Schiller CLASSEN TR-20H User manual

OPERATING & PARTS MANUAL
MAN C100618 Rev. F
MODELS:
TR-20H / TR-20B / TR-20K
TURF RAKE
TR-20MH / TR-20MB
TURF RAKE with MULTI-PURPOSE BLADE
TR-20RH / TR-20RB
TURF RAKE with SPRING TINE REEL
TS-20H / TS-20B / TS-20K
TURF SEEDER

ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State of
California to cause cancer, birth
defects or other reproductive harm.
www.p65warnings.ca.gov
L’ é mission du moteur de ce mat é riel
con-tient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è
re de reproduc-tion.
www.p65warnings.ca.gov
El estado de California hace saber que los
gases de escape de este producto
contienen productos quÍmicos que
producen cáncer, defectos de nacimiento
y otros daños en el proceso de
reproducción humana.
www.p65warnings.ca.gov
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, wiring
insulation, and related accessories
contain lead and lead compounds,
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
WASH HANDS AFTER HANDLING.
www.p65warnings.ca.gov
TURF RAKE/ SEEDER
2

IMPORTANT MESSAGE
Thank you for purchasing this Classen product. You have purchased a world class product, one of the best
designed and built anywhere.
This product comes with a Parts/Operator's Manuas. The useful life and good service you receive from this
product depends to a large extent on how well you read and understand this manual. Treat this product
properly and adjust it as instructed, and it will give you many years of reliable service.
See a Classen dealer for any service or parts needed. Classen service ensures that you continue to receive
the best results possible from Classen products. You can trust Classen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Classen designs and builds its equipment to serve many years in a safe and productive manner. For longest life,
use this product only as directed in the manual, keep it in good repair and follow safety warnings and instruc-
tions. You'll always be glad you did.
.
CLASSEN®
SCHILLER GROUNDS CARE, INC.
1028 STREET ROAD, P.O. BOX 38
SOUTHAMPTON, PA 18966
PHONE [phone] • FAX [phone]
TABLE OF CONTENTS PAGE
SAFETY .........................................................................................................................................................4-9
SET-UP INSTRUCTIONS ..............................................................................................................................10
OPERATION ............................................................................................................................................11-12
ADJUSTMENTS .......................................................................................................................................14-15
MAINTENANCE/STORAGE...........................................................................................................................16
TIRE SCRAPER ............................................................................................................................................17
ENGINE & RAKE ASSEMBLY ..................................................................................................................18-19
HANDLE ASSEMBLY ...............................................................................................................................20-21
MAIN FRAME & WHEEL ASSEMBLY ......................................................................................................22-23
LABELS ....................................................................................................................................................24-25
SEEDER BOX ASSEMBLY ......................................................................................................................26-27
RAKE BLADE ASSEMBLY ............................................................................................................................28
MULTI-PURPOSE ASSEMBLY (OPTIONAL) ................................................................................................29
SLICER ASSEMBLY (OPTIONAL) ................................................................................................................30
SPRING TINE REEL ASSEMBLY (OPTIONAL) ............................................................................................31
WARRANTY ................................................................................................................................. BACK PAGE
CONTROLS..................... ...............................................................................................................................13
TURF RAKE/ SEEDER
3

NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Schiller Grounds Care, Inc. strongly warns against,
rejects and disclaims any modifications, add-on
accessories or product alterations that are not
designed, developed, tested and approved by Schiller
Grounds Care, Inc. Engineering Department. Any
Schiller Grounds Care, Inc. product that is altered,
modified or changed in any manner not specifically
authorized after original manufacture–including the
addition of “after-market” accessories or component
parts not specifically approved by Schiller Grounds
Care, Inc.–will result in the Schiller Grounds Care,
Inc. Warranty being voided.
Any and all liability for personal injury and/or property
damage caused by any unauthorized modifications,
add-on accessories or products not approved by
Schiller Grounds Care, Inc. will be considered
the responsibility of the individual(s) or company
designing and/or making such changes. Schiller
Grounds Care, Inc. will vigorously pursue full
indemnification and costs from any party responsible
for such unauthorized post-manufacture modifications
and/or accessories should personal injury and/or
property damage result.
MODEL NUMBER: This number appears on sales
literature, technical manuals and price lists.
SERIAL NUMBER: This number appears only
on your unit. It contains the model number fol-
lowed consecutively by the serial number. Use this
number when ordering parts or seeking warranty
information.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify
levels of hazard seriousness. These words
appear in this manual and on the safety labels
attached to Schiller Grounds Care, Inc. machines.
For your safety and the safety of others, read and
follow the information given with these signal
words and/or the symbol shown above.
DANGER indicates an imminently hazardous
situation which, if not avoided, WILL result in death
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, MAY result in minor or moderate
injury. It may also be used to alert against unsafe
practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage
Schiller Grounds Care, Inc.
1028 Street Road
Southampton, PA 18966 U.S.A
Phone: [phone]
Fax: [phone]
MODEL NUMBER
SERIA
L NUMBER
SAFETY
TURF RAKE/ SEEDER
4

