Scan Sign SF Series User manual

A
A
B
B
C
C
B
AC
Installation instruction SF letters –
Single letters with single converters
1., Purchased parts package
letters with cable
connection
converters wiring diagram and
assembling aid
incidentals installation drawing
B
A C
2., Fastening of the letters
B
A C A
1., Adjust the drawing 2., Drill the fixing and cable
holes according to the
drawing
3., Fix the letters
B
A C
red
red
red
red
black
black
black
black
3., Wiring of letters to converters
S-E-R-I-E-S C-O-N-N-E-C-T-I-O-N!
Always connect a red wire to a black one as shown
in the picture.
Attention!
Inversion of the wires can cause damages and
malfunction!
B
A
4., Proper connection of wires
1., Cut wires to length 2., Impose shrink hose on

5., Installation of converters and power connection
If all connections were made properly and our instructions followed, your signage will work reliably.
6., Necessarily avoid!
Avoid connecting earth to
LED wire!
Attention!
Keep distance between converters.
Care for proper ventilation.
Keep out of strong solar radiation and permanent
humidity.
Power connection according to standard:
brown – phase, blue – null, yellow-green - earth
230 V
Accurate power supply
voltage: 230V
Connection should be made
by a certified electrician.
5 cm
2 cm
3., Strip 2-3cm of insulation
and twist wires
4.,Turn wires down and
position middle of the hose
over the twisted wires
Heat hose with hot air or
fire until the joint has
been completely closed
5.,
~
Attention!
Damages on wire insulation
and short circuit cause
destruction of LEDs and
converters.
