PREFACE
Congratulations!
In purchasing this new SCHOLL appliance you have chosen a product which meets highest technical stand-
ards while providing outstanding convenience in practical use.
This appliance has been designed with minimal energy consumption in mind. Used responsibly, it will serve
you well in an ecologically sound manner.
Please read the information in this manual carefully before starting up this appliance. On the following
pages you will find important notes regarding its operation, care and maintenance so that you will be able
to enjoy its use for a long time.
If a malfunction should nevertheless occur, please consult the "Troubleshooting" section first. In many cases
you should be able to remedy minor problems yourself, thus saving unnecessary service costs.
Please retain this manual carefully and pass it on to any subsequent user for his or her information and
safety.
A quality product, properly treated, will give you many years of satisfactory service.
We trust you will enjoy using this product!
Yours sincerely
Gustav Scholl Apparatebau GmbH & Co. KG

GBA A 0811 0 E
BA Page 4 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
CONVENTIONS
PICTOGRAMS –GENERAL SAFETY NOTES
Be sure to observe these Instructions for Use as well as the safety notes to prevent
injuries or damage to health or property. Do not alter or modify this appliance.
Never use a defective appliance. If you suspect the unit of being faulty or discover an
unusual noise or smell, turn off the power switch and pull the plug out of the socket-
outlet, or otherwise disconnect the appliance from the mains and de-energize it (i.e.,
ensure that it no longer carries any voltage). Do not use this appliance when its power
cord is damaged.
Failure to observe this warning may result in a fire hazard or electrical shock!
Maintenance and repair work must be carried out only by qualified professionals using
original spare parts and accessories. Do not attempt to carry out repairs on this appli-
ance yourself!
Connect this appliance to suitably earthed mains outlets only. Ensure that your mains
power supply conforms to the data stated on the nameplate of the appliance.
Failure to observe this warning may result in a fire hazard or electrical shock!
This appliance is not intended to be used by persons (including children) of limited
physical, sensory or intellectual abilities, or lacking in experience and/or knowledge,
unless they are supervised by a person responsible for safety who instructs them in
the use of the device. Children should be supervised to ensure they will not play with
this appliance.

GBA A 0811 0 E
BA Page 5 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
Do not run the power cord near heat sources, over sharp edges, etc. Always pull on
the plug, not the cord, to remove it from a socket-outlet since the cord might be dam-
aged as a result. Do not allow cords to hang unsupported. Route the cord so that it will
not form a tripping hazard!
When using an extension cord, unwind the cord from the reel to prevent heat build-up
or cord fires, respectively. The socket-and-plug connection must be splash-proof and
be made of, or coated with, rubber. Each wire must have a cross-section of at least
1.5 mm².
Do not allow this appliance to operate unattended. Ensure that its power switch is set
to „0“ before inserting the plug into an electrical socket-outlet. Avoid starting the unit
unintentionally. Connecting the unit to the mains with its power switch set to ON may
cause accidents.
Protect this appliance from moisture (water spray, rain). Do not immerse the appliance
in water or other fluids and do not place it in a dishwasher. Any penetration of water
into the unit will increase the risk of an electrical shock.
Do not touch the surfaces of the appliance. The surfaces of this appliance may get hot.
Please allow the unit to cool down fully before cleaning or stowing it. Never cover this
appliance.
Burn injury or fire hazard!

GBA A 0811 0 E
BA Page 6 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
PICTOGRAMS –WARNING NOTES
Cleaning must only be performed by qualified persons who have read and under-
stood these Instructions for Use and are familiar with applicable hygiene rules. En-
sure that care is exercised during cleaning of the unit.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked
in warm water which contains a small amount of dishwashing detergent. Follow this
up by wiping with clear water until no cleaning agent residue remains on the sur-
face, as the latter might cause discoloration or stains. Finish by rubbing the surface
dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product
may be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents.
abrasive cleaning products such as scouring creams/pastes, steel wool, sa-
ponified steel wool, metal or plastic sponges, or sponges with a scratchy
surface (scouring side).
Never use steam and/or pressure jet cleaning equipment to clean this appliance.
This might damage the appliance to the point where it may pose a hazard to your
life!
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
The total permitted regeneration and hot-holding time according to HACCP will be
exceeded after 3 hours.
Risk of potential health impairment!

