Scandex SX-1141 User manual

SX-1141 User Guide

Characteristic…………………………………………………………………1
Output Mode…………………………………………………….…………………2
Languages Setting………………………………………….………………2-3
Serial Interface Setting…………………………………..……………4-5
Lowercase And Uppercase Setting…………………………...…………………5
Barcode Type Setting……………………………………….....…………………5
UPC/EAN-attached code Setting……………………………...……………………6
Line Skip and Enter Setting……………………………………...…………………6
Add Prefix And Suffix……………………………………..…………………7
Hide The Front/Behind Part Characters Of Barcode………….....……………8
Prefix and Suffix Character………………………………..….………………9-10
The Number of The Hidden Characters…….……………...…………………11-12
Statement of Warranty…………………….………...……………………13
Catalogue
...
..

1
The SX-1141 has two auto-induction modes and a standard trigger mode.
See below modes:
1.Auto-induction A
When mounted in the stand, the scanner will be in continuous scan mode, out of
the stand the scanner is trigger operated.
2.Auto-induction B
Press & hold the trigger for 10 seconds, continuous scan mode is activated.
Pressing the trigger for another 10 seconds, continuous scan mode will
be deactivated.
NB The stand is an optional accessory. DO NOT use the Auto-induction mode
without the optional stand.

Output Mode
Version Number Recover Procedure PS 2 Keyboard Mode Serial Port Mode
USB Keyboard Mode USB Serial Port Mode Continuous Scanning Mode
Language setting
America Belgium Brazil Canada -French
Croatia Czech Republic Slovakia Denmark
Finland France Germany Hungary
2

Italy Latin America Netherlands Norway
Poland Portugal Yugoslavia/Serbia Slovenia
SpaIn Sweden Switzerland - French
UK General Turkey -F Turkey-Q
Buzzer settings
3
Sound Off Sound On
Switzerland-German

Serial Interface Settings
Baud Rate
Handshake Protocol
None
Handshake Signal Time
Response – 5 Seconds
Data bits Stop Bit
8-bit 7-bit 1-bit 2-bit
4
Handshake Signal Time
Response-2 Seconds
2400 4800 9600 19200

Check Mode
None Odd Check Even Check Label Check
Blank Reset
Lowercase And Uppercase Settings
Lowercase Uppercase Recover
Barcode Type Settings
5
Close ID Character Open ID Character
before Barcode before Barcode
Close ID
Character after Barcode

UPC/EAN-attached code Settings
Close the Attached
Code of UPC/EAN
Add Two Bit Attached
Codes to UPC/EAN
Enter and Line Skip Settings
Enter Line Skip
6
Open ID Character
after Barcode
Add Five Bit Attached
Codes to UPC/EAN
Add Two Bit & Five Bit
Attached Codes to
UPC/EAN
Cancel Enter
Hide Barcode
Type after Barcode
Display Barcode
Type after Barcode

1.Add Prefix
The first step: scan “add prefix” setting code (this step will clear the prefix previously set)
Add Prefix
The second step:scan the needed “prefix and suffix ”,(no more than 32 characters).
The first step:scan“add suffix” setting code (this step will clear the suffix previously set).
Add Suffix
The second step:scan the needed “prefix and suffix ”,(no more than 32 characters).
7
2.Add Suffix

3.Hide The Front Part Characters Of Barcode
Scan “Hide The Front Part Characters of Barcode” setting code(This step will clean the
previous setting)
Hide The Front Part Characters Of Barcode
Scan“The Number Of The Hiding Characters”(It can hide 32 character at most)
4.Hide The Behind Part Characters Of Barcode
Scan “Hide The Front Part Characters Of Barcode” setting code (This step will clean the
previous setting)
Scan “The Number Of The Hiding Characters (It can hide 32 character at most)
Hide The Behind Part Characters Of Barcode
8

5.Prefix And Suffix
0 1 2 3 4 5
6 7 8 9
A B C D E F
G H I J K L
M N O P Q R
9

10

6.The Number Of The Hiding Characters
01 02 03 04 05 06
07 08 09 10 11 12
11

13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32
12

13
About the Warranty
The product is covered by a 12 months RTB (return to base)
UK warranty. The warranty covers all
parts, labour & return carriage.
Exceptions to warranty
a. The warranty period has expired.
b. Accidental damage and/or operator error
c. The product is damaged due to incorrect installation.
d. The serial number of the scanner is altered or missing.
e. The working or storage environment of the product is out of
operating range.
