Schaller PMSA User manual

78,0°F | 6,16% | 456kg/m
3
| -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m
2
| 09m/s | 4,90Ugl | 1
Operating Manual
Always read this operating manual before using the PMSA!
PMSA
Single paper sheet moisture analyser
for measuring the moisture content of a single sheet
of paper
Moisture meter
Version 2.1

PMSA Operating Manual
Page 2
Your PSMA at a glance
The main unit
No Name
1 Lid push button
2 Sensor plate
3 LED status bar
4 IR temperature sensor
2
3
41

Page 3
The rear of the main unit
No Name
1 Identification plate
2 Reset button
3 USB port
ATTENTION
Sensitive sensor plate
The white sensor surface consists of a thin ceramic plate. This plate may be
destroyed by mechanical pressure!
►Take care of the sensitive sensor surface during cleaning!
2
3
1

PMSA Operating Manual
Page 4
Table of contents
Your PSMA at a glance ����������������������������������������������������������������� 2
The main unit ..........................................................................................................2
The rear of the main unit .........................................................................................3
1� Introduction �������������������������������������������������������������������� 6
1.1 Information about this operating manual ................................................6
1.2 Limitation of liability ................................................................................ 6
1.3 Symbols used in this manual ...................................................................7
1.4 Customer service ....................................................................................7
2� For your safety ���������������������������������������������������������������� 8
2.1 Proper use ..............................................................................................8
2.2 Improper use ..........................................................................................8
2.3 User qualications ................................................................................... 8
2.4 General safety information ...................................................................... 9
2.5 Warranty ................................................................................................ 9
3� On receipt of your device �������������������������������������������� 10
3.1 Taking the device out of its packaging ...................................................10
3.2 Making sure that all of the components have been included .................10
4� Setting up ���������������������������������������������������������������������� 11
4.1 Setting up the PC software ...................................................................11
4.2 Setting up the device ............................................................................11
4.3 Setting the COM Port ...........................................................................12
5� The measuring process ������������������������������������������������� 12
6� Product types ���������������������������������������������������������������� 14
6.1 Selecting the product type ....................................................................15
6.2 How moisture content is dened .......................................................... 15
7� Database / Archive ������������������������������������������������������� 16
7.1 Filter .....................................................................................................16

Page 5
7.1.1 Filter by date .........................................................................................16
7.1.2 Filter by keyword ..................................................................................17
7.2 Additional database functions ...............................................................18
7.2.1 Deleting measurements ........................................................................ 18
7.2.2 Edit measurements ...............................................................................18
7.2.3 Printing measurements ......................................................................... 18
7.2.4 Exporting measurements ....................................................................... 18
8. Conguringthedevice������������������������������������������������� 19
8.1 Sensor settings ...................................................................................... 19
8.1.1 Deactivating the "Measurement Valid" window ....................................19
8.1.2 Updating the PMSA Firmware ...............................................................19
8.1.3 Entering the Admin password ...............................................................20
8.2 Product types ........................................................................................20
8.3 Selecting a language .............................................................................21
9� Cleaning and maintenance ������������������������������������������ 21
9.1 Resetting the hardware/device .............................................................. 21
9.2 Care instructions ...................................................................................21
9.3 Cleaning the device ..............................................................................22
10� Faults ����������������������������������������������������������������������������� 23
11� Storage and disposal ���������������������������������������������������� 24
11.1 Storing the device .................................................................................24
11.2 Disposing of the device .........................................................................24
12� Device information ������������������������������������������������������� 25
12.1 EC declaration of conformity ................................................................. 25
12.2 Technical data .......................................................................................29
13� Notes ����������������������������������������������������������������������������� 30

PMSA Operating Manual
Page 6
1. Introduction
1.1 Information about this operating manual
This operating manual is designed to enable you to use the PMSA safely and effec-
tively. It is part of the device, has to be stored nearby and must be easily accessible to
users at all times.
All users are required to carefully read and make sure that they have understood this
operating manual before using the PMSA. All of the safety and operating instructions
detailed in this manual have to be observed to ensure the safety of the device.
1.2 Limitation of liability
All of the information and instructions provided in this operating manual have been
compiled on the basis of the current standards and regulations, the state of the art,
and the extensive expertise and experience of Schaller Messtechnik GmbH.
Schaller Messtechnik GmbH does not accept any liability for damage associated with
the following, which also voids the warranty:
• Non-observance of this operating manual
• Improper use
• Inadequately qualified users
• Unauthorised modifications
• Technical changes
• Use of unapproved spare parts
This fast measuring procedure can be affected by a range of different factors. For this
reason, we recommend periodically checking the device’s measurements with a stan-
dardised oven-drying method.
We, as the manufacturer, do not accept any liability for any incorrect measurements
and associated consequential damage.

