Congratulations on purchasing the SCHERTLER® RESOCOIL. It is our pleasure to welcome you to
a growing family of musicians and technicians, including many of the world’s leading soloists and
sound engineers, who have chosen to work with SCHERTLER® products.
RESOCOIL has been specially designed for classical guitar, mandolin, ukulele and banjo players
who want a more permanent microphone solution for their instrument, while benetting from the
same outstanding sound quality offered by our external transducers. During installation, RESOCOIL
can be precisely positioned in order to bring out the best characteristics of your instrument sound, or
to suit your personal taste and playing style. This not only ensures consistency, but also offers added
convenience when quickly switching between instruments during a performance.
All SCHERTLER contact microphones are developed and manufactured according to the highest
standards of design, material quality and workmanship in order to ensure longevity. However, it is
important to always handle your microphone with care so that it will provide reliable service.
In our continuing quest to improve the transmission and reproduction of acoustic instrument sound,
we hope that RESOCOIL will also enhance your personal performing or recording experience.
Stephan Schertler
and the SCHERTLER Team

INTRODUCTION
3
RESOCOIL is a high-quality, passive, electrodynamic contact microphone designed for xed
installation in classical guitars, mandolin family instruments, ukulele and resonator guitars.
Fixed inside the instrument’s sound box, RESOCOIL delivers the warm, natural sound typically
associated with SCHERTLER DYN Series contact microphones, while offering the added convenience
of a permanent installation that leaves no visible holes on the instrument.
To make the most of your RESOCOIL’s capability and to ensure trouble-free operation, please
read this manual carefully before installation. We also advise keeping the manual for future
reference.
SCHERTLER RESOCOIL: Made in Switzerland

ELECTRODYNAMIC
PICKUPS
INSTALLATION
RESOCOIL XLR
1. Remove the strings
2. Choose whether you want to install the
XLR connector on the side (Fig. 1 - step
3.1) or on the tailblock (Fig. 2 - step 4.1)
3.1 Drill a 20 mm hole in the guitar side
for the XLR connector
3.2 Follow the XLR connector instructions
(page 5)
4.1 Drill a 20 mm hole in the guitar
tailblock for the XLR connector
4.2 Install the XLR connector and x it with
wood screws
5. Follow the “Fitting the Microphone”
instructions
6. Replace the string set
RESOCOIL JACK
1. Remove the strings
2. Choose whether you want to install
the 1/4” jack connector on the side
(Fig. 1) or on the tailblock (Fig. 2)
3. Drill a 12 mm hole in the guitar side
for the jack connector
4. Install the jack connector by tightening
the inside and outside nuts
5. Follow the “Fitting the Microphone”
instructions
6. Replace the string set
Fig. 1:
Installation
on the side
Fig. 2:
Installation on
the tailblock

5
1. Take one string and
make a knot at the end (or
use the little ball if present
on the string). Thread the
string through one of the
holes in the aluminum part
and pull it.
2. Thread the string
through the XLR hole, then
through one of the screw
holes.
3. Put the aluminum part
inside the instrument
through the XLR hole.
Hold the string with one
hand.
4. Thread the string in your
hand through the screw
hole of the XLR connector.
Slip the transducer inside
the instrument and t the
connector into the hole.
5. Pull the string towards
you and put the metric
screw into the free hole.
Fix the screw with your
screwdriver.
6. Push the string into the
instrument and remove it.
Fix the second screw.
XLR on the side

ELECTRODYNAMIC
PICKUPS
FITTING THE
MICROPHONE
Acoustic guitar Classical guitar Flamenco/jazz
guitar
Mandolin - Lute
Oud - Bouzouki Ukulele
Using double-sided tape, temporarily x the pickup on the outside of the instrument.
See the above pictures for typical positioning on the most commonly-used instruments.
Test the pickup, trying out different positions to nd the best sound.
Once you have found the best position, remove the strings to access the inside of
the body and permanently install the pickup inside the instrument. Fix in place using
contact glue (like the one used for shoe repair).
Replace the strings.

7
TECHNICAL
INFORMATION
*Output frequency response is electronically ltered to better match the specic application.
Transducer type
Mechanical decoupling
Frequency response (@ ±3 dB) - ltered*
Sensitivity
Dynamic range
Output impedance (@ 1 kHz)
Operating voltage
Built-in preamp
External preamp
Contacts
For xed installation
Removable
Connection
Cable length
Electrodynamic moving coil contact microphone
Butterworth 2nd order
20 Hz to 16 kHz
ca. -25 dBu
139 dB
380 Ω
No (passive)
No
No
All hard gold plated 0.5 mm
Yes
No
XLR balanced or 1/4” jack balanced
0.25 m

ELECTRODYNAMIC
PICKUPS

9
FAQ
For specic information on personal instrument
compatibility or setup, please email our
assistance service. Our specialists will be
pleased to help you.
You can nd all our contacts in the footer of
every SCHERTLER website page: www.schertler.
com
You can follow the “Fitting the Microphone”
instructions in this manual. There are also some
tutorial videos on the SCHERTLER YouTube
channel (please subscribe if you like).
However, please bear in mind that the positioning
might affect the overall sound, depending on
your personal taste or the characteristics of
your instrument.
Yes, being a passive transducer RESOCOIL can
simply be connected to the input on the wireless
transmitter, no phantom power is required.
No, superglue creates a hard layer when it dries.
We suggest using contact glue (like the one used
for shoe repair). It becomes elastic enough to
propagate the vibrations to the transducer in a
more natural way, resulting in a natural acoustic
sound. Follow the manufacturer’s instructions to
correctly apply the glue.
Is my setup correct?
Have I tted the microphone correctly? is there
a video?
Can I use my RESOCOIL with a wireless system?
Can I use superglue to install the pickup?

ELECTRODYNAMIC
PICKUPS

11
APPENDIX
WARRANTY
All SCHERTLER products are covered by a limited two-year factory warranty (from the date of
purchase) in respect of manufacturer defects. Details can be obtained from your local dealer /
representative.
SCHERTLER SA strongly believes in “common sense”. Therefore, misuse of our products is not
covered under rights obtained through our warranty policy, or through internationally recognized
terms and conditions. For more information on warranty, please visit the SCHERTLER website.
PRODUCT DISPOSAL
This product must not be disposed of in general household waste. It should be taken to a disposal
center for electrical / electronic waste. Please note any local or national regulations that may be
applicable here.
TRADEMARKS
The SCHERTLER® name and logo are registered trade names / trademarks of SCHERTLER SA
Switzerland. All SCHERTLER® products use proprietary technology and are covered by one or
more worldwide patents.
DISCLAIMER
All information and technical specications published here are based on data that was available at
the time of publication. SCHERTLER is, however, constantly aiming to improve its range of products
and therefore reserves the right to amend product specications and information without notice.
SCHERTLER takes no responsibility for any direct or indirect damage (including loss of prot), which
arises as a result of, or in connection with the information in this manual.
COPYRIGHT
This manual is the property of SCHERTLER SA and, as such, is subject to Swiss copyright law. No part
of this manual should be reproduced, edited or distributed without prior consent from SCHERTLER.