GBA A 0811 0 E
BA Page 7 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
Allow the unit to cool down before starting any cleaning work.
Burn hazard
PICTOGRAMS –IMPORTANT NOTES
DANGER
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or
death.
WARNING
indicates a potentially dangerous situation.
Failure to observe this warning notice may result in severe physical injury or
death.
CAUTION
indicates a potentially harmful situation.
Failure to observe this notice may result in damage to property.
DANGER –electrical voltage
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or
death.

GBA A 0811 0 E
BA Page 8 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
IMPORTANT
Improper use may result in minor injuries or damage to property.
In addition to these Instructions for Use, a number of accident prevention and
other regulations apply with regard to the operation of this appliance. As re-
gards food handling, please observe HACCP rules concerning compliance with
hygiene requirements.
If you have any questions, please contact your supervisor(s) or safety repre-
sentative.
This product must not be disposed of in domestic waste.
Please arrange for proper recycling of this product via your local provider of
waste disposal services.

GBA A 0811 0 E
BA Page 9 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
INTRODUCTION
This operating manual gives information about the function, operation and use of your stacking and output
devices, hereinafter called "stacker".
The operating manual applies to everyone, who
receives and checks the device,
installs, sets up and connects the device,
uses the device,
cleans the device,
services and maintains the device.
Please, first read the chapters Description and Function, because they give you a good overview. That is
necessary for correctly operating and functioning of the stacker.
Some texts in this manual are printed in red; they are warnings. If you do not heed those warnings, you
run the risk of your stacker not functioning properly or you getting injured. We do not accept liability for
such cases.
Depending on model and version, the stacker is meant for:
storing of one or more items of tableware,
dispensing tableware at collection level,
pre-warming of heat-resistant tableware, if the stacker is fitted with a heater,
transporting tableware.
Tableware encompasses:
plates, saucers, bowls, cups, mugs, glasses, 1)
trays,
baskets with tableware, as mentioned under 1).
The tableware is clean and may be empty or filled with solid food or, in the case of liquid food, may be shut
tight with a lid.
It is imperative that damage and deficiencies are reported within eight days from receipt of the goods.
A guaranty period of six months applies to electrical components (connection leads, wires, thermo-
stat, switches, heating elements).
A guaranty period of 12 months applies to mechanical components (stacking units with guide
wheels, castors).
The guaranty only applies if the stacker has been used for its intended purpose and only covers re-
placement of defective parts and not labour.
Stackers with electric heating:
comply with EN 60335-1 and 60335-2-50 according to the provisions of the VEM directive,
comply with EN 50081-1 and 50082-1 according to the provisions of the EMC directive.

GBA A 0811 0 E
BA Page 10 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
DESCRIPTION
Depending on model and version, the stacker has been made up of the following element:
1) Casing:
a) closed, half-open (model ORT-MS) or completely open (model OX-MS),
b) with or without heating tray and switch panel,
c) with or without push-in grip.
2) Stacking slots:
a) with or without flange,
b) with guide frames or individually adjustable guides,
c) with spring buckles.
3) Stacking platform:
a) with rollers,
b) in the shape of a frame, with or without loading platform,
c) with spring buckles.
4) Coil springs that connect the stacking slots with the loading platform.
5) Electric heating installation:
a) connection lead,
b) switch,
c) thermostat,
d) heating element with or without ventilation fan.
The model description is affixed to the outside of the stacker. Write the model description and the serial
number on the input form.

