SBC PCD7.D23 Series User manual

Document 26/795; Edition EN10 │ 2013-10-14
Manual
Serie PCD7.D23x Graphic Terminals

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Content
0-1
0
0 Content
0 Content
0.1 Document History ........................................................................................... 0-3
0.2 About this manual ........................................................................................... 0-3
0.3 Brands and trademarks .................................................................................. 0-3
1 Quickstart
1.1 Introduction ..................................................................................................... 1-1
1.2 Use of the PCD7.D230, D231 and D232 terminals as remote displays for PCS1... 1-2
1.2.1 Congurationwithoneterminalasremotedisplay ......................................... 1-2
1.2.2 CongurationwithoneterminalasseconddisplayforPCS1 ......................... 1-4
1.2.3 CongurationwithtwoormorePCD7.D230,D231andD232
terminalsasremotedisplaysforPCS1(mixingnotpossible)......................... 1-5
1.3 Use of the PCD7.D230, D231 or D232
as remote displays for the Saia PCD®range .................................................. 1-7
1.3.1 Congurationforoneterminal......................................................................... 1-7
1.3.2 Congurationforseveralterminals(mixingisnotpossible)............................ 1-9
1.4 Specialcongurationwithseveralterminals
withRS-422FreeTerminalProtocol(MultiDrop)(mixingisnotpossible) ..... 1-11
1.5 Powersupply .................................................................................................. 1-12
1.6 Communication connector, D-Sub 9 pole ....................................................... 1-12
1.7 Dimensions ..................................................................................................... 1-12
2 Hardware-System Overview
2.1 Function .......................................................................................................... 2-1
2.2 TechnicalDataPCD7.D230,D231andD232................................................. 2-2
2.2.1 Blockdiagram ................................................................................................. 2-3
2.3 Standard interface connection cables............................................................. 2-4
2.3.1 PCD7.K412:forinterfaceRS-232(withouthandshakeRTS/CTS)................. 2-4
2.3.2 PCD7.K413:forinterfaceRS-232................................................................... 2-4
2.3.3 PCD7.K422:forinterfaceRS-232(withouthandshakeRTS/CTS)................. 2-5
2.3.4 PCD7.K423:forinterfaceRS-232(withhandshakeRTS/CTS)...................... 2-5
2.3.5 PCD7.K456:forinterfaceRS-485 .................................................................. 2-6
2.4 User created interface connection cables....................................................... 2-7
2.4.1 ConnectioninRS-422mode(singleterminal)................................................ 2-7
2.4.2 ConnectioninRS-485 .................................................................................... 2-7
2.4.3 ConnectioninRS-422MultiDrop(examplewithPCD7.F110module) .......... 2-8
2.4.4 ConnectioninRS-232(withHandshakeRTS/CTS)
foranautonomousversionwithout24VDCpowersupply ............................. 2-8
3 Communication mode setting
3.1 Serial mode – Baudrate and Controls............................................................. 3-1
3.1.1 Standardmodes(availablewithD23x,FW25)............................................... 3-1
3.1.2 Specialmodes(availablewithD23x,FW25) ................................................. 3-2
4 Software
4.1 Basic commands............................................................................................. 4-1
4.1.1 ThePCD7.D23xreturncodesindirectmode ................................................. 4-1
4.1.2 ThePCD7.D23xdisplayreturnset ................................................................. 4-3
4.1.3 Serial lock command to acces in the setup mode .......................................... 4-4
4.2 All commands ................................................................................................. 4-5

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Content
0-2
0
4.3 AdvancedCommands..................................................................................... 4-10
4.4 FreeTerminalProtocolMode.......................................................................... 4-13
4.5 ReturncodesinFTPmode............................................................................. 4-17
4.6 CompatibilitybetweenPCD7.D202,D160/170commands
and PCD7.D232, D231 commands................................................................. 4-19
4.6.1 PCD7.D202,D160/170(andD250)commands
nolongerusedwiththePCD7.D232/D231terminals .................................... 4-19
4.6.2 Auto-repetitionupgradecommands................................................................ 4-19
5 Handling
5.1 SetupMenu..................................................................................................... 5-1
5.2 Useofthefunction“Playas”ofPCD7.D230withtheHMI-Editor................... 5-5
5.3 CreationofuserdialoguewiththeHMI-Editor ................................................ 5-6
6 Maintenance
6.1 Care ................................................................................................................ 6-1
A Appendix
A.1 Icons ............................................................................................................... A-1
A.2 Code maps...................................................................................................... A-2
A.3 Contact ........................................................................................................... A-4

