scentify Tower Diffuser User manual

TOWER DIFFUSER
USER MANUAL

TOWER DIFFUSER USER MANUAL
01
TABLE OF CONTENTS
Product Overview...................................................... 02
Package Includes....................................................... 03
Technical Specications............................................ 03
Introductions.............................................................. 04
Features...................................................................... 04
Setting Up................................................................... 05
Warnings.................................................................... 11
Equipment Cleaning................................................... 12
Maintenance & Storage.............................................. 12
Troubleshooting.......................................................... 12

PRODUCT OVERVIEW
Fragrance
Export
Display Screen
Decrease
the level
Increase
the level
Adapter
Connecter
Port
Power
ON/OFF
TOWER DIFFUSER USER MANUAL
02

Brand Name:
Product Dimensions:
Bottle capacity:
Weight:
Coverage:
Power:
Connectivity: Bluetooth
Scentify
112*112*288mm
120ml
1.4kg
1000 Sq
5W
TOWER DIFFUSER USER MANUAL
03
PACKAGE INCLUDES
• 1 X Scentify Tower Diuser Device
• 1 X 120ml Bottle
• 1 X Power Adapter
• 1 X User Manual
TECHNICAL SPECIFICATIONS

TOWER DIFFUSER USER MANUAL
04
INTRODUCTION
The Scentify Tower Diuser is a scent machine that is
designed with smart technology that transforms your
favorite oil into a gentle fragrance mist. This device
covers the area up to 1000 square feet and creates a
scented environment. It connects to the app via
Bluetooth called “Scentify” which allows you to use your
oils eciently for a long-lasting aroma. It diuses the
fragrance in silence, allowing you to work or sleep in
peace. This device can impress your clients and visitors
with the aroma of your home and oce.
FEATURES
• Excellent coverage, up to 1000 square feet of space.
• Easily connect with the Bluetooth app to set your
preferred time and strength.
• Diuses the fragrance in silence.
• The dimensions, width, and height are suitable for
stand-alone anywhere.
• 5-foot adjustable power cord.
• Easily rellable bottle essential oil container.

TOWER DIFFUSER USER MANUAL
05
GETTING STARTED
Setting Up the Device:
Press the top cover
to open the machine.
1Take out the top cover with
diusion head and bottle.
Fill your bottle with your favoriteoil, screw in the bottle to
the diffuser head, then put the top cover back. (Do not
pour oil inside the diffuser)
3
Connect the power supply cable and turn “ON” the device.
4
2
2

TOWER DIFFUSER USER MANUAL
06
Connecting to App:
1. Open the “Google Play” store or “App Store” on your
smartphone, then type the “Scentify” text in the search bar.
Once the search results appear on your screen select the
following icon and download this app.
NOTE: Make sure the Bluetooth and Location function of
your mobile phone is turned “ON”.
NOTE: Screen light will shut o after 60 seconds.
Press + or – to wake.
OPERATIONS:
Connect to the Power:
Connect the device with the 12v 1A power
supply, The tower will make a beep sound.
POWER ON/OFF:
Press the button to turn ON and OFF the device.
SET INTENSITY SETTING:
The machine has 10 intensity levels, press the
button to increase the intensity, press the button
to decrease the intensity.
POWER INDICATOR:
Sign indicates the direction of the power supply.

TOWER DIFFUSER USER MANUAL
07
2. Open the “Scentify” app on your mobile phone, select your
device name or press the “+” icon on the top right of the page
to add a new one as shown in the image below;
3. Once you have selected your device name, the following
page will appear on your screen,
Enter the default password “8888” and then press the “Login”
button.
In the “Device Setting” section, you can change your device
name and label information of your scent machine.
NOTE: Press the “Save” button at the top right corner of the
screen after each change.

TOWER DIFFUSER USER MANUAL
08
On the “Working period settings” page, set the “Start working
time” and “Stop working time”, select days of the week that you
want your machine to run, and then click the “Save” button to
update the settings.
You can also access and customize the run time and intensity
settings of your machine. To create a new schedule, press the “+”
button, the following page will appear on your screen;

TOWER DIFFUSER USER MANUAL
09
You can also click the “Grade” check box and then press the up
and down arrows to adjust the scent intensity run-time as
shown in the image below;
Click the “Custom” check box to set how long the diuser will
pump and stop between diusing the scent by adjusting the
“Work time (S)” and “Stop Time (S)” as shown in the above image.
Note: Press the “Save” button at the top right corner of the screen
after adjusting your settings.
Note: To delete a setting press and swipe left.

5. You can change the default password by pressing on the
“About” tab, in the “Device control” page, press the “Change
Password” button as shown in the image below;
TOWER DIFFUSER USER MANUAL
10
6. Enter your new password, conrm password, and then press
the “Change Password” button as shown in the image below;
Note: If you forgot the password, press the reset button to restore
the factory settings. The factory setting password is 8888.

TOWER DIFFUSER USER MANUAL
11
Intensity and Oil Consumption:
Set your preferred fragrance intensity as detailed below;
WARNINGS
Always keep the machine vertical. Tilted or angled may cause
oil to overflow and damage the circuit.
Reset Bluetooth App Password:
Press and hold the button for 3 seconds to reset
the password to 8888.
Grade Working(s) Stop(s) Consume(ml/h)
G1 30s 270s 0.07
G2 60s 240s 0.13
G3 90s 210s 0.20
G4 120s 180s 0.27
G5 150s 150s 0.33
G6 180s 120s 0.40
G7 210s 90s 0.47
G8 240s 60s 0.53
G9 270s 30s 0.60

MAINTENANCE & STORAGE
• Always turn o and unplug the diuser when not in use.
• Do not leave fragrance oil in the container bottle for a long time.
• Do not move the diuser while in use.
• Do not carry the unit from the top cover.
• Permanently remove the power cord before cleaning.
• Store the diuser in a dry and clean place.
PROBLEM SOLUTION
No Diusion
-Check if the power is ON or OFF.
- Replace the oil with rubbing alcohol and
run it through the machine for 5 minutes.
Oil Leaking
-Bottle is loose. Screw it in properly and straight.
-Seal is broken or missing. Replace the supplied
seal that came with the machine.
No Display
on Screen
-Make sure the power is ON.
-Screen light shuts o after 60 seconds.
-Press + or – to wake.
TROUBLESHOOTING
TOWER DIFFUSER USER MANUAL
12
EQUIPMENT CLEANING
1. Fill the bottle with water-vinegar or rubbing alcohol.
2. Let the diuser run for about 3-5 minutes.
3. Drain the diuser bottle completely.
4. Using a cotton swab dipped in vinegar, clean the tight spots
and corners of the diuser to make sure that no spots are left dirty.
5. Use a dry cloth or more cotton swabs or cotton balls to wipe
the diuser and dry it thoroughly.