Operator Preparation and Training
– Read the operation manual.
– Read the engine manufacturer's owner manual.
– Explain this material to any operator or mechanic
who cannot read English.
– Contact your factory representative for
clarification if any portion of this material is
unclear.
– Adhere to the warnings and instructions depicted
in the safety decals on the machines.
– Replace any missing or damaged labels.
– Keep warning labels and this operator's manual
legible and intact.
– Become familiar with the safe operation of the
equipment, operator controls and safety signs.
– Know how to stop the engine and attachments
quickly in an emergency.
– Do not operate or allow another person to
operate this machine if there are any questions
about safety.
– Train all operators and mechanics; the owner is
responsible for training the users and for
accidents or injuries occurring to themselves,
other people or property.
– Never attempt to use a machine that is damaged
or has unauthorized modifications.
– Wear appropriate clothing, including long trousers
and gloves.
– Do not operate barefoot or wearing open sandals.
– Do not operate with loose clothing, long hair or
jewelry which may get tangled in moving parts.
– Wear hearing protection.
– Wear safety glasses with side shields.
– Wear a dust mask to avoid breathing dust.
– Never allow underage children (as defined by
local regulations), unskilled or improperly trained
people to operate this equipment.
– Do not operate machine while under the influence
of drugs, alcohol, or any other condition of
impairment.
– The owner/user can prevent and is responsible
for accidents or injuries occurring to themselves,
other people or property.
Site Preparation and Circumstances
– Evaluate the terrain to determine what
accessories and attachments are needed to
properly and safely perform the job.
– Only use accessories and attachments
approved by the manufacturer.
– Remove all objects or debris from the area that
may be picked up or thrown by the machine.
– Keep pets and people, especially young
children, away from the area and immediately
cease operation of the equipment if any enter
the area.
– Operate only in daylight or in good artificial light.
– Evaluate the terrain to determine how to safely
perform the job.
Machine Preparation
– Do not tamper with or defeat safety devices; they
exist for your protection.
– Keep guards, shields and interlocked safety
devices in place and in proper working condition.
– Keep all fasteners—nuts, bolts and pins—
secured.
– Visually inspect blades, blade bolts and the
aerating assembly for wear or damage and
replace worn or damaged parts.
– Verify that the machine and any attachments are
in good operating condition.
– Do not start machine until ready to use.
TURF RAKE/ SEEDER
SAFETY
5

OPERATION SAFETY
GENERAL
– Use extra care when loading or unloading the
machine onto a trailer or truck. Do not use split
ramps; use full width ramps.
– Watch out for traffic when near or crossing
roadways.
– Do not run the engine in an enclosed area where
dangerous carbon monoxide fumes can collect.
– Use extreme caution when reversing or pulling
machine towards you.
– Never leave a machine unattended; stop engine.
STARTING
– Start only according to instructions in this manual
or on the machine.
Before starting:
•Make sure the bail is released.
•Make sure hands and feet are clear of
the blades.
– Do not change engine governor settings or
overspeed the engine. Operating the engine
at excessive speed can increase the hazard of
personal injury.
MANEUVERING SAFELY
GENERAL
– Slow down before turning.
– Do not rake/seed in reverse unless absolutely
necessary; verify area is clear of pets and people.
– Be aware when approaching blind corners,
shrubs, trees, tall grass or other objects that may
obscure vision.
– Release the bail when crossing surfaces other
than grass.
INTERRUPTING OPERATION
– Before leaving the operator's position for
refueling, project end, or transport:
a. Park on level ground
b. Release bail
c. Reduce throttle setting
d. Shut off the engine
e. Wait until blades stop moving
– Before leaving the operator's position for
clearing blockages, making blade adjustments,
repairs, inspection, checking, cleaning or
working on the machine:
a. Park on level ground
b. Release bail
c. Reduce throttle setting
d. Shut off the engine
e. Wait until blades stop moving
f. Disengage the master clutch, disconnect the
spark plug wire(s) or remove the key
Some repairs or adjustments as specifically
noted, such as for carburetor adjustment,
require the engine to be running. Keep hands
and feet clear of moving parts in these
circumstances.
TURF RAKE/ SEEDER
SAFETY
6