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Content
0-3
0
Document History | Brands and trademarks
0.1 Document History
Date Version Changes Remarks
2003-04-28 EN01 -PublishedEdition
2003-06-30 EN02 -Chap.4.1-4.3,new,add.,corr.
2003-10-15 EN03 - Chap. 2, colours free cable ends
2004-03-31 EN04 -Chap.1,page1-5,1-12,Add.ofD231and
D232
2004-05-01 EN05 - Chap. 3, Communication
2005-02-25 EN06 - Chap. 2 and chap. 4 corr.
2005-04-01 EN07 - Corrections in all chapters
2009-09-28
2009-12-02
EN08 -Errorin2.4.2Picture«Connectionin
RS-485»
4.1.3newGrammaticalcorrections
in Ch04, Ch05 and Ch0A
2010-04-08 EN09 - Chapter 2.3: PCD7.K413 -> D-Sub connector
2013-10-14 EN10 -Newlogoandnewcompanyname
0.2 About this manual
Seethesectionintheappendixinrelationtosomeoftheterms,abbreviationsand
the references used in this manual.
0.3 Brands and trademarks
Saia PCD®andSaiaPG5®
areregisteredtrademarksofSaia-BurgessControlsAG.
Technicalmodicationsarebasedonthecurrentstate-of-the-arttechnology.
Saia-BurgessControlsAG,2003.©Allrightsreserved.
PublishedinSwitzerland

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-1
1
Introduction
1 Quickstart
1.1 Introduction
This manual covers the technical aspects of the PCD7.D23x graphic terminals.
The aim of the Quickstart chapter is to talk about the essentials regarding the use
and installation aspects of PCD7.D23x components. We are talking about:
● Howtousetheterminals
as remote displays for PCS1
as remotedisplaysforthewholeSaiaPCD®range
in a specialcongurationwithRS-485andRS-422 Free Terminal Protocol
● HowtoconguretheterminalswiththeHMI-Editor
● Powersupply
● The communication connector
● Dimensions
Details about the
● Hardware
● Communication
● Software
● Handling and
● Maintenance
can be found in separate chapters. The appendix covers more general topics like
information about the iconsweused,charactermapsandsoon.

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-2
1
Use of the PCD7.D23x terminals for PCS1
1.2 Use of the PCD7.D230, D231 and D232 terminals as remote displays for PCS1
1.2.1 Congurationwithoneterminalasremotedisplay
Valid for: PCS1.C822, C823, C882, C883 (without integrated display)
A - Basic equipment with RS-232 interface
D230 (or D231 or D232)
● Usetheport2(withorwithoutHandshake)oftheterminalblockX3
or
● usetheport1(withorwithoutHandshake)oftheterminalblockX4
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 or 19200 bps
Serialmode: RS-232RTS/CTS
Use of HMI-Editor V 1.3 (recommended):
Terminaltype: D230with8×20(orD231orD232)
Terminal topology: single terminal
Serial line: 2 or respectively 1
Typeofserialline: RS-232
Baudrate: 9600 or 19200 bps
Handshake:  RTS/CTS
Hardware connection:
Connectioncable(length:2.5m)betweenPCS1andPCD7.D23x:PCD7.K423

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-3
1
Use of the PCD7.D23x terminals for PCS1
B - Extra PCD7.F110 interface for RS- 422
D230 (or D231 or D232)
● RS-422:usetheport1ofthe
terminalblockX4
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 or 19200 bps
Serialmode: RS-422XON/XOFF-[orXON/XOFF(R)]*
Use of HMI-Editor V 1.3 (recommended):
Terminaltype: D230with8×20(orD231orD232)
Terminal topology: single terminal
Serial line: 1
Typeofserialline: RS-422
Baudrate: 9600 or 19200 bps
Handshake:  SoftwareXON/XOFF
Connection diagram: see chapter 2.4
* ThereducedXON/XOFFmodeisasave,nonlocking,XON/XOFFmodewiththe 
 PCD7.D23xalwaysresponding.IfusingXON/XOFF,itisrecommendedtousethisre-
 ducedmode,especiallyifyounoticethataftersometimeofuseyouhavetoswitchthe
 poweroffandonagaintogetthePCD7.D23xrespondingagain.Inthismode,thetrafc
from the Saia PCD®tothePCD7.D23xissupervisedbyowcontrol,intheotherdirection,
from the PCD7.D23x to the Saia PCD®,thereisnoowcontrol
Saia PCD®..... PCD7.D23x
owcontrol
noowcontrol

