SCH MSMGT User manual

OPERATING INSTRUCTIONS
.
MUST BE READ PRIOR TO OPERATING THIS MACHINE
Towed Multi Surface Manège
Groomer
Ref: MSMGT

DESCRIPTION
The manège groomer is ideal for maintenance of both sand and fibre or sand and
rubber surfaces. Spring tines lift the sand and the two crumb rollers redistribute
the material evenly, providing you with a level, even and safe surface for riding.
The wheels make transportation and storage of the unit quick and easy.
The groomer has two crumble rollers. The front roller has bar runners to carry out
the first crumbling action. This is followed by two rows of spoon shaped spring
tines. These are staggered/off set to give the required coverage to maintain the
working surface. The rear crumble roller has round bars to complete the task.
SPECIFICATIONS
Working width –MSMGT60
1500mm (60”)
Working Width –MSMGT72
1830mm (72”)
Working Width - 3MSMGT
1500mm (60”)
Towed version –MSMGT60/72
Three-point linkage mounted version –3MSMGT

SAFETY INSTRUCTIONS
Never leave your unit where someone could trip or walk into it.
Always make sure that the groomer is firmly fixed to the towing vehicle
when in use.
Never allow people to ride on the frame.
Be aware of your surroundings and do not use the groomer in close
proximity to other people.
Do not travel at speeds which would allow the unit to bounce.
Do not turn sharply at the end of a row, take a wide turning arc.
Never reverse the unit with the tines or roller in contact with the ground.
If in doubt, please call the SCH customer help line at 01473 328272.

TRANSPORT
Two puncture proof wheels are incorporated in the design to allow the unit to be
safely and easily transported to and from the storage area.
The tow bar can be used in two positions:
In a fixed position –for transport
In a floating position –we recommend the floating position for levelling.
IMPORTANT
It is essential that the front and rear tines are not lowered into the surface too
deep otherwise you run the risk of catching the top membrane and causing
damage to your arena.
We recommend tines are lowered no deeper than 40mm. (if you suspect your
surface levels are below 100mm anywhere on the arena it is essential that you
address this problem before using your groomer.
Once you have adjusted the depth setting be sure to replace the holding pins that
stop the depth control handles from moving.
SCH Supplies accept no responsibility for any damage caused by incorrect
settings.

OPERATION
Once the unit is in the arena:
1. Raise the transport wheels fully by winding the wheel handles in a
clockwise direction until the wheels are fully retracted and the unit is
riding on its back and front crumble bars.
2. Remove the transport fixing pin so that the tow bar is in its ‘floating
position’.
3. Using the crumble bar roller adjuster first lower the front crumble bar so
that the tines directly behind it go into the surface around 10mm. Then
repeat the same process for the rear crumble bar adjusting so that the
unit sits level to the eye and both front and back tines go into the
surface at approximately the same depth. It is best to gradually
increase the depth in stages of 10mm at a time.

MAINTENANCE
Wash down after use, do not pressure wash the bearings on the
crumble roller.
Grease the screw jacks and all moving parts at regular intervals.
GENERAL GUIDELINES
Maintenance of your arena surface is one of the most important activities you can
carry out to maintain its importance.
Use a vehicle that does not have agricultural tyres as they can dig up the surface.
Keep heavy vehicles off the surface except of maintenance purposes.
Try to pick up horse droppings and other debris prior to raking, to help prevent
contamination.
The grooming rake is not designed to correct un-level surfaces, major tracking or
dips due to jumping etc, must be hand raked first.
Always try to vary the location of the starting position.
Work at a fairly brisk pace.
Setting the tines shallower will result in a firmer riding surface and vice versa.
Sand based Surfaces should be kept damp at all times.

WARRANTY
Your Towed Multi Surface Manège Groomer is guaranteed for 12 months from
the date of purchase. This guarantee covers faults which may occur from
defective parts or manufacture.
SCH Supplies accept no responsibility for any damage caused by incorrect
settings.
Damage caused by inability to follow instructions will void warranty.
