INSTRUCTION MANUAL
PLU 585722
5” DYNAMIC GUIDELINE
REVERSE CAMERA KIT

Thank you for purchasing the SCA-RC51 Dynamic
guideline reversing camera kit. The dynamic
guidelines show the intended motion of the
vehicle while reversing. This product is designed
for easy DIY installation but does require some
specific tools, and may require a qualified
technician to install.
1. Monitor (Labelled 1)
2. Reverse camera signal harness (Labelled 2)
3. Monitor power harness (Labelled 3)
4. Video extension cable (Labelled 4)
5. Camera power harness (Labelled 5)
6. Reverse camera (Labelled 6)
7. Adhesive mount
8. Suction mount
PRODUCT OVERVIEW
WARNING
To avoid personal injury and/or property damage,
please read and follow ALL of these instructions
before assembling and operating.
2
PACKAGE COMPONENTS

3
The video signal is transferred from the camera to a
monitor via an RCA cable that will need to be run
from the boot, through the passenger compartment
to the monitors wiring loom. From there the video
signal is sent directly to the monitor.
At the rear of the car the camera is powered directly
from the reversing tail lamp. Check the priority input
on the monitor as it has 2 inputs.
Camera
Power connector
Positive wire (red) connects to positive reverse lamp feed
Monitor/Display
6 Metre RCA
extension cable
WIRING INSTALL DIAGRAM

4
WIRING DIAGRAM
12V + Power connector
Positive wire connects to ACC/IGN +12V
Ground
Negative wire connects to
vehicle chassis
Monitor
Power Harness
Male RCA
Monitor
25cm
1.7m
1.0m
F
F
F
2
3
1
+
FUSE
M
Reverse Camera Signal
(Yellow Female RCA)
Additional Input
(White Female RCA)

5
WIRING DIAGRAM CONT...
Camera Power Harness
Female RCA to 4 Pin Female.
(Yellow Video/Signal)
Video extension cable
Male to Male RCA (Yellow Video/Signal)
Connects to video signal RCA (cable no: 2)
6.0m
4
1.7m
5
1.4m
6
12V + Power connector
Positive wire connects
to reversing lamp
(Trigger)
Ground
Negative wire connects to
vehicle chassis
+
+
+
F
M
M
Camera Harness
4 Pin Male
12V+ Power
connector
Positive wire
connects to power
wire on display
monitor
Alternative power
supply for display
monitor. Display
monitor can be
powered from the
vehicles reverse lamp
12V+ Power
connector
Positive wire
connects to
reversing lamp

INSTALLATION
When mounting the camera, make sure that the
camera does not cover any part of the license
plate. Choose a position that does not impede the
access/operation of the boot release or tailgate
latch. For easy DIY installation, the cables for this
product are numbered 1 to 6. This corresponds to
the wiring diagrams on page 4 and 5 of this
manual.
STEP 1. Mounting the Monitor
1. Check the mounting position of the Monitor and
camera first before installation.
2. Ensure windscreen or dash is clean and free of
debris. Use an alcohol wipe to enhance adhesion.
3. Remove backing off 3M tape off mount and
press & hold firmly to the surface for 60 seconds.
4. Fix where the drivers vision is not blocked. Do
not install the device on airbag or within its working
range.
STEP 2. Connect Monitor Input Harness
Connect signal output cable of the monitor to the
RCA input cable.
6

STEP 3. Connect Monitor Power Harness
Recommended Power Connection: The end of
the monitor power harness cable connects to the
red power input cable connector. This connection
splits into two wires, a red and a black wire.
Connect the red wire (+12V) to a wire that is
powered when the vehicles accessories or ignition
is turned on. Connect the black wire, using a
suitable ring terminal to vehicle chassis.
Alternative Power Connection: The monitor can
also be powered from the reverse light in the
vehicle. Connect the red wire (+12V) from the red
power input cable connector to the red wire on the
RCA video lead at the display monitor end of the
cable. At the camera end of the cable, connect the
red wire to positive (+12V) at the reverse light in
the vehicle. Connect the black wire from the
monitor harness, using a suitable ring terminal to
vehicle chassis.
NOTE: if you power the monitor with this method,
the start up screen on the display will appear
everytime you select reverse, which will delay the
reverse image from appearing.
7
INSTALLATION Cont...

STEP 4. Connect Video Extension Cable
Connect one end of the video extension RCA
cable to the RCA socket from the camera power
harness, then run the RCA cable to the front under
side of the driver side dash board to connect to
Monitors video input RCA (Yellow AV1).
NOTE: There may be multiple video inputs for
different monitors. (ie AV1 or AV2). When using
both inputs, when triggerred AV1 becomes priority.
To do this you may need to remove the rear seat
and or floor scuff panels to run the extension cable
along the side of the vehicle. The RCA cable will
be hidden when you replace the scuff panels.
STEP 5. Connect Camera Power Harness
Connect the RED wire of the camera power
harness to the wire that supplies power to the
reversing lamp (the wire that is powered only when
the car is put into reverse). Before making the
electrical connection, temporarily disconnect the
camera harness from the power plug whilst making
the connection to the reversing lamp. Use a
suitable splicing/crimp connector (scotch lock type)
or strip connector. This connection can also be
soldered, making sure to insulate the joint with
electrical insulation when done. The camera power
harness has two wires to connect (positive (+) to
reverse lamp and (-) to chassis.
8
INSTALLATION Cont...

9
INSTALLATION Cont...
STEP 6. Connect Camera Harness
Connect the camera power harness to the camera
harness. Mount the camera to vehicle
NOTES: CAN BUS
In the event that the cars reversing lights are driven
by CAN BUS the above wiring system may not
trigger the system correctly. It may even create a
globe fault warning. In this case a CAN BUS module
(sold separately) may need to be installed. However,
just because the vehicle has a CAN BUS system
does not necessarily mean that it will require such a
module to work. In fact the opposite is true. Most
vehicles do not require an additional module. If a
CAN BUS module is required we recommend
seeking advice from a professional installer.
Some cars that switch negative, run LED or digital
data controlled lighting systems may not deliver
correct voltage to run the camera, or could cause
flicker with the image. If the voltage at the reversing
wire light is less than 12 volts it may be necessary to
use a relay to supply power to the camera harness
from the wiring in the front of the car. In this case the
reversing light only needs to trigger the relay. Use a
multimeter to test this.

Function buttons located on the back of monitor
1. Press continuously the Menu button to scroll
through settings
2. Press the +or -button to increase & decrease
the settings
3. The menu settings on the monitor will save and
dissapear from the display after 3 seconds
- Brightness: Adjusts screen brightness (50 - 100)
- Contrast: Adjusts screen contrast (50 - 100)
- Saturation: Adjusts screen saturation (50 - 100)
- Language: Select menu language
- Mode: Changes display between 16:9 & 4:3 ratio
- Reset: Resets all settings back to factory default
TESTING THE REVERSING CAMERA
1. Engage the park brake and turn the ignition key to
the on position. DO NOT START THE VEHICLE.
2. Select reverse gear with the gear shift. The
monitor will trigger and turn on automatically when it
receives the camera video signal.
10
MENU FUNCTIONS

5.0 inch 16:9 TFT-LCDDisplay
100 degree wide viewing angleLens view angle
Effective pixels
420 (TV Lines)Resolution
480(H)*234(V)
PAL/NTSCTV system
500:1Contrast
500cd/m2Brightness
12V DC
Monitor Rated
working voltage
2Video inputs
Dynamic guidelinesCamera
W125 x H82 x D30 mmDimensions
PRODUCT SPECIFICATIONS
11