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-4
1
Use of the PCD7.D23x terminals for PCS1
1.2.2 CongurationwithoneterminalasseconddisplayforPCS1
Valid for: PCS1.C820, C821, C880, C881 (with integrated display)
A - Extra PCD7.F120 interface for RS-232
D230 only
The integrated display is connected physically on the port 2.
● Usetheport1(withorwithoutHandshake)oftheterminalblockX4.
Don’tusetheport2oftheterminalX3(reservedforinternaldisplay)4.
PCD7.D230 setup (recommended):
(see also chapter 3)
Baudrate: 9600 bps
Serialmode:  RS-232RTS/CTS
Use of HMI-Editor V 1.3 (recommended):
Terminaltype:  D230with8×20(only)
Terminaltopology:  Multipointterminals
Numberofchannels: 2
Serial line: 2 (internal display) and 1 (PCD7.D230)
Typeofserialline:  RS-232
Baudrate: 9600 bps
Handshake:   RTS/CTS
Hardware connection:
Connectioncable(length:2.5m)betweenPCS1andPCD7.D230:PCD7.K423

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-5
1
Use of the PCD7.D23x terminals for PCS1
1.2.3 CongurationwithtwoormorePCD7.D230,D231andD232
terminalsasremotedisplaysforPCS1(mixingnotpossible)
Valid for: PCS1.C822, C823, C882, C883 (without integrated display)
A - Basic equipment with RS-232 interface + Extra PCD7.F120 interface for RS-232
Congurationwith2PCD7.D230terminals(or2D231or2D232)
● Usetheport2(withorwithoutHandshake)oftheterminalblockX3
● Usetheport1(withorwithoutHandshake)oftheterminalblockX4
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 bps
Serialmode:  RS-232RTS/CTS
Use of HMI-Editor V 1.3 (recommended):
Terminaltype:  D230with8×20(orD231orD232)
Terminaltopology:  Multipointsterminal
Numberofchannels: 2
Serial line: 2 and 1 corresponding to the terminal 1 and 2
Typeofserialline:  RS-232
Baudrate: 9600 bps
Handshake:   RTS/CTS
Hardware connection:
Connectioncable(length:2.5m)betweenPCS1andPCD7.D23x:PCD7.K423
B - Extra PCD7.F110 interface for RS- 485

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-6
1
Use of the PCD7.D23x terminals for PCS1
Congurationwith3PCD7.D230or3D231or3D232
● Usetheport1oftheterminalblockX4
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 or 19200 bps
Serialmode:  RS-485FTP
Addresses: same number of different addresses
as number of terminals: from 01 to 31
Use of HMI-Editor V 1.3 (recommended):
Selecttheterminal:  D230with8×20(orD231orD232)
Terminal topology: terminal bus
Terminal number: xx terminals
Terminallist:  number1,2,3,…31correspondingtotheidentication
number (address) of each terminals.
Serial line: 1
Typeofserialline:  RS-485
Baudrate: 9600 or 19200 bps
Handshake:   None
Connection diagram: see chapter 2.4
Forfurtherdetailsseethemanual“HMI-Editor”26/768.
General restriction: Don’tusethePGUportofthePCS1asRS-232serialportbe-
causeitisreservedforModem!!!