Page 7
1.3 Symbols used in this manual
All of the safety information provided in this manual is shown with a corresponding
symbol.
CAUTION
It is essential to observe this warning. Non-compliance can lead to injury.
ATTENTION
It is essential to observe this warning. Non-compliance can lead to damage to
property or equipment.
iInformation
This symbol indicates important information that enables users to use the de-
vice more efficiently and cost effectively.
1.4 Customer service
For technical advice, please contact our customer service department at:
Schaller Messtechnik GmbH
Max-Schaller-Straße 99
A - 8181 St.Ruprecht an der Raab
Telephone: [phone]
Fax: [phone] - 901
E-Mail: [e-mail]
Internet: www.humimeter.com
© Schaller Messtechnik GmbH 2022

PMSA Operating Manual
Page 8
2. For your safety
The device complies with the following European directives:
• Restriction of Hazardous Substances in Electrical and Electronic Equipment
(RoHS)
• Electromagnetic compatibility (EMC)
The device corresponds to state-of-the-art technology. However, it is still associated
with a number of residual hazards.
These hazards can be avoided through strict observance of our safety information.
2.1 Proper use
• Easy to use device for quickly measuring the water content of single sheets of
paper
• The device must only be used for taking measurements on the products defined
in the following sections of this manual (see 6. Product types).
2.2 Improper use
• The device must not be used in ATEX.
• Corrugated board cannot be measured.
• Papers and cardboard that have been carbon (graphite) blackened.
• Papers and cardboard with metallic coatings
• The device is not waterproof and must be protected from water and fine dust.
2.3 User qualifications
The device should only be handled by persons who are expected to carry out the work
reliably. Persons whose reactions are influenced, by drugs, alcohol or medication, are
not permitted to use the device.
Persons who use this device must have read and understood the user manual and fol-
low its instructions.

Page 9
2.4 General safety information
Follow the safety instructions below to avoid personal injury and material damage:
• If you notice loose parts or damage on the device contact your distributor.
All of the device’s technical features have been inspected and tested before delivery.
Every device has a serial number. Do not remove the tag with the serial number.
2.5 Warranty
The warranty does not apply to:
• Damage resulting from non-observance of the operating manual
• Damage resulting from third-party interventions
• Products that have been used improperly or modified without authorisation
• Products with missing or damaged warranty seals
• Damage resulting from force majeure, natural disasters, etc.
• Damage from improper cleaning

PMSA Operating Manual
Page 10
3. On receipt of your device
3.1 Taking the device out of its packaging
• Take the device out of its packaging.
• Next, make sure that it is not damaged and that no parts are missing.
ATTENTION
Sensitive sensor plate
The white sensor surface consists of a thin ceramic plate. This plate may be
destroyed by mechanical pressure!
►Take care of the sensitive sensor surface during cleaning!
3.2 Making sure that all of the components have been included
Make sure that all of the components have been included by checking the package
contents against the following list:
• PMSA
• USB mini B cable
• USB stick with software
• Operating manual
Optional accessories:
• Paper grammage precision scale
• Laboratory analysis for creation of calibration curve

Page 11
4. Setting up
4.1 Setting up the PC software
1. Plug the delivered USB stick containing the
evaluation software into a free USB port on your
computer.
2. Open the USB Stick and start the installation file of
the evaluation software (figure1).
3. Now follow the instructions of the installation
wizard.
4. After successful installation exit the installation
wizard with Finish (figure2).
4.2 Setting up the device
• Insert the USB Mini B connector into the PMSA (figure3).
• Insert the USB connector into the computer.
»The required driver was installed with the evaluation
software in the previous step and should now be ready
for use.
1
2
3

