411901, HKGH0285411903 and HKGH02870816)
Microbiological
Test
Exposure
Time
Escherichia
coli K12
Staphylococcus
aureus
Enterococcus
hirae
Pseudomonas
aeruginosa
10s
≥99.999%
COVID-19 10s
10s
10s
10s
Degradation of Effective Chlorine Level
According to the result of Intertek test report, hypochlorous acid
disinfectant produced by FreshQ can be kept for at least
5 days at room temperature and avoid exposure to the sunlight.
(Test Report No.: HKGH02862142)
460
430
400
370
340
310
280
0123456
(Days)
(ppm)

External Cleaning
Wipe the machine with a dry towel.
* Do not use chemicals or general cleaning agents to clean
the outside of the bottle.
Internal Cleaning
Add no more than 300ml of tap water to the bottle.
Cover the lid and shake the bottle several times. Clean the product
with water before using it again.
!
How to clean
1. Use tap water to rinse the food again after disinfection.
2. Match the concentration of disinfectant according to the different
usage scenarios.
3. The hypochlorous acid disinfectant may contain a slight bleach-like
odour.
4. There is an exhaust at the nozzle for ventilating the pressure
generated while the FreshQ sterilizer is operating. You may
experience a small amount of leakage when shaking or using the
product.
5. Do not spray on any electrical appliance. It may seep into the
appliance and causes damage or malfunctioning.
6. Please keep the hypochlorous acid disinfectant in a cool, dry place
and avoid exposure to the sunlight.
7. Do not spray hypochlorous acid disinfectant towards the face and
eyes.
8. Do not drink FreshQ hypochlorous acid disinfectant.
9. In case of contact with eyes, nose or mouth, rinse immediately and
thoroughly with plenty of water.
10.If skin allergic reaction occurs after using this product, please stop
using it immediately. If symptoms persist, please seek medical
advice.
11.Please keep the hypochlorous acid disinfectant out of children's
reach.
!Precautions

Warranty Terms & Conditions
Important Notes:
• This Product Warranty Service is applicable to products purchased on
Savewo Website and authorized distribution channels
• While providing service under warranty period, customer must present the
original purchase invoice issued by Savewo Distribution Limited or other
authorized distribution channels to our staff for verification, otherwise, the
service would be on a charge basis. (Please refer to Terms and Conditions for
details)
• For details of Terms and Conditions, please refer to the website of Savewo
Distribution Limited: https://www.savewo.com/warranty/freshQ
• In case of dispute, the decision of Savewo Distribution Limited shall be final.
Terms and Conditions
Savewo Distribution Limited (“The Company”) offers 12 months warranty service
for the product from the date of purchase. Repair and maintenance of the product
beyond the stated warranty period will be charged.
1. Any malfunction, damage, breakdown by improper usage, The company has
no responsibilities for any direct or indirect loss or damages to any person or
property.
2. Customer is responsible for delivering the product to our service centres or
designated locations, and to pick up the repaired product from the same
location when warranty service is required.
3. Warranty service is valid only in Hong Kong. Customer is required to present
the official purchase invoice issued by the company or the dealers of Hong
Kong to our technician for verification when service is rendered
4. The company will offer customers maintenance service for free under normal
use for the applicable period (excluding any surface, cabinet, consumptive
parts, accessories and consumables).
5. Warranty service does not cover the following items. Additional charges shall
be levied if services are required.
(a) The product has been explicitly or implicitly modified, tampered with,
altered or repaired in any way by non-authorized person.
(b) The product has been damaged through misuse, negligence, neglect of
care after use, power interruption or abnormal voltage input, accident,
natural calamities, or due to ingress of insects, foreign matter or liquid,
corrosion, normal wear and tear or external factors.
(c) The product has been damaged due to use contrary to that indicated in
the instruction manual.
6. All terms stated are subject to change without further notice. The Company
retains final decision in case of dispute.

Product
Model
Product
material
Battery
Capacity
Dimensions
Specification
Portable Electrolytic Sterilizer
50 minutes use on a full charge
3 minutes of electrolysis: approx. 15 times
5 minutes of electrolysis: approx. 10 times
Type-C
300ml
FQ300
PC5V 1A
2000mAh Li-Po
265x75x75mm
Product
Name
Voltage
Charging
Method
Capacity
Duration
of Us
SAVEWO Service Centre
G/F, 266-270 Texaco Road,
Tsuen Wan, N.T., Hong Kong
www.savewo.com
Customer Service and
After-Sales Support Hotline
Customers Service and
After-Sales Support Hotline
[phone]
@savewohk Intertek Reports
FreshQ
Portable Electrolytic Sterilizer