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-7
1
Use of the PCD7.D23x terminals for the whole Saia PCD®range
1.3 Use of the PCD7.D230, D231 or D232
as remote displays for the Saia PCD®range
1.3.1 Congurationforoneterminal
A - with RS-232
D230 or D231 or D232
● UseoneportRS-232(withHandshake)
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 or 19200 bps
Serialmode:  RS-232RTS/CTS
Use of HMI-Editor V 1.3 (recommended):
Terminaltype:  D230with8×20(orD231orD232)
Terminal topology: single terminal
Serialline:   xx(portnumber)*
Typeofserialline:  RS-232
Baudrate: 9600 or 19200 bps
Handshake:   RTS/CTS
*YoucanusethePGUportasRS-232serialline.Inthiscase,selectPGUline:Yes.
Hardware connection:
Connectioncablelength:2.5m,betweenSaiaPCD®andPCD7.D23x:PCD7.K423

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-8
1
Use of the PCD7.D23x terminals for the whole Saia PCD®range
B - with RS- 422
D230 or D231 or D232
● UseoneportRS-422
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 or 19200 bps
Serialmode:  RS-422XON/XOFF-[orXON/XOFF(R)]*
Use of HMI-Editor V 1.3 (recommended):
Terminaltype:  D230with8×20(orD231orD232)
Terminal topology: single terminal
Serial line: xx (port number)
Typeofserialline:  RS-422
Baudrate: 9600 or 19200 bps
Handshake:   XON/XOFF
Connection diagram: see chapter 2.4
* ThereducedXON/XOFFmodeisasave,nonlocking,XON/XOFFmodewiththe 
 PCD7.D23xalwaysresponding.IfusingXON/XOFF,itisrecommendedtousethisre-
 ducedmode,especiallyifyounoticethataftersometimeofuseyouhavetoswitchthe
 poweroffandonagaintogetthePCD7.D23xrespondingagain.Inthismode,thetrafc
from the Saia PCD®tothePCD7.D23xissupervisedbyowcontrol,intheotherdirection,
from the PCD7.D23x to the Saia PCD®,thereisnoowcontrol
Saia PCD®..... PCD7.D23x
owcontrol
noowcontrol

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-9
1
Use of the PCD7.D23x terminals for the whole Saia PCD®range
1.3.2 Congurationforseveralterminals(mixingisnotpossible)
A - with several RS-232 ports (with or without RTS/CTS)
Congurationwith6PCD7.D230or6D231or6D232
● Upto6×RS-232portsaccordingtothetypesofSaiaPCD®.
PCD7.D23x setup (recommended):
(see also chapter 3)
Same Baudrate and serial mode for all terminals
Baudrate: 9600 or 19200 bps
Serialmode:  RS-232withRTS/CTSorwithoutRTS/CTSdepending
    ofthenumberofRS-232interfaceswithfullcontrolthat
you can connect to your Saia PCD®.
Use of HMI-Editor V 1.3 (recommended):
Terminaltype:  D230with8×20(orD231orD232)
Terminaltopology:  Multipointterminal
Numberofchannels: xx(upto6)
Serial line: 1 to 6 corresponding to the number of terminals.
Typeofserialline:  RS-232
Baudrate: 9600 or 19200 bps
Handshake:   RTS/CTSorNone
Hardware connection (recommended): Connectioncable(length:2.5m)between
Saia PCD®andPCD7.D23x:PCD7.K423(withRTS/CTS)
Connectioncable(length:2.5m)betweenSaiaPCD®andPCD7.D23x:PCD7.K422
(withoutRTS/CTS)

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-10
1
Use of the PCD7.D23x terminals for the whole Saia PCD®range
B - with one RS- 485 port
Upto31PCD7.D230orD231orD232terminalscanbeconnectedtooneRS-485
port.
PCD7.D23x setup (recommended):
(see also chapter 3)
Baudrate: 9600 bps
Serialmode:  RS-485FTP
Addresses: same number of different addresses
as number of terminals: from 01 to 31
Use of HMI-Editor V 1.3 (recommended):
Selecttheterminal:  D230with8×20(orD231orD232)
Terminal topology: bus
Terminal number: xx terminals
Terminallist: number1,2,3…31correspondingtotheidentication 
number (address) of each terminal.
Serial line: 1
Typeofserialline:  RS-485
Baudrate: 9600 bps
Handshake:   None
Connection diagram: see chapter 2.4
Forfurtherdetailseethemanual“HMI-Editor”26/768.