OPERATING ON SLOPES
All slopes require extra
caution. Loss-of-control and
tip-over accidents can lead to
severe injury or death.
– Evaluate the risks involved before operating on
slopes
– Do not operate on slopes if uneasy or uncertain.
Ultimate responsibility for safe operation on slopes
rests with the operator.
– Do not rake/seed steep slopes if:
- The machine must be crabbed (turned partially
sideways uphill) to drive across the slope.
- The machine turns downhill going across the
slope.
-You are uneasy about being on the slope.
–Travel up and down slopes at a 45° angle to prevent
unit from tipping over.
– Avoid starting or stopping on a slope. If tires lose
traction, disengage the blades and proceed slowly
straight down the slope.
– Keep all movement on the slopes slow and
gradual. Do not make sudden changes in speed
or direction.
– Do not turn on slopes unless necessary, and then
turn slowly and downhill when possible.
– Stay away from slopes if the ground is loose or
wet.
– Use lower speeds on a slope to avoid stopping or
shifting.
– Use extra care with attachments. These can
change the stability of the machine.
– Avoid driving over ruts, holes, rocks and roots.
Be alert to dips and rises. Uneven terrain can
overturn a machine or cause it to slide.
– Do not rake/seed dropoffs, ditches or
embankments. The machine could suddenly turn
over if a wheel runs over the edge or an edge
caves in.
WARNING
MAINTENANCE SAFETY
GENERAL
– Maintain machine according to manufacturer's
schedule and instructions for maximum safety
and best results.
– Park machine on level ground.
– Never allow untrained personnel to service ma-
chine.
– Do not adjust or repair until the engine is stopped
and all parts have stopped moving.
– Replace parts if worn, damaged or faulty.
For best results, always replace with parts
recommended by the manufacturer.
– Disconnect spark plug wire(s) before making any
repairs.
– Do not dismantle the machine without releasing
or restraining forces which may cause parts to
move suddenly.
– Provide adequate support for lifted machine or
parts before working beneath them
– Do not put hands or feet near or under rotating
parts.
– Clean up oil or fuel spillage thoroughly.
– Replace faulty mufflers.
– Keep the engine, muffler, battery compartment,
and fuel storage area free of grass, leaves,
debris buildup or grease to reduce fire hazards.
– Guards should only be removed by a qualified
technician for maintenance or service. Replace
when work is complete.
Blades
–Use extra caution when handling
the rake/seeder blades. Blades
are sharp and can cut.
–Remove obstructions with
care; wrap the blade or wear gloves.
–Replace the blade; do not repair,
straighten or weld.
–Keep other persons away from blades.
WARNING
TURF RAKE/ SEEDER
SAFETY
7

