Scan Sign SF Series User manual

Installation instruction SF letters –
Single letters with low-voltage transformers
1., Purchased parts package
letters with cable
connection
Low-voltage
transformers
incidentals installation drawing
2., Fastening of the letters
B
A C A
1., Adjust the drawing 2., Drill the fixing and cable
holes according to the
drawing
3., Fix the letters
3., Wiring of letters to converters
A
B
C
B
A C
B
A C
red red red red
black
black black
black
230 V
~
PARALELL CIRCUIT!
Always connect a red wire to the red main, a black
wire to the black main.
Mixing-up the cables DOES NOT cause any damage
in the sign.
branch connector filled with conductive gel

4., Installation of converters and power connection
If all connections were made properly and our instructions followed, your signage will work reliably.
6., Necessarily avoid!
Avoid connecting earth to
LED wire!
230 V
Accurate power supply
voltage: 230V
Connection should be made
by a certified electrician.
~
Attention!
Damages on wire insulation
and short circuit cause
destruction of LEDs and
converters.