GBA A 0811 0 E
BA Page 11 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
FUNCTION
If the tension force of the coil spring has been adjusted well to the weight of the tableware, the upper ta-
bleware part should be flush with the upper edges of the guides.
When the upper tableware part is removed, the tableware part below it will take its place. The totality of
the springs determines the tension force of the stacker.
Too many springs: the tableware parts will be above the guides and if you use a lid, the lid will not shut
tight.
Too few springs: the tableware part cannot be removed or only with difficulties.
Versions with heating allow for warming up the tableware.
The heating element heats the air in the stacker, which, in turn, provides convection for the tableware.
The stacker is closed by a lid on top, ensuring that less hot air gets lost. Therefore, we recommend to use a
lid.
The locking devices on the two castors are operated by foot and block the wheels and the swivel move-
ment.

GBA A 0811 0 E
BA Page 12 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
ACCEPTANCE CHECKING
Between production and despatch, every stacker is checked for:
damage
completeness of deliverables
functioning of the stacking mechanism
functioning of switches, thermostat and heating element as well as for electrical safety.
Please check immediately upon receipt:
has the packing been damaged?
has the device been damaged?
is the device complete and are the accessories included?
NOTIFY YOUR SUPPLIER WITHIN EIGHTS DAYS OF ANY DAMAGE TO YOUR STACKER.

GBA A 0811 0 E
BA Page 13 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
INSTALLING
1) Remove the packaging.
2) Remove the plastic foil from the casing and the platform.
3) Adjust the spring force by using an item of tableware on the stacker:
a) Take the platform off the support or the removable panel from the side of the push-in grip
(only model OX-MS) and the springs can now be reached.
b) Suspend the springs outward (for less tension force) or inward (for more tension force) until
the upper edge of the stacker is flush with the upper edge of the guides.
Standard, all springs are suspended when delivered.
DO NOT PUSH THE SUPPORTS DOWN WHEN ADJUSTING THE SPRING FORCE, BECAUSE THE
SPRING MAY NOT BE UNDER TENSION.
LOOSEN THE SPRING ON THE UNDERSIDE, WHERE THE SPRING ARE SUSPENDED FROM THE
SPRING BUCKLES OF THE STACKER PLATFORM.
SPREAD THE TENSION FORCE EVENLY OVER THE SPRING BUCKLES; NOT ALL SPRING ON ONE SIDE
AND NONE ON THE OPPOSITE SIDE.
4) Adjust the adjustable guides:
a) lift the guide and turn it into the desired position,
b) allow the guide to fall back and check the immobilisation hole next to it.
CHECK, WHETHER THE TABLEWARE CAN MOVE FREELY BETWEEN THE GUIDES.
5) Commissioning heated stackers:
SET THE SWITCH TO "0" BEFORE PLUGGING THE PLUG INTO THE SOCKET.
ONLY USE EARTHED SOCKETS.
HANG THE CONNECTION LEAD ON THE FACILITY THAT HAS BEEN PROVIDED FOR THAT PURPOSE,
AFTER YOU HAVE PULLED THE PLUG OUT OF THE SOCKET.

GBA A 0811 0 E
BA Page 14 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
OPERATION
Engage the castors during loading and unloading and when pre-warming tableware.
Disengage the castors when moving the stacker.
TAKE CARE AT TRESHOLDS:
NEVER BUMP FORCEFULLY INTO THRESHOLDS, REGARDLESS OF WHETHER THE STACKER IS LADEN OR
EMPTY.
TAKE CARE AT STRONLY SLOPING SECTIONS:
REQUEST HELP, TO ENSURE THAT THE STACKER DOES NOT GET OUT OF CONTROL.
Load the stackers one after the other with small stacks of tableware.
THAT WAY YOU AVOID INJURIES AND DAMAGE TO TABLEWARE.
Set the switch to "1" and the pilot light comes on. Turn the button of the thermostat to the desired
temperature and the heating element becomes hot.
The temperature setting, the time, the tableware itself and the using of a lid all have influence on
the temperature of the tableware. Keep changing the temperature setting and the warming-up
time, until you have achieved the desired result.
Turn the heating about two to three hours before dispensing on and use, during that time, a lid on
the stacker. Use the lid also as much as possible during dispensing, in order to avoid heat loss. Use
the lid when the stacker is not used; the stacker and plates will then remain clean and free of dust.
A lid is not part of the standard equipment of the stacker, but will be delivered - if ordered - as an
accessory. Individual lids can be supplied afterwards; consult you supplier on that.
THE HEATING ELEMENT WILL TURN OFF AUTOMATICALLY WHEN THE TEMPERATURE IN THE UPPER PART
OF THE DEVICE REACHES 120 ℃. AT THE BOTTOM OF THE DEVICES, NEAR THE HEATING ELEMENT, THE
TEMPERATURE IS ABOUT 10 - 20 ℃HIGHER.
AFTER A FEW HOURS OF PRE-WARMING, THE CASING WILL HET HOT ON THE OUTSIDE; USE THE PUSH-IN
GRIP OR GLOVES WHEN MOVING THE STACKER.