PMSA Operating Manual
Page 12
4.3 Setting the COM Port
1. Start the evaluation software on your
computer.
2. Open the sensor settings by clicking on the
"Settings" button (figure4) .
3. Select the COM interface of the PMSA from
the drop-down menu.
4. After selecting the COM interface, the con-
nection to the PMSA can be tested via the
"Test" button.
»After successful completion of the test, a
message appears and the LED bar of the
device lights up blue.
5. The measuring process
To do so: The connection between the device and the eva-
luation software has been established successfully.
1. Select the desired product type from the drop-down
menu (figure6).
2. Click the "Start" or "F1" button to start the
measuring process.
»The window "Measurement progress" opens
(figure7).
3. Make sure that there is no paper in the machine
and close the lid (figure8).
4. Continue the measurement process by clicking
the "OK" button .
5. Now the device performs a blank measurement.
»During the blank measurement, the progress
window closes.
4
5
6
7
8

Page 13
6. After successful completion of the blank mea-
surement, the progress window opens again
(figure9).
7. Now place the paper to be measured in the
device and close the lid (figure10).
8. Continue the measurement process by clicking
the "OK" button .
9. Now the device performs the measurement.
»During the measuring process the LED bar on
the device flashes.
10. After successful completion of the measure-
ment, the window "Measurement Valid" opens,
displaying the measured values and options to
enter further additional data (figure11).
»It is possible to deactivate the opening of the
window "Measurement Valid" (see section 8.1.1
Deactivating the "Measurement Valid" window).
11. By clicking the button "Save" the measu-
ring results including entered additional data
are saved.
ATTENTION
Risk of injury
Crushing due to the lid of the device
►Pay attention to the position of your fingers when closing the lid.
iInformation - Incorrect readings
Always make sure to select the correct product type for the material you are
measuring. This prevents taking incorrect readings (see 10. Faults).
9
10
11

PMSA Operating Manual
Page 14
6. Product types
Product type Paper type Grammage
[g/m²]
*Reference ! Only used for testing the moisture meter !
Carbonless paper CFB 60 60 g/m²
Fluting 100 100 g/m²
Fluting 110 110 g/m²
Fluting 127 127 g/m²
Fluting 140 140 g/m²
Fluting 160 160 g/m²
Fluting 80 80 g/m²
Fluting 90 90 g/m²
Copy paper 80 80 g/m²
Kraftliner 125 125 g/m²
Kraftliner brown 280 280 g/m²
Kraftliner brown 300 300 g/m²
Kraftliner brown 400 400 g/m²
Kraftliner white Top 140 135 g/m²
Kraftliner white Top 200 200 g/m²
Lumi Silk 150 150 g/m²
Mango Star 90 90 g/m²
Maximago 110 110 g/m²
Nopa Coat 300 300 g/m²
Pre-Print R39 205 205 g/m²
Schrenz 90 90 g/m²
Testliner 100 100 g/m²
Testliner 125 125 g/m²
Testliner brown 135 135 g/m²
Testliner brown 170 170 g/m²
Testliner brown 210 210 g/m²
Testliner white 140 140 g/m²
Testliner white 180 180 g/m²

Page 15
Newsprint 45 45 g/m²
Celulose paper JIRVJ 186 186 g/m²
6.1 Selecting the product type
Due to the wide range of different types of papers in use, there are no default product
type categories. For the different product types of the PMSA, the grammage of the
paper sheet and the paper type are decisive.
The product type overview contains suggestions for different paper types and their
associated grammage [g/m²].
To achieve an accurate measuring result, it is necessary to create a specific calibration
curve.
The recording of a new calibration curve can be carried out by Schaller Messtechnik
GmbH or by the customer (with separate instructions).
If required, please request the manual for creating calibration curves from Schaller
Messtechnik GmbH.
6.2 How moisture content is defined
The device measures and shows a material’s moisture content. The moisture content
readings it displays are calculated in relation to the material’s overall mass:
Mn: Mass of the sample with average moisture content
Mt: Mass of the sample with zero moisture content
%MC: Moisture content (in accordance with EN ISO 287)

PMSA Operating Manual
Page 16
7. Database / Archive
In the database all stored measuring values can be displayed.
Each stored measurement has its own identification number.
7.1 Filter
To facilitate the search, filters can be applied to the stored measurements in the data-
base. When leaving the archive, the applied filters are reset.
7.1.1 Filter by date
1. When using the date filter, select Period to display all measurements taken within
this period.
2. In the first field, enter the start date of the
desired time period (figure13).
»The start date can be chosen on the calen-
dar (figure14) or entered manually in the
format (TT-MM-JJJJ).
»Clicking on "today" the current date is entered.
12
13
14

