Scala SMPA-R1505G User manual

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
AMD R1505G Player
SMPA-R1505G
User Manual

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
1、Product Overview
SMPA-R1505G PLAYERI is a smart player box that supports Windows and Linux operating systems.
Customers can develop their own under this system. (for detailed configuration, please refer to
the product configuration parameter table of SMPA-R1505G Player box). Customers can use the
player box to provide multimedia content of the display through documents or network
Figure 1、Product interface diagram：
2、Boot up
1）、Connecting power supply
Connect the 12V / 5A power adapter of the accessory to the power socket, connect the DC
anti disconnection connector of the adapter to the DC12V socket of the equipment, and tighten
the nut;
2）、Key switch and status indication
Press the power button to turn on the device, power is always on green. Hold down the power
button for 8 to 10 seconds, the system shuts down and the power is always bright red.
3、Instructions
1）、External display：
The player box HDMI out is connected with the external display HDMI in through the HDMI
cable to realize the display interface output;
The external device can input interface data through the player box HDMI in, and the player
box can synchronously output the display interface from the HDMI out to the external display.
(The HDMI in is option)
Figure 2: display desktop

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
2）. External USB device:
In the state of connected external display device, USB mouse and USB keyboard can be
connected through USB2.0 and USB3.0 ports to realize interface switching, data input and output
and other functions.
The function of copying or loading data files of external storage devices such as USB flash disk
can be realized.
Figure 3: USB insertion display in Explorer

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
3）. Wired, wireless networking and WiFi functions:
The player box can be connected to the network through RJ45 port and wifi antenna for network
data transmission.
Figure 4: wired and wireless networking setting interface entrance
Figure 5: Bluetooth setting interface entry
4）. Audio transmission:
The player box can transmit audio with external player equipment through aux port.
Figure 6: sound adjustment

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
5）. Serial communication:
The external equipment can realize the RS232 serial communication function through the COM
port of the player box.
6). Extended switch machine: (it needs to be refitted professionally, temporarily omitted, you can
contact the manufacturer)
7). Equipment reset: in case of equipment crash, the device can be forced to restart by pressing
reset hidden button.
4. firmware upgrade:
The player box is equipped with the best firmware at the factory. Customers need to contact Scala
if they have firmware requirements.
5. packing configuration
1. Player box host, 1pcs;

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
2. 12V / 5A adapter, 1pcs;
3. HDMI transfer line, 1pcs;
4. Install screw pack, 1pcs;
SCALA Digital Technology(Ningbo) Co., Ltd.
Address: No. 7 Hong Da Road , Jiang Bei District, Ning Bo,Zhe Jiang
Tel: [phone]
Fax: [phone]
Website:https://scala-china.com/
R PLAYER Product configuration parameters
Spec Date: 10th September, 2019
Spec Date: 15th JAN, 2021
Product
Descriptions
Scala SMPA Player
Hardware & OS
OS
SUPPORT window10，Linux-Ubuntu
APU
AMD RYZEN EMBEDDED R1505G
Graphics
AMD Vega GPU with up to 3 Compute Units
Memory
8GB DDR4-2400 SO-DIMM Dual channel,Max 32GB

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
Network
RTL8111H
Interface
1 x DC input[with anti-loose mechanism],
4 x USB3.0
2xAudio Jack (Front-L/R + ,Aux-In)
2 x HDMI Output (HDMI 2.0，up to 2160@60fps , support HDCP)
1x HDMI IN (PCIE, 1080P, Option) or 2nd 1G Ethernet
1x Power button
1 x 1G Ethernet
1 x Mic
1XDB9 for RS232
1x Emulation on button
1x Copy/eras button
2X SIM socket (Inside the machine)
1X RJ11 for Tethered Power Button & LED Indicator Port
1X Reset Button
SSD
128GB NVME SSD，Max 2T
WIFI
WiFi 2.4GHz/5GHz Dual-Band Support 802.11a/b/g/n/ac
Bluetooth
Bluetooth 4.0 standard including Bluetooth 4.0 Low Energy (BLE)
Expansion Slots
1xM.2 M key (2280) for starage ,1xM.2 E key for HDMI Capture or
2nd Ethernet, 1x M.2 E key(2230) for WIFI, 2x SODIMM sockets for
memory
Power
Power input by adapter
DC12V,5A
Power input by POE
NA
General
information
Storage Temp
(-15 -- 65 degree)
Working Temp
(0 -- 40 degree)
Storage/Working
Humidity
(10 -- 90﹪)
Dimension
180X358X35mm
Net Weight
2.98KG

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.1
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in mobile exposure condition, the use distance is 20cm, compliance with exposure
requirements.