GBA A 0811 0 E
BA Page 15 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
CLEANING
1) Remove every day dust / dirt from the lid and the cover of the stacker, using a moist cloth.
2) Remove dust / dirt from inside the stacker at least twice a year:
a) set the switch to "0",
b) take the plug out of the socket,
c) take the tableware parts and loading platform out of the stacker,
d) wipe the dust off or suck it away from the inner sides,
e) wipe the inside with a moist cloth.
DO NOT USE A DRIPPING WET CLOTH OR SPONGE FOR CLEANING STACKERS WITH HEATERS, BUT ONLY A
MOIST ONE.
DO NOT USE HIGH-PRESSURE CLEANERS FOR CLEANING STACKERS WITH HEATERS.
DO NOT USE AGGRESSIVE DETERGENTS FOR CLEANING THE PLASTIC LID (IN THE DISHWASHER).
3) Place the loading platform and tableware parts back in the stacker and reconnect the stacker
with the power network.

GBA A 0811 0 E
BA Page 16 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
SERVICE AND MAINTENANCE
1) Check the suitable spring force twice a year. The tension force can weaken as a result of excessive
pulling out and the influence of heat. Now suspend unused springs or replace all springs by new
ones:
a) set the switch to "0",
b) take the plug out of the socket,
c) take the tableware parts and loading platform out of the stacker,
d) suspend not yet used springs from the spring buckles or replace all old springs.
DO NOT PUSH THE SUPPORTS DOWN WHEN ADJUSTING THE SPRING FORCE, BECAUSE THE SPRING MAY
NOT BE UNDER TENSION.
SPREAD THE TENSION FORCE EVENLY OVER THE SPRING BUCKLES; NOT ALL SPRING ON ONE SIDE AND
NONE ON THE OPPOSITE SIDE.
2) Check twice a year, whether all nuts and bolts of the castors are properly seated. Check, whether
the castors turn and swivel well, if not:
a) take the castors out of their holders,
b) clean the castors and bearings with a moist cloth with detergent.
REPLACE DEFECTIVE CASTORS AND LOST NUTS FORTHWITH.
TIGHTEN THE BOLTS EVENLY AND CROSSWAYS (TIGHT IS TIGHT).
USE SAFETY BOLTS (SUPPLED EX FACTORY).
3) Check the functioning of all electrical elements twice a year:
a) set the switch to "0",
b) take the plug out of the socket,
c) disassemble the heating insert and the switch panel.
All electrical elements can now be seen and reached.
MAINTENANCE AND REPAIR WORK ON HEATING SYSTEMS MAY ONLY BE CARRIED OUT BY QUALIFIED
ELECTRICIANS.
ONLY USE ORIGINAL SPARE PARTS OR PARTS WITH EXACTLY THE SAME CHARACTERISTICS AND THE SAME
PROOF MARKS.
TEST THE CIRCULATION AIR FAN SEVERAL TIMES A YEAR; THEY ATRACT DUST, WHICH LEADS TO IM-
PAIRED FUNCTIONING AND CAN CAUSES THE VENTILATOR TO FAIL.

GBA A 0811 0 E
BA Page 17 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
4) Replace defective or damaged parts as follows:
a) inform your supplier or customer service centre,
b) make a note of the position and connections of the defective part and mount the new parts in
exactly the same way,
c) put the heating tray and switch panel in the old position and carefully tighten all screws.
5) Place the loading platform and the tableware parts back in the stacker and reconnect the device.