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-11
1
SpecialcongurationwithseveralPCD7.D23xterminals
1.4 Specialcongurationwithseveralterminals
withRS-422FreeTerminalProtocol(MultiDrop)(mixingisnotpossible)
AvailableforPCS1withoutdisplayandalltherangeofSaiaPCD®.
ThismodeallowstheconnectionofseveralterminalsononeRS-422port.Inthis
case,onlyoneterminalisactive(senderandreceiver)andtheotherarepassive
(Readonly).
PCD7.D23x setup:
Baudrate: up to 19200 bps
Serialmode:  RS-422FreeTerminalProtocol(MultiDrop)
Addresses: Same address for all terminals
OnlytheterminalwiththefullconnectionsTXD/TXDandRXD/RXDisfullactive
(singleknobanddisplay).TheotherterminalswiththeconnectionsRXD/RXDwork
only as displays.
Advantages:
● justoneterminalisfullmaster.
● Otherterminalshaveashortrefreshtime.    
RS-422TXD/TXDRXD/RXD
RS-422RXD/RXD
ReadonlyTerminals
Master
Use of HMI-Editor V 1.3 (recommended):
Selecttheterminal:  D230with8×20(orD231orD232)
Terminal topology: bus
Terminal number: xx terminals
Terminallist:  justoneaddress(thesameastheterminalsaddress)
Serial line: 1
Typeofserialline:  RS-422
Baudrate: up to 19200 bps
Handshake:   None
Connection diagram: see chapter 2.4

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
Quickstart
1-12
1
Power supply | Communication connector | Dimensions
1.5 Powersupply
Connection type Connector J2 pin no.
24VDC+30%/-20%
or
19VAC±15%full-waverectied
Powerconsumption:200mAon24VDC
24 VDC 1
GND 2
PGND 3
Powersupplyviaplug-inspringconnectorforwiresofmax1,5mm2.
1.6 Communicationconnector,D-Sub9pole
Standard D-Sub 9 pole:
Pin1:RXD_422   Pin6:/RXD_422
Pin2:TxD_232   Pin7:CTS_232
Pin3:RxD_232   Pin8:RTS_232
Pin4:TXD_422/TX-RX_485 Pin9:/TXD_422//TX-/RX_485
Pin5:SGND   Metal support connected to PGND
1.7 Dimensions
12345
9 8 7 6
115 mm
67,6 mm
125 mm
35.8 mm
10,5 43.1
99 mm
109 mm
Cutout

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
2
Hardware-System Overview
2-1
Function
2 Hardware-System Overview
2.1 Function
The new range of PCD7.D230, D231 and D232 terminals are remote graphic displays
for the Saia PCS1 and the whole Saia PCD®range.
They have been developed for building automation and industrial applications. In
combination with the HMI-Editor, an add-on tool of the Saia PG5®programming pack-
age, they provide a simple way of implementing menu-driven user interface.
This new range consists of three different graphic displays:
PCD7.D230 easy to use! like a mouse.
The single-knob control has “turn” and “press” functions which
can be used to select submenu structures and different process
parameters.
PCD7.D231 with large keys
10 function keys allow to control a lot of processes, the auto-
repeat function with 2 speeds allows to increment and decrement
a value easily.
PCD7.D232 with numeric keyboard and LED indication
8 function keys, 1 numeric keyboard, 8 LEDs allow to control,
enter values and control a process.
All terminals, with backlighting, have a resolution of 128 × 64 pixel and can therefore
be used for high quality representation too:
● inplaintext(8lines×20characters)suchastemperature,pressure,unitnum-
bers, date, time, etc., and messages about operating states and alarms
● ingraphicmode(withtheHMI-Editoronly)todisplaygraphicsymbols,
bargraphs…
In the basic equipment, the terminal offers RS-232, RS-422 and RS- 485 inter-
faces,whichallowsabroadrangeofcongurations.