FUEL
– Use extra care when handling gasoline and
diesel fuels; they are flammable. Gasoline
vapors are explosive.
– Store only in containers specifically designed for
fuel.
– When refueling or checking fuel level:
- Stop the engine and allow to cool
- Do not smoke
- Refuel outdoors only
- Use a funnel
- Do not overfill
- Clean up all spills and wait for vapors to clear
before starting the engine
WARNING
STORAGE SAFETY
– Stop the engine and allow to cool before storing.
– Drain the fuel tank outdoors only.
– Store fuel in an approved container in a cool, dry
place.
– Keep the machine and fuel containers in a locked
storage place to prevent tampering and to keep
children from playing with them.
– Do not store the machine or fuel container near
heating appliances with an open flame such as a
water heater or an appliance with a pilot light.
– Keep gasoline storage area free of grass, leaves
and excessive grease to reduce fire hazard.
– Clean grass and debris from unit, drives, mufflers
and engine to help prevent fires.
To prevent static electricity sparks:
–Keep containers electrically grounded;
flowing fuel can generate static electricity.
–Refill fuel containers on the ground away
from the vehicle; do not fill containers in a
–vehicle or on a truck or trailer bed with a
plastic liner.
–When practical, remove equipment from the
truck or trailer and refuel it on the ground.
–If equipment must be refueled on the truck or
trailer, refuel from a portable container rather
than a dispenser nozzle.
–Keep the dispenser nozzle in contact with the
rim of the fuel tank or container opening until
fueling is complete.
–Do not use a nozzle lock-open device.
- Replace caps on fuel cans and tanks securely.
- Change clothing immediately if fuel is spilled on
it.
TURF RAKE/ SEEDER
SAFETY
8

100504
WARNING
Operation of This Equipment
May Create Sparks That Can
Start Fires Around Dry
Vegetation. A Spark Arrestor
May be Required. The
Operator Should Contact Local
Fire Agencies For Laws or
Regulations Relating to Fire
Prevention Requirements.
--This label meets California
4442.6
TURF RAKE/ SEEDER
SAFETY DECALS
9

ASSEMBLY / SET UP INSTRUCTIONS
NOTE: Units ship with no gas or oil.
1. READ THE OPERATOR'S MANUAL BEFORE ASSEMBLY.
2. Cut banding and roll rake off pallet.
3. Unfold by pulling up on handle.
4. Slide lock rings down.
5. Add oil to the engine with the engine resting in a level position. Refer to the engine manufacturer’s Owners
manual for the correct type and amount of oil.
6. Fill the fuel tank according to the engine manufacturer specifications.
SEED BOX INSTALLATION
For shipping purposes only, the seed box assembly is attached to the machine improperly.
To set up your machine correctly for operation:
STEP 1:
1. Remove hairpin clip (A) from lower connecting rod (B).
2. Slide lower rod (B) out of stabilizing bracket on seed box.
STEP 2:
1. Mount seed box so that the wheels of the seed box are resting on the front wheels of the machine.
2. Reinstall lower rod (B) and clip (A).
PRE-OPERATION CHECK LIST
(OWNER’S RESPONSIBILITY)
___ Review and follow all safety rules and safety
decal instructions.
___ Check that all safety decals are installed and in
good condition. Replace if damaged.
___ Check to make sure all shields and guards are
properly installed and in good condition.
___ Check that all hardware is properly installed.
and secured.
___ Check that equipment is properly and securely
attached to power unit.
___ Check to be sure engine is free of dirt and
debris. Pay particular attention to the cooling
fins, governor parts and muffler. Clean air
intake screen. Check air cleaner; service if
necessary.
___ Never allow riders.
___ Inspect area and remove stones, branches or
other hard objects that might affect operation,
cause injury or damage.
___ Clean area around oil fill dipstick. Remove
dipstick and check to be sure oil is in operating
range (between marks on dipstick). Refer to
the engine manufacturer’s Owners manual for
the correct type and amount of oil. Dipstick
assembly must always be secured into fill tube
when engine is running.
___ Check all lubrication points and grease as
instructed in engine manual.
___ Perform a functional check of the safety
interlock system each time you operate the
unit. (If present)
A
B
B
A
STEP 1
STEP 2
TURF RAKE/ SEEDER
SET-UP INSTRUCTIONS
10

