Congratulations on purchasing a SCHERTLER® DYN P48 Series microphone. It is our pleasure
to welcome you to a growing family of musicians and technicians, including many of the world’s
leading soloists and sound engineers, who have chosen to work with SCHERTLER® products.
DYN P48 Series microphones represent the latest generation of our agship range, which has
proved a rm favorite for over 20 years. Developments in electronics and ltering technology have
enabled us to match each model even more precisely to the sound characteristics of its intended
instrument. This has led to more natural-sounding results and more user-friendly operation.
All SCHERTLER contact microphones are developed and manufactured according to the highest
standards of design, material quality and workmanship in order to ensure longevity. However, it is
important to always handle your microphone with care so that it will provide reliable service.
In our continuing quest to improve the transmission and reproduction of acoustic instrument sound,
we hope that our DYN P48 Series microphones will also enhance your personal performing or
recording experience.
Stephan Schertler
and the SCHERTLER Team

INTRODUCTION
3
SCHERTLER DYN P48 Series contact microphones are high-quality transducers designed for
professional applications. Suitable for use on a variety of instruments in both live/amplied and
studio environments, these fully-balanced, active, dynamic contact microphones can be safely
applied to even the most valuable of instruments using the special adhesive putty provided.
The microphones can be quickly transferred between instruments during performances or recording
sessions. Once in place, their lightweight design makes them unobtrusive to the performer.
A balanced XLR connector enables direct connection to a microphone input on a mixing console, or
a full range amplication system. (Note: these contact microphones require 22 to 48 VDC phantom
power, with the exception of the passive DYN UNI.) The torsion-resistant, Kevlar-reinforced cable
is designed to withstand the rigors of daily use while delivering best possible performance results.
SCHERTLER DYN P48 Series microphones all feature built-in Class-A preamps and advanced ltering
technology that enables an optimum frequency response to be obtained from each individual
instrument.
To make the most of your microphone’s capability and to ensure trouble-free operation, please
read this manual carefully before using the mic for the rst time. We also advise keeping the
manual for future reference.
SCHERTLER DYN P48 Series: Made in Switzerland

ELECTRODYNAMIC
PICKUPS

5
FITTING THE
MICROPHONE
• Using the GREEN PUTTY supplied in the package, form a ball that is approximately 8mm in
diameter.
• Place the ball on a at surface and “work” the putty back and forth to form a “worm” of around
6 cm in length.
• Apply the “worm” of putty lightly to the underside of the microphone, as shown above. Make
a complete ring around the surface - this will create a “vacuum” effect once the microphone is
attached to the instrument, thus ensuring improved adhesion.
• Fit the microphone to the instrument by pressing rmly. Don’t press too hard, but press rmly
enough to achieve sufcient contact. At the same time, twist the microphone back and forth slightly
to allow any trapped air to escape. When the microphone has been correctly tted, you will feel
that the center spot is making contact with the instrument.
Note: This putty is derived from a special inert formula, so it can be used many times without
presenting any risk to even the nest of instrument nishes. If any trace is left on the instrument it
can easily be removed. Take a generous dab of putty from the container and use it as an eraser
by making “dabbing” motions. This completely removes any residue that might be left when the
microphone is detached.

ELECTRODYNAMIC
PICKUPS
RECOMMENDED
POSITIONING
steel string
guitar nylon string
guitar amenco / jazz guitar
mandolin violin / viola
banjositar double bass / cello

7
grand piano
harp
ukulele
percussion
kalimba
cithara
move the DYN to the
left - more high end
move the DYN to the
right - softer sound
ca. 20 mm
DYN P48
soundboard
side

ELECTRODYNAMIC
PICKUPS
ACTIVE FILTERS
DYN G P48
DYN M P48 - DYN UKE P48
DYN V P48

9
DYN B P48 - DYN C P48 - DYN H P48 - DYN P P48 - DYN GP P48
DYN UNI P48 - DYN UNI

ELECTRODYNAMIC
PICKUPS
48 VDC on
Phantom power required
(except DYN UNI)
DYN V P48 and
DYN C P48 with
binder connector
DYN B P48 with
custom XLR
connector mounted
between strings
CONNECTIONS