GBA A 0811 0 E
BA Page 18 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
TECHNICAL DATA
Art. No.
Execution
ExternalDimensions
B x T x H in mm
Dimensions
crockery
in mm
Pile height
in mm
Voltage
Power
A 0811
1 pile
heated
485 x 520 x 978
190-238
611
230V
0,6kW
A 0812
1 pile
heated
485 x 520 x 978
230-278
611
230V
0,6kW
A 0813
1 pile
heated
485 x 520 x 978
260-308
611
230V
0,6kW
A 0814
2 piles
unheated
485 x 920 x 978
190-238
611
A 0815
2 piles
unheated
485 x 920 x 978
230-278
611
A 0816
2 piles
unheated
485 x 920 x 978
260-308
611
A 0817
2 piles
heated
485 x 920 x 978
190-238
611
230V
1,6kW
A 0818
2 piles
heated
485 x 920 x 978
230-278
611
230V
1,6kW
A 0819
2 piles
heated
485 x 920 x 978
260-308
611
230V
1,6kW
Design:
Chromium-nickel steel 18/10, heated/unheated, for plates and serving plates, heated plate dispenser ther-
mostatically adjustable from 30-90°C, capacity approx. 50/100 plates, mounted on 4 castors - diameter
125mm - 2 lockable, incl. handle and corner bumper

GBA A 0811 0 E
BA Page 19 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
DISPOSAL AND ENVIRONMENT
The appliance has been packed before shipping to protect it against damage in transit.
After unpacking, please dispose of packing materials in an environmentally sound
manner.
All packing materials are eco-compatible, 100% recyclable and marked with a symbol
to that effect.
While unpacking, keep packing materials (polyethylene bags, pieces of polystyrene,
etc.) out of the reach of children.
ENVIRONMENTAL NOTES
DISPOSAL OF PACKING MATERIAL
Recyclable packing materials should be disposed of in sorted fractions for recycling via approved local dis-
posal facilities.
For approved disposal facilities in your area, please contact your local government or community admin-
istration.
DISPOSAL OF THE APPLIANCE
Render the appliance inoperable before disposal.
Pull the plug out of the socket-outlet or arrange for disconnection by an electrician, then cut the mains cord
off the appliance.
This product must not be disposed of in normal household waste at the end of its service life, but must be
turned in for recycling at an approved collecting facility. This requirement is identified by a symbol on the
product, in the Instructions for Use, or on the packing material.
Materials are recyclable as marked. By arranging for the recycling, recovery, or other form of re-use of end-
of-life appliances you will make an important contribution to the protection of our environment.
Your local government or community administration will advise you as to which disposal facilities in your
area accept discarded appliances for recycling.

GBA A 0811 0 E
BA Page 20 of 21 Juli 24, 2014
Last revised 07-2014 Rev. 0
Scholl Apparatebau GmbH & Co. KG
WARRANTY AND SERVICE
WARRANTY CONDITIONS
The manufacturer accepts no liability or warranty in the following cases:
failure to observe notes and instructions given in the Instructions for Use;
use of the product in a manner not conforming to its intended use;
alteration or modification of the appliance or its functionalities;
use of non-original spare parts.
Except as otherwise stipulated by special warranty conditions, a 12-month warranty is granted on all prod-
uct vis-a-vis merchants (details are covered by para. 11 of our General Terms and Conditions of Sale).
The warranty granted on appliances is a material warranty valid for a 1-year period, i.e., if a defect should
occur we will send you the relevant part. The defective part must be returned to our address within two
weeks. No claim based on alleged unsoundness of goods or for consequential loss or damage involving fac-
tors unrelated to the appliance will be accepted. Further warranty information is contained in our General
Terms and Conditions of Sale or can be made available upon request.
Appliances not produced by ourselves are subject to the warranty terms and conditions or the relevant man-
ufacturer. These, too, will normally be limited to a material warranty. We do not grant any direct warranty
on such items.