Page 17
3. In the second field enter the end date of
the desired time period (figure15).
»By default, the current date is selected as
the end date.
»The end date can be chosen on the calendar or entered manually in the format
(TT-MM-JJJJ).
»Clicking on "today" the current date is entered.
7.1.2 Filter by keyword
1. It is also possible to filter the database according to entered specific data such as
the type of paper, batch number or grammage.
2. Click on the drop-down arrow (figure23) of the button "Search in "
and choose the desired filter option.
3. Enter the required search term.
4. The search term is applied to the database after entry.
»Press the Enter key or the "Search in" button to manually apply the search term
to the database.
»To filter even more precisely, it is also possible to combine date filter and filter by
search term.
5. By clicking on the column headings (e.g. ID), the list can be sorted in ascending
or descending order.
15
23

PMSA Operating Manual
Page 18
7.2 Additional database functions
All data from the database can be deleted, further processed or exported.
7.2.1 Deleting measurements
• Mark the desired measurement series by clicking on the empty field in front of
the "ID" column.
»To select an entire area, keep the Shift key pressed.
»To select several individual measurement series, keep the Ctrl key pressed.
• Click on the button "Delete" to delete the marked measurement series.
»The marked measurements are irrevocably deleted from the database!
7.2.2 Edit measurements
1. Mark the desired measurement series by clicking on the empty field in front of
the "ID" column.
2. Click on the button „Edit“ to edit the
marked measurement series.
»The "TableEdit" window opens (figure16).
3. Now you can change the paper type as well as
the batch number.
4. Confirm your entry by clicking on Save .
7.2.3 Printing measurements
• Click on the button „Print“ to print all measurements shown in the table.
»If a filter is set, only the records corresponding to the filter are printed.
7.2.4 Exporting measurements
• Click on the button "Export" to export all measurements shown in the
table.
»The export is possible in CSV, HTML or XML format.
»If a filter is set, only the records corresponding to the filter are exported.
16

Page 19
8. Configuring the device
8.1 Sensor settings
• Open the sensor settings by clicking on the button "Settings" .
8.1.1 Deactivating the "Measurement Valid" window
• Navigate to the tab "Common".
• Remove the tick from the setting "Show Measurement Valid Window".
»Now the "Measurement Successful" window is no longer displayed after a mea-
surement has been completed.
»If the "Measurement Valid" window is deactivated, your measurements are not saved
in the archive.
8.1.2 Updating the PMSA Firmware
Before starting the update
• Before starting the Firmware Update, contact Schaller Messtechnik GmbH
([email protected]) to clarify if an update is necessary for your PMSA
device.
• Attach the file „pmsa.log“ and the serial number of your device.
»The file „pmsa.log“ can be usually found in your public documents folder:
»"C:\Users\Public\Documents\Schaller Messtechnik GmbH\PMSA\log"
• If necessary, you will receive a new file from Schaller Messtechnik GmbH, which
is matched to the serial number of your PMSA.
»Do not install the update on another PMSA with a different serial number!
ATTENTION
Do not install the update on another PMSA with a different serial number!
You can potentially render your device unusable trying to install a wrong up-
date.
►Only install the update on the PMSA for the correct serial number.

PMSA Operating Manual
Page 20
Performing the Firmware Update
1. Check if the correct COM port is set (see 4.3
Setting the COM Port).
2. Navigate to the tab "Update" (figure 17).
3. Drag the Hex file into the text field (figure 18) or
click and select it using the file explorer.
4. Reset the PMSA (see 9.1 Resetting the hard-
ware/device).
5. Within 5 seconds after resetting the device, click
the button "Update" .
6. The update starts now (figure 19).
»The update process can take up to 2 minutes.
7. After the update has been completed your
PMSA device is ready for use again.
8. If an "Error" message appears on the display
(figure 20), please check whether the correct
COM Port is set (see 4.3 Setting the COM Port).
9. Reset the PMSA again (see 9.1 Resetting the
hardware/device) and within 5 seconds click the
button "Update" .
8.1.3 Entering the Admin password
• Navigate to the tab "Admin".
• Enter the Admin password.
8.2 Product types
• The creation of a new product type is described in a separate operating ma-
nual.
17
18
19
20