11
TECHNICAL
INFORMATION
Transducer type
Mechanical decoupling
Frequency response (@ ±3 dB) - ltered*
Sensitivity
Dynamic range
Output impedance (@ 1 kHz)
Operating voltage
Built-in preamp
External preamp
Contacts
For xed installation
Removable
Connection
Cable length
DYN P48
Electrodynamic moving coil active contact microphone
Butterworth 2nd order, Q = 0.6
20 Hz to 16 kHz
ca. -30 dBu
139 dB
4.7 kΩ
22 to 48 VDC
Yes, Class-A
No
All hard gold plated 0.5 mm
No
Yes
XLR balanced
DYN G P48 - 2.2 m
DYN V P48 - 2.2 m - pickup to binder conn. + extra
cable binder conn. to XLR
DYN M P48 - 2.2 m
DYN UKE P48 - 2.2 m
DYN B P48 - 0.3 m - custom connection to string holder
DYN C P48 - 1.3 m - pickup to binder conn. + extra
cable binder conn. to XLR
DYN H P48 - 1.4 m
DYN P P48 - 1.4 m
DYN GP P48 - 1.4 m
DYN UNI P48 - 4 m
*Output frequency response is electronically ltered to better match the specic application.
Transducer type
Mechanical decoupling
Frequency response (@ ±3 dB) - ltered*
Sensitivity
Dynamic range
Output impedance (@ 1 kHz)
Operating voltage
Built-in preamp
External preamp
Contacts
For xed installation
Removable
Connection
Cable length
DYN UNI
Electrodynamic moving coil contact microphone
Butterworth 2nd order, Q = 0.6
40 Hz to 14 kHz
ca. -38 dBu
139 dB
380 Ω
No (passive)
No
No
All hard gold plated 0.5 mm
No
Yes
XLR balanced
4 m

ELECTRODYNAMIC
PICKUPS
FAQ
No, you can always use the same putty. If it
becomes drier or harder, you can simply restore
it by manipulating and remodeling it with your
ngers. It will then return to its soft, sticky state
ready for the next use. There is no need to
change the GREEN PUTTY every time.
GREEN PUTTY, like every other SCHERTLER
accessory, can be purchased directly from the
SCHERTLER webshop www.schertler.com
No, the GREEN PUTTY is 100% natural rubber
and doesn’t in any way ruin the nish of your
instrument. You can stick it on and remove it as
many times you want with no harm done.
Do I have to change the GREEN PUTTY every
time I remove the pickup from the instrument?
I lost the GREEN PUTTY, how can I buy a new
one?
Using the GREEN PUTTY, is there any risk for
my instrument nish?

13
For specic information on personal instrument
compatibility or setup, please email our
assistance service. Our specialists will be
pleased to help you.
You can nd all our contacts in the footer of
every SCHERTLER website page: www.schertler.
com
You can follow the “Fitting the Microphone”
and “Recommended Positioning” instructions in
this manual. There are also some tutorial videos
on the SCHERTLER YouTube channel (please
subscribe if you like).
However, please bear in mind that the positioning
might affect the overall sound, depending on
your personal taste or the characteristics of
your instrument.
Yes, DYN P48 mics work from a minimum
voltage of 22 VDC. However, higher levels (up
to 48 VDC) provide greater volume and the full
dynamic range of the pickup’s output.
You can basically regard your DYN as a
condenser microphone. As long as the wireless
system supports a condenser mic, it should work
with your DYN pickup. Remember that active
DYN P48 pickups require phantom power in
order to work, so the wireless transmitter must
provide it for the pickup. The passive DYN UNI
can simply be connected to the XLR input on the
wireless transmitter.
You can use a common balanced XLR-XLR cable
as an extension for the connection of your DYN.
Is my setup correct?
Have I tted the microphone correctly? is there
a video?
Does my DYN P48 work when connected
directly to my SCHERTLER amp that has 24 V
phantom power labeling?
Can I use my DYN with a wireless system?
The cable length of my DYN is too short, what
can I do?

ELECTRODYNAMIC
PICKUPS

15
APPENDIX
WARRANTY
All SCHERTLER products are covered by a limited two-year factory warranty (from the date of
purchase) in respect of manufacturer defects. Details can be obtained from your local dealer /
representative.
SCHERTLER SA strongly believes in “common sense”. Therefore, misuse of our products is not
covered under rights obtained through our warranty policy, or through internationally recognized
terms and conditions. For more information on warranty, please visit the SCHERTLER website.
PRODUCT DISPOSAL
This product must not be disposed of in general household waste. It should be taken to a disposal
center for electrical / electronic waste. Please note any local or national regulations that may be
applicable here.
TRADEMARKS
The SCHERTLER® name and logo are registered trade names / trademarks of SCHERTLER SA
Switzerland. All SCHERTLER® products use proprietary technology and are covered by one or
more worldwide patents.
DISCLAIMER
All information and technical specications published here are based on data that was available at
the time of publication. SCHERTLER is, however, constantly aiming to improve its range of products
and therefore reserves the right to amend product specications and information without notice.
SCHERTLER takes no responsibility for any direct or indirect damage (including loss of prot), which
arises as a result of, or in connection with the information in this manual.
COPYRIGHT
This manual is the property of SCHERTLER SA and, as such, is subject to Swiss copyright law. No part
of this manual should be reproduced, edited or distributed without prior consent from SCHERTLER.