FUELING
–Fill the fuel tank according to the engine
manufacturer specifications.
– Use a funnel to avoid spillage.
WARNING
TO CHECK OR ADD FUEL:
– Do it outdoors
– Do not smoke
– Stop engine; allow to cool
– Fill to one inch below bottom
of filler neck
– Do not overfill
– Clean up spilled fuel
BEFORE STARTING THE ENGINE
1. Be familiar with the controls, how each functions,
and what each operates. Read operator’s manual
before using.
2. Check engine oil level while the machine is on
level ground, . Add oil if necessary, following the
engine manufacturer’s recommendations. Refer to
engine manual supplied with machine.
3. Open the fuel valve.
4. Fill the fuel tank with the amount and type of fuel
recommended by the engine manufacturer.
5. Check all moving parts, fasteners, and blades.
Tighten or replace any if necessary.
Cold starts:
1. Set the throttle lever to the half-open position.
2. Move the choke to the ON position.
STARTING THE ENGINE
3. Turn fuel cock to the “open” position.
4. Turn ignition switch to “on”.
5. Pull recoil starter rope until engine starts.
6. After engine is warm, move the choke to the
OFF position
7. Allow engine to run one minute before using.
OPERATING
1. Start the engine
2. Move Turf Rake/ Seeder to the area to be raked
or seeded.
3. Move height adjustment lever to the appropriate
setting for the shaft assembly being used. (see
“optional shaft assemblies” section
4. Engage the bail.
5. Release the bail to stop
Warm starts:
1. Set the throttle to the half-open position.
2. Move the choke to the OFF position.
TURF RAKE/ SEEDER
OPERATION
11

OPTIONAL BLADE ASSEMBLIES
Changing Complete Blade Assemblies
Within minutes your machine can be converted to a
turf rake, turf seeder or turf slicer by purchasing the
optional blade assemblies available complete with
the side plates, bearings and drive pulley.
1. Set unit up on block allowing enough distance
beneath machine to change blade assembly.
2. After removing the belt shield, remove twelve
bolts (six on the left and six on the right) which
hold the blade assembly to the main body.
3. Remove the belt and remove the entire blade
assembly. There is no need to loosen any set
screws.
4. Next install the optional blade assembly and
fas-ten with six 1/4” x 5/8” bolts on each side.
Tight-en all bolts on both shields. Center the
shaft and tighten the two set screws in each
bearing using medium-strength thread locker.
5. When changing back to the original shaft it will
not be necessary to loosen any set screws.
Only the bolts in the belt shields and the eight
bolts holding the shaft will be to be removed.
BE CERTAIN THAT THE SET SCREWS ARE
TIGHTENED PROPERLY IN BEARINGS AND
PULLEY WHEN REASSEMBLING.
Changing Partial Blade Assemblies
1. Set unit up on block allowing enough distance
beneath machine to change blade assembly.
2. After removing the belt shield, remove twelve
bolts (six on the left and six on the right) which hold
the blade assembly to the main body.
3. Remove the belt and remove the entire blade
assembly.
4. Remove the drive pulley and bearing plates
from the main shaft (one on each side). Replace
with new shaft. Reinstall the bearing plates and
drive pulley on the new shaft using a medium-
strength thread locker on the bolt and set screws.
The pulley will be positioned on the shaft by bolts,
the 1/4” lock washer, and the pulley retainer
washer.
5. Reinstall the blade assembly. Ensure the
hardware is tightened on the end plates.
6. Route the belt behind the idler pulley and roll
the belt onto the lower pulley, then reinstall the belt
shield.
TURF RAKE/ SEEDER
OPERATION
12

FUEL SHUT OFF (A) - Move to the “OFF”
position to shut off the fuel whenever transporting the
machine by trailer, truck or during storage. Move to the
“ON” position before starting the engine.
SWITCH (B) -
Move to the “OFF” position to stop the engine.
Move to the “ON” position before starting engine.
Note: the Kohler engine switch is built into the Fuel
Shut Off (A).
CHOKE (C) -
Move to the “CHOKE” position to apply the choke.
Move to the “RUN” position to remove the choke.
RAKE BAIL (F) - Pull up on bottom bail to engage
the main shaft. Release bail to disengage.
HEIGHT ADJUSTMENT (G) - Place on lawn
surface and adjust the wheel height up to lower the
blades. Adjust wheel height down to raise blades.
SEED FLOW CONTROL (S) - Pull up on
bottom bail to engage the main shaft. Release bail to
disengage. (SEEDER ONLY)
TURF RAKE/ SEEDER
CONTROLS
13
C
A

