Savoy EASY FIT DECKING KIT User manual

EASY FIT DECKING KIT ASSEMBLY INSTRUCTIONS
STEP 1
Thank you for choosing this Easy Fit Decking Kit from Savoy Timber.
PLEASE RETAIN FOR FUTURE REFERENCE: READ CAREFULLY!
Important: Assembly of
this Easy Fit Decking Kit
requires two people.
Assembly should take
approx 1/2 a day.
Project Essentials: Sold Separately
DRILL
TAPE MEASURE
GOGGLES
SCREWDRIVER
SAW
Cut Joints (B) to suit decking kit size (e.g. 2.4m x 2.4m)
Position the JOISTS equally from centre to centre and
secure.
Position the NEWEL posts as shown on the
inside of the base frame.
Secure using M10 Coach Bolts.
STEP 2 Go to step 3 if you are
not fixing a handrail.
Pre-drill all holes
Pre-drill all holes
10x4
LEVEL
Timber
DIY Made Easy!
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
(10X4) X 2
DUST MASK
M10 Coach
Bolts
B
B
B
B
B
B
A
A

STEP 3STEP 3
STEP 4
STEP 5
2”
STEP 6
Position the DECKING BOARDS equally spacing them
across the entire deck base. Secure to each supporting
joist using 2 screws on each deck board.
If you are fitting a handrail and balustrade you will need to
notch the first and last deck board around the newel post
using a handsaw.
2” X 2
2” X 2
2” X 2
2” X 2
2” X 2
2” X 2
Position the HANDRAIL
BRACKETS 930mm from the
deck base and secure to
newel.
Measure between the newel posts and cut 3 equal
lengths of HANDRAIL.
Position the SPINDLES equally
spacing them across the entire
handrail. Secure using
2 screws for each spindle.
Position the remaining
HANDRAIL on top and secure.
Secure the constructed BALUSTRADE to the handrail
brackets and the decking boards as shown.
Approx
6mm