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
2
Hardware-System Overview
2-2
Technical Data
Customising
A polyester foil with the type and the Saia Burgess Controls logo covers the whole
front side.
Upon request:
● Speciallabellingisavailableonrequest
● Specialdesign(ownlogo)canberealizedandplacedonthefront-panel.
Bothsolutionsareavailableforsmallquantities(minimumorder100piecesandmini-
mumdelivery25pieces)byextracharges.
● Neutralversions(Z11)withoutSBClogoandtypeisalsoavailable
Hardware improvement between current PCD7.D230 and the new ones
● Bettervisibility(transparentplasticinsteadofplasticlmonfront)
● Framearoundthefrontside(frontdimensions115mm×125mm)
● LogoandSBCreferencemorediscreetonfront
● Buzzer
2.2 Technical Data PCD7.D230, D231 and D232
Type designation PCD7.D230 PCD7.D231 PCD7.D232
Display
Type Graphic Display
Displaydimensions(w×h) 8lines×20characters/128×64Pixel(70×40mm)
Charactersize(w×h) 5×7(5×8)Pixel+cursor(2.52×3.54mm)
Contrast adjustment via software or setup
LED backlighting on/off
Character sets ASCII(basicset:95character),withasdefaultthestandardWestern-
Europeancharacterset(DOSgraphical437,128characters).An
addedalternativeenhancedWesternundCentralEuropeancharacter
set(128characters)isselectablebysoftware
Controls, LEDs
Single-knob control/keys yes/- -/10(large) -/25
Function keys - 10 8
Numerickeypad - - yes(12keys)
LEDs - - 8(6red,1orange,
1green)
Auto-repeat keys - yes yes
Memory
Terminal storage capacity Volatilestoragefor100symbols(18×16pixels).Permanentstorage
ofcommunicationandcontrastsettings.Withadvancedcommands
(forotherthanHMIusers):16volatilebackgroundscreens(120×64
pixels).Freetodenecharactersetswithupto128redenedcharac-
terpixelmaps(withupto18×24pixelsforeachcharactercode)
Redeneduseofcharactercodesoverredenitiontables.
Interfaces
to the PCS1 and Saia PCD®RS-232/RS-422/RS-485,9-pole,D-type
Switch for line termination res. yes
Performance and programming
Performance features All performance features of Saia PCD®controllers are also available
if with them the terminals are used, such as: up to 8000 texts, data in
any format, alarm handling, password protection, real time clock
Programming software HMI-Editor(integratedwithinSaiaPG5®asadd-ontool)
General data
Supply voltage Un24VDC,+30%/-20%or19VAC,±15%,full-waverectied
Power consumption on Un200 mA
Interference immunity CEmarkaccordingtoEN50081-1and50082-2
Operatingtemperature 0...50°C
Storage temperature -25...+70°C
Permissible humidity 5...95%r.H.w/ocondensation(DIN40040classF)

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
2
Hardware-System Overview
2-3
Technical Data
Protectionsystem(front) IP 54 IP 65 IP 65
2.2.1 Block diagram
Controller
RAM
32KB
Serial EE-
PROM 4K
Display graphic
128x64 dots
Power Supply
24V-5V
RS232 2
RS422 2
RS485 5
Communi-
cation
D-SUB 9p
Rotary switch
or
keys

Saia-Burgess Controls AG
Manual for PCD7.D23x │ Document 26/ 795 EN10 │ 2013-10-14
2
Hardware-System Overview
2-4
Standard interface connection cables
2.3 Standard interface connection cables
2.3.1 PCD7.K412: for interface RS-232 (without handshake RTS/CTS)
Recommended is to use PCD7.K413
Connection between terminal PCD7.D23x and PGU socket of all Saia PCD®s.
Connectioncable,2.5minlengthwith2×D-Sub9pole.
Terminal PCD7.D23x “PGU”
at PCD1, PCD2, PCD3 and PCD4
TxD 2
RxD 3
SGND 5
CTS 7
RTS 8
2 RxD
3 TxD
5 SGND
7 RTS
8 CTS
9-pole
D-type connector
(male)
9-pole
D-type connector
(male)
Shield housing Shield housing
Cable RS 232
2.3.2 PCD7.K413: for interface RS-232
Recommended
Connection between terminal PCD7.D23x and PGU socket of all Saia PCD®s.
Connectioncable,2.5minlengthwith2×D-Sub9pole.
Terminal PCD7.D23x “PGU”
at PCD1, PCD2, PCD3,
PCS1 and PCD4
TXD 2
RXD 3
SGND 5
CTS 7
RTS 8
2 RXD
3 TXD
5 SGND
7 RTS
8 CTS
9-pole
D-type connector
(male)
Shield housing
Cable RS 232
9-pole
D-type connector
(male)
Shield housing