Recommended Height Adjustments
Raking Assembly Height
When using the Turf Rake with its raking (flail) blade
assembly adjust the raking height as follows.
Normal height is set by placing the Turf Rake on a
hard surface making sure one satellite shaft is at
dead bottom. Adjust the wheels so the raking fingers
on the bottom shaft just touch the ground. DO NOT
set the fingers so that they will penetrate the ground
as this will counteract the centrifugal force of the
fingers and prevent the from raking properly.
With repeated use, raking side of the fingers will
begin to wear. To give the fingers a new square
raking edge, remove the end plates and turn the
entire main shaft assembly 180° and replace it on
the Turf Rake. NOTE: Use Pro-Lock (retaining 1,
medium strength) on the 7” pulley on the
main shaft.
To prolong the life of the main shaft, extra holes are
provided. If the circular holes holding the satellite
shafts become distorted, rotate all four satellite
shafts to the next set of holes.
When using the Turf Rake with it’s raking (spring
tine) assembly, adjust the raking height as follows:
Normal height is set by placing the Turf rake on a
hard surface. Adjust the wheels so the spring blades
just barely touch or are slightly above the ground.
DO NOT set the spring blades so that they penetrate
the ground. Doing this will cause premature damage
to the spring blades.
Seeding / Multipurpose Blade Assembly Height
The seeding/multipurpose blades are used for cutting
grooves for over-seeding and can also be used
for verticutting grasses. To set the height properly
place unit on the lawn surface and adjust the wheel
height up (see Fig. 4 ). Adjusting the wheel height up
lowers the blades.
Seeding:
The proper height setting for over-seeding is
approximately 1/4” into the ground. Adjust the wheel
height up approximately one notch. If
set deeper, grass seed being applied may not
germinate.
For best results, over-seed in two passes of 1/2
application rate at right angles or in a criss-cross
pattern. Water heavily immediately after seeding
then lightly for 10-14 days keeping soil moist.
Slicing
The proper height setting for slicing or aerating is 1/2”
to 3/4” into the ground. Adjust the wheel height up
one or two notches.
For crawling grasses such as Zoysia, Bermuda,
Bahia, etc. raise the wheels only one notch. Crawling
grasses should not be sliced too deeply.
For single strand grasses like Bluegrass or Rye,
rake/seed in perpendicular directions for more even
slicing. For example, slice in a North-South direction
on the first pass, switching to an
East-West direction on the second pass.
As the seeder/multipurpose blades wear they
may be rotated to provide a new cutting edge.
The wheels may be raised to allow the blades to
penetrate deeper into the ground.
FIGURE 4
TURF RAKE/ SEEDER
ADJUSTMENTS
14

Slicer Blade Assembly Height
The slicer blade assembly is recommended for
slicing, verticutting or aerating when a thinner blade
is preferred. This is the recommended blade for use
on golf course greens. To set the height properly
place unit on the lawn surface and adjust the wheel
height up (see Fig. 4). Adjusting the wheel height up
lowers the blades.
The proper height setting for slicing or aerating is 1/2”
to 3/4” into the ground. Adjust the wheel height up
one or two notches.
For crawling grasses such as Zoysia, Bermuda,
Bahia, etc. Raise the wheels only one notch.
Crawling grasses should not be sliced too deeply.
For single strand grasses like Bluegrass or Rye,
rake/seed in perpendicular directions for more even
slicing. For example, slice in a North-South direction
on the first pass, switching to an
East-West direction on the second pass.
As the slicer blades wear they may be rotated to
provide a new cutting edge. The wheels may be
raised to allow the blades to penetrate deeper into
the ground.
FIGURE 4
TURF RAKE/ SEEDER
ADJUSTMENTS
15

DAILY
•Perform daily maintenance checks to keep the turf
rake/seeder in good operating condition.
•Use genuine Classen parts or parts with
equivalent characteristics including type, strength,
and material when replacement parts are required
to avoid product malfunction and injury to the
operator and/or bystanders.
• Keep all safety decals legible, remove grease, dirt
and debris; replace illegible decals immediately.
•Do not operate equipment without shield(s) in
place.
•Do not make any adjustments or perform any
maintenance while the engine is running.
• Check engine mounting bolts frequently to
maintain proper tightness.
•Clean off blades when application is completed
and apply a light coat of oil to prevent rust on
blades.
•Lubricate the rake each time it is put into service.
• Keep belt free of oil and dirt.
•Check for worn or deteriorating components that
could create a hazard.
Engine Maintenance
• Refer to engine manufacturer’s Owner’s Manual.
• Check engine oil level with engine resting in a
level position.
• Inspect air filter element and replace if necessary.
• If carburetor adjustment is necessary, stand to
one side and keep feet and hands clear while
making adjustments.
STORAGE INSTRUCTIONS
Before the rake is put into storage for any period ex-
ceeding 30 days, do the following:
1. Follow the storage instructions included in the
engine manufacturer's owner's manual.
2. Lubricate all lubrication fittings.
REMOVE FROM STORAGE
1. Check for loose parts and tighten if necessary.
2. Check for cracked or broken blades and replace.
3. Fill fuel tank.
4. Check oil levels with engine on a flat surface. (refer to
Engine Manufacturer’s Owner's Manual)
5. Start engine.
6. Check for fuel leaks.
7. Check operation of control handle(s) to make sure unit
stops when lever is released.
8. Rake is equipped with fuel shut-off valve, close valve
before transporting.
TURF RAKE/ SEEDER
MAINTENANCE / STORAGE
16

TIRE SCRAPER INSTALLATION:
TURF RAKE/ SEEDER
TIRE SCRAPER
17

9
21
28
3
15
30
25
14
16
34 26 29 8
24 18
4
35
11
20
19
31
27
12
23
22
37
2
5
17
7
10
13
36
1
224
6
32
18
28
28
11
13
39
38
TURF RAKE/ SEEDER
ENGINE & RAKE ASSEMBLY
18

DESCRIPTION QTY
ITM PART NO. DESCRIPTION QTY
ITM PART NO.
1 4179011 S - RAKE DECK
4179012 S - SEEDER DECK
1
2 4173430.17 PLATE, END TR/TS 2
3 C300012.17 1
4 C100137 1
C100051
5 4179013 1
6 C100067 1
7 C400035.17 1
8 C500079 1
9 C500086 2
10 C500069 8
11 C500068 10
12 C500081 1
13 C500011 2
14 C500240 1
15 C500064 2
16 C500085 2
17 C500029 2
18 C500083
PAD, ENGINE
HONDA GX160 ENGINE
B & S 550 SERIES ENGINE
S-GUARD, BELT
GUARD, SHAFT
ARM W/ STEEL
BOLT, 3/8-16 X 1-3/4 BOLT,
5/16-18 X 3 TAP BOLT,
1/4-20 X 5/8
NUT, 1/4-20 NYLOC
NUT, 3/8-16 WHIZ LOCK
KEY, 3/16 SQUARE X 1
KEY, 3/16 SQUARE X 1 1/2
SET SCREW, 5/16-18 X
3/8 NUT,5/16-18 WHIZ
LOCK BOLT, 1/4-20 x 3/4
WASHER, 5/16 FLAT 2
19 C500070 WASHER, 1/4 SPRING LOCK 1
20 C500071 BOLT, 1/4-28 X 5/8 1
21 C100065 BELT, RAKE 1
22 C500074 BOLT, 5/16-18 X 1-3/4 4
23 C500078 E-RING, 1/2" 1
24 C500073 BOLT, 5/16-18 X 1-1/4 6
25 C300029 SPACER, 5/16 X 2 2
26 C300030 BUSHING, STRUT 2
27 C100058 PULLEY, DRIVE 1
28 C500072 NUT, 5/16-18 NYLOC 16
29 C100072 IDLER W/ FLANGES, FLAT 1
30 C100038 SHEAVE W/OUT KEY,0 1
31 C300025 "WASHER, PULLEY RETAINER 1
32 C500115 WASHER, 5/16 LOCK 4
34 C100052 BEARING, CONTROL 2
35 C100075 DECAL, TR-20 1
36 C600014 SUB-ASSY RAKE 1
37 C100050 BEARING, FLANGE 2
38 C500001 FITTING, GREASE 2
39 C500063 SET SCREW, 1/4-28 X 1/4 4
40* C100096 DECAL - ROTATING PARTS 1
* NOT ILLUSTRATED
102-0004-00 KOHLER CH245 ENGINE
11
1
TURF RAKE/ SEEDER
ENGINE & RAKE ASSEMBLY
19

16
15
6
4
5
21
7
13
8
22
14
2
11
18
1
17
16
10
12
19
9
3
20
17
4
19
3
10
12
TURF RAKE/ SEEDER
HANDLE ASSEMBLY
20
